Sunny SN Series User manual

User Manual
Self-Contained Emergency Light SN And SEM Series
1. The unit uses high quality LEDs providing bright and constant illimitation throughout
its operation with a lifetime of over 50,000 hours.
2. The unit has a Battery Low Voltage Cut-Offto prevent the battery from draining
completely, which helps to extend the life of the battery.
3. The unit automatically charges the battery while keeping the power supply’s Voltage
constant and limiting the current.
4. The buttons on the unit are self-resetting to prevent them from being accidentally left off.
Indicating input status
Indicating charging status
For testing the device
(during normal circumstance)
For turning on the device
(not plugged in)
For turning off the device
(not plugged in)
Status Indicators and Testing Buttons
Installation and Operation

1. The unit can be installed on leveled ground or hung up.
2. Install properly and securely to prevent accidents that could cause damage to the unit or
other people and property.
3. Press and hold the ON Switch. Both emergency lamps will illuminate and the LED ON light
on the unit will turn on indicating that the unit is operational.
4. Plug the unit into a power socket with a 220Vac power supply. The LED AC will turn on
indicating that the unit is receiving power. The LED Charge will be on when the battery is
charging and will turn off when the battery is fully charged.
5. When the unit is operational, tests can be performed.
5.1 Pressing the TEST switch on the unit should turn on the emergency light. Release the
TEST switch and the light should turn back off.
5.2 Unplug the unit from the AC220V 50Hz socket and the emergency light should turn on
automatically. Plugging the unit back in should cause the emergency light to turn back off.
6. During power outages the emergency light should automatically turn on and will turn off
automatically and start charging the battery once power is restored.
Installation and Operation
Important Note on Using the Unit
1. The unit should be installed indoors away from direct sunlight and rain or moisture.
2. The unit should be stored in temperatures under 25 Degree Celsius and the battery
should be charged every 3 months to maintain its operational life.

SIDE VIEWBACK VIEWFRONT VIEW
H 220
W 70
138
L 210
H 220
L
H 220
210
Initial Trouble Shooting
- Power not getting to the unit
after plugging in.
The LED AC light does not
turn on.
- The power socket might not have
any power.
- The plug or socket is loose.
- The AC.220V fuse is blown.
- Check the 220VAC power supply.
- Check the plug and socket.
- Contact customer service.
- Emergency light does not
turn on afterthe power went
out.
- Emergency light onlyturns
on for a short time after the
power went out.
- The battery is not fully charged.
- The battery has degraded.
- Fully charge the battery.
- Contact customer service to
replace the battery
ProblemCause What to do
-The unit is not plugged in.
-Battery terminal not connected
-The lamp is faulty.
-The circuit’s wiring is loose.
-The DC fuse is blown.
-Check that the unit is plugged in.
- Please connect the battery
terminals.
-Contact customer service.
-Contact customer service.
-Contact customer service.
Dimension (mm)

For any further questions about your product
please feel free to contact SUNNY’s customer
service department.
Tel. [phone]
E-mail: [e-mail]
1. The product will only be under warranty if the customer lls in the “warranty card”
and return the “return part” to the company within 7 days of purchasing the product.
If this is not done within the specied time then the warranty will be considered void.
2. The warranty only covers the unit’s internal parts for the duration specied by the
company counting from the date of purchase.
3. Please show the warranty card everytime when contacting our service department or the
dealer you purchased the unit from.
4. The warranty will be considered void in the following cases.
4.1 The unit has been used outside of its intended use specied in the manual.
4.2 The unit has been used with equipment that does not meet the specications specied
within the manual.
4.3 The unit has been damaged from impact, for example parts are dented, scratched
missing or distorted.
4.4 The unit has been modied or repaired by people not ofcially certied by our company.
4.5 The StickerWarranty Void has been removed or torn.
4.6 The unit is damaged from negligence or incompetent use, for example, the battery is
swollen, the batter has been overcharged, the battery has been damaged from quick
charging,the battery has been short-circuited, the battery’s charged has been
completely drained.
4.7 The unit has been stored improperly, for example, it was exposed to moisture causing
rust and damage to the internal circuitry.
4.8 Damaged was caused by a malfunction in the AC power supply.
4.9 Damage from natural disaster such as re, moisture, submersion in liquids,
chemical damage or from unavoidable circumstances.
4.10 Damage from animals or insects.
Note : Please read the manual carefully before installation and operation to understand
how to properly operate the unit.
Terms for Warranty and Service
IsOn Import-Export Co., Ltd.
2915-2917 Ladprao Road, Klongjan,
Bangkapi, Bangkok 10240
