Sunbeam Juice Stream JE5200 User manual

JE4800 Juicer Issue: A Page 1 of 7
SERVICE MANUAL
JE5200
Juicer
ISSUE: A
DATE: 25
th
February 2010

JE4800 Juicer Issue: A Page 2 of 7
SPARE PARTS LIST
Note: Not all parts are available as spare parts. Please check price list.
No.
Parts name Materials Cat No. Manufacture
Sunbeam
Part No
1 Pusher assembly JE52101
1-1 Cover(Pusher) ABS ABS5000(b)
TAITA CHEMICAL CO
LTD(TTC)
1-2 Pusher ABS ABS5000(b)
TAITA CHEMICAL CO
LTD(TTC)
2 Cover assembly JE52102
2-1 ring ABS ABS5000(b)
TAITA CHEMICAL CO
LTD(TTC)
2-2 Lid
AS
PN-127 CHI MEI CORPORATION
AS-C+
DENKI KAGAKU KOGKO
KABUSHIKI KAIAHA
透明 ABS PA-758(+) CHI MEI CORPORATION
3 blade assembly JE52103
3-1 blade SUS430
HUA KAI SHENG
HARDWARE PRODUCTS
CO., LTD.
M&T MANUFACTURING
CO., LTD.
3-2 Strainer(metal) SUS304
JIAZHOU ELECTRONIC
FACTORY
3-3 Disc blade PA66+30%GF
6210G(c)
NAN YA PLASTICS CORP
PLASTICS 4TH DIV
4
Middle base
assembly JE52104
4-1 Middle base ABS 5000(b)
TAITA CHEMICAL CO
LTD(TTC)
4-2 Lever(2) POM FM090
FORMOSA PLASTICS
CORP
4-3 spring
SUS304
SHEHG HUEI SPRING
HARDWARE CO.,LTD.
SUS304
HUA YI HARDWARE
PRODUCTS FACTOR
4-4 baffle PP PC-366
LEE CHANG YUNG
CHEMICAL IND CORP
5 spout AS
PN-127 CHI MEI CORPORATION
AS-C+
KINGFA SCI & TECH CO
LTD JE52105
6 Clutch process
6-1 Clutch ABS PA-777D CHI MEI CORPORATION
6-2 Embedding grain
CU
ZHOU SHUN MOTOR
SHAFI CO.,LTD
CU
GUO XIANG ME TAL
PROOVCTS FACTORY
Aluminum ZHOU SHUN MOTOR

JE4800 Juicer Issue: A Page 3 of 7
SHAFI CO.,LTD
Aluminum
GUO XIANG ME TAL
PROOVCTS FACTORY
6-3 Slide Button POM FM090
FORMOSA PLASTICS
CORP
6-4 Spring
SUS304
SHENG HUI SPRING
HARDWARE CO.,LTD.
SUS304
HUAYI HARDWARE
PRODUCTS FACTOR
7 Container(2)
AS
PN-127 CHI MEI CORPORATION
JE52106
AS-C+
KINGFA SCI & TECH CO
LTD
透明 ABS PA-758(+) CHI MEI CORPORATION
８ Switch assembly
8-1 Wire assembly
8-
1-1 Diode
IN5408TP-
MIC
TUNHOUD ELECTRIC
INSTRUMENTS CO., LTD
8-
1-2
Heat-shrinkable
Tube Polyolefin RSFR-X
Shenzhen Woer Heat-
Shrinkable Material Co.,Ltd.
8-2 Power switch R4L24
JENTEX INDUSTRIAL
CO.LTD.
8-3 Wire (Black) PVC 1015
DongGuan HaoYang
Electronics Co Ltd
DongJu Electronics Co Ltd
Various
9 Clamp(right) PC 301V(a) DOW EUROPE S A
10 Lever(clamp) POM FM090
FORMOSA PLASTICS
CORP
11 Knob ABS ABS5000(b)
TAITA CHEMICAL CO
LTD(TTC)
12 Washer Iron
13 Knob bracket ABS ABS5000(b)
TAITA CHEMICAL CO
LTD(TTC)
14 Screw Iron
JIN ZHUANG SCREW
HARDWARE FACTORY
15
Aluminum
panel(right) Aluminum AL1050
HUA KAI SHENG
HARDWARE PRODUCTS
CO., LTD.
16 Clamp(left) PC 301V(a) DOW EUROPE S A
17 Juice container
半逶明 PP ST868M
LEE CHANG YUNG
CHEMICAL IND CORP JE52107
18
Aluminum
panel(left) Aluminum AL1050
HUA KAI SHENG
HARDWARE PRODUCTS
CO., LTD.
19 Main housing ABS ABS5000(b)
TAITA CHEMICAL CO
LTD(TTC)
20 Safety Lever POM FM090
FORMOSA PLASTICS
CORP
21
Mocro switch
assembly

JE4800 Juicer Issue: A Page 4 of 7
21-
1 Wire (Brown)
PVC 1015
DongGuan Hao Yang
Electronics Co., Ltd.
PVC 1015
Various
21-
2 Wire (Yellow) )
PVC 1015
DongGuan Hao Yang
Electronics Co., Ltd.
PVC 1015
Various
21-
3
Micro switch 16506
Trantek Electronics Co.Ltd
Micro switch DMB-1206 Defond Components. Ltd
22 Spring SUS304
SHEHG HUEI SPRING
HARDWARE CO.,LTD.
23
Fixture
base(switch)
ABS+20%GF PA-717C ( + ) CHI MEI CORPORATION
ABS ABS5000(b)
TAITA CHEMICAL CO
LTD(TTC)
24 Screw Fe
JIN ZHUANG SCREW
HARDWARE FACTORY
25 Screw Iron
JIN ZHUANG SCREW
HARDWARE FACTORY
26 Washer Iron
JIN ZHUANG SCREW
HARDWARE FACTORY
27 Motor fixture base Iron
XIN LIAN ZHAN Hardware
Electrical Equipment Co.,
Ltd
JING YU DA Metals &
Plastics Factory
28
Vibration-proof
rubber Rubber
HENG BAO Rubber
Products Co., Ltd.
29 Screw Iron
30 motor
MA-
882523H06
YA HORNG(DONG GUAN)
ELECTRONIC.,LTD.
31 fixture base Rubber
32 Fixture shelf PA66 P50FI NILIT LTD
33 base ABS ABS5000(b)
TAITA CHEMICAL CO
LTD(TTC)
34 Screw Iron
JIN ZHUANG SCREW
HARDWARE FACTORY
35 Feet Rubber
XiaMen, YUN-CHENG
Rubber Industrial Co., Ltd.
36 Latch (Foot) PA66 P50FI NILIT LTD
37
0.22UF Capacitor-
RoHS
MPX Carli Electronics Co. Ltd
MCY
HSUAN TAI ELECTRICAL
CO,LTD
MPX Strong Capaciton Co.ltd
MEX-X2 MPP
DongGuan Huajia
Electronics Co.Ltd
38 Resistance
C.C.OHM ENTERPRISE
CO LTD
39 wire tie
Nylon66 CV-100K
Kai Suh Suh Enterprise Co
Ltd
Nylon66 GT-100M Hua Wei Industrial Co Ltd
40 Plug SP-501A
I-SHENG ELECTRIC WIRE
& CABLE CO., LTD

JE4800 Juicer Issue: A Page 5 of 7
Cord H05VV-F
I-SHENG ELECTRIC WIRE
& CABLE CO., LTD
plug LP-15A
Tai Wan Line Tek Electronic
Lo.,Ltd.
cord H05VV-F
Tai Wan Line Tek Electronic
Lo.,Ltd.
plug NT008AS
Perennialcabel(Shen
Zhen)Ltd
cord H05VV-F
Perennialcabel(Shen
Zhen)Ltd
41
Heat-shrinkable
Tube PVC RSFR
Shenzhen Woer Heat-
Shrinkable Material Co.,Ltd.
42
Heat-shrinkable
Tube PVC RSFR
Shenzhen Woer Heat-
Shrinkable Material Co.,Ltd.
43
close-end
connector Nylon66 CE2X Heavy Power Co Ltd

JE4800 Juicer Issue: A Page 6 of 7
EXPLODED VIEW DRAWING

JE4800 Juicer Issue: A Page 7 of 7
CIRCUIT DIAGRAM
