Summit FFAR-10 User manual

FELIX STORCH, INC.
SUMMIT APPLIANCE DIVISION®
INSTRUCTION MANUAL FOR MODEL:
FFAR-10
Thank you for your trust and for buying this appliance. It’s designed to refrigerate your
fresh foods, while adding an elegant touch to your home or office.
The FFAR-10 is a single door all-refrigerator with automatic defrost, loads of shelf space
and door shelves. This unit also features a reversible door, adjustable shelves, adjustable
thermostat and interior lights.
ALL-REFRIGERATOR

Before Putting Into Use
Instructions for Use
These instructions for use are intended for the user. They describe the appliance
and the correct and safe way to use it. The instructions were prepared for various
models/types of refrigerators therefore you may find in it descriptions of some
accessories and functions that do not apply to your appliance.
•Remove the interior and exterior packaging
•Before connecting the appliance to the power source, let it stand
upright for approximately 2 hours. This will reduce the possibility of a
malfunction in the cooling system from handling during transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
We Care About the Environment
•Our appliances are distributed in packaging made of environmental
friendly materials which could safely be recycled, disposed of or
destroyed without any effects on the environment whatsoever.
•Our instruction manuals are printed on recycled paper or chlorine free
bleached paper.
Tips for Energy Savings
•Try not to open the door too often, especially when the weather is hot
and humid. Once you open the door try to close it as soon as possible.
•Every now and then check if the appliance is sufficiently ventilated
(adequate air circulation behind the appliance).
•Set thermostat from higher to lower settings as soon as possible
(depending on how loaded the appliance is, the ambient temperature
etc...).
•The coils on the rear of the refrigerator should be cleaned and free of
dust or any other impurities.
•Ice and frost layer increase energy consumption, so do clean the
appliance as soon as the layer is 1/8” thick.
•Always consider instructions stated in sections Positioning and Energy
Saving Tips, otherwise the energy consumption is substantially higher.
•Do not place hot foods in the refrigerator.
•A cool dry place allows your refrigerator to operate more efficiently so
keep the refrigerator away from stoves and other heat sources.
Instructions for Use

Important
To reduce the risk of fire, electrical shock,
Warnin
g
! or in
j
ur
y
when usin
g
y
our appliance,
follow these basic precautions:
•Read all instructions before using the appliance
•If you bought this appliance to replace an old one equipped with a lock
that cannot be opened from inside (lock, bolt), make sure that the lock
is broken. This will make it impossible for children to lock themselves
inside the appliance and suffocate.
•The appliance must be correctly connected to the power supply
•If the food has a strange smell or color throw it away because it is very
likely that it is spoiled and therefore dangerous to eat.
•Disconnect the appliance from the power supply before repairing it
(only a qualified technician should repair it), cleaning it and before
replacing the light bulb.
•For the sake of environmental protection be careful not to damage the
rear wall of the appliance (the condenser unit or the tubes when
moving the refrigerator) or any part of the refrigerating system inside
the appliance. Use only enclosed tools or tools recommended by the
manufacturer.
•The refrigerating system of the appliance is filled with refrigerant and
oil, so when the appliance is damaged handle it with care and dispose
of it in compliance with the environmental protection precautions.
•Before throwing away your old refrigerator or freezer please remove
the doors and leave the shelves in place so that children may not easily
climb inside.
•DANGER: Risk of child entrapment.
•The rating plate is inside the appliance or outside on the rear wall.
Disposing of the Worn Out Appliance
•When your appliance finally wears out, dispose of it. If the appliance
has a lock, break it to prevent eventual accidents (danger of children
getting locked inside the appliance).
•The refrigerating system of the appliance is filled with refrigerant and
insulating substances which should be separately treated and
processed, you should call your nearest authorized service agent or
specialized servicing center if they cannot be contacted call your local
authorities or your distributor to remove the refrigerator. Be careful
not to damage the tubes on the rear wall of the appliance (danger of
pollution).
Instructions for Use

Placing and Installation
Choosing the Right Place
Place the appliance in a dry and regularly ventilated room. Allowed ambient
temperature depends on the model (class) of the appliance and is stated on the
rating plate of the appliance. Make sure the appliance is on a floor that is strong
enough to support the appliance when it is fully loaded.
Class Ambient Temperature
SN (sub-normal) from + 56°F to + 90°F
N (normal) from + 62°F to + 90°F
ST (sub-tropical) from + 64°F to +100°F
T (tropical) from + 64°F to +120°F
The appliance may be exposed to lower or higher temperatures but only for
shorter period of time and the temperature should never be lower than 41°F.
Never place the appliance near heat emitting devices (e.g. cooker, radiator, water
heater or similar devices) and do not expose it to direct sunlight. The appliance
should be positioned 3cm from the electric or gas cooker. Behind the appliance
there should be at least 200 cm² wide and above the appliance at least 5 cm away
from the appliance in order to assure adequate ventilation of the condenser unit.
Placing the Self-Standing Appliance
•It is important to make sure the appliance is leveled evenly to prevent
falling.
•Do not place the appliance in direct sunlight and sources of heat
(stove, heater, radiator, etc.). Direct sunlight may affect the acrylic
coating and heat sources may increase electrical consumption.
•The appliance with the ventilation grid may be placed close to the
wall. The grid enables sufficient air circulation that is required for
adequate ventilation of the rear wall.
Connection to Power Supply
Connect the appliance with the cable and plug to the power supply socket outlet
with a ground terminal (safety socket).
“DO NOT USE AN EXTENSION CORD.”
Required nominal voltage and frequency are indicated on the rating plate.
The connection to the power supply and grounding has to be made according to
current standards and regulations. The appliance resists temporary voltage
tolerance up to -15 to 10%.
Instructions for Use

Use
Storing Fresh Foods
•Foods to be stored in the refrigerator should be properly packed as to
prevent mixing various moisture degrees and odors (in polyethylene
bags or sheet, aluminum foil, wax paper, covered containers or
bottles).
•Never store any inflammable, volatile or explosive substances.
•Beverages with high alcohol percentage shall be stored in tightly
sealed bottles in a vertical position.
•Food should not touch the rear wall of the refrigerator.
•Some organic solutions like volatile oils in lemon and orange peel,
acid in butter etc. can cause damages when in contact with plastic
surfaces or gaskets for a long period of time.
•An unpleasant odor inside the refrigerator is a sign that something is
wrong with the food or that your refrigerator needs cleaning. Odors
may be eliminated or reduced by washing the interior of the
refrigerator with a mild solution of water and vinegar. We also
recommend using activated carbon filters to clean the air or to
neutralize odors.
•If you plan on taking a long trip make sure you remove all perishable
food before you leave to prevent any odors.
Fresh Food Storage Time in the Refrigerator
Storage time (days)
Article of Food
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Butter +++++++=== = =
Eggs ++++++++++ = = = =
Fresh uncut meat ++=
Chopped meat + =
Smokedmeat ++++++++++ = = = =
Fish +=
Marinade ++++++++++ = = = =
Root ++++++++== = = = =
Cheese ++++====== = = = =
Sweets ++====
Fruit ++========
Prepareddishes ++==
Legend: + means recommended storage time
= means possible storage time
Instructions for Use

Maintenance and Cleaning
Automatic Defrosting of the Refrigerator
There is no need to defrost the refrigerator, because the ice depositing on the inner
back wall is defrosted automatically.
Ice is depositing on the inner back wall during the compressor operation; later on,
when the compressor is not operating, ice is defrosting and water drops, collects
and drains through the outlet in the inner back wall into the drain pan situated
above the compressor where it evaporates.
Cleaning the Appliance
Disconnect the power supply before cleaning the appliance. Do not use coarse or
Aggressive cleaning agents as you can damage the surface.
•Clean the exterior with water and detergent. Varnished surfaces are
cleaned with soft cloth and an alcohol based cleaning agent (for
example glass cleaners). You may also use alcohol (ethanol or
isopropyl alcohol). The application of abrasive and especially
aggressive cleaners, such as stainless steel cleaners, is not appropriate
for the cleaning of plastic and coated parts.
•Remove the detachable accessories in the interior of the appliance and
clean it with water and liquid detergent. Plastic parts cannot be
washed in a washing machine.
•Wash the interior of the appliance with lukewarm water, in which you
add one or two spoonfuls of vinegar.
•Every now and then wipe the condenser on the rear wall. Use a soft
non-metal brush or vacuum cleaner.
•Do not forget to clean the defrost water receptacle above the
refrigerators compressor (do not remove the receptacle). After
cleaning, connect the appliance to the power supply and reload the
packages.
Switch Off the Appliance When Not in Use
If you do not intend to use the appliance for an extensive period of time set the
thermostat knob to the 0 (off) position and disconnect the power supply. Then
take out the foods and clean the appliance. Leave the door slightly open.
Instructions for Use

Trouble-Shooting Guide
During the service of your appliance, you can come across some troubles that in
most cases result from improper handling of the appliance that can easily be
eliminated.
The Appliance Fails to Operate After Connecting to the Power Supply
•Check the supply in the outlet socket and make sure the appliance is
switched on (thermostat in the operating position).
Continuous Operation of the Refrigerating System
•The door was frequently opened or it was left open too long.
•The door is not properly closed (the door may sag; the gasket may be
polluted or damaged).
•Perhaps you have overloaded the appliance with fresh foods.
•The reason may be inadequate ventilation of the compressor and
condenser (assures adequate air circulation and wipe off the
condenser).
Ice Formation on the Inner Rear Wall
As long as the defrost water runs to the channel and through the opening to the
drain pan on the compressor, automatic defrosting of the appliance is assured. In
case the ice formation on the inner back wall is increased (1/8”), ice should be
manually defrosted.
Set the thermostat knob to 0 (off) position and leave the door open. Never use
electric devices for defrosting and do not scrape the ice or frost layer with sharp
objects. After completed defrosting, turn the knob to desired position and close
the refrigerator door.
The cause of increased ice formation may be one of the following reasons:
-The door does not seal well (clean the gasket if it is contaminated,
or replace it if it is damaged).
-The door was frequently opened or it was left opened for too long.
-The food stored in the refrigerator was warm.
-The food or dish is touching the inner back wall.
Water is Leaking from the Refrigerator
In case the discharged water outlet is clogged, the defrost water drips over the
channel, or water leaks from the refrigerator just clean the clogged opening with a
plastic straw. Manually defrost the increased ice layer.
Instructions for Use

Noise
Cooling in refrigerating-freezing appliances is enabled by the refrigerating system
with the compressor, this produces noise. How noisy the appliance is depends on
where it is placed, how it’s used and how old the appliance is.
•During the operation of the compressor, a liquid noise is heard and
when the compressor is not operating a refrigerant flow is heard. This
is a normal condition and it has no influence whatsoever on the
lifetime of the appliance.
•After starting the appliance, the operation of the compressor and the
refrigerant flow may be louder and this does not mean something is
wrong with the appliance. The noise will reduce gradually, this will
not affect the lifetime of the appliance.
•Sometimes unusual and strong noises occur which is rather unusual for
the appliance. This noise is often a consequence of inadequate placing.
To avoid the noise make sure the appliance is placed and leveled
firmly on a solid base. Make sure the appliance is not touching the
wall or kitchen units standing next to it. And always make sure you
check the accessories in the interior of the appliance; they should be
placed correctly in their positions. Check the bottles, tins and other
vessels that might touch each other and rattle.
Before Calling for Service:
•Check the plug and fuse.
•Test the outlet with a lamp
•Be sure the control is not set to OFF
•Read the manual, especially the items under the Use and Care sections.
You may find the answer to your questions.
•If you don’t find the answer to your questions in this manual, find the
unit model number (on the upper back part of the refrigerator) and
contact your Summit Appliance Dealer at 718-893-3901.
Specifications are Subject to Change Without
Notice.
Instructions for Use
