Sunny EP-HS2 User manual

USER MANUAL
Emergency Power Packs
Wiring Diagram for EP-HS1, EP-HS2, EP-HS3
Wiring Diagram for EP-LS1, EP-LS2, EP-LS3
L
N
L
L
N
N
Model: EP-HS1, EP-HS2, EP-HS3
Model: EP-LS1, EP-LS2, EP-LS3
Connect the unit’s INPUT electrical cable to the mains power supply of the building. Press the ON switch on
the unit. The green LED should blink once to indicate that the unit is operational. Securely install the unit to
prevent any accidents that could result in injury or damage. The unit will start operating the first time it receives
a 230VAC/50 power supply (AC Start). The orange AC LED should turn on to indicate that the unit is receiving
an AC power supply. The green ON LED will be on to indicate that the unit is operational. When there is a power
outage the unit should start operating automatically. Once power has returned, the unit will continue to provide
power from its battery for another 3-5 seconds before turning o. The EP-HS1, EP-HS2, EP-HS3 model also
comes with a built-in Transfer Relay that can be connected to a 230VAC control switch at a desired location.
Installation and Operation
Warring : For best operation do not connect the unit to a 230V bulb using ballast resistor.

On
AC
Charge
The battery test is performed to help extend the operational lifetime of the battery, it will also
test that the unit is in good condition and ready for operation. If the test finds that the battery
can supply the unit with power for less than a designated amount of time, the red Charge LED
will blinks red 3 times every 2 seconds to indicate a Battery Testing Fault.
Automatic Battery Test
- A continuous green light
- The green light turns o
- The unit is turned on and operational
- The unit is not turned on
Indication
Lights Display Meaning
- A continuous orange light
- The orange light turns o
-Blinking orange light
- The unit is receiving a normal AC power supply
- The unit is receiving an AC power supply of
less than 150VAC
- When the automatic battery testing function is activated
- A continuous red light
- A continuous green light
- A red light blinks once
every 2 seconds
- A red light blinks three
times every 2 seconds
- A red light blinks four times
every 2 seconds
- The battery is charging
- The battery is fully charged.
- The Low Voltage Indicator is warning that the
battery’s charge is about to fall below the Voltage
Cut-O point.
- The Battery Testing Fault is indicating that the battery
can only hold less than 30 minutes of charge
- The Battery Charging Fault is indicating that the
battery is still not fully charged even after 10-15 hours
of charging
Indicators

Dimension (mm)
Initial Trouble Shooting
Problem Cause
- Power not getting to the unit
after plugging in. The LED AC
light does not turn on.
- Emergency light does not turn
on after the power went out.
- Emergency light only turns on
for a short time after the power
went out.
- The power socket might not have any
power.
- The plug or socket is loose.
- The AC.230V fuse is blown.
- Check the 230VAC power supply.
- Check the plug and socket.
- Contact customer service.
- The battery is not fully charged.
- The battery is past its operational
lifetime or has deteriorated
- Plug the unit in to charge the
battery for about 10 – 15 hours.
- Contact customer service to
replace the battery
- The ON switch was not pressed
- The lamp is faulty
- The circuit's wiring is loose.
- The DC fuse is blown
- Press the ON switch
- Contact customer service.
- Check the unit’s circuit connections
- Contact customer service.
1. The unit should be installed indoors away from direct sunlight and rain or moisture.
2. Always press the "ON" switch every time after installation to turn on the unit.
3. When the unit is not in use always turn it o by pressing the "OFF" switch.
4. The unit should be stored in temperatures under 25 Degree Celsius and the battery should
be charged every 3 months to maintain its operational life.
5. Please always read the manual carefully prior to operating the unit for the saftest and most
eective use of the product.
Important Note on Using the Unit
SIDE VIEW
FRONT VIEW
56
170
220
56
70
SIDE VIEW
FRONT VIEW
73
170
220
73
70
Model: EP-HS1, EP-LS1 Model: EP-LS2, EP-LS3, EP-HS2, EP-HS3

For any further questions about your product
please feel free to contact SUNNY’s customer
service department.
Tel. [phone]
E-mail: [email protected]
1. The product will only be under warranty if the customer fills in the “warranty card” and return
the “return part” to the company within 7 days of purchasing the product. If this is not done
within the specified time then the warranty will be considered void.
2. The warranty only covers the unit’s internal parts for the duration specified by the company
counting from the date of purchase.
3. Please show the warranty card every time when contacting our service department or the
dealer you purchased the unit from.
4. The warranty will be considered void in the following cases.
The unit has been used outside of its intended use specified in the manual.
The unit has been used with equipment that does not meet the specifications specified
within the manual.
The unit has been damaged from impact, for example parts are dented, scratched missing
or distorted.
The unit has been modified or repaired by people not ocially certified by our company.
The Sticker Warranty Void has been removed or torn.
The unit is damaged from negligence or incompetent use, for example, the
battery is swollen, the batter has been overcharged, the battery has been damaged from
quick charging, the battery has been short-circuited, the battery’s charged has been
completely drained.
The unit has been stored improperly, for example, it was exposed to moisture causing rust
and damage to the internal circuitry.
Damaged was caused by a malfunction in the AC power supply.
Damage from natural disaster such as fire, moisture, submersion in liquids, chemical
damage or from unavoidable circumstances.
Damage from animals or insects.
Note : Please read the manual carefully before installation and operation to understand how to
properly operate the unit.
IsOn Import-Export Co., Ltd.
2915-2917 Ladprao Road, Klongjan,
Bangkapi, Bangkok 10240
Terms for Warranty and Service
