Sunmyung IRIS-L series User manual

(Model: 4/ 8/ 16CH H.264 DVR)
Rev. 1.6
Digital Video Recorder
* All contents of this document may change without prior notice, and actual product appearance may differ
from that depicted herein.
Installation and User’s Guide
H.264 IRIS-L DVR User’s Manual

v
2
Safety Precaution
This label may appear on the rear of the unit due to space limitations.
Warning
To reduce the risk of fire or electric shock, Do not expose this product to rain or moisture.
Do not insert any metallic object through ventilation grills.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION
The lightning flash with arrow point symbol, within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
Power disconnect: Units with or without ON-OFF switches have power supplied to
the unit whenever the power cord is inserted into the main source. To disconnect it
from the main source, you have to disconnect the Power cord.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of importance operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

v
3
FCC COMPLIANCE STATEMENT
A CLASS Acomputing device subject to certification by the Commission shall be identified
pursuant to Par 2.925 et Seq of the chapter. In addition, the label shall include the following
statement:
Where a device is constructed in two or more sections connected by wires and marked
together, the statement specified in this Section is required to be affixed only to the main
control unit.
The user’s manual or instruction manual for the EUT shall contain the following statement or
equivalent.
Caution: Changes or Modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
If the EUT requires accessories such as special shield cables and/or connectors to enable
compliance with emission limits, the instruction manual for the EUT shall include appropriate
instruction on the first page of the text concerned with the installation of the device that
these special accessories must be used with the device. It is the responsibility of the user to
use the needed special accessories supplied with the equipment.
For a CLASS A digital device or peripheral, the instruction furnished the user shall include
the following or Similar statement placed in a prominent location in the text of the manual.
Note: This equipment has been tested and found to comply with the limits for a CLASS a
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment, This equipment Generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of the this equipment in a
residential area is likely to cause harmful interference in which cause the user will be
required to correct the interference at his own expense.
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received,
including interference that may cause undesired operation.

v
4
Preface
This document is a basic manual for the H.264 DVRusers. The manual describes the
appearance and name of products, how to configure the system program, and how to use the
system. Please review the whole contents before using H.264 DVR, and access the product
with caution.
The pictures and names of the products are subject to change depending on hardware
upgrade. However, the usages may be similar.
To open the system case and touch the inner parts for corrective maintenance, a user should
contact the place where he/she purchased the products to get the help from expert.
In addition, if there are any questions for use or any damage on the product, please contact
the place where he/she purchased the products.
The pictures and names of the products are subject to change without notification. However,
the usages may be similar.

v
5
Warning on Installation and Usage
1. Warning on Installation
•Install the product on a flat floor, open space, and keep the minimum of 6 inches distance from the rear
panel to the wall.
•Install the product on a well-ventilated place.
•Keep it away from strong magnetism or electromagnetic wave.
•Installing it near to radio equipment such as TV or radio may cause a malfunction.
•Do not install it on a place directly exposed to the sun or other heating sources, such as near a heating
apparatus.
•Do not install it on a cold place.
•While installing the equipment, keep the equipment and related tools in safe position to prevent any injury.
•Do not install it on a place with constant vibration, high humidity, grease, or dust.
•Should use the product in the rated voltage (The equipment requires DC 12V and the power supply
included can be used for the voltage between 110V and 240V.)
•Connect it to the outlet with the ground terminal.
•Discard the vinyl bag well as it may be dangerous under a child’s hands.
2. Warning on Usage
•For the repair, contact the company or the place where you purchased the product.
•Read the user manual before using the products.
•Do not open the cover at your discretion since parts are sensitive to the environment within the equipment.
•Arrange the power cord safely and do not touch it with wet hands.
•Do not use a loose outlet or a damaged power cable.
•Do not use benzene, thinner and alcohol for cleaning.
•Do not touch the exposed terminal.
•To properly turn off the system, use the power button on the front panel before disconnecting the power
supply.
•Be careful to prevent a conductive object from falling into a hole that was punched for ventilation.
•Do not disassemble nor remodel the product.
•Do not place a heavy object on the body.
•Handle with care while moving the equipment.
In case of any smoke or odor emitted, immediately block the power switch and contact the company you
purchased the products to consult it with a special technician.

v
6
Contents
1. Product Contents  7
2. Features  8
3. Product Description  9
3-1. Front Panel Connection  9
3-2. Rear Panel Connection  9
3-3. Front Panel Description  10
3-4. Rear Panel Description  12
3-5. Remote Controller  14
4. Main Menu Programming  15
4-1. Overview Main Menu  15
4-2. DVR Menu Tree  16
4-3. System Setup  17
4-4. Display Setup  19
4-5. Recording Setup  20
4-6. Event Setup  21
4-7. Schedule Setup  23
4-8. Network Setup  24
4-9. Copy Setup  25
4-10. Hard Disk Setup  26
4-11. Camera Setup  27
5. Live Display & Recording  28
5-1. Live Picture Display Mode  28
5-2. OSD (On Screen Display) on Live Mode  29
5-3. PTZ Control  30
5-4. Recording Options  30
6. Search and Backup  31
6-1. Search List  31
6-2. Search by Recording Type  32
6-3. Search by Time & Date  32
6-4. Playback  33
6-5. Backup  34
7. USB Mouse Operation  35
7-1. Mouse Operation on Live Display  35
7-2. Mouse Operation on Search  36
8. Firmware Update  37
Appendix 1. H.264 DVRSpecification  38
Appendix 2. Description of Terminals  39

v
7
1. Product Contents
At the point of purchase, please verify that following contents are included:
•H.264 DVR IRIS L - 4//8/16CH Stand Alone DVR
•Power Supply (12V/5.8A)
•Power cord
•User’s manual (inside “CMS Install CD”)
•Quick Guide
•CMS Install CD
•Remote controller (two ‘AAA’ batteries included)
H.264 IRIS – L DVR Series
Power Supply Power Cord User’s manual
(Inside CMS install CD)
CMS Install CD Remote controller
Quick Guide
(Inside CMS install CD)

v
8
2. Features
H.264 DVR is an embedded Stand-Alone DVR, based on Linux. It is capable to record 4/8/16
channels of video and audio. It is also capable to playback, live display, back-up and network function
while it is continuously recording. And it also offers the following features:
•4/8/16 composite video inputs / 4/8/16 loop-through video outputs:
- Compatible with color (NTSC or PAL) and B&W (CCIR and EIA-170) Video.
•1 composite video outputs / 1 VGA output
•1 S-Video output (exclude 4ch models).
•4/8/16 channels of audio inputs / 1 channel of audio outputs.
•1 HDMI (High Definition Multimedia Interface) Output
•High quality video display and recording:
- NTSC (720x480), PAL (720x576) real time display.
•Compression: H.264 for video, G.723 for audio.
•Multiple search methods (date/time or recording types).
•Real time recording and playback support:
- 480 FPS recording and playback for NTSC at CIF image (400 FPS for PAL).
- Pre-recording by event (Motion or Alarm)
•Continuous recording in disk overwrite mode.
•Pentaplex: simultaneously monitor, record, playback, back-up and network.
•Easy back-up to external devices:
- CD/DVD back up and USB 2.0 memory drive support.
•User-friendly GUI menu, operating with USB mouse.
•PTZ camera control support from the unit and remote access.
•4/8/16 alarm inputs / 4 relay outputs available.
•Various network functions:
- Access through static IP, dynamic IP (DHCP, floating IP), or DDNS.
- View live or retrieve recorded video via remote connection.
- Change configuration from a remote location.
- Support multi-user access (up to 5 users can be connected simultaneously).
- Support CMS (Center Monitoring Software) to access multiple sites at once.
- Two way audio transmission and remote event (alarm, motion) notification.
•Audio recording and playback:
- Record 4/8/16 channels of audio inputs
- Playback 1 selected channel on 1 audio output available.

v
9
3. Product Description
3-1. Front Panel Connection
3-2. Rear Panel Connection
USB Memory DriverRemote Controller
4/8/16
Audio Inputs
LAN
(Ethernet)
Cameras (1~16 Ch)
PTZ
• • • • •
4/8/16 Loop-Through outputs
Power
Supply
(12V, 5.8 A)
1 Composite &
1 S-Video Output
1 VGA
Output
RS232
1 Audio
Outputs
4/8/16
Sensor 4
A
larm
Outputs
HDMI

v
10
3-3. Front Panel Description
1. CD Tray: This place can hold various types of backup media. A DVD rewritable drive is installed at default.
2. Jog and Shuttle: Jog and shuttle enables user to operate DVR easier in handling such as fast forward, fast
reverse playback and one frame movement in still picture.
3. LED Indicators
4. Channel Selection Buttons These buttons, from Ch. 1 to Ch. 16, allow user to select a specific channel to be
displayed on the monitor.
5. Function Buttons
1) FUNC This button enables additional features for other buttons when combined.
•FUNC + ENTER: Display system information (video format, HDD info, IPAddress, version, etc.).
•FUNC + MENU : Opens interface to select a channel for audio output.
•FUNC +ESC :Turns on/off motion detection display, for channels with motion recording.
•FUNC + STOP: VGA resolution change from VGA to XGA
Power: LED turns on red when power is on.
Network: LED turns on green when a connection established remotely.
Copy: LED turns on green while copying data to CD, DVD or USB device.
Record: LED turns on red while recording images.
Key Lock: LED turns on yellow if Lock function is enabled.
Remote Controller Receiver: sensor input window for remote controller.
134 5 6
7
8
2
