mPulse®Power Box Installation Guide
We’re very excited you received your replacement power box and are eager to get your unit
back up to optimal operation! This power box is designed with customer installation in mind
and this guide will help you through that process while avoiding any potential pitfalls.
Labeling
The wiring connections of your power box are labeled with stickers of particular shapes and
colors to help you classify them.
Each wall is assigned a different shape. Walls are labeled with the viewpoint of facing the
back wall inside the sauna. Colors correspond with different levels of power distributed to
parts of the unit - power feeds, blue sensor or NTC feeds, and green near infrared feeds.
INSTALLATION
Step 1
Unplug the unit from the power source or ip the breaker for the dedicated circuit to the sauna. You
may nd the power box area more easily accessible if you also remove the bench. What follows can
be done without bench removal, but is more efcient and comfortable with the added space.
Near Infrared (NIR) Heat Sensor (NTC) Left Wall Back Wall Front Wall Right Wall

To remove the bench, unmount the heater frames from the surrounding walls. Reach
underneath, with your palms upward, and the bench will lift straight up from the
supports mounted to the walls (for Discover and Empower cabins, you only need to
remove the back-wall bench sections). You can then rotate the detached bench vertically
and walk it backwards out of the sauna.
Step 2
The very last portions of the oor, under the bench and back against the wall, cover the power
box. Unscrew the power box covers. The Phillips head screws will be located in the grooves
between the oor boards. You will see the sections of the power box covers with a bisecting
cut perpendicular to the wood slats. Remove all screws for all sections of the power box covers.
Step 3
Once exposed, remove the Phillips screws anchoring the power box to the ground - two on the
long front edge and one on the right edge close to the back wall (as you are facing the back wall).
mPulse Power Box Installation Guide mPulse Power Box Installation Guide
Step 4
Disconnect the power cord on the left edge of the power box.
NOTE: The power cord is also anchored by a Phillips screw to the wood inside the base,
immediately to the left of the power box.
Step 5
We are now ready to begin disconnecting the power box from the wiring from the walls.
Start with the left wall connections. These will both be labeled with a triangle. Disconnect
the power feed, G1, from the wall feed, A1. Each connector has a lever on one side that you
press to pull them apart.
Step 6
Disconnect the L sensor connector, then disconnect the NIR connector. Finally, disconnect the
main power cord on the left side from the power box. You may need to remove the Phillips screw
anchoring the cord to the oor.

mPulse Power Box Installation Guide mPulse Power Box Installation Guide
Step 7
Move along the front edge to the right front port of wires. Disconnect the 4-pin at G17 connector
(red, white, black, and blue wires) from the corresponding connection, F18. This wire’s connector
splits into two connections going out the other side, one labeled F5 and the other unused.
Disconnect the G4 power connector from the F7 power cables. Disconnect the G28 sensor line
from the corresponding F8 connector. You’ll nd a connector that is covered with black tape (red/
white wires) and zip-tied with a screw anchoring it to the base. Unscrew the anchored zip tie.
Step 8
Turn the corner to the rst port of wires on the right edge of the power box and note that these
wires pass through the wood support to the section to the immediate right of the power box in the
oor. There will be a zip tie holding a bundle of wires between the two black boxes. Cut this zip tie
and another in this section to the right, to allow for a better view of the connectors.
In this section, disconnect the G30 power connector from the corresponding F10 connector.
Disconnect the sensor connector (labeled R) from the corresponding connector F11.
Depending upon which mPulse sauna you have, you’ll nd this wire in one of the following
congurations: in Aspire, the F19 will split from the back wall to the left and right walls. In
Believe and Conquer, it will split from the right wall to the left wall. Discover and Empower
models may skip this step.
Now, disconnect the G32 NIR connector (semi-transparent connection) from the F19 harness.
Step 9
In this same section, disconnect the 3-pin G41 connector from the F16 harness.
Disconnect both the G42 and G43 2-pin connectors from the paired transformer
connectors (black box) located closer to the back wall.

If you have any questions, you can contact us in the following ways:
Phone: [phone]
Live Chat on our website or view FAQs: www.sunlighten.com/customer-service
DM on social: facebook.com/SunlightenSaunas or instagram.com/sunlightensaunas/
mPulse Power Box Installation Guide mPulse Power Box Installation Guide
Step 10
Move back to the right edge of the power box and disconnect the back wall wires: the G2
power cable from the B1 connector, the sensor cable from the B5 sensor connector,
and the G31 NIR connector from the B6 connector.
Congratulations! All connections will now be separated for removal of the power box. To
install your replacement power box, you can reverse the same steps making the connections
described above.
Please see the diagram on the next page for which connections to pair as a reference.
