Instruction Manual
Compact Steam Iron
MODEL: 32610075
ITEM: 12858
READ AND SAVE THESE INSTRUCTIONS
www.sunbeamhome.com

-1-
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety instructions should
always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THE STEAM IRON.
1. READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
2. Use appliance only for its intended use.
3. To reduce the risk of electric shock, do not immerse the appliance in
water or other liquids.
4. Always turn the appliance to “Off” before plugging or unplugging the
appliance from the electrical outlet. Never yank cord to disconnect
from outlet; instead, grasp plug and pull to disconnect.
5. Do not allow cord to touch hot surfaces. Let appliance cool completely
before putting away. Loop cord loosely around appliance when
storing.
6. Make sure unit is off, unplugged and allow it to cool completely before
filling or cleaning.
7. Always disconnect appliance from electrical outlet when filling with
water or emptying, and when not in use.
8. Do not operate appliance with a damaged cord, or if the appliance has
been dropped or damaged. To reduce the risk of electric shock, do not
disassemble or attempt to repair the appliance, take it to a qualified
service center for examination and repair. Incorrect reassembly or
repair could cause a risk of fire, electric shock, or injury to persons
when the appliance is used.
9. This appliance is not intended for use by children.
10. Burns could occur from touching hot metal parts, hot water, or steam.
Use caution when you turn a steam appliance upside down – there
may be hot water in the reservoir.
11. To reduce the risk of contact with hot water emitting from steam vents,
check appliance before each use by holding it away from body and
operating steam button.
12. To reduce the likelihood of circuit overload, do not operate another
high wattage appliance from the same outlet.

-2-
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
13. If an extension cord is absolutely necessary, a cord with an ampere
rating equal to or greater than the maximum rating of the iron shall
be used. A cord rated for less amperage can result in a risk of fire or
electric shock due to overheating. Care shall be taken to arrange the
cord so that it cannot be pulled or be tripped over.
14. When filling the water tank, watch for water that can drip onto the
floor and cause you to slip and fall.
15. Appliance may cause personal injury or be damaged if dropped.
16. The use of attachments not recommended or sold by the appliance
manufacturer may cause injuries or void your warranty.
17. To avoid personal injury and damage to the appliance, only add water
to the water tank. NEVER add cleaning solutions, perfumes, oils or any
other chemical additives.
18. Care should be taken when using the appliance due to the emission of
steam.
19. Do not set the iron on an unprotected surface, even if it is on the heel
rest.
20. The iron must not be left unattended while it is connected to the
supply mains.
21. The plug must be removed from the socket-outlet before the water
reservoir is filled with water.
22. The filling aperture must not be opened during use. Instructions for the
safe refilling of the water reservoir must be followed.
23. The iron must be used and rested on a stable surface.
24. When placing the iron on its stand, ensure that the surface on which
the stand is placed is stable.
25. The iron is not to be used if it has been dropped, if there are visible
signs of damage or if it is leaking.
26. If the iron is not operating normally, disconnect from power supply
and have the iron serviced by an authorized service center.

-3-
DESCRIPTION OF THE APPLIANCE
1: Soleplate
2: Spray nozzle
3: Water filler cap
4: Steam selector
5: Spray button
6: Shot of steam button
7: ON/OFF indicator light
8: Handle
9: Temperature control dial
10: Water tank
1
2
3
4
5
67
8
9
10

-4-
BEFORE FIRST USE
• When using the iron for the first time, test it on a piece of old cloth to be sure
that the Soleplate and the Water reservoir are clean.
• It is possible that the iron will discharge some smoke or give off a slight odor
during it is first usage. This is due to the initial heating of the materials used.
This is completely normal and will stop shortly afterwards.
• When not ironing, always have the Steam Select Switch turned to the close
position .
• INSTRUCTIONS FOR USE
CHOOSING THE RIGHT WATER
• This steam iron may be used with normal tap water. However, if the water
in the region in which you live is especially hard, it is recommended to use
distilled water to prolong the life of your iron.
• Do not use water that has been desalinated with chemicals.
INSTRUCTIONS FOR USE
1. Turn off the iron and disconnect the plug from
the electrical wall outlet before filling the Iron
with water.
2. Turn the Steam Select Switch to the closed
position .
3. Set the Iron in the position indicated (Figure 2)
and fill it with water, no higher than the Max fill
level shown on the See-Through Water Window.
(Figure 2)

-5-
DRY IRONING
1. Insert the plug in the electrical wall socket.
2. Make sure that the Steam Select Switch is in the closed position.
3. After the Indicator Light goes off, you may start to iron.
STEAM IRONING
Steam ironing is only possible at high temperatures (silk, wool, cotton, linen),
as indicated on the Temperature Control Dial
(Figure 3).
1. Be sure that there is enough water in the
Reservoir.
2. Set the iron in an upright position.
3. Plug the steam iron into the wall electrical
outlet.
4. Turn the Temperature Control Dial to
the desired position within the range of
temperatures included in the steam area
of the dial.
5. Wait until the Indicator Light has turned off
after lighting up.
6. Set the Steam Select Switch to the desired steam level position. You are
now ready to start steam ironing. The steam will be released evenly through
vents located in the soleplate for easier ironing.
SPRAY MIST
The Spray Mist feature is a powerful water spray mist that dampens the fabric
to help remove wrinkles from heavy fabrics and to set creases.
Press the Spray Mist button firmly to start the spray.
(Figure 3)

-6-
SHOT OF STEAM®
The Shot of Steam®feature provides an extra burst of steam for deep
penetration of stubborn wrinkles. The Shot of Steam®feature can be used
with dry or steam ironing provided it has at least a ¼ tank of water and
the Temperature Control Dial is set within the steam band.
1. Allow the iron to heat for approximately 2 minutes.
2. Press the Shot of Steam®Button several times to prime the pump.
3. Press the Shot of Steam®Button another 3-4 times in order to clean
the unit.
4. The Shot of Steam®feature is now ready for use. The Shot of Steam®
feature can be used continuously with just a short pause between
shots. The Shot of Steam®feature is most effective with the Iron held
in a horizontal position on the fabric being ironed.
5. If the Water Reservoir runs dry, unplug the iron and refill with water.
The iron may be filled with water while it is hot. Note: It may be
necessary to re-prime the pump before using the Shot of Steam®
feature again.
VERTICAL SHOT OF STEAM®
The vertical Shot of Steam
®
feature allows your iron to function as a garment steamer.
Tip: When using the vertical Shot of Steam
®
on clothing, hang the clothing
on clothes hanger for best results. Hanging curtains and drapes may also be
steamed.
HOW TO USE VERTICAL STEAM
1. Allow iron to warm up.
2. Hold the iron in a vertical position, with the iron close to but not
touching the fabric you want to steam.
3. With your other hand, pull the fabric tight.
4. Press the Shot of Steam
®
button in approximately 3-second intervals
as you move the iron across the wrinkled area.

-7-
WARNING: To prevent the risk of burns, keep your hand away from the area
being steamed.
WARNING: DO NOT steam garments while wearing them; this may result in
injuries.
IRONING TEMPERATURE
• Check the ironing instructions on the label of the items that you wish to
iron. Check the temperature setting table for further instructions.
• Should the specific ironing instructions not appear on the label, follow
instructions on the temperature setting table. This table is only for fabrics
indicated and does not apply to special textiles with a gloss finish, etc.
Textiles with special coatings (such as gloss, relief wrinkles, etc.) are best
ironed at very low temperatures. If the textile consists of several different
type of fibers, always select the lowest temperature, i.e the temperature
recommended for the most delicate fiber in the composition (for example, if
the composition consists of 60% polyester and 40% cotton, you should iron
at the temperature indicated for polyester).
SETTING THE TEMPERATURE
1. Set the iron in on upright position.
2. Connect the iron to an electrical wall socket.
3. Set the Temperature Control dial (Figure 4) to the correct ironing
temperature as indicated on the lable or the temperature settings table.
(Figure 4)

-8-
TEMPERATURE SETTINGS TABLE
Temperature
Control Dial
Kind of Textile Fiber Material
DRY
synthetic
acrylic, modacrylic,
polypropylene,
acetate, rayon,
viscose, polyester,
curpo, modal
STEAM
silk
wool
cotton
Linen
silk
wool
cotton
Linen
On the label means: This article cannot be ironed
(e.g. chlorofiber, elastodiene)

-9-
MAINTENANCE AND CLEANING
Before cleaning your iron, always make sure that it is disconnected from the
electrical wall socket and is completely cool.
SOLEPLATE
• Residue on the Soleplate can be wiped off with a cloth soaked in a solution
of water and vinegar.
• Do not use scouring pads, abrasives or chemical cleaning solvents as they
may damage the finish.
HOUSING
• The housing can be cleaned with a moist cloth and then wiped dry.
• Other than the recommended cleaning, no further user maintenance should
be necessary. If for any reason your iron should require repairs, do not try to
fix it yourself.
STORING THE IRON
1. Turn off the iron and disconnect the plug from the electrical wall
socket.
2. Set the iron in an upright position and let it cool down completely.
3. Set the Steam Select Switch to the closed position .
4. Empty out all the water remaining in the Water Reservoir by opening
the Water Reservoir Lid and inverting the iron over the sink.
5. The Power Cord can be wound around the Heel Rest for easier and
tidy storing once the unit has cooled down. The iron should always
be stored in an upright position.

-10-
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 years from the original date of
purchase against workmanship and defects in material. If under normal
use, your product fails to operate, please contact our customer service
department at [email protected] . A refund or replacement will be
provided to you with proof of purchase. Star Elite Inc. may deny claims of
damage caused by misuse or modifications of this product.
