Sunsky FX-02 User manual

User manual of FX-02
1.On/Off Button 2. Reset button 3. Infrared night vision light
4. Indicator 5. HD camera 6. Micro TF card slot 7.USB Port
Features
.High quality image HD FULL HD1080P DV DC
. Imported HD lens
. Compact form factor, portable handheld DV DC
. High-definition video recording in low light
. The video format is: 1920*1080P
. Photo mode is: 12M (4032*3024)
. Motion detection recording: 1080P
. USB interface for high speed transmission
. Supports up to 64G T-flash card
. Built-in lithium battery for up to 60 minutes
Operation guide
Charging:
This camera has a built-in rechargeable lithium battery. When using the
unit for the first time, please charge it first. You can charge it in the
following ways.
Connect the computer to charge and connect to the computer using USB
cable.
The red light flashes when the power is on, and the red light is long after
the battery is fully charged.
note
1. When the battery is low, when the TF card is recorded, the DV red and
blue lights will flash off for 5 seconds and then directly shut down to
enter the protection state, save the file and automatically shut down. At
this time, please charge the unit.
2.There is no card at boot, and the red and blue lights are automatically
turned off at the same time for 5 seconds.

3.After the power on, there is no working mode in standby mode, and it
will automatically shut down in 1 minute. Recording while charging, you
can record or charge (external USB 5V charger or charging treasure)
1080P video does not flash
Click the button to turn on the key for three seconds, the blue light is on,
enter the camera and video standby mode, press and hold the blue light
for 3 seconds to stop recording. During the video recording, press the
key once to pause the video and return to standby State, press and hold
again for about 2 seconds, the blue light flashes three times to stop
recording, the video file is automatically segmented every 5 minutes, and
the loop is overwritten.
Photographed 12 million
In the power-on standby mode, each time you press the key, the blue
light flashes to take a picture, and the camera resolution: 4032*3024 is
automatically saved.
Infrared light on and off
This product will automatically recognize the light and turn on the night
vision recording function during the recording process. When the light is
dark, the night vision light will automatically turn on and enter the night
vision video.
Motion Detection
In the power-on standby mode, the button is pressed twice in succession
for a short time, and the blue light is turned on and the red light flashes
three times to enter the motion detection recording standby mode. After
detecting the movement of the object, the red and blue lights flash
simultaneously to enter the movement. After detecting the video, if there
is no object moving after three minutes, it will enter the motion detection
standby mode again. When the detected object moves, the motion
detection function will be turned on again. The motion detection video
file will be saved every 3 minutes, and the loop will be covered until it is
over. No electricity. (Press the key to exit the motion detection mode)
Recording while charging:
After the machine is plugged into the TF card, the external 5V power
supply or charging treasure, the red light flashing is charging, short
press the key blue light long light, long press the open key for about two

seconds, the blue light flashes three times to enter the side charge
recording. The video files recorded while charging are automatically
saved every 5 minutes, and the loop is overwritten. You can also click the
on button to pause the recording and automatically switch to the
charging mode without operating for one minute.
Reset:
The machine crashes, the button is invalid, and it cannot be used
normally. You can use a sharp object to insert the reset hole and press
the reset button to reset. After reset, it can be used normally.
Shutdown:
In the stop (recording, photographing, motion detection) function mode,
you need to turn off the machine, long press the switch button for about
5 seconds until the red light is on and the dual light is off to complete the
shutdown. The standby mode will automatically shut down without any
operation for one minute.
Modify settings at your own time
After the machine is powered on, a TXT text file will be automatically
created in the root directory of the TF card. The computer will be
connected to the computer with the data cable. After the TIMEREST.txt
text file is opened on the removable disk, the time required to edit it in
the original format will be saved. The video file recorded again will be the
modified time. You don't need a time watermark to change the "Y" after
the time format to "N", as follows:
1:20180101102526Y (with time watermark)
2:20180101102526N (no time watermark)
note:
a. Please make sure that the TF card is inserted in the product. If the card
is not plugged in, the red and blue lights will flash for five seconds and
then automatically shut down.
b. In a well-lit environment, aim the lens at the subject and keep a
distance of 50 cm or more from the subject. This will result in an image
with correct color, natural scenery, clear picture and stable picture.
Connect to a computer:
In the boot, standby, shutdown state, you can directly connect to the
computer, can be used as a USB flash drive after connecting to the
computer, free to copy files, cut and paste, delete, format U disk.
Insert the unit into the USB port of the computer. After a few seconds, the
computer will pop up the removable disk identifier. The blue light
indicator lights up to identify the USB device for data transmission. The

red indicator light flashes for charging. The long red light indicates that it
is fully charged.
a. If the computer is not recognized after connecting the computer, or
The removable disk ID has not been ejected after 30 seconds, please
reset e-plug once.
b. It is recommended to use the TF card reader to directly read the video
file for playback, and directly play the video file saved in the built-in
memory of the recorder through the USB connection. The data may be
too large and the transmission cannot keep up, which may cause
playback. Not smooth.
Related parameters
Project related parameters
Video format :AVI
Video encoding :M-JPEG
Video resolution :1920*1080P
Video frame rate: 30fps
Playback software:Operating system comes with or mainstream audio
and video playback software
Picture format: JPG
Image ratio :4:3
Support system :Windowxp/7/10/vista; Mac os; Linux
Battery capacity :160MAh
Working time :about 60 minutes
Charging voltage :DC-5V
Interface Type :MICRO USB
Storage support: TF card
Infrared night vision range: 3-5 meters
Battery Type: Polymer Battery
Remarks:
Please charge immediately after each use. The red light will flash when
charging, and the red light will be on after full charge.
Because this product is a true HD high-definition DV, the power
consumption current of the product is larger than normal, and it may be
normal for the product to have a hot state during use.
Precautions:
Use occasions: Please strictly abide by the relevant laws of the country,
and do not use this product for any illegal purposes, otherwise you will
be responsible for the consequences.
Working temperature: Please use at natural temperature, do not work at
temperatures that the human body cannot adapt.
Operating humidity: Do not place the product in a damp working
environment. The product is not waterproof. Please avoid letting the
product get drenched or exposed to rain.

Photographic illumination: Please use it in an environment with
sufficient light source. Do not point the camera directly at a strong light
source such as the sun to avoid damage to the optics.
Cleaning requirements: Do not use in an environment with excessive
dust density, so as to avoid dust on the lens and other components,
affecting the camera effect.
Disposal: Please pay attention to environmental protection, do not
discard this product. It is forbidden to throw this product into the fire to
avoid an explosion.
