Sunrich Tech U-1000 User manual

Dual/Quad Channel 4-Port USB 3.0
PCI Express Card
User Manual
Ver. 1.00
All brand names and trademarks are properties of their
respective owners.

Contents:
Chapter 1: Introduction..........................................................3
1.1 Features........................................................................3
1.2 System Requirements ..................................................4
1.3 Package Contents.........................................................4
Chapter 2: Getting Started .....................................................4
2.1 Hardware Installation ..................................................4
2.2 Driver Installation........................................................5
2.3 Hardware Verify...........................................................7
2.4 Driver Uninstall ...........................................................8
Chapter 3: Troubleshooting Tips ...........................................9
MN2000000222 Page 2

Chapter 1: Introduction
1.1 Features
PCI-Express 2.0x4
Provides four Super Speed USB 3.0 Type-A ports to support total
transfer bandwidth up to 20Gb/s (10Gb/s for Dual Bus Model)
Support USB Battery Charging Specification Revision 1.2
Complaint with Intel’s eXtensible Host Controller Interface
(xHCI) Specification Revision 1.0

Supports simultaneous operation of multiple USB 3.0, USB 2.0
and USB 1.1 devices
Supports the following speed data rates as follows:
Low-speed (1.5Mbps) / Full-speed (12Mbps) / High-speed
(480Mbps) / Super-speed (5Gbps)
Supports 4 downstream ports for all speeds
Built-in 4-
pin power connector for receiving extra power supply
from system
Hot-swapping feature allows you to connect/disconnect devices
without powering down the system
MN2000000222 Page 3

1.2 System Requirements
Windows XP/Vista/7/2008 R2/8/8.1 (32/64 bit), Linux 2.6.31 or
later
PCI Express x4, x8 or x16 slots
1.3 Package Contents
1 x Dual/Quad Channel 4-Port USB 3.0 PCI Express Card
1 x Driver CD
1 x User Manual
Note: Contents may vary depending on country/market.
Chapter 2: Getting Started
2.1 Hardware Installation
1. Turn off the power to your computer.
2. Unplug the power cord and remove your computer’s cover.
3. Remove the slot bracket from an available PCI-Express x4 (x8,
x16) slot.
MN2000000222 Page 4

4. To install the card, carefully align the card’s bus connector with
the selected PCIe slot on the motherboard. Push the board down
fir mly.
5. Replace the slot bracket’s holding screw to secure the card.
6. Secure the computer cover and reconnect the power cord.
2.2 Driver Installation
1. Insert the provided CD into your disk drive. The CD-ROM will
start automatically. The following screen will show up and please
click “Install Driver”.
*Note: Actual image may vary
Note: If the install program doesn’t run automatically, please
locate and double-click on the Autorun.exe file in the CD to
MN2000000222 Page 5

launch the install program.
2. Please click “720201/720202” to start the installation.
*Note: Actual image may vary
3. Click “Next” to continue.
Please check accept license agreement box, and click “Next” to
continue.
4. Click “Install” to continue.
MN2000000222 Page 6

Click “Finish” to end of the driver installation steps.
Note: Dual/Quad Channel 4-Port USB 3.0 PCI Express Card’s
driver was embedded into Windows 8/8.1 OS. That’s, the driver
can be installed into Windows 8/8.1 automatically.
2.3 Hardware Verify
1. Click on the “Device Manager”tab in the Windows Control
Panel.
Start > Control Panel > Device Manager
MN2000000222 Page 7

2. Entry “Universal Serial Bus controllers” item, and you can read
“Renesas Electronics USB 3.0 Host Controller” and “Renesas
Electronics USB 3.0 Root Hub” in the Device Manager.
2.4 Driver Uninstall
1. Click on the “Programs and Features”tab in the Windows
Control Panel.
MN2000000222 Page 8

Start > Control Panel > Programs and Features
2. Entry “Uninstall or change a program” page, and double click
“Renesas Electronics USB 3.0 Host Controller Driver” to
process driver uninstallation procedure.
Chapter 3: Troubleshooting Tips
If card and devices connected to the computer do not seem to be
MN2000000222 Page 9

working properly, please perform below basic troubleshooting
steps:
1. Check that all cables are correct and securely connected.
2. Make sure USB device’s power is turned on.
3. Make sure the devices are getting enough power they require.
4. Make sure there is no problem with the card installation.
Computer failed to start after inserting the USB 3.0 PCI Express
card.
Turn off the computer, remove the USB 3.0 PCI Express Card, and try
to restart the computer. If the computer starts successfully, it means
that the card has not been inserted into the PCI Express slot correctly.
Please clean golden figure by rubber firstly, then change another PCI
Express slot.
How to deal with there is a yellow exclamation point on
controller?
1. Please shutdown your computer and move the card to
another available slot then re-install USB 3.0 driver.
MN2000000222 Page 10

2. Please point on this device then right-click on the mouse.
Selecting “Update Driver” to renew USB driver.
3. This exclamation point usually means there is a resource
conflict between this card and another card in your system.
Please move the card to another available slot. Restart your
computer. Windows will re-configure itself and re-assign
resources. Check your device manager again.
A message is displayed starting that not enough power can be
given to the connected device.
Make sure to plug 4-pin power cable on board to provide efficient
power to USB devices. But the better way is using device self-power to
satisfy it.
Is it possible to connect current USB 1.1 or 2.0 devices to the
USB 3.0 PCI Express card?
Yes it works. Device will not obtain the USB 3.0 speed, but USB
2.0/1.1.
MN2000000222 Page 11
