1-1
BeforeYouStart 1
This manual explains how to install a SPARCstorage Library in a 56-inch Data
Center Expansion Cabinet. Procedures described in this manual are:
•Preparing the SPARCstorage™ Library
•Preparing the 56-inch Data Center Expansion Cabinet
•Installing the SPARCstorage Library
•Reassembling the 56-inch Data Center Expansion Cabinet
1.1 SCSI Cable Length
Your system performs reliably with a maximum SCSI bus length of 20 feet
(6 meters). The internal signal path of your system unit and the external SCSI
cables must not exceed this maximum length.
1.2 Shutting Down Your System
Refer to the installation manual you received with your system for instructions
on powering off the system:
•SPARCcenter™ 2000 system — SPARCcenter 2000 Installation Manual
(P/N 800-6975-xx)
•SPARCserver™ 1000 system — SPARCserver 1000 System Installation Manual
(P/N 801-2893-xx)

1-2 SPARCstorage Library Installation Manual—February 1995
1
1.3 Help with UNIX Commands
If you need help with UNIX commands, refer to the Solaris Handbook for SMCC
Peripherals that came with your operating system.

2-1
PreparingtheSPARCstorage
Library 2
2.1 Inspecting the SPARCstorage Library
Warning – The tape library shipping weight is approximately 90 pounds (40.86
kg). Use safe lifting procedures when unpacking and installing the tape library
to prevent damage to the equipment or injury to personnel.
After unpacking, Inspect the tape library for evidence of damage. If damaged,
keep all contents and packing materials for the carrier’s agent to inspect and
do not proceed with the installation. Once you have unpacked the tape library
from the shipping carton, check the contents against the packing slip to make
sure you have all of the following items:
•SPARCstorage Library with at least one tape drive installed
•Power cord
•SCSI cable
•Tape cartridge holder and top cover
•Cleaning cartridge
•Regulated SCSI terminator
•Box of data tapes
•Manuals
•SCSI jumper plug
•Bezel
•Slide rails and attaching hardware
•Locking brackets and attaching hardware
•Key
!

2-2 SPARCstorage Library Installation Manual—February 1995
2
Save the packing materials for future use.
Note – If the tape library is not installed in the United States or Canada, you
may have to use a country-kit power cord. Consult your Sun sales
representative for further information.
2.2 Removing Internal Packing Material
Warning – Before performing any of the following steps, be sure that the
power switch is off. To avoid damaging the tape library, be sure that the work
area is free of conditions that could cause electrostatic discharge (ESD).
To gain internal access to the library:
1. Locate the key in your accessory kit.
2. Insert the key vertically into the lock and turn it clockwise 90 degrees.
3. Pull the front door open.
4. Reach in through the open door and pull out the large piece of packing
material.
See Figure 2-1.
5. Pull the Cartridge Handling Mechanism (CHM) towards you to free it
from the second piece of packing material that is inserted in the
removable cartridge holder.
6. Push the CHM up towoard the right side of the tape library and remove
the packing material that is in the holder.
Keep the packing material in case the tape library needs to be transported.

Preparing the SPARCstorage Library 2-3
2
.
Figure 2-1 Removing Packing Material
12
34

2-4 SPARCstorage Library Installation Manual—February 1995
2
2.3 Installing Slide Rail Runners on the SPARCstorage Library
1. Separate runners from slide rails.
a. Locate the slide rails that were shipped with the SPARCstorage
Library.
b. Fully extend one slide rail until it locks.
c. Press the rail release button in the center of the rail
See Figure 2-2. This action releases the two-part portion.
Figure 2-2 Rail Release Button on the Slide Rail
d. Continue extending the slide rail until it separates from the runner.
e. Repeat Step b through Step d for the other slide rail.
Rail release button

Preparing the SPARCstorage Library 2-5
2
2. Install runners on the SPARCstorage Library.
See Figure 2-3.
a. Locate the slide rail runners that you separated from the slide rails.
b. Position the runners on the sides of the tape library, just behind the
front panel by aligning each runner with the three predrilled holes on
each side of the tape library.
c. Attach the runners with the 8-32 Phillips screws provided.
Figure 2-3 Installing Slide Rail Runners
Slide rail runner

2-6 SPARCstorage Library Installation Manual—February 1995
2

3-1
PreparingtheExpansionCabinet 3
3.1 Powering Off the Expansion Cabinet
1. Turn front panel key switch to the standby position.
See Figure 3-1.
Figure 3-1 Key Switch Positions
2. Turn the AC distribution unit power switch to Off.
The switch is at the rear of the cabinet. See Figure 3-2.
Warning – The power must be turned off at the AC distribution unit or risk of
electrical shock to personnel exists.
OFF Position ON Position
STANDBY position ON position

3-2 SPARCstorage Library Installation Manual—February 1995
3
Caution – Do not disconnect the power cord from the facilities outlet when
working on the system. This connection provides a ground path that prevents
damage from electrostatic discharge.
Figure 3-2 AC Distribution Unit Power Switch
!
R E M O T E
L O C A L
OFF
12
SWITCHED
20 Second Delay
ON I REMOTE POWER CONTROL BUS
J8 J9
I
II0
OFF OFF OFF
Main power circuit breaker

Preparing the Expansion Cabinet 3-3
3
3.2 Removing Panels from the Expansion Cabinet
3.2.1 Extending the Anti-Tilt Bar
♦Grasp the anti-tilt bar underneath the bottom front edge of the cabinet
and pull it out to its fully-extended position.
See Figure 3-3.
Figure 3-3 Extending the Anti-Tilt Bar
Anti-tilt bar
Front view

3-4 SPARCstorage Library Installation Manual—February 1995
3
3.2.2 Removing the Panels
Follow the instructions in this section to remove the necessary panels from
your cabinet.
3.2.2.1 Removing the Front Panel
1. Determine where you will be installing the tape library.
Tape libraries can be installed behind either of the top two front panels.
2. Pull on both sides of the front panel on the cabinet to remove the panel,
and set it aside.
See Figure 3-4. The procedure is the same for the remaining front panels for
all cabinets.
Figure 3-4 Removing a Front Panel from the 56-Inch Data Center Expansion Cabinet
