Sune Technology QVI-LX11(1CH) Series Manual

Your best partner for better driving
Release Date
2014.03.28
Model
QVI-LX11(1CH)-V7.1 SET
Product Code
LVTX-1CH-1203-005
SUNE TECHNOLOGY CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN
TEL:[phone] FAX:[phone]
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
CarNavi-Tech

Table of Contents
1. Specifications
1.1 Main Specifications
1.2 Features
1.3 System Diagram
1.4 Components
1.5 Exterior
2. Installation
2.1 Installation Diagram
2.2 Use caution
2.3 Installation
3. Settings
3.1 DIP Switch
3.2 Remote Control
3.3 OSD (On Screen Display)
3.4 Factory Mode
3.5 Rear Parking Guidelines
3.6 Touch Calibration
3.7 Remote button Input
4. Trouble Shooting
1
2
3
4
5
6
7
8
19
20
21
23
24
25
26
28
CarNavi-Tech

Warning
When installing the main unit, do not remove or alter existing
vehicle fasteners, including nuts, bolts, screw, clips, and fittings.
Never detach, move or alter existing vehicle wiring, including
electrical grounds and straps. Alteration of existing vehicle
components may make vehicle unsafe to operate. Should be
no any electronic devices or magnetic pole around installation
place.
Air bags are vital part of a safety system. Never install main unit
in a way which will alter air bag wiring or interfere with air bag
deployment. Air bags must function properly in the event of an
accident.
Before installing, check the location of pipe, tank, electrical
cables and others.
Read and follow the instruction manual.
Wiring location must not interfere driving, get in or out from car.
Use electrical tape to insulate the ends of all wires, even if they
are not used. Proper insulation prevents arcs, shocks and fires.
When installation is complete, test all vehicle electrical systems
to ensure they operate correctly, including lights, horn, brake
lights, and emergency flashers.
According to our sales policy, any problems caused by user’s
mistake, careless can not be guaranteed.
Caution
All steps of installation should be done by well-trained specialist.
During installation ignition key should be taken off and after all
installation finish connect power cable with interface for the last
step.
Do not install the main unit in places where it ma be exposed to
dew condensation (around the air conditioning hose, etc), or in
locations where it may come in contact with water, high levels of
moisture, dust or oily smoke
Install wiring in a manner in which cables will not come in contact
with metal parts. The wiring may be damaged by contact with
metal parts, resulting in fire and shocks. Avoid all contact with hot
surfaces when wiring the main unit. High temperatures may
damage wiring, causing shorts, arcing and fires.
Kindly check all parts are in the box, when receiving the product, if
anything missing, inform to the supplier or manufacturer.
Warning / Caution
3
CarNavi-Tech

1. Specification
-1-
1. Main Components
Multimedia Interface * 1EA
Sub-board * 1EA
2. MULTIMEDIA INTERFACE input specification
3 * A/V (NTST&PAL) Input
1 * CVBS(Rear Camera) Input
1 * Analog RGB
1 * LCD input (Car system input)
3. MULTIMEDIA INTERFACE output specification
1 * LCD output (LCD performance)
1 * Audio output
2 * CVBS output
4. Power specification
Input power : 8VDC ~ 16VDC
Consumed power : 4WATT (Max)
5. Switch input mode
-External display skip function : Through DIP switch, user can
control each video input
-Through remote control, user can change input mode
-By pressing the MODE SWITCH, the mode will be switched.
1.1 Main Specifications
CarNavi-Tech

1. Specifications
-2-
Able to adjust DVD, NAVI on the screen
Improvement in Screen Display(User friendly interface)
Add Safe function (While driving, the screen shows the main
page)
A MODE SWITCH button is provided to switch the mode.
1.2 Features
CarNavi-Tech

1. Specification
-3-
1.3 System Diagram
DISPLAY
A/V 1
NAVIGATION Input
(Analog RGB)
CVBS
(Rear camera)
Car Screen Input
(CAR MAIN BOARD)
A/V 2
A/V 3
VIDEO
CIRCUIT
VIDEO MUX
MCU
Power Input
(+8VDC ~ +16VDC)
POWER
CIRCUIT
Dip S/W
A/V OUT HEADREST
MONITOR
Remote control Switch for source toggle
OEM Navi Button (Can Signal)
Car Installation
OEM LCD
CarNavi-Tech

1. Specification
-4-
1.4 Components
POWER cable (24P) * 1ea
(HPOWER0011)
REMOTE CONTROL * 1ea
(REMOTE0001)
A/V cable * 1ea
(HAVCAB0002)
TOUCH OUT cable * 1ea
(HTOUCH0004)
REAR CAMERA POWER cable * 1ea
(HARETC0002)
IR cable * 1ea MODE cable * 1ea RGB cable * 1ea
(HARETC0001) (HNAVIC0004)
(HIRCAB0002)
LVDS cable * 1ea
(HLVDSC0020)
Sub-board * 1ea
Sub-board Bracket * 1ea
(PRESET0155)
8P TOUCH cable * 1ea
(HTOUCH0017)
FFC cable * 2ea
(FFCABL0036)
8P FFC cable * 1ea
(FFCABL0035)
CarNavi-Tech

1. Specifications
-5-
1.5 Exterior
Dimension
Width 125mm
Length 105mm
Height 21mm
- SUB BOARD -
⑨
⑪
⑩
⑨LVDS-IN
⑩BUTTON
⑪TOUCH IN/OUT
⑫TTL_OUT
⑬TTL_IN
①LED
②POWER
③RGB IN-2
④R-CAM
⑤AV(IN/OUT)
⑥DIP Switch
⑦TOUCH OUT TO NAVI
⑧LVDS OUT
⑥⑦⑧
①②③④⑤
⑫
⑬
CarNavi-Tech

2. Installation
-6-
2.1 Installation Diagram
IR-AV2 (DVD)
AUX-ON (N.C)
CAN-L
CAN-H
IR-AV3 (DTV)
IR-AV1 (NAVI)
PARKING (SAFE)
REAR
OPT2 (N.C)
MODE : Toggle S/W
IR
PB12 (N.C)
GPIO-ZO : MMI
GND
ACC
RGB
REAR (9V OUT)
GND
AV1 AV2 AV3
REAR C
Audio L
Audio R
AV/OUT Video
Navigation Touch cable
COMMAND
LCD
TOUCH IN/OUT cable
QDIS FFC cable
QDIS FFC cable
LVDS cable
OEM TOUCH cable
QDIS TOUCH cable
※ In case of connecting the
cable to Monitor’s module
directly, Please use caution
especially ESD.
It may cause the critical
damage on the monitor)
CarNavi-Tech

2. Installation
-8-
2.2 Installation
①Remove the monitor from the vehicle.
② Detach Monitor’s cover from the head unit.
CarNavi-Tech

-9-
①Separate LCD part from the head unit.
②Disconnect the OEM cables and remove the black
plastic connector.
2. Installation
2.2 Installation
CarNavi-Tech

-10-
①Attach black connectors to FFC cables provided by us as shown on
the left
②Link the new FFC cable to the place where OEM FFC cables were
connected. Refer to the right picture.
2. Installation
2.2 Installation
CarNavi-Tech

-11-
①Assemble the bracket provided by us on the top of the body.
②Holes where are marked in red are the place to be assembled with
our bracket.
2. Installation
2.2 Installation
CarNavi-Tech

-12-
①take out the FFC cable from the gap of the head unit
and then link it to TTL IN of our Sub-board.
2. Installation
2.2 Installation
CarNavi-Tech

-13-
①Remove the cover of LCD part which was
separated from the head unit.
2. Installation
2.2 Installation
CarNavi-Tech

-14-
①Connect our touch FFC cable to the place where OEM touch
cable was removed.
2. Installation
2.2 Installation
CarNavi-Tech

-15-
①Connect touch out cable to our FFC cable and link touch in cable to
OEM FFC cable.
2. Installation
2.2 Installation
CarNavi-Tech

-16-
①Draw out our touch in/out cables and FFC cables between gaps
marked
2. Installation
2.2 Installation
CarNavi-Tech

-17-
①TOUCH IN/OUT cables are linked to TOUCH IN/OUT of subboard, FFC
cable linked to LCD is connected to TTL_OUT
②Tighten the marked bolts to be fixed with bracket.
2. Installation
2.2 Installation
CarNavi-Tech

-19-
PIN
Function
Dip S/W choice
1
RGB input skip ON : RGB mode skip
OFF : RGB Display
2
A/V 1 Skip ON : A/V 1 Skip
OFF : A/V1 Display
3
A/V 2 Skip ON : A/V 2 Skip
OFF : A/V2 Display
4
A/V 3 Skip ON : A/V 3 Skip
OFF : A/V3 Display
5
Car model setting OFF : DEFAULT
6
OFF : DEFAULT
7
Rear mode ON : external Rear Camera
OFF : OEM Rear Camera
8
ON : OEM Navigation
OFF : External Navigation (Default)
※ ON : DOWN / OFF : UP
※ For example, Use of DIP S/W
- Input mode: A/V3, Navigation (RGB)
- OEM Navigation Not available
- Rear Camera : When it is installed to
CVBS4
▷DIP S/W : 1 OFF
▷DIP S/W : 2,3 ON (Input mode Skip)
▷DIP S/W : 4 OFF (A/V3 possible)
▷DIP S/W : 5 OFF
▷DIP S/W : 6 ON
▷DIP S/W : 7 ON (CVBS4 possible)
▷DIP S/W : 8 OFF
※ After resetting the DIP switch, disconnect the power and reconnect the
power. Otherwise, the new settings will not be applied.
3. Setting
3.1 DIP Switch
CarNavi-Tech
ON:7inch IS and 8inch LS460/Land CRUISER
