Sun Oracle Netra SPARC T5-1B User manual
Netra SPARC T5-1B Server Module
Installation Guide
Part No.: E35781-02
October 2013
Please
Recycle
Copyright © 2013, Oracle and/or its affiliates. All rights reserved.
This software and related documentation are provided under a license agreement containing restrictions on use and disclosure and are protected by
intellectual property laws. Except as expressly permitted in your license agreement or allowed by law, you may not use, copy, reproduce, translate,
broadcast, modify, license, transmit, distribute, exhibit, perform, publish, or display any part, in any form, or by any means. Reverse engineering,
disassembly, or decompilation of this software, unless required by law for interoperability, is prohibited.
The information contained herein is subject to change without notice and is not warranted to be error-free. If you find any errors, please report them to us
in writing.
If this is software or related software documentation that is delivered to the U.S. Government or anyone licensing it on behalf of the U.S. Government, the
following notice is applicable:
U.S. GOVERNMENT END USERS. Oracle programs, including any operating system, integrated software, any programs installed on the hardware,
and/or documentation, delivered to U.S. Government end users are "commercial computer software" pursuant to the applicable Federal Acquisition
Regulation and agency-specific supplemental regulations. As such, use, duplication, disclosure, modification, and adaptation of the programs, including
any operating system, integrated software, any programs installed on the hardware, and/or documentation, shall be subject to license terms and license
restrictions applicable to the programs. No other rights are granted to the U.S. Government.
This software or hardware is developed for general use in a variety of information management applications. It is not developed or intended for use in any
inherently dangerous applications, including applications which may create a risk of personal injury. If you use this software or hardware in dangerous
applications, then you shall be responsible to take all appropriate fail-safe, backup, redundancy, and other measures to ensure its safe use. Oracle
Corporation and its affiliates disclaim any liability for any damages caused by use of this software or hardware in dangerous applications.
Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names may be trademarks of their respective owners.
Intel and Intel Xeon are trademarks or registered trademarks of Intel Corporation. All SPARC trademarks are used under license and are trademarks or
registered trademarks of SPARC International, Inc. AMD, Opteron, the AMD logo, and the AMD Opteron logo are trademarks or registered trademarks of
Advanced Micro Devices. UNIX is a registered trademark of The Open Group.
This software or hardware and documentation may provide access to or information on content, products, and services from third parties. Oracle
Corporation and its affiliates are not responsible for and expressly disclaim all warranties of any kind with respect to third-party content, products, and
services. Oracle Corporation and its affiliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party
content, products, or services.
Copyright © 2013, Oracle et/ou ses affiliés. Tous droits réservés.
Ce logiciel et la documentation qui l’accompagne sont protégés par les lois sur la propriété intellectuelle. Ils sont concédés sous licence et soumis à des
restrictions d’utilisation et de divulgation. Sauf disposition de votre contrat de licence ou de la loi, vous ne pouvez pas copier, reproduire, traduire,
diffuser, modifier, breveter, transmettre, distribuer, exposer, exécuter, publier ou afficher le logiciel, même partiellement, sous quelque forme et par
quelque procédé que ce soit. Par ailleurs, il est interdit de procéder à toute ingénierie inverse du logiciel, de le désassembler ou de le décompiler, excepté à
des fins d’interopérabilité avec des logiciels tiers ou tel que prescrit par la loi.
Les informations fournies dans ce document sont susceptibles de modification sans préavis. Par ailleurs, Oracle Corporation ne garantit pas qu’elles
soient exemptes d’erreurs et vous invite, le cas échéant, à lui en faire part par écrit.
Si ce logiciel, ou la documentation qui l’accompagne, est concédé sous licence au Gouvernement des Etats-Unis, ou à toute entité qui délivre la licencede
ce logiciel ou l’utilise pour le compte du Gouvernement des Etats-Unis, la notice suivante s’applique :
U.S. GOVERNMENT END USERS. Oracle programs, including any operating system, integrated software, any programs installed on the hardware,
and/or documentation, delivered to U.S. Government end users are "commercial computer software" pursuant to the applicable Federal Acquisition
Regulation and agency-specific supplemental regulations. As such, use, duplication, disclosure, modification, and adaptation of the programs, including
any operating system, integrated software, any programs installed on the hardware, and/or documentation, shall be subject to license terms and license
restrictions applicable to the programs. No other rights are granted to the U.S. Government.
Ce logiciel ou matériel a été développé pour un usage général dans le cadre d’applications de gestion des informations. Ce logiciel ou matériel n’est pas
conçu ni n’est destiné à être utilisé dans des applications à risque, notamment dans des applications pouvant causer des dommages corporels. Si vous
utilisez ce logiciel ou matériel dans le cadre d’applications dangereuses, il est de votre responsabilité de prendre toutes les mesures de secours, de
sauvegarde, de redondance et autres mesures nécessaires à son utilisation dans des conditions optimales de sécurité. Oracle Corporation et ses affiliés
déclinent toute responsabilité quant aux dommages causés par l’utilisation de ce logiciel ou matériel pour ce type d’applications.
Oracle et Java sont des marques déposées d’Oracle Corporation et/ou de ses affiliés.Tout autre nom mentionné peut correspondre à des marques
appartenant à d’autres propriétaires qu’Oracle.
Intel et Intel Xeon sont des marques ou des marques déposées d’Intel Corporation. Toutes les marques SPARC sont utilisées sous licence et sont des
marques ou des marques déposées de SPARC International, Inc. AMD, Opteron, le logo AMD et le logo AMD Opteron sont des marques ou des marques
déposées d’Advanced Micro Devices. UNIX est une marque déposée d’The Open Group.
Ce logiciel ou matériel et la documentation qui l’accompagne peuvent fournir des informations ou des liens donnant accès à des contenus, des produits et
des services émanant de tiers. Oracle Corporation et ses affiliés déclinent toute responsabilité ou garantie expresse quant aux contenus, produits ou
services émanant de tiers. En aucun cas, Oracle Corporation et ses affiliés ne sauraient être tenus pour responsables des pertes subies, des coûts
occasionnés ou des dommages causés par l’accès à des contenus, produits ou services tiers, ou à leur utilisation.
iii
Contents
Using This Documentation v
Understanding the Server Module 1
Installation Task Overview 1
Server Module Overview 2
Front and Rear Panel Components 4
Confirming Specifications 7
Physical Specifications 7
Electrical Specifications 8
Environmental Specifications 8
Preparing for Installation 11
Shipping Kit 12
Handling Precautions 12
ESD Precautions 13
Tools Needed for Installation 14
▼Plan Communication With the Server Module During Installation 15
Dongle Cables 17
Installing the Server Module 21
▼Prepare the Modular System and Server Module 21
▼Install Optional Components 22
▼Insert the Server Module Into the Chassis 23
iv Netra SPARC T5-1B Server Module Installation Guide • October 2013
Powering On the Server Module for the First Time 27
Powering On the Host for the First Time 28
▼Power On the Host Through the CMM (Web Interface) 28
▼Power On the Host Through the CMM (CLI) 30
▼Power On the Host Through the Front Panel (CLI) 32
▼Power On the Host Through the CMM SER MGT Port (CLI) 34
Installing the OS 37
▼Configure the Preinstalled OS 37
Oracle Solaris Configuration Parameters 37
▼Reach a State to Install a Fresh OS (Oracle ILOM Web Interface) 40
▼Reach a State to Install a Fresh OS (Oracle ILOM CLI) 43
▼Assign a Static IP Address to the SP 44
Glossary 47
Index 53
v
Using This Documentation
This document provides instructions and reference material to help you install
Oracle’s Netra SPARC T5-1B server module in Oracle’s Sun Netra 6000 modular
system.
■“Product Notes” on page v
■“Related Documentation” on page vi
■“Feedback” on page vi
■“Access to Oracle Support” on page vi
Product Notes
For late-breaking information and known issues about this product, refer to the
product notes at:
http://www.oracle.com/goto/NETRA-T5-1B/docs
vi Netra SPARC T5-1B Server Module Installation Guide • October 2013
Related Documentation
Feedback
Provide feedback on this documentation at:
http://www.oracle.com/goto/docfeedback
Access to Oracle Support
Oracle customers have access to electronic support through My Oracle Support. For
information visit http://www.oracle.com/pls/topic/lookup?ctx=acc&id=
info or visit http://www.oracle.com/pls/topic/lookup?ctx=acc&id=trs
if you are hearing impaired.
Documentation Links
All Oracle products http://www.oracle.com/documentation
Netra SPARC T5-1B server module http://www.oracle.com/goto/NETRA-T5-1B/docs
Sun Netra 6000 modular system http://www.oracle.com/goto/SN6000/docs
Oracle ILOM http://www.oracle.com/goto/ILOM/docs
Oracle Solaris 11 OS http://www.oracle.com/goto/Solaris11/docs
Oracle Solaris 10 OS http://www.oracle.com/goto/Solaris10/docs
Oracle VM Server for SPARC http://www.oracle.com/goto/VM-SPARC/docs
Oracle VTS http://www.oracle.com/goto/VTS/docs
1
Understanding the Server Module
These topics describe the server module and the installation tasks.
■“Installation Task Overview” on page 1
■“Server Module Overview” on page 2
■“Front and Rear Panel Components” on page 4
Related Information
■“Confirming Specifications” on page 7
Installation Task Overview
Step Description Links
1. Review the product notes for any
late-breaking news.
Netra SPARC T5-1B Server Module
Product Notes
2. Review the server module features and
components.
“Server Module Overview” on page 2
“Front and Rear Panel Components” on
page 4
3. Review the server module requirements. “Confirming Specifications” on page 7
4. Confirm that you received all the items
you ordered.
“Shipping Kit” on page 12
5. Review safety and ESD precautions. “Handling Precautions” on page 12
“ESD Precautions” on page 13
6. Gather the required tools. “Tools Needed for Installation” on
page 14
7. Choose a method for connecting to the
server module during installation.
“Plan Communication With the Server
Module During Installation” on page 15
“Dongle Cables” on page 17
2Netra SPARC T5-1B Server Module Installation Guide • October 2013
Related Information
■“Server Module Overview” on page 2
■“Front and Rear Panel Components” on page 4
Server Module Overview
8. Install optional components in the server
module, and install the server module in
the chassis.
“Installing the Server Module” on
page 21
9. Power on the server module for the first
time.
“Powering On the Server Module for the
First Time” on page 27
10. Configure the OS on the host. “Installing the OS” on page 37
11. (Optional) Assign a static IP address to
the SP.
“Assign a Static IP Address to the SP”
on page 44
Step Description Links
Understanding the Server Module 3
Related Information
■“Front and Rear Panel Components” on page 4
■“Installation Task Overview” on page 1
■“Confirming Specifications” on page 7
Feature Description
Processor One 16-core 128-thread SPARC T5 processor.
Architecture SPARC V9 architecture, ECC protected.
Platform group: sun4v.
Platform name: Netra SPARC T5-1B.
Memory 16 slots supporting 8 GB or 16 GB DDR3 DIMMs
Ethernet Two 10/100/1000 GbE ports
HBA One on-board SAS RAID 0 or 1 controller (controls the two internal drives).
Internal drives Up to two hot-pluggable 2.5-inch SAS-2 300 GB or 600 GB hard drives.
Front panel I/O One UCP connector. For local KVMS support, use a UCP-3 or UCP-4 dongle cable to
access the following server module interfaces:
• Two USB 2.0 ports
• One RJ-45 Serial port
• One DB-15 SVGA video port
Midplane I/O • Four x8 PCIe interfaces (two to NEMs, two to PCIe EMs), operating at Gen2 speeds
• Two 10/100/1000 GbE interfaces, one per NEM
• One 10/100 Ethernet management port to CMM
OS Oracle Solaris OS
Note - Refer to the Server Module Product Notes for details on software that is
preinstalled and for information about required patches for supported Oracle Solaris
OS releases.
Remote management SP running Oracle ILOM.
Power The modular system chassis provides power.
Cooling The modular system chassis provides environmental controls.
4Netra SPARC T5-1B Server Module Installation Guide • October 2013
Front and Rear Panel Components
No. Description
1 Locator LED (white, also functions as the physical presence
switch)
2 Ready to Remove LED (blue)
3 Fault LED (amber)
4 OK LED (green)
5 Power button
6 NMI (Reset) button (for service use only)
7 Drive Ready to Remove LED (blue)
8 Drive Fault LED (amber)
9 Drive OK LED (green)
10 Ejector arm latch
Understanding the Server Module 5
Refer to Server Module Service, identifying LEDs, for more information about the
LEDs.
Related Information
■“Server Module Overview” on page 2
■“Installation Task Overview” on page 1
11 RFID tag (provides the serial number of the server module)
12 Top cover release button
13 UCP
14 Drive slots
15 Rear chassis power connector
16 Rear chassis data connection
No. Description
6Netra SPARC T5-1B Server Module Installation Guide • October 2013
7
Confirming Specifications
Site-planning information is included in the documentation for the Sun Netra 6000
modular system. Refer to the Sun Netra 6000 Modular System Installation Guide.
These topics help you plan installation of the server module.
■“Physical Specifications” on page 7
■“Electrical Specifications” on page 8
■“Environmental Specifications” on page 8
Related Information
■“Installing the Server Module” on page 21
■“Installation Task Overview” on page 1
■“Server Module Overview” on page 2
Physical Specifications
Description U.S. Metric
Height 12.9 in. 327 mm
Width 1.8 in. 44 mm
Depth 20.1 in. 511 mm
Weight*
* Weight specifications vary based on the model and internal options.
17 lb 7.7 kg
Minimum service clearance (front) 36 in. 91 cm
8Netra SPARC T5-1B Server Module Installation Guide • October 2013
Related Information
■“Server Module Overview” on page 2
Electrical Specifications
For information on power specifications, use the power calculator at:
http://www.oracle.com/us/products/servers-storage/sun-power-calc
ulators
Also refer to information about configuring server module power usage in the Netra
SPARC T5-1B Server Module Product Notes.
Related Information
■“Powering On the Server Module for the First Time” on page 27
Environmental Specifications
Description Value Notes
Voltage 12V From chassis backplane.
Voltage (auxiliary) 3.3V From chassis backplane.
Maximum operating power 740 W Estimated.
Description Operating Nonoperating
Temperature 5˚C to 40˚C (41˚F to 104˚F)
Short-term: -5˚C to 55˚C (23˚F to 131˚F)
Up to 93%, noncondensing, 40˚C
(104˚F)
Relative
humidity
5% to 85%, non-condensing
Short-term: 5% to 90%,
non-condensing, but not to exceed
0.024 kg water/kg dry air (0.053 lb.
water/2.205 lbs. dry air)
Up to 93%, noncondensing, 40˚C
(104˚F)
10 Netra SPARC T5-1B Server Module Installation Guide • October 2013
11
Preparing for Installation
These topics help you prepare to install the server module.
■“Shipping Kit” on page 12
■“Handling Precautions” on page 12
■“ESD Precautions” on page 13
■“Tools Needed for Installation” on page 14
■“Plan Communication With the Server Module During Installation” on page 15
■“Dongle Cables” on page 17
Related Information
■“Installing the Server Module” on page 21
■“Installation Task Overview” on page 1
12 Netra SPARC T5-1B Server Module Installation Guide • October 2013
Shipping Kit
Related Information
■“Handling Precautions” on page 12
■“ESD Precautions” on page 13
■“Tools Needed for Installation” on page 14
■“Plan Communication With the Server Module During Installation” on page 15
■“Dongle Cables” on page 17
Handling Precautions
■Use both hands to carry the server module.
No. Description
1 Printed documentation, including the Getting Started Guide.
2 Server module.
3 Customer information sheet (on outside of shipping carton). Save this sheet as a
record of the MAC address and other information about installed hardware and
software.
Preparing for Installation 13
■Extend the ejector arms on the front panel only while they need to be in that
position to perform a step in a task.
Related Information
■“Physical Specifications” on page 7
■“Shipping Kit” on page 12
■“ESD Precautions” on page 13
■“Tools Needed for Installation” on page 14
■“Plan Communication With the Server Module During Installation” on page 15
■“Dongle Cables” on page 17
ESD Precautions
Electronic equipment is susceptible to damage by static electricity. Use a grounded
antistatic wrist strap, foot strap, or equivalent safety equipment to prevent ESD when
you install the server module.
Caution – To protect electronic components from ESD, which can permanently
damage electronics, place components on an antistatic surface, such as an antistatic
discharge mat, or an antistatic bag. Wear an antistatic grounding strap connected to a
metal surface on the chassis when you work on server module components.
The following figure shows the modular system chassis ground connector for which
you can connect antistatic equipment.
14 Netra SPARC T5-1B Server Module Installation Guide • October 2013
Related Information
■“Shipping Kit” on page 12
■“Handling Precautions” on page 12
■“Tools Needed for Installation” on page 14
■“Plan Communication With the Server Module During Installation” on page 15
■“Dongle Cables” on page 17
Tools Needed for Installation
The following tools are sufficient for installing the server module, whether or not you
need to install components inside the server module:
■Antistatic mat
■Antistatic wrist strap
■UCP-3 or UCP-4 dongle cable
■Terminal device or terminal emulator
■Stylus (to press power button)
Related Information
■“Dongle Cables” on page 17
■“Handling Precautions” on page 12
Table of contents
Other Sun Oracle Control Unit manuals
