SUNPRO DD2700H User manual

1. The delay time between buttons is within 6
seconds. If there is no input within 6 seconds,
the remote will exit the current setting
procedure
2. The motor will jog and beep as a hint. Continue
programming after the hint.
UPPER LIMIT
Move the screen up to the desired upper
limit
LOWER LIMIT
Move the screen down to the desired
lower limit
Adjust Upper Limit
Adjusting Lower Limit
Motorized Screen
Remote Instructions
DD2700H Remote –Single Channel
DD2702H Remote - 15 Channel
1 Pairing
IMPORTANT READ ME FIRST
Apply power to motor (1 jog and
long beep once), within 7s,
press STOP for 2s (2 jogs and 3
beeps), the motor has been
paired successfully
2 Switching Rotating Direction (Optional)
If the UP button is pressed, but the
screen goes down, you will need to
complete this step
Press and hold the UP and DOWN buttons
simultaneously for 2s, motor will jog once
and rotation will be switched successfully
*The motor needs to be in the reversing operation
without limits
3 Setting Upper and Lower Limits
Press and hold UP + STOP
simultaneously for 2s (2
jogs, 3 beeps) upper limit
is set
Press and hold DOWN +
STOP simultaneously for
2s (2 jogs, 3 beeps) Lower
limit is set
4 Adjusting Limits
Press and hold UP + STOP
simultaneously for 5s (1
jog, 1 Long beep) Repeat
step 3
Press and hold DOWN +
STOP simultaneously for
5s (1 jog, 1 Long beep)
Repeat step 3

Set Preferred Position
Check that both upper and lower limits are set.
Operate the screen to the desired preferred
position. Press P2 (1 jog and 1 beep), press STOP (1
jog and 1 beep), press STOP again (2 jogs and 3
beeps), preferred position is now set
Remove Preferred
Press P2 (1 jog and 1 beep), press STOP (1 jog and 1
beep), press STOP again (1 jog and 1 Long beep),
preferred position is now deleted
Press P2 (1 jog and 1 beep), Down and 1 beep), P2
(2 jogs and 3 beeps), all limits are now removed
On existing remote, Press P2 (1 jog and 1 beep)
Press P2 again (1 jog and 1 beep), then on new
remote, press P2 (2 jogs and 3 beeps). New remote
is now linked. Repeat for any additional remotes
1. Press the LEFT and RIGHT buttons
simultaneously, a “C” will appear followed by “15”
2. Press the LEFT arrow to display the desired
number of channels to be displayed on the remote
3. Press the Stop Button, a square will appear on
the screen, number of channels has been saved
Issue –Possible Cause
Solution
Motor has no response - No
Power or poor wire
connection
Check power and connections
Motor has no response -
Remote battery low
Replace Battery
Motor has no response - RF
Interference
Check motor antenna, check
for other RF source
interference
Motor has no response - Out
of remote control range
Move remote closer to unit
Remote can’t control single
motor - Multiple motors
paired to the same channel
Use multi-channel remote to
control multiple screens or
single channel per screen
Motor starts slow or makes
loud noise - Incorrect
installation or overload
Verify installation is correct
and level
Motor stops during travel -
Motor has reached limit
Adjust limits
Motor stops during travel -
Run time exceeds 4 minutes
Allow motor to cool to reset
the internal thermal fuse
Screen does not reach lower
limit or goes too far into the
housing –Screen has re-
wrapped itself
Remove hood and check for
re-wrap, break limits if
needed to relieve re-wrap
Remote A →Remote A →Remote B
5 Preferred Position
6 Delete All Limits
7 Pair / Unpair Additional Remotes
8 Remove All Remotes
9 Setting Number of Channels
Troubleshooting
Press P2 (1 jog and 1 beep), STOP (1 jog
and one beep), P2 (2 jogs and 3 beeps)
10 Motor Mode Switching
Press P2 (1 jog and 1 beep), UP (1 jog and
one beep), UP (1 jog and 1 long beep)
