Sunell SN-D2-F User manual

Bi-Spectrum Radiometric Detector
User Manual
Issue
V 1.0
Date
2019-10-08

Bi-Spectrum Radiometric Detector
User Manual
Precautions
Issue V1.0 (2019-10-08)
i
Precautions
Precautions
Fully understand this document before using this device, and strictly observe rules in
this document when using this device. If you install this device in public places,
provide the tip "You have entered the area of electronic surveillance" in an eye-
catching place. Failure to correctly use electrical products may cause fire and severe
injuries. To prevent accidents, carefully read the following context:
Symbols
This document may contain the following symbols whose meanings are described
accordingly.
Symbol
Description
It alerts you to fatal dangers which, if not avoided, may
cause deaths or severe injuries.
It alerts you to moderate dangers which, if not avoided,
may cause minor or moderate injuries.
It alerts you to risks. Neglect of these risks may cause
device damage, data loss, device performance
deterioration, or unpredictable results.
It provides a tip that may help you resolve problems or
save time.
It provides additional information.
To prevent electric shocks or other dangers, keep power plugs dry and clean.
Strictly observe installation requirements when installing the device. The
manufacturer shall not be held responsible for device damage caused by users' non-
conformance to these requirements.
Strictly conform to local electrical safety standards and use power adapters that are
marked with the LPS standard when installing and using this device. Otherwise,
this device may be damaged.

Overview
Bi-Spectrum Radiometric Detector
User Manual
ii
Issue V1.0 (2019-10-08)
Use accessories delivered with this device. The voltage must meet input voltage
requirements for this device.
If this device is installed in places with unsteady voltage, ground this device to
discharge high energy such as electrical surges in order to prevent the power supply
from burning out.
When this device is in use, ensure that no water or any liquid flows into the device.
If water or liquid unexpectedly flows into the device, immediately power off the
device and disconnect all cables (such as power cables and network cables) from
this device.
Do not expose the thermal imaging camera or unpacked product to extremely
strong radiation sources, such as the sun, laser, or arc welding machine, regardless
of whether the device is being electrified or not; do not put the camera close to high
thermal objects such as the sunlight; otherwise, the precision of the camera may be
affected and even the detector inside the camera may suffer a permanent damage.
If this device is installed in places where thunder and lightning frequently occur,
ground the device nearby to discharge high energy such as thunder strikes in order
to prevent device damage.
Unless otherwise specified, do not use the camera in a temperature lower than -
20 °C (-4 °F) or higher than +60 °C (+140 °F). Too-high or too-low temperature
may cause image display anomaly of the camera and the camera will be damaged if
it is working under such a condition for a long time.
If the camera is installed outdoors, avoid direct sunlight at dawn and dusk on the
camera lens and install a sunshield with frontal and rear positions adjusted
according to the sunlight angle.
Avoid heavy loads, intensive shakes, and soaking to prevent damages during
transportation and storage. The warranty does not cover any device damage that is
caused during secondary packaging and transportation after the original packaging
is taken apart.
Protect this device from fall-down and intensive strikes, keep the device away from
magnetic field interference, and do not install the device in places with shaking
surfaces or under shocks.
Clean the device with a soft dry cloth. For stubborn dirt, dip the cloth into slight
neutral cleanser, gently wipe the dirt with the cloth, and then dry the device.
Since the camera lens is painted with a durable coating material, it adapts to
outdoor environment. The lens must be cleaned regularly. If the image quality is
reduced or excessive dirt is deposited on the lens, clean the lens in a timely manner.
In sandy (in desert) or corrosive (on sea) environment, use the camera with caution;
improper use may cause the coating to peel off.
Do not jam the ventilation opening. Follow the installation instructions provided in
this document when installing the device.
Keep the device away from heat sources such as radiators, electric heaters, or other
heat equipment.

Bi-Spectrum Radiometric Detector
User Manual
Precautions
Issue V1.0 (2019-10-08)
iii
Keep the device away from moist, dusty, extremely hot or cold places, or places
with strong electric radiation.
If the device is installed outdoors, take insect- and moisture-proof measures to
avoid circuit board corrosion that can affect monitoring.
Remove the power plug if the device is idle for a long time.
Before unpacking, check whether the fragile sticker is damaged. If the fragile
sticker is damaged, contact customer services or sales personnel. The manufacturer
shall not be held responsible for any artificial damage of the fragile sticker.
Special Announcement
All complete products sold by the manufacturer are delivered along with nameplates,
operation instructions, and accessories after strict inspection. The manufacturer shall
not be held responsible for counterfeit products.
This manual may contain misprints, technology information that is not accurate enough,
or product function and operation description that is slightly inconsistent with the
actual product. The manufacturer will update this manual according to product function
enhancement or changes and regularly update the software and hardware described in
this manual. Update information will be added to new versions of this manual without
prior notice.
This manual is only for reference and does not ensure that the information is totally
consistent with the actual product. For consistency, see the actual product.

Bi-Spectrum Radiometric Detector
User Manual
Overview
4
Issue V1.0 (2019-10-08)
Contents
Precautions.................................................................................................................... i
1 Overview ................................................................................................................... 6
1.1 Principle of Thermal Imaging and Advantages .............................................................. 6
1.2 Product Introduction....................................................................................................... 7
1.2.1 Function ............................................................................................................. 7
1.2.2 Product Features................................................................................................. 7
1.3 Description of PTZ cable ............................................................................................... 7
1.3.1 Multi-cable......................................................................................................... 7
2 Device Dimensions ................................................................................................. 9
3 Device Installation................................................................................................. 11
3.1 Cabinet Installation .......................................................................................................11
3.1.1 General Installation...........................................................................................11
3.1.2 Magnet Installation........................................................................................... 13
3.2 Walling Installation ...................................................................................................... 14
3.2.1 Bracket Installation .......................................................................................... 14
3.2.2 Magnet Installation........................................................................................... 15
3.3 Packing list................................................................................................................... 17
4 Quick Configuration ............................................................................................. 19
4.1 Login and Logout......................................................................................................... 19
4.2 Main Page Layout ........................................................................................................ 20
4.3 Change the Password.................................................................................................... 23
4.4 Browse Video............................................................................................................... 24
4.5 Install Plugins............................................................................................................... 26
4.5.1 Set Local Network Parameters......................................................................... 26
4.6 Thermal Settings .......................................................................................................... 29
4.6.1 Temperature Parameters................................................................................... 29
4.6.2 Temperature Area............................................................................................. 33
4.6.3 Shield Area....................................................................................................... 36
4.6.4 Schedule Linkage............................................................................................. 37
4.6.5 Thermal Mapping............................................................................................. 38
4.6.6 Bad Point Check............................................................................................... 40
4.6.7 LED Control Parameter.................................................................................... 41

Bi-Spectrum Radiometric Detector
User Manual
Overview
Issue V1.0 (2019-10-08)
5
5 Thermal Parameter Configuration...................................................................... 43
5.1 Access the Sensor Setting Interface.............................................................................. 43
5.2 Sensor Setting Parameter description........................................................................... 44
5.2.1 Mode................................................................................................................ 44
5.2.2 Image Setting ................................................................................................... 44
5.2.3 Scene................................................................................................................ 46
5.2.4 Set Psecudocolor.............................................................................................. 46
5.2.5 FFC Control ..................................................................................................... 47
5.2.6 Noise Reduction............................................................................................... 49
5.2.7 Enhance Image................................................................................................. 50
6 Visible-light Parameter Configuration.............................................................. 52
6.1 Access the Sensor Interface.......................................................................................... 52
6.2 Sensor Setting Parameter description........................................................................... 52
6.2.1 Mode................................................................................................................ 52
6.2.2 Image Adjust.................................................................................................... 53
6.2.3 Scene Mode...................................................................................................... 55
6.2.4 Exposure .......................................................................................................... 56
6.2.5 WB Setting....................................................................................................... 57
6.2.6 Daynight........................................................................................................... 59
6.2.7 Noise Reduction............................................................................................... 61
6.2.8 Enhance Image................................................................................................. 63
A Common Emission Rate ...................................................................................... 65

Bi-Spectrum Radiometric Detector
User Manual
Overview
6
Issue V1.0 (2019-10-08)
1 Overview
1.1 Principle of Thermal Imaging and Advantages
Any object with temperature higher than the absolute zero (-273.15°F) will emit
infrared (IR) ray, even though it does not emit light. The IR ray is also called thermal
radiation. IR rays emitted by objects with different temperatures can be absorbed by the
detector to reflect temperature change and thus generate an electric effect. The electric
signal is amplified and processed to produce a thermal image that corresponds to the
thermal distribution of the object surface. This is the process of thermal imaging.
Adapt to any environment
Traditional cameras rely on natural or environmental light to shoot images, but this
IR thermal imaging camera relies on the IR energy radiated by an object itself to
form an image, not requiring any light. The IR thermal imaging camera is
applicable to any environment and not affected by light strength. It can detect and
identify any camouflage and concealed object both in daytime or nighttime,
implementing round-the-clock monitoring.
Monitor the temperature field with object energy distributed
The IR thermal imaging camera can show the temperature field of an object,
converting the invisible surface temperature distribution situation to a visible
thermal image that reflects the surface temperature distribution situation of the
object. By this monitoring, users can discover temperature anomaly in a timely
manner and take precautionary measures to avoid any risk that may be caused by
the anomaly, for example, a fire.
Boast cloud penetration capability
Visible light and near IR ray will be absorbed by the air, cloud and smoke, but they
are transparent to IR ray of the 3~5 μm Medium Wavelength Infrared (MWIR)
region and 8~14 μm Long Wavelength Infrared (LWIR) region. Traditional
cameras cannot shoot clear images under cloudy environment, but the IR thermal
imaging camera can penetrate the cloud and smoke to shoot clear images.
Bi-Spectrum Radiometric Detector
"Temperature warning type thermal imaging camera + HD visible light" binocular
monitoring.
Compact, lightweight, compact and cost effective.
Support horizontal/vertical installation.

Bi-Spectrum Radiometric Detector
User Manual
Overview
Issue V1.0 (2019-10-08)
7
1.2 Product Introduction
Bi-Spectrum Radiometric Detector, the whole machine shell and the base are all
made of high strength aluminum alloy material with comprehensive function and
high stability. It can be widely used in power switch cabinets, machine rooms,
storages, etc.
1.2.1 Function
To support a variety of scanning methods, such as cruise scan, pattern scanning, etc.
It supports the function of power off memory and automatically returns to the
monitoring scene before power off.
Support network signal and analog signal double output, cloud platform control
classification operation.
The double helix structure of worm gear and worm drive, the electronic image
stabilization, and mechanical locking design, power self-locking function.
1.2.2 Product Features
The shell of the machine adopts the material of high strength aluminum alloy die
casting machine with anti-corrosion materials, anti-corrosion treatment, key parts
filling nitrogen seal, all-weather protective design, IP66 protection grade, can adapt
to the maritime and coastal defense environment such as salt fog video monitoring
application.
Double spiral worm gear transmission structure, mechanical anti-loosening design,
power-off self-lock, strong wind resistance, high stability. .
The imaging is clear: the thermal imaging system is able to produce clear and
penetrating images through the dark environment with no light, the image is clear,
the focal length is fine, and the optical fog is supported.
The machine assembly is easy to operate and easy to maintain.
1.3 Description of PTZ cable
1.3.1 Multi-cable
Aviation power supply and network cable of twenty-six cores is shown as Figure 1-1,
and the description is shown in Table 1-1.

Bi-Spectrum Radiometric Detector
User Manual
Overview
8
Issue V1.0 (2019-10-08)
Figure 1-1 Aviation power supply and network cable
Table 1-1 Description of cores
SN
Port
Description
1
Power
DC 12 V
2
USB
Connect USB port
3
Video port
Connect to video screen
4
G
Ground earth wire
5
Network port
Connect to a standard Ethernet cable
6
Orange
RS232 RX
Blue
RS232 TX
Purple
ALARM OUT
Brown
ALARM OUT COM
Grey
ALARM IN
Pink
ALARM IN COM
Yellow
RS232 COM

Bi-Spectrum Radiometric Detector
User Manual
Device Dimensions
Issue V1.0 (2019-10-08)
9
2 Device Dimensions
Figure 2-1 shows the dimensions of the Bi-Spectrum Radiometric Detector。

Bi-Spectrum Radiometric Detector
User Manual
Device Dimensions
10
Issue V1.0 (2019-10-08)
Figure 2-1 Dimensions (unit: mm)
92
65
42 43
80.5
42
9.25
58
80.5
4-M3 Depth 6
2-1/4-20UNC-1A Depth 8
4-M3 Depth 6
116
4
50
101
107
123
104
126
φ63
φ55
3-φ4.5 Symmetrically array

Bi-Spectrum Radiometric Detector
User Manual
Device Installation
Issue V1.0 (2019-10-08)
11
3 Device Installation
3.1 Cabinet Installation
3.1.1 General Installation
Step 1 Stick the installation sticker label 1 on the cabinet door „s mounting surface, drill
three holes based on the marks on the sticker, as shown in Figure 3-1. It is
recommended that the drill size be φ3 - φ4 mm, and it is better to remove the label
after the hole is finished to avoid affecting heat dissipation.
Figure 3-1 Stick the sticker
Step 2 Take out the camera and attach the camera to the corresponding step 1 on the back of
the cabinet door, as shown in Figure 3-2.

Bi-Spectrum Radiometric Detector
User Manual
Device Installation
12
Issue V1.0 (2019-10-08)
Figure 3-2 Put the device
Step 3 Take out the PWM3×6 screws in the accessory and fix them on the screw holes of the
camera through the hole punched in step 1 on the front of the door and tighten the
screws.
Figure 3-3 Install the device
Step 4 Connect the multi-connector cable, start up the device.
----End

Bi-Spectrum Radiometric Detector
User Manual
Device Installation
Issue V1.0 (2019-10-08)
13
3.1.2 Magnet Installation
If you can't break the hole in the door or the camera position needs precise adjustment,
you need to use the magnet bracket.
Step 1 Take out the camera and the magnet bracket, install the magnet bracket on the back of
the camera, and fix it with the PWM3×6 screws, as shown in Figure 3-4.
Figure 3-4 Install the magnet bracket
Step 2 Attach the camera assembly to the back of the cabinet door, as shown in Figure 3-5.
Connect the multi-head combination cable to start up the camera.
Figure 3-5 Fixed the magnet bracket
Step 3 Combine with the image of live video to move the camera to appropriate location.

Bi-Spectrum Radiometric Detector
User Manual
Device Installation
14
Issue V1.0 (2019-10-08)
----End
3.2 Walling Installation
3.2.1 Bracket Installation
If the camera angle needs to be adjusted, you need to use the gimbal bracket.
Step 1 Stick the installation sticker label 3 on the walling „s mounting surface, drill three
holes based on the marks on the sticker, drive three swell plastic buttons into the
holes.
Step 2 Take out the gimbal bracket, align the three through holes at the bottom of the bracket
with the expansion rubber, and fix the bracket with the self-tapping screws in the
accessory, as shown in Figure 3-6.
Figure 3-6 Install the gimbal bracket
Step 3 Take out the camera, align the 1/4 UNC hole on the back of the camera to the bracket
screw, and then tighten the bracket nut, as shown in Figure 3-7.

Bi-Spectrum Radiometric Detector
User Manual
Device Installation
Issue V1.0 (2019-10-08)
15
Figure 3-7 Install the magnet bracket
Locking screw
Nut
Bracket nut
Step 4 Connect the multi-head combination cable to start up the camera.
Step 5 Adjust the universal rod of the bracket to adjust the camera angle, tighten the bottom
bracket nut and tighten the locking screw on the bracket to complete the angle
adjustment.
----End
3.2.2 Magnet Installation
Step 1 Open the label 2 in the positioning label and attach it to the mounting position on the
wall. Drill the hole in the small round hole of the positioning label with the drill bit
and insert the expansion rubber into the hole.
Step 2 Take out the camera and the magnet bracket, install the magnet bracket on the back of
the camera, and fix it with the PWM3×6 screws, as shown in Figure 3-8.

Bi-Spectrum Radiometric Detector
User Manual
Device Installation
16
Issue V1.0 (2019-10-08)
Figure 3-8 Install the magnet bracket and camera
Step 3 Attach the camera assembly to the sticker position and remove the self-tapping
screws to secure the camera assembly, as shown in Figure 3-9.
Figure 3-9 Install the magnet bracket and camera
Step 4 Connect the multi-head combination cable to start up the camera.
----End

Bi-Spectrum Radiometric Detector
User Manual
Device Installation
Issue V1.0 (2019-10-08)
17
3.3 Packing list
After receiving the equipment, please follow the list of packing list to check, if there is
any omission, please contact the seller.
Table 3-1 Packing list
No.
Item
Quantity
1
Camera
1
2
Power supply and cable
1
3
User manual
1
4
Installation location sticker
1
5
Screws PWM 3*6
4
6
Focus lever
1
7
Magnet bracket
1
8
Self –tapping screw PT4*40
4
9
Swell plastic button
4
10
Network access port
protective cover and
waterproof rubber seal
1

Bi-Spectrum Radiometric Detector
User Manual
Device Installation
18
Issue V1.0 (2019-10-08)
11
Gimbal bracket
1
