Sun Telecom Flex T5 User manual

[T5]
Alphanumeric Pager
Ver.11/14

T5
CONTENTS
FEATURES
DESCRIPTION OF INDICATORS & SYMBOLS
CONTROL BUTTONS
OPERATION
Turning The Pager On / Off
Main Screen
Function Menu Screen
Inbox Message Screen
Info Message Screen
Saved Message Screen
FUNCTION MENU
Reading a Stored Message in each Message Screen
Setting the Time and Date
Setting the Alarm
Setting the Paging Alert
Setting the Audible On / Off
Enabling the Display Zoom
Enabling the Reminder Alert
Locking and Unlocking Messages
Deleting Message
Moving a Message to the Saved Folder
Selecting an Info Alert Type
Display Lock
3
4
7
8
9
10
10
11
11
12
13
14
15
16
17
17
18
19
20
20
21

T5
3
FEATURES
•Encrypted Message (AES-128) Support
•16 Flex addresses
•4 Line x 20 Alpha Character Display
•20 Inbox Message Slots
•15 Info Message Slots
•16 Saved Message Slots
•Inbox Message Storage: 6400 Bytes
•Info Message Storage: 19200 Bytes
•Saved Message Storage: 3200 Bytes
•Inbox Max. Message Length: 1000 Bytes
•Info Max. Message Length: 1000 Bytes
•10 Inbox Messages Lock with Lock Icon
•7 Sub-slots of each Info Slot (optional)
•Zoom On / Off (User Selectable)
•Battery Status Display
•One Alarm with Message ("ALARM TIME")
•Message with Time & Date Stamping
•Automatic Alert Reset
•1 Beep, 7 Different pleasing Alerts, a Chirp, Vibrate, Sleep
•User-Selectable Reminder Alert
•Audible ON / OFF
•Manual ON / OFF using Softkey
•No Message Indication (No Message)
•New Message indication (Flashing Icon)
•Unread Message Indication
•Continuous Message Indication (with Icon)
•Error Message Indication (with Icon)
•All & Selective Message Delete
•Message Full Indication (with Icon)
•Message Slot Number
•Duplicated Message Indication (with Icon)
•EL Backlight Display
•Smart Unread Reminder On / Off (Optional)
•Lock Display

T5
4
DESCRIPTIONOFINDICATORS&SYMBOLS
Audio Alert Full Battery Status
Silent Alert (Vibration) 2/3 Battery Status
Enabled Alarm 1/3 Battery Status
Private Time Enabled Low Battery Status
New Page or Unread Message Indication Message Continuation
Lock Message Power On
Unlock Message
Indicators
Note: When the battery is low the pager will alert with a short chirp at the top of every hour.

T5
5
DESCRIPTIONOFINDICATORS&SYMBOLS
Inbox Folder Move to NoteBook
Info Folder Saved Slot
Saved Folder Unread Inbox Slot
Read Inbox Slot
Delete All Read Info Slot
Delete Unread Info Slot
MessageFull Cursor (Current Slot)
Escape
Symbols (Message Status)

T5
6
DESCRIPTIONOFINDICATORS&SYMBOLS
Escape Zoom
Set Time Pager Off
Set Alarm Disable Reminder
Set Alert Enable Reminder
Set Info Alert Set Private
Set Audible ON Set Lock
Set Audible OFF
Symbols (Function Menu)

T5
7
CONTROLBUTTONS
•Use to navigate through the Function
menu and through your messages.
•Use to navigate through time, alarm,
and date setting function
•Use to enter the Function menu mode.
•Use to turn the Backlight off.
•Use to exit to current Function mode.
•Use to turn the pager on and off.
•Use to read the received message.
•Use to activate your selection.
•Use to adjust the time, alarm, and
date setting functions.

T5
Turning the Pager On
Press for two (2) seconds to turn the pager on.
A start-up screen is momentarily displayed and the pager
alerts the currently selected alert-mode.
(Vibrator, Audio, Sleep)
8
OPERATION
Note: If you choose the function key while the pager is off, the pager will display Pager Off
Mode and the time and date. The display disappears after eight (8) seconds or after you
press any of the pager keys.
Turning the Pager Off
Press button to display the Function menu.
Press or button to move the cursor on OFF icon.
Press button.
"TURN PAGER OFF?" is displayed.
Press button again to turn the pager off.
PowerUp Screen
SPOK
12:00A 1/01/15
Time/Date display on Pager Off
PAGER OFF MODE
12:00A 1/01/15

T5
9
OPERATION
Main Screen
Pressing any of the buttons on the Standby Screen will
provide access to the Main Screen.
The Main Screen shows both the current status of message
folders (Inbox / Info / Saved) and the time and date.
The Main Screen also displays any activated pager settings
in the split screen.
When the Main Screen is initially displayed, the Inbox
Folder icon is the first icon followed by the Info and
Saved icons. The Inbox folder is also highlighted.
Choosing either arrow button will highlight the other icons.
Press or to move the cursor within the Message Folder.
Press to enter the selected Folder.
Main Screen
12:00A 1/01/15

T5
10
OPERATION
Function Menu Screen
The Function Menu provides access to the many features incorporated in the T5.
As you navigate through the Function menu, the Function
Icon will reverse to indicate the current location of the cursor.
Press or to navigate through the Function menu.
Press to enter the current menu.
Press to exit the Function menu.
Inbox Message Screen
The Inbox Message Screen shows the current status of
Inbox messages by displaying the first line of your
message. (Message Preview)
Function Menu Screen
SET AUDIBLE OFF
Inbox Message Screen

T5
11
OPERATION
Info Message Screen
The Info Message Screen shows the current
status of Info messages by displaying the first
line of your message. (Message Preview)
Saved Message Screen
The Saved Message Screen shows the current
status of the messages by displaying the first
line of your message. (Message Preview)
Info Message Screen
Saved Message Screen

T5
12
FUNCTIONMENU
Reading Stored Message in each Message Screen
From each Message screen press or to move the cursor to the message
you want to read. Press button to read the message.
Auto Scrolling Screen by Screen
Press and hold button.
Reading Previous or Next Message
Press or button.
Note: When an unread message exists, the pager gives a periodic reminder alert until all
unread messages are read. A flashing symbol on the StandBy screen indicates
that there are unread messages on your pager.

T5
13
FUNCTIONMENU
Setting the Time and Date
From the Function menu, press or to move
the cursor to display "SET TIME".
Press to display the Set Time screen.
Press to move the cursor to the next digit.
Press to adjust the current digit.
Repeat the two previous steps to adjust all time digits.
Press to activate the time and date setting.
Setting the Alarm
From the Function menu, press or to move
the cursor to display "SET ALARM".
Press to display the Set Alarm screen.
Press again to select Daily or 1Time alarm
Press or to move the cursor to the time digits
Press to adjust the current digit.
Repeat the two previous steps to adjust all the time digits.
Press button to activate the current setting.
Set Time Screen
12:00A 1/01/15
Set Alarm Screen
DAILY 12:00A

T5
Setting the Paging Alert
You can set the paging alert to an audible alert, a vibrating
alert, a chirp alert, a sleep alert(completely silent), or one
of seven other alerts. From the Function menu:
Press or to move the cursor to display "SET ALERT".
Press to display the Set-Alert screen.
Press or to move the cursor to the alert you want to set.
Press to activate the alert setting.
14
FUNCTIONMENU
Note: If no changes have been made, please wait for at least five (5) seconds before exiting
the screen. You may also choose to exit from any screen.
Alert #7 is continuous so you must press a button to silence it when a message is received.
Set Alert Screen

T5
15
FUNCTIONMENU
Setting the Audible On/Off
The alert can be set as either audible on or off.
Press to display the function menu.
Press to move the cursor to or .
The symbol is displayed if the pager is in the audible off mode(prompting you to enter the
audible on mode, if desired). The symbol is displayed if the pager is in the audible on mode
(prompting you to enter the audible off mode, if desired).
Press to select the desired audible mode. The alert can be set as either audible or vibrate.
If the Audible On function is set ( ), the pager will alert.
If the Audible Off function is set ( ), the pager will be on vibrate mode. Audible Mode
applies to all alerts, including reminder alert, alarm, etc.
Note: If the Alert has been set for sleep(no alert),
setting the Audible On/Off Function will not be activated.

T5
16
FUNCTIONMENU
Setting Display Zoom
When this feature is enabled, the standard 4-line Display is
converted to a 2-line Display. The characters are enlarged
to increase message readability. From the Function Menu:
Press or to more the cursor to display "ZOOM".
Press to display the Zoom screen.
Press or to move the cursor.
Press to activate the Zoom.
EnableZoom‐InScreen

T5
17
FUNCTIONMENU
Enabling Reminder Alert
When this feature is enabled and there are unread Inbox messages, the pager will
alert the user with a short beep or vibration depending on the current Inbox alert
type or Audible mode. The pager does not emit reminder alerts for Info messages,
or messages with no alert setting.
To Enable Reminder Alert
From the Function menu, press or to move the cursor to display "ENABLE REMINDER".
Press to activate the current setting.
To Disable Reminder Alert
From the Function menu, press or to move the cursor to display "DISABLE REMINDER".
Press to activate the current setting.

T5
18
FUNCTIONMENU
Locking and Unlocking Messages
Up to 10 messages can be locked to prevent them from being deleted or from
being replaced when the memory is full.
To Lock/Unlock a Message
From the Inbox Message Status Screen, press or to select the message you
want to lock or unlock.
Press and then press or to move the cursor to show "LOCK" or "UNLOCK".
Press to activate the setting.
To lock or unlock a message while reading it, follow the last two steps above while
the message is displayed.
Note: Info and Saved Messages can not be locked.

T5
19
FUNCTIONMENU
To Delete One Message
From the Inbox Message Status Screen, press or to select the message
you want to delete.
Press and then press or to move the cursor to show "DELETE".
Press to activate the setting.
To Delete All Messages
From the Inbox / Info / Saved Message Status Screen, press or
to select the message you want to delete.
Press and then press or to move the cursor to show "DELETE ALL".
Press to activate the setting.
Note: Neither a NEW Inbox message nor a LOCKED message can be deleted by using
the Delete All function. Using Delete all with the Info, will only delete those
messages in the current subfolder.

T5
20
FUNCTIONMENU
Moving A Message to the Saved Folder
From the Inbox / Info Message Status Screen, press or to select
the message you want to move.
Press and then press or to move the cursor to show "NOTEBOOK".
Press to activate the setting.
To Move a message while reading it, follow the last 2 steps above while the
message is displayed.
Selecting the Info Alert Type
From the Info Message Status Screen, press or to select the message
you want to set alert.
Press and then Press or to move the cursor to show "ALERT".
Press or to move the cursor to the desired alert type.
Press to activate the your setting.
While reading a message, follow the last four steps.
Note: When Inbox Pager alert is set to SLEEP , all alerts revert to SLEEP regardless
of the current mail alert type.
