User’s Manual
SUN-100/1000 Fiber Optic Media Converter
All the trademarks mentioned in this manual are registered property of Sun Telecom.
The right to interpret this manual is reserved by Sun Telecom

F ib e r O p tic So l ut i o ns P rov i de r 1/4
www.suntelecom.cn • [phone] • [e-mail]
1. Instruction
Sun Telecom’s SUN-100/1000 series fiber optic media converters can
transform Ethernet electric signals into optical signals or vice-versa and
transmit optical signals over multimode or single-mode fiber. Under the
premise of ensuring high-bandwidth transmission, these media converters
can achieve a transmission of hundreds of kilometers long by using optical
fiber media, which breaks the limitation of copper cable transmission
distances. SUN-100/1000 series fiber optic media converters comply with
IEC802.3 standards.
2. Packing List
No.
Product
Unit
Quantity
1
Fiber Optic Media Converter
set
1
2
Power Adaptor (Only for external power type)
piece
1
3
Power Line (Only for internal power type and
rack mount chassis)
piece
1
4
User’s Manual
piece
1
5
Certification
piece
1
*Card type fiber optic media converters DO NOT include any power line or adaptor and
are used with the rack mount chassis.
3. Installation
Fiber optic media converters are used in pairs. The graph below shows the
typical connection.

F ib e r O pt ic S o l u t io n s P ro v i d er 2/4
www.suntelecom.cn • [phone] • [e-mail]
Note
While using card type fiber optic media converters, please use related 19
inch rack mount chassis.
17 slots rack mount chassis
4. LED Indicator Instruction

F ib e r O pt i c S o l u t io n s P ro v i d er 3/4
www.suntelecom.cn • [phone] • [e-mail]
Name
State
Description
Link/Act (FP)
ON
Fiber link is connected
Blink
Packets go through FX end
OFF
Fiber link is disconnected
Link/Act (TP)
ON
Electric link is connected
Blink
Packets go through TX end
OFF
Electric link is disconnected
FDX/COL
ON
Full duplex mode
OFF
Half duplex mode
PWR
ON
Power on
OFF
Power off
SD
ON
Fiber signal is detected
OFF
Fiber signal is not detected
100M
ON
Transfer rate of electric interface is 100Mbps
OFF
Transfer rate of electric interface is 10Mbps
1000M
ON
Transfer rate of electric interface is 1000Mbps
OFF
Transfer rate of electric interface is 100Mbps

F ib e r O pt i c S o l u t io n s P ro v i d er 4/4
www.suntelecom.cn • [phone] • [e-mail]
Warranty Instructions
Warranty
We promise three years warranty for the SUN-100/1000 series of media
converter.
During the warranty period, we provide free maintenance service, but in
following circumstances, we will require the cost of materials and
components
Damage caused by not following the instructions of user’s manual
Damage caused by unauthorized disassembling the product
Damage caused by lightning, fire and irresistible natural disasters
Damage caused by matching problems due to poor design of other
manufacturers' products
