SUNGOLD POWER GT1500 User manual

Applicable to GT1500 / GT1200 / GT1000 product manual
Please read the instruction manual carefully before use
Sun Gold Power Co.,Ltd www. sungoldpower.com

01
Thank you for purchasing Portable Power Station.
This manual is written to guide you in the safe and effective use of your
portablepower station.
This manual describes the correct operation, inspection and care of this
product. If this product is used incorrectly, it may cause electric shock,
injury or otherlife-threatening dangers,so please read this manual carefully
before using this product.
After reading this manual, please keep it in a safe place for easy reference
at any time.(Please note that the pictures in this manual are for illustrative-
purposes only, and the product may be different from the pictures).
Due to changes in specifications, the illustrations and contents of this
manual may differ from the actual product contents in some cases.
Sun Gold Power Co.,Ltd www. sungoldpower.com

02
For your safety and the safety of others, please follow the instructions below.
1. Before using the product, please read this manual to ensure that you fully understand how
to use the product correctly.
2. Do not use this product for medical equipment, as this may cause accidents.When this
product and charger are used, electromagnetic waves are generated. If you are using an
implantable pacemaker or similar device, please check with your doctor or medical device
manufacturer before using it.
3. Do not attempt to disassemble or modify this product, as this may cause overheating, fire
or electric shock. Do not strongly impact or drop the product.If the product is deformed or
damaged, please do not use the product.This may cause fire, burns, electric shock, or injury.
4. Do not damage the charger body, wires or plugs. Using damaged products may cause fire
or electric shock
5. Do not use the charger in places with a lot of steam, dust, oily smoke or corrosive gas. Do
not expose the product to high temperature or corrosive gas. Do not put the product in the
fire or heat it. Do not usethis product near a fire, under the scorching sun, near a stove, in a
hot car, or any other high-temperature place. Doing so may cause
the product to overheat, rupture or catch fire.
6.Do not operate the product or charger with wet hands. This may cause electric shock.Do
not let the product get wet with rain, water orsea water and other liquids.Do not use this
product where it will be exposed to liquids. Do not use the product where it will come into
contact with liquids, as this may cause overheating, fire or electric shock.
7. Do not connect the AC output to any wires of the power company or indoor wires, as this
may cause electric shock or fire. When charging the product, besure to use a dedicated
adapter. When charging the product, Don't use random charger, as this may cause
overheating or fire. Please use household power supply, DC vehicle power supply, and solar
panels to charge the product battery.Please charge within the standard power supply
voltage (Europe/China 220-240Vac/50Hz)/(US or Japanese version only supports
100-120Vac (50Hz/60Hz). Do not exceed the specified AC voltage, otherwise it will cause
product failure, the company will not take the responsibility of providing free maintenance
services.
Sun Gold Power Co.,Ltd www. sungoldpower.com

03
8. Do not plug the accessory cigarette lighter car charging cable into the car cigarette
lighter socket when it is not in use, because this may cause it to overheat or catch fire.
9. If you find any unusual smell, overheating, discoloration or deformation during
charging, please unplug the charger from the socket. This may cause the battery to leak,
overheat or catch fire. When connecting the power plug of electrical equipment to the
machine, insert the plug firmly into the root. Failure to do so may result in electricshock
or fire.If you notice any unusual smell, overheating, discoloration or deformation during
the power supply process, please unplug the device from the socket. This may cause
the battery to leak, overheat or burn.
10. Please keep it out of reach of children, otherwise it may cause electric shock or
injury.
11. Do not store in a humid, dusty or high temperature environment. Because this may
reduce the insulation performance, resulting in overheating or fire.Storage at high
temperatures may also shorten the life of the battery.
12. This product should not be disposed of together with domestic garbage. Please
dispose or recycle this product and battery in accordance with local regulations.
Sun Gold Power Co.,Ltd www. sungoldpower.com

A: Portable Power Station X1
B: Adapter X1
C: Cigarette lighter car charger cable X1
D: Type-C line X1
E: User Manual X1
F: Storage bag X1
04
Sun Gold Power Co.,Ltd www. sungoldpower.com
AB C
DEF

3
11
13
4
5
2. LED lighting
05
1 22
6
7
8
9
10
11
12
1. LED light button
3. DC output button
4. DC-cigarette lighter output port
5. DC (6530) input port
6. USB output button
7. USB output port
8.Type-C output port
9.POWER button
10. LED display
11.AC socket
12.
13.AC output button
50Hz/60Hz frequency switch
(Japanese standard only)
Sun Gold Power Co.,Ltd www. sungoldpower.com

06
Long press "POWER" to turn on, the LED display will light up, and the batterytemperature
display, OUTPUT, POWER, INPUT, WATTS, and battery icons will all light up. Press and
hold the button for more than 3 seconds to turn off the product.
When using an AC outlet for output, turn on the power of the product and press the "AC
output button". If you press this button while using AC output, the AC outputwill be
turned off.
To use the DC cigarette lighter output, please turn on the product power and shortpress
the "DC output button". If you press this button while using the on-board output, the
on-board output will be turned off.
When using USB and Type-C output, please turn on the power of the product and short
press the "USB output button". If you press this button while using USB and Type-C
output, the USB output will be turned off.
To use the LED lighting, please turn on the power of the product and short press
the "LED light button". If you press the LED light button while using the LED light,
the LED light will turn off.
* AC frequency switch can be customized*
Turn off the AC output before switching the 50Hz/60Hz frequency, switch the "frequency
switch" to the terminal matching frequency position, and then press the ACoutput
button, otherwise the wrong frequency will damage the electrical equipment.
Japanese standard only
Sun Gold Power Co.,Ltd www. sungoldpower.com

07
1
2345
8
9 10 11 12
7
6
1:Temperature icon
2: The fan icon is ON , which means the fan is ON
3: Temperature value icon
4: Battery level icon
5: Fast charge icon
6: Output power value (updated once in 3S)
7: The warning icon is ON , which means abnormal temperature alarm
8: Input power value
9: The AC-OUT icon is ON to indicate that the AC inverter function is ON.
Working output voltage
10: The USB icon is ON to indicate that the USB output is on (3 USB ports
simultaneously output power <25W)
11: The DC-OUT icon is ON, it means the cigarette lighter is turned on and
output
12: The Type-C icon lights up to indicate that Type-C is working.
Sun Gold Power Co.,Ltd www. sungoldpower.com

08
1. When the battery pack voltage is 19.8V, the AC function of the product stops using, and
the DC part of the function can continue to be used up to the battery pack voltage
18.2-18.6V. At this time, the product will enter the dormant state due to low voltage
protection; the product must be charged at this time .
2. When the temperature is about -10°C, only the USB function and the LED light can be
used normally; AC can be turned on when the ambient temperature is less than -5°C,
USB/Type-C, and cigarette lighter plug-in can be turned on normally ( The temperature error
is within ±2°C).
3. Due to the low temperature properties of lithium-ion iron phosphate batteries, it is
recommended that the product be used in an environment above -3°C.
4. During the use of Type-C, pressing the POWER button will enter the dormant
state. At this time, you need to unplug the Type-C cable before you can activate
the product through the POWER button.
*Long press the POWER button to turn ON, and the port output is turned on by the
button, and the display shows the corresponding port icon.
*When the product recognizes that there is a charging input, the green LED indicator
is on. When the product is not fully charged, the battery icon in the display is indicated
by a marquee, and the charging power prompt can be seen; the battery bar in the fully
charged screen will be fixed and there is no power prompt (when the product is almost
fully charged) .
It will enter trickle mode. It is recommended to continue charging for about 20minutes
until the screen displays the input power as "00" or "01".
*The product only allows the DC output port to work when charging, AC cannot work.
Sun Gold Power Co.,Ltd www. sungoldpower.com

A: How to use USB/DC/Type-C output
B: How to use AC outlet output
09
A: How to use USB/DC/TYPE-C output
1. Long press "POWER" to turn on.
2. Short press the "USB/DC output button". The "USB ""DC-OUT" "TYPE-C" icon lights
up, and the USB / DC-OUT / TYPE-C output starts to work.
3. Insert the USB data cable, DC (car charging cable) or TYPE-C data cable plug for DC
appliances to be used into the output port.
4. After using the DC appliance, pull out the plug and turn off the output button.
B: How to use AC outlet output
1. Long "POWER" to turn ON.
2. Adjust the output "frequency switch" to select the appropriate frequency for the
electrical appliances to be used(Japanese standard only).
3. Long press the AC output button; when "AC-OUT" appears on the LED display,the AC
output starts to work.
4. Insert the AC plug of the equipment to be used into the AC socket of the product.
5. Unplug the electrical plug after use and turn off the AC output.
Sun Gold Power Co.,Ltd www. sungoldpower.com

10
LED lighting
C. How to use LED lighting
D. How to change the AC output frequency (Japanese only)
Frequency switch
1. Long press "POWER" to turn on.
2. Short press the "LED light button" ,to mode 1: the LED light will be highlighted,
3. Short press the "LED light button",to mode 2: the LED light is on,
4. Short press the "LED light button" ,to mode 3: the LED light flashes,
5. Short press the "LED light button" ,to mode 4: the LED light enters the "SOS" mode,
6. Long press the "LED light button" in any mode for 2-3 seconds to turn off the LED light.
* AC frequency can be customized *
*AC frequency can be switched between 50Hz and 60Hz*
1. Long press "POWER" to turn on.
2. Check the frequency of the equipment to be used.
3. Adjust the AC output frequency switch to match the frequency of the equipment
to be used.
4. Long press the AC output button, when "AC-OUT" appears on the LED display,
the AC output starts to work.
Sun Gold Power Co.,Ltd www. sungoldpower.com

1.Charge with solar panels
There are 3 charging methods
AC mains input
Solar panel input
Car cigarette lighter input
11
1. Place the solar panel (CTECHI optional solar panel is recommended) under direct
sunlight.
2. When the solar panel output port is connected to the product input port, this product
supports MPPT input voltage range 15~24V/input current 6-8A (18V200W recommended).
When the battery icon on the display is indicated by.
a marquee, it means normal charging.
3. If the internal temperature of the product rises during the charging process, the cooling
fan will be activated to cool the device by blowing air.
4. When the battery display is full and always on, the built-in overcharge protection circuit
control module will be activated, and the charging will stop automatically, indicating that
the charging is complete. Please remove the solar panel from the device.
Sun Gold Power Co.,Ltd www. sungoldpower.com

2. Charge with AC adapter
12
1. Connect the AC adapter to the power socket, and then connect the charging cable to the
input of the product. When the power icon on the LED display is indicated by a marquee, it
means normal charging.
2. Please use the standard adapter to charge the product, it takes about 7 hours to fully
charge.
3. If the internal temperature of the product rises during the charging process, the cooling fan
will be activated to cool the device by blowing air.
4. When the battery display is full and always on, it means charging is complete, the built-in
overcharge protection circuit control module will be activated, and charging will stop
automatically. Please disconnect the AC adapter from the device and the power socket in
time.
Sun Gold Power Co.,Ltd www. sungoldpower.com

13
3. Charge with car charger
1. Insert the provided cigarette lighter car charging cable into the car cigarette lighter seat and
start the car.
2. Connect the DC head of the cigarette lighter car charging cable to the DC input port. This
product supports car charging voltage range 12~14V/input current 10A. When the LED
display shows the running water light cycle, it means normal charging.
3. During the charging process, when the internal temperature of the battery rises, the cooling
fan is activated to cool the battery by blowing air.
4. When the battery display is full and always on, it means the charging is completed, the
built-in overcharge protection circuit control module will be activated, and the charging will
stop automatically. Please disconnect the car charging cable from thedevice and the car in
time.
Sun Gold Power Co.,Ltd www. sungoldpower.com

14
Battery indicator State of charge
S10:91-100%
S9:81-90%
S8:71-80%
S7:61-70%
S6:51-60%
S5:41-50%
S4:31-40%
S3:21-30%
S2:10-20%
S1:1-10%
1. When the battery level is 0%, the battery frame flashes for 3 seconds, and it willautomatical-
ly shut down. When the charger is plugged in to charge, the first bar will flash up.
2. When the power is between 1%-10%, one grid is always on, and it flashes upwardsfrom the
corresponding number of grids when charging (0.5S interval flashing).
Sun Gold Power Co.,Ltd www. sungoldpower.com

15
3.When the power is between 11%-20%, the two bars are always on, and it flashes
upwards from the corresponding number of bars when charging (0.5S interval flashing)
4.When the power is 21%-30%, the three bars are always on, and the corresponding
number of bars flashes upwards when charging (0.5S interval flashing)
5. When the power is between 31%-40%, the four bars are always on, flashing upwards
from the corresponding number of bars when charging (0.5S interval flashing)
6. When the battery level is between 41%-50%, the five bars are always on, and it flashes
up from the corresponding number of bars when charging (0.5S interval flashing)
7. When the power is between 51%-60%, the six bars are always on, and it flashes
upwards from the corresponding number of bars when charging (0.5S flashes at intervals)
8. When the battery level is between 61% and 70%, the seven bars are always on, and it
flashes upwards from the corresponding number of bars when charging
(0.5S flashes at intervals)
9. When the battery level is 71%-80%, the eight bars are always on, and it flashes
upwards from the corresponding number of bars when charging (0.5S interval flashing)
10. When the power is 81%-90%, the nine bars are always on, and it flashes upwards from
the corresponding number of bars when charging (0.5S interval flashing)
11.When the power is 91%-100%, ten bars are always on, flashing upwards from the
corresponding number of bars when charging (0.5S interval flashing).
*When the power of the product is fully charged, the charging current will decrease as the
"charging power on the screen will also change", that is, when the product is almost full,
the product will enter a trickle charging mode until the product is fully charged.In order to
store the product for a long time, it is recommended to charge the product to 60%-80%
every 3 months.
Sun Gold Power Co.,Ltd www. sungoldpower.com

GT1500
Product model
Capacity 1210Wh
Voltage adjustment method
Input
sine wave
27V/8.5A, up to 180W
Cigarette lighter
socket output
USB-A*3
Type-C output*1
LED light
Battery
Use times
Recharging temperature
Operating temperature
Storage temperature
Safety protection
12V=10A 120W
AC output
US standard*4 100V-120V 60Hz Rated power: 1200W Peak value: 1700W
Size
Weight
5V-2.4A (12W)
5V/9/12/15/20V (maximum 60W)
2W
Lithium iron phosphate battery
more than 2000 times
0° C~40° C
-10° C~40°C
-10° C~40° C
temperature control, surge protection,
short circuit protection, etc.
400*210*290mm
16 kg
16
（Customizable）
Sun Gold Power Co.,Ltd www. sungoldpower.com

One: The product cannot be powered
Two: What are the common display fault prompts?
17
Please make sure that the POWER button and output button are turned on. (If the ambient
temperature is not within the range of -10°C to 40°C, the power supply may not be available).
When connecting the power plug of electrical equipment to the machine, be sure to insert the
plug to the root. If there is any water or foreign matter on the charger connector or charging
input terminal, remove it.
Please check the remaining power on the display. If the remaining power is less than 10%, you
need to recharge the portable emergency power supply.
Please check whether your device voltage and power consumption are higher than the output
power limit of this product.If the upper limit is exceeded, short circuit protection, overcharge
protection,over current protection, discharge protection, temperature protection, overload
protection, etc. will be activated, and the portable emergency power supply will automatically
shut down. Please check whether the protection circuit is normal.
1. When the USB is over-current or short-circuit protected, the port closes the output, and the
USB icon flashes to warn.
2. When Type-C over-current or short-circuit protection, the port closes the output, and the
Type-C icon flashes to warn.
3. When the cigarette lighter output over-current or short-circuit protection, the port closes the
output, and the DC-OUT icon flashes to warn.
4. When AC continues to output to the low voltage of the product, the AC icon on the screen
will report an error and flash, and the AC will turn off the output.
Sun Gold Power Co.,Ltd www. sungoldpower.com

Three: When I charge the portable power supply, the adapter
becomes very hot, is this normal?
18
5. (1. When the AC output triggers the module over-temperature protection, the AC closes the
output and automatically restores the output after the over-temperature state is released;
(2. When the AC is overloaded, the inverter board AC shuts down the output; the "AC" on the
screen will flash and alarm. After the overload state is removed, press the AC output button
and the screen will clear the error message, and then restart the AC function button to restore
the output.
(3. When the AC is over-voltage, the AC closes the output, after removing the overvoltage
state,
restart the AC function key to restore the output
(4. When the AC output is short-circuited, the AC closes the output. After the shortcircuit state
is removed, restart the AC function key to restore the output
6. When the battery is 65°C over temperature protection, all outputs will be turned off. The
temperature value shows the highest battery temperature value. The temperature icon and
temperature value flash at the same time (1 flash for 1 second), and the fan works until the
battery over temperature protection is released.
7. The display is completely black, disconnect all electrical equipment on the product. After
charging the power for 2-3 minutes, turn on the POWER button and the display will be reset.
Our portable power supply is equipped with an AC adapter . According to safety standards, the
maximum temperature of the adapter is 75°C. For your safety, the configured adapter has
passed UL, CE, GS, PSE, TUV, ETL, CCC and other certifications.
Sun Gold Power Co.,Ltd www. sungoldpower.com

19
This guarantee guarantees that the product will be replaced free of charge under the
conditions stipulated in the guarantee policy.
Please read the guarantee carefully and keep it in a safe place.
1. Only when the product is used in accordance with the instructions in the operating
instructions and fails within the warranty period, it will be replaced. Products replaced during
the warranty period become the property of the company.
2. To get a warranty replacement, please send this warranty card together with the product.
The shipping cost of returning the product for replacement is the customer' s responsibility.
3. Under the following conditions, it will not be replaced during the warranty period
1) Failure or damage caused by failure to follow the precautionary measures described in the
instruction manual.
2) Failure or damage caused by improper storage and storage (complete discharge).
3) Failure or damage caused by the use of a non-designated power adapter.
4) Failure or damage caused by improper repair, disassembly or modification.
5) Failure or damage caused by falling, vibration, water leakage, condensation, etc. after
purchase.
6) Failure or damage caused by fire, earthquake, flood or other natural disasters.
7) Any appearance change or discoloration caused by use.
8) Failure or damage caused by use at temperatures other than the applicable operating
temperature.
4. There is no guarantee for secondary damage caused by the malfunction of
this product.
5. We are not responsible for any failure or malfunction of other equipment caused
by the use of this product.
6. This manual is only valid for use in (this sales area), and the company has the final
interpretation right.
7. This manual will not be reissued, so please keep it in a safe place.
Sun Gold Power Co.,Ltd www. sungoldpower.com
No copy
