Introduction
Introduction
Super-Speed USB3.0 interface is the next revolution in I/O interconnect standards that will deliver the
bandwidth and features required by PCs, consumer electronics and communications devices. With 10 times
faster throughput than USB 2.0 standard and backward compatible with current USB device features, USB3.0
interface will be the trendy of IT technology.
SUNIX USB2300D is a dual-port Super-Speed USB3.0 PCI Express card, and it is compliant with the PCI
Express Generation 2 specification for host PC system. It works up to 5 Gbps for data transfer when connecting
to USB 3.0 compliant peripherals, while maintaining compatibility with existing USB peripheral devices. With
USB Hot-Swapping and Plug-n-Play function, you don't have to worry about running out of slots on your
motherboard or complicated hardware installation process.
SUNIX USB2300D card supports USB3.0 High-Speed device and backward compatible with USB2.0 High-
Speed and USB1.1 Full-Speed device. It is an ideal choice for external storage devices, MP3 players, external
writer, digital cameras, webcam, networking and video devices, and all other USB devices.
Features
Features
• Supports PCI Express Base Specification Revision 2.0.
• Single-lane ( x1) PCI Express throughput rates up to 5 Gbps.
• Compliant with Universal Serial Bus 3.0 specification Revision 1.0.
• Compliant with xHCI (eXtensible Host Controller Interface) specifications Revision 0.96.
• Supports simultaneous operation of multiple USB 3.0, USB 2.0 and USB 1.1 devices
• Supports USB data transfer rate of 1.5/12/480/5000 Mbps.
• Expands two external USB3.0 Super-Speed ports on the system.
• Each USB port supplies maximum +5V / 900mA power output to USB device.
• Built-in 4-pin power connector for receiving sufficient power supply from system.
• Hot-swapping feature allows you to connect/disconnect devices without powering down the system.
• Driver supports for Microsoft Windows XP, Vista, and 7 operation system.
• Certified by CE, FCC, RoHS, and Microsoft WQHL approval.
USB2300D
USB2300D
USB3.0 Dual ports PCI Express
Host Controller
Ver1.0 Feb. 2010 Copyright 2007 by SUNIX Group all right reserved

SUNIX Taiwan Headquarters
http://www.sunix.com.tw
[email protected]
SUNIX Vertriebs GmbH
http://www.sunix-europe.com
[email protected]
SUNIX do Brasil Ltda.
http://www.sunix-brasil.com.br
[email protected]
SUNIX USA Corp.
http://www.sunix-usa.com
[email protected]
Specification
Specification
Interface: Single-Lane (x1) PCI Express Gen2
Mode: USB3.0
Controller: NEC µPD720200
Port: 2 external USB3.0 ports
Speed: Data Transfer rate of 1.5/12/480/5000 Mbps.
Low Speed (1.5Mbps), Full Speed(12Mbps), High Speed(480Mbps), Super Speed(5Gpbs)
Power Input: 4-pin CD-ROM Type Power Connector
Power Output: +5V / 900mA (each port)
PCB Dimension: 80 (W) x 68.5(L)mm
Bracket: Standard 121mm / Low Profile 79.2mm
O.S. support: Windows XP/2003/Vista/7/2008, (32/64-bit)
Environment : Operation temp. 0 °C ～57 °C
Operation humidity: 5 ～95% RH
Storage temp.-20 °C ～85 °C
Package
Package
• USB2300D
• CD Drive
• User's Manual
Backward Compatible Application
Backward Compatible Application
USB2.0 Device
USB2.0 Cable
USB2.0 Cable
X
USB2.0 Device
USB3.0 Cable
USB3.0 Cable
USB3.0 Device
USB2.0 Cable
USB2.0 Cable
USB3.0 Device
USB3.0 Cable
USB3.0 Cable
USB2.0 Host USB2.0 Host
USB3.0 Host USB3.0 Host
Ver1.0 Feb. 2010 Copyright 2007 by SUNIX Group all right reserved

SUNIX Taiwan Headquarters
http://www.sunix.com.tw
[email protected]
SUNIX Vertriebs GmbH
http://www.sunix-europe.com
[email protected]
SUNIX do Brasil Ltda.
http://www.sunix-brasil.com.br
[email protected]
SUNIX USA Corp.
http://www.sunix-usa.com
[email protected]
Cable
Length
Power
Supply
TransmissionSpeedLogo
5M5V /
900mA
Dual-simplex, four
wire differential
signaling separate
from USB2.0
signaling
Simultaneous bi-
directional data flows
Low-speed(1.5Mbps)
Full-speed(12Mbps)
High-speed(480Mbps)
Super-speed(5.0Gbps)
USB3.0
USB3.0
5M5V /
500mA
Low-speed(1.5Mbps)
Full-speed(12Mbps)
High-speed(480Mbps)
USB2.0
USB2.0
5M5V /
500mA
Half-duplex two-wire
differential signaling
Unidirectional data
flow with negotiated
directional bus
transitions
Low-speed(1.5Mbps)
Full-speed(12Mbps)
USB1.1
USB1.1
USB Comparison
USB Comparison
PCI-E Ver1.0 / 1.1 USB Device
>150MB/sec
>150MB/sec
2.5Gbps
2.5Gbps
2.5Gbps USB3.0
5.0Gbps
USB3.0
5.0Gbps
SUNIX
USB2300D
PCI-E Ver2.0 USB Device
>300MB/sec
>300MB/sec
5.0Gbps
5.0Gbps
5.0Gbps USB3.0
5.0Gbps
USB3.0
5.0Gbps
SUNIX
USB2300D
The Performance of USB3.0
The Performance of USB3.0
