Sune Technology QPI-LVTX-NCC5 User manual

SUNE TECHNOLOGY CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN
TEL:[phone] FAX:[phone]
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
CarNavi-Tech

•Specification
Car Compatibility : 2015 Polo 5inch monitor
Components : Interface* 1ea, Sub-board*1ea
Multimedia interface Input/output spec
Input : Analog RGB*2 (Navigation, SMI), A/V*3,
CVBS(Rear Camera)*1
Output : To LCD*1
Power spec
Input power : 8VDC ~ 18VDC
Consumption : 5WATT
Switch input mode
External video sources skip function : able to control input
videos on and off via DIP switches.
Able to switch videos via the remote, button switch, and
original buttons.
Able to detect the rear view camera (back up camera) via
Lamp or CAN.
2
•Features
Control external videos sources (DVD, DTV) via Multi Media
Touch GUI
Adjust external videos screen position
Check the improved Screen Display (User Friendly Interface)
Switch modes via original OEM button
Supply power to connect rear view camera (Back up
camera)
Assist your parking via Dynamic PAS(Parking Assistance
System), PDC(Parking Distance Control), moving parking line
according movement of steering wheel.
CarNavi-Tech

3
Sub-board * 1ea
MODE(Button cable connection) | IR(IR cable connection) | POWER(Power cable connection)
| REAR(Rear cable connection) |RGB-IN-HDMI(Mirroring device connection)
| RGB-IN-NAVI(RGB Navigation connection) |AV IN/OUT(AV cable connection) | TO NAVI T/S OUT(NAVI
touch cable connection) | LVDS-OUT(Sub board connection)
TEST(No use) | LED | DIP S/W(Dip switch setting)
POWER * 1ea
(HPOWER0044)
LVDS * 1ea
(HLVDSC0020)
RGB * 1ea
(HRGBCA0013)
AV * 1ea
(HAVCAB0002)
NAVI TOUCH * 1ea
(HTOUCH0004)
REAR* 1ea
(HARETC0002)
BUTTON * 1ea
(HARETC0001)
IR * 1ea
(HIRCAB0002)
RC * 1ea
(REMOTE0001)
Bracket * 1ea
(PRESET0378)
Touch board * 1ea
•Product exterior
Length-90mm
Height-18mm
Width-140mm
•Components
CarNavi-Tech

PIN
FUNCTION
Dip S/W SETTING
1
RGB INPUT MUTE
OFF : RGB DISPLAY
ON : Skipping RGB Mode
2
HDMI1 MODE MUTE
OFF : HDMI1 DISPALY
ON : Skipping HDMI1 Mode
3
AV MODE MUTE
OFF : AV DISPLAY
ON : Skipping AV Mode
4
FRONT CAM MUTE
OFF : Front camera function on
ON : Front camera function off
5
NO USE (OFF)
6
MONITOR SETTING
OFF : Default
7
REAR MODE
OFF : OEM Rear Camera
ON : External Rear Camera
8
NO USE (OFF)
※ON : DOWN / OFF : UP
※Please make sure to disconnect the power cable of the interface
and reconnect the power cable again to apply the dip switch
setting whenever changing DIP switch. Otherwise, DIP switch setting
will not be applied.
4
•DIP SWITCH
•REMOTE CONTROL SETTING
KEY
FUNCTION
POWER & PIP NO USE
MENU Activating FACTORY MENU
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can
access the factory mode.)
▶
Moving rightward
(If you press this button 2 seconds long, you can
reset all the data about user environment.)
CarNavi-Tech

PARK
UTIL1
UTIL2
INFO
H-POSITION
V-POSITION
H-SIZE(NAVI)
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
PAS TYPE
PAS SETUP
REAR TYPE
SAFE ENABLE
RADAR ENABLE
Menu of FACTORY
MENU to Return SEL to Select/Save
5
•Factory setting
Adjust a current screen position and size.
PAS TYPE : Select type of parking guide line
- NOT USED : No use parking guide line
- PAS ON : Selecting Dynamic parking guide line
- PAS OFF : Selecting fixed parking guide line
PAS SETUP : Adjusting the position of the parking guide line
REAR TYPE : Choose rear camera recognition.
- CAN : By connecting to “CAN” cable of the car gear, changing to
rear camera mode when shifting into reverse. (Connect “CAN”
cable of the power cable to the “CAN” cable of the car gear.)
- LAMP : By connecting to the rear lamp of the car, switch to rear
camera mode when shifting into rear. (Connect “Rear-C” cable of
the power cable to the rear lamp of the car.)
SAFE ENABLE : If it is enable, RGB, and A/V mode doesn’t show up while
driving. (Default : OFF)
<H-POSITION> <V-POSITION>
Adjust rear view camera setting.
H-POSITION : Move display horizontally
V-POSITION : Move display vertically
H-SIZE(NAVI) : Adjust the horizontal size of
Navigation
CarNavi-Tech

6
Navigation & Car model setting up
NAVI MODEL : Setting up RGB Navigation.
(Default, QWGA, Q-ROI)
CAR MODEL : Selecting the model of car.
(POLO)
AVOUT SELECT : Selecting background sound
through car AUX. (HDMI1, HDMI2, AV)
HDMI2 SKIP : Skipping HDMI mode when
switching modes.
FACTORY RESET : Reset the factory setting.
Other options setting up
I-DRV REMOTE : Able to use remote control on
DVD, DTV by selecting “User” after IR
memory registered. (Default, User)
I-DRV CONTROL : Turning on or off of Remote
control usage.
IR MEMORY : Registering IR memory (Remote
control values) of DTV, DVD.
System version information
PARK
UTIL1
UTIL2
INFO
NAVI MODEL
CAR MODEL
AVOUT SELECT
HDMI SKIP
FACTORY RESET
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
I-DRV REMOTE
I-DRV CONTROL
IR MEMORY
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
SYSTEM VERSION
(MAIN-130723)
Menu of FACTORY
MENU to Return SEL to Select/Save
•Factory setting
CarNavi-Tech

7
LVDS Cable
NAVI BOX
AV1
AV2
AV3
REAR C
Audio L
Audio R
AV/OUT Video
ACC
REAR
MMI
GND
CAN-H-HS
CAN-L-HS
F-CAM-DET
SAFE
CAN-H-LS
CAN-L-LS
REAR (9V OUT)
GND
RGB
Cable
Touch Cable
•Installation Diagram
CarNavi-Tech

8
CAN1-H
CAN1-L CAN2-H
CAN2-L
Original Power Cable
※Find the original 12 pins cable as above at the back side of command.
- Provided CAN1-H wire (Yellow+White) → Original CAN-H wire #1 pin (Orange+Black)
- Provided CAN1-L wire (White) → Original CAN-L wire #7 pin (Orange+Brown)
- Provided CAN2-H wire (Black+White) → Original CAN-H #6 pin (Orange+Purple)
- Provided CAN2-L wire (Black) → Original CAN-L #12 pin (Orange+Brown)
※Color of cable would be different depending on Cars.
•CAN cable connection
CarNavi-Tech

9
•Connect S/B to Monitor
Remove monitor from car Remove LCD part from the head unit and disassemble
the bracket as picture above.
Disconnect the original
FPC cable and connect it
to Touch sub-board.
Connect the provided
FFC cable #1 to the other
side of Touch sub-board.
Connect the provided FFC
#2 cable to where the
original cable removed.
Tape it well so it
wouldn't disconnect
Assemble the sub-board
and connect FFC cables
Reassemble the bracket Reassemble the LCD part to
the head unit with arranging
cables as picture above.
Install the provided bracket
on the back side of LCD as
picture above.
FFC #2 from LCD part
↓Connect
TTL_IN
FFC #1 from Touch S/B
↓Connect
TTL_OUT
CarNavi-Tech

10
•Trouble shooting
Q. I cannot change mode
A. Check connection of Ground cable and IR Cable. Check LED lamp
is on, if not check connection of POWER cable.
Q. All I got on the screen is black.
A. Check second LED lamp of the interface is on, if not, check A/V
sources connected are working well.
(Second lamp indicates AV sources connected works well.)
Check interface connection has been done well.
Q. Displayed image color is not proper (too dark or unsuitable color)
A. Press ▶button on the remote control for 2 seconds and check how
it goes, if it does not work, inform to manufacturer.
Q. I cannot watch the rear camera on the screen
A. Set the DIP switch #7 as state “ON”.
Q. Set mode not appear
A. Check DIP Switch.
Q. OEM image is not displayed.
A. Check interface’s LCD In/Out cable connection. If the status keeps
on, inform to manufacturer.
Q. Screen only displays white color.
A. Check LCD out cable is connected well, if this status keeps, inform to
manufacturer.
Q. Show PIP function via handle button, and original screen appear half
only.
A. This is not because of faulty interface, please check original monitor
split function settings.
Q. If no image is shown on screen after connecting CAN wire with Park
gear.
A. Go on the “FACTORY MODE”, check “UTIL-Rear Select”. If “LAMP”,
change the setting as “CAN” with the remote control. (※when
connecting Rear-C wire of LAMP power cable to Backup lights,
Setting should be like this / CAN : if controlling rear camera with
CAN wire)
