Sune Technology SUNE10-MIB2 User manual

Instruction Manual
DATE.
2018.12.27
SUNE10-MIB2
ANDROID INTERFACE

[ANDROID INTERFACE]
COMPONENTS
SUNE-MIB2 Power/CAN Cable Universal Cable
LVDS Cable AV Cable IR Cable
Speaker External GLONASS
GPS Antenna WiFi/BT Antenna x 2
MIC Key Pad

[ANDROID INTERFACE]
SPEC
※ ANDROID
OS
CPU
VPN
Memory
USB
USB
3.0
Wireless
GPS
HDMI OUT
Speaker
I/O
Temperature
Operating
Android 8.1(OREO)
Six-Core 64bit Server Class Cortex-A72 Core @2.0Ghz,
Mali-T860 Quad-Core GPU (Total Ten-Core)
H.264/H.265/VP9 up to 4Kx2K@60fps (4K Video)
2GB DDR3
USB2.0 High Speed Port x 1
USB3.0 5.0Gbps Port x 1
2.4GHz/5GHz Dual-Band WiFi,
Support 802.11a/b/g/n/ac, Bluetooth 4.1
Ublox8 GPS(GLONASS/BEIDOU/GALILEO/QZSS/SBAS)
HDMI 2.0, Support maximum 4K@60Hz display
2W
Mic (voice recognition),
-20°C ~ 80°C
-15°C ~ 70°C
※ INTERFACE
Input Spec.
Output Spec.
Power Spec.
I/O
1 x HDMI IN (1280x720),
2 x A/V Input ( external video source )
1 x
CVBS ( Front Camera )
1 x CVBS ( Rear Camera )
1 x Audio L/R Output
1 x LVDS Output ( LCD Operation )
Input Power : 12V DC ~ 24V DC
Consumption Power : 12 Watt Max
Input : 10P Dip Switch
Output : 12V Output ( 3A Max )
DVB
-T IR ( Remote Control )
DVD IR ( Remote Control )

[ANDROID INTERFACE]
CONNECTOR PIN ASSIGNMENT
Power Cable
(POWER/CAN)
AV Cable
(AV IN)
Universal Cable
(AV IN/OUT)
1 3 57911 13 15
24 6 810 12 14 16
1 3 5 7 9 11 13 15
Yellow Purple Green White Purple Orange
BATTERY N.C VDD-12V REVERSE N.C ECU_CAN_
IN_H
MON_CAN_
IN_H
MON_CAN_
OUT_H
2 4 6 8 10 12 14 16
Black Orange Blue Brown Green
GND N.C N.C REAR_12V N.C ECU_CAN_
IN_L
MON_CAN_
IN_L
MON_CAN_
OUT_L
1357911 13 15
2 4 6 8 10 12 14 16
1 3 5 7 9 11 13 15
White White White White White White White White
AV1_IN_V AV1_IN_R AV1_IN_L AV2_IN_V AV2_IN_R AV2_IN_L FRONT_IN REAR_IN
2 4 6 8 10 12 14 16
Black Black Black Black Black Black Black Black
GND GND GND GND GND GND GND GND
1357911 13 15 17 19 21
2 4 6 8 10 12 14 16 18 20 22
1 3 5 7 9 11 13 15 17 19 21
White White White White Blue White Yellow Red White Brown Green
SPK_P
AUX_OUT_R
AUX_OUT_L
MIC_P Capacitive
Touch SCL
Capacitive
Touch SDA
Capacitive
Touch
Interrupt UART TX UART RX DVB-T IR DVD IR
2 4 6 8 10 12 14 16 18 20 22
Black Black Black Black Black Red Green Black White Black Red
SPN_N GND GND MIC_N GND Capacitive
Touch 3.3V
Capacitive
Touch Reset
UART_GND
IR_IN IR_GND
IR_POWER
POWER/CAN
AV IN AV IN/OUT
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
DIP S/W INFORMATION
ON 1 2 3 4 5 7 86 9 10
11
ON OFF
Pin No. ON OFF
1HDMI Mode Skip HDMI Mode
2External Rear Camera Orignal Rear Camera
3External Front Camera Skip External Front Camera
4DVB-T Mode Skip DTV Mode
5DVD Mode Skip DVD Mode
6NC NC
7
Selection of Car Model
(Next Page)
8
9
10
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
DIP S/W INFORMATION
ON 1 2 3 4 5 7 86 9 10
11
ON OFF
7 8 9 10 Brand Model Inch Remark
On
Off
On
Off
Audi
A3
5.8˝MMI Radio
(Low Resolution)
On
Off
Off
On
Audi
A3
7˝MMI Radio
Off
On
On
On
Audi
A4, Q5
7˝MIB2
Off
Off
On
Off
Audi
Q7, Q5
8.3˝MIB2
Off
Off
Off
On
Bentley
Bentayga
8˝MIB2
Off
On
Off
On
Porsche
PCM 4.0 / PCM 4.1
8˝PCM 4.0
PCM 4.1
Off
Off
On
On
Porsche
Panamera
12.3˝PCM 4.1
Off
On
On
Off
Volkswagen
Golf,
Passat, Tiguan
5.8˝Automatic Transmission
Composition Media
Composition Colour
Skoda
Octavia
Off
Off
Off
Off
Volkswagen
Golf,
Passat, Tiguan
6.5˝, 8
˝
Automatic Transmission
2017 Discover Media
Discover Media, Pro
Composition Media
Skoda
Octavia
Off
On
Off
Off
Volkswagen
Golf,
Passat, Tiguan 9.2˝Automatic Transmission
2017 Discover Pro
On
On
On
Off
Volkswagen
Golf,
Passat, Tiguan
5.8˝Manual Transmission
Composition Media
Composition Colour
Skoda
Octavia
On
Off
Off
Off
Volkswagen
Golf,
Passat, Tiguan
6.5˝, 8
˝
Manual Transmission
2017 Discover Media
Discover Media, Pro
Composition Media
Skoda
Octavia
※ Selection of Car Model
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
DIP S/W INFORMATION
ON OFF
Pin No.
On Off
11200x720
(Same Ratio 800x480) 1280x720
2Use External GPS Antenna
(DIP S/W 2 Must ON)
Use Car GPS Cable
(Option)
1 2
ON
1 2
ON 1 2
ON
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
SCREEN VIEW
1NAVIGATION Quick icon for Navigation Application
2Multimedia Quick icon for Multimedia Application
3Music Player Music player Widget
4File Manager Quick icon for File Manager Application
5APPS Application List
6Back Button Return
7Home Button Home
8Multitasking 1. Multitasking
2. PIP Mode by Long Press
9APP Shortcut Quick icon
10 Sound Volume control
11 WiFi Open Wifi setting screen
12 Settings Open Android Settings
13 Zoom Tool Screen Zoom in / out
※ This icon will show when car monitor have “Resistive Touch”,
1 2 3
4 5
6 7 8 9 10 11 12
13
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
SCREEN VIEW –Split Screen Mode
Long Press
Normal
Mode
Split Screen Mode
Mode
※ Split Screen
1. Multitasking button Long press 2. Press Home button
3. Apps 4. Select application
※ Some apps are not work on Split Screen Mode
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
ANDROID
INTERFACE
POWER/CAN KEYPAD LVDS IN/OUT AV IN/OUT SW GPS WIFI/BT
DEBUG
DIP SW R-KEY HDMI OUT USB 2.0 MicroSD
AV IN
USB 3.0HDMI IN
CABLE CONNECTION
BATGND
Universal Cable
AV Cable
Grey LVDS Cable
from command
LVDS Cable from
Interface to command
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
OEM BUTTON USAGE - AUDI
No.
Button Press Function
Steering wheel
1BACK
Long Press ( 2sec ) Front View Camera
Short Press Change to previous screen
2NAV Short Press Back to oem screen
Touch pad
3 NAV/MAP
Short Press Back to oem screen
4 TEL
5 RADIO
6 MEDIA
7
Move Wheel
Dial, Push Remote menu choice and move (DVBT,DVD)
1
2
7
3
4
5
6
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
OEM BUTTON USAGE - BENTLEY
No.
Button Press Function
1NAV Press for 2sec Change to interface home screen
Short Press Change to previous screen
RADIO
Short Press Back to OEM screen
MEDIA
TEL
HOME
BACK
1
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
OEM BUTTON USAGE –PORSCHE (PANAMERA)
No.
Button Press Function
Radio Button
2NAV
Long Press ( 2sec ) HDMI->NAVI->DVBT->DVD->OEM
Short Press Back to oem screen
3 Jog Wheel Dial, Push Remote menu choice and move (DVBT,DVD)
2
3
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
OEM BUTTON USAGE - PORSCHE (PCM 4.0)
No.
Button Press Function
1NAV Press for 2sec Change to interface home screen
Short Press Change to previous screen
Tuner
Short Press Back to OEM screen
Media
Map
Source
Phone
Car
Home
1
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
OEM BUTTON USAGE - VOLKSWAGEN / SKODA
No.
Button Press Function
1MENU Long Press ( 2sec ) Change to previous screen
Short Press Back to OEM screen
RADIO
Short Press Back to OEM screen
MEDIA
PHONE
CAR
SETUP
SOUND
MUTE Short Press OEM function
1
1
No.
Button Press Function
Monitor Button
1 MENU
Long Press ( 2sec ) HDMI->NAVI->DVBT->DVD->OEM
Short Press Back to oem screen
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
OEM BUTTON USAGE - Skoda
No.
Button Press Function
1MENU Long Press ( 2sec ) Change to previous screen
Short Press Back to OEM screen
RADIO
Short Press Back to OEM screen
MEDIA
PHONE
CAR
SETUP
SOUND
MUTE Short Press OEM function
1
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
REMOTE CONTROL (How To Control) - DVBT / DVD
AUDI(Q7, Q5)
PORSCHE(PANAMERA)
You can select a menu by turning the jog dial. (for DTV, DVD)
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
ANDROID
INTERFACE
POWER/CAN KEYPAD LVDS IN/OUT AV IN/OUT SW GPS WIFI/BT
DEBUG
DIP SW R-KEY HDMI OUT USB 2.0 MicroSD
AV IN
USB 3.0HDMI IN
1 3 5 7 911 13 15 17 19 21
2 4 6 8 10 12 14 16 18 20 22
1357911 13 15
246810 12 14 16
DVB-T CONNECTION DIAGRAM FOR AV INPUT
Open the cover of DVB-T.
Connect ‘DVBT-IR’ provided to ‘A’ on picture
1 2
3 4
A
1
23
4
1
23
4
UNIVERSAL CABLE AV CABLE
1IR –DVB-T
2DO NOT USE.
3DO NOT USE.
4DO NOT USE.
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
ADD REMOTE CONTROLLER
K-PAD
Remote Model
Setting Remote select
Remote Memory
Selected remote control
setting
DVB-T Model
DVB-T Model select
Enter the setting menu. And DVB-T select.
SUNE TECH SUNE TECH

[ANDROID INTERFACE]
MMI TOUCH PAD GESTURE -AUDI
Click
Push Touch pad
Scroll
Slide two fingers
up or down
the touch pad to scroll
Drag
Push Touch pad
and sliding
Apply YouTube gesture
By watching video on YouTube, press the MMI Touch pad and Slide MMI Touch
Pad to Close Video.
1 2
3 4
SUNE TECH SUNE TECH
