Sunstech TAB87DCBT User manual

TAB87DCBT
Tablet PC
Android 4.2
User Manual

Attention:
This handbook contains important security measures and the correct use of
the product information, in order to avoid accidents. Pls make sure to reading
the manual carefully before use the device.
1. Please don’t be in high temperature, moisture or very dust place
2. Please don’t be in high temperature, Especially in summer don't put the
device in the car when Windows closed.
Avoid fall or Violent collision of the device, don’t make the TFT display
screen were violent tremor, This could cause TFT display screen abnormal
or damage.
Please choose the appropriate volume, Use headphones shoulds not be
too big volume, If feel tinnitus, Lower the volume or stop using it
please charge In the following condition,
4The battery power ICONS shows have no power
5The system automatically shut off, startup after power off soon
6Operation buttons no response
7The machine that the top right corner show red icons
1. When the device in the format or ongoing upload and download
file, please don't suddenly disconnect, This could cause application
error.
1. For those who because of damage to the product, repair, or other causes
of erased the memory, The company shall not be liable for any
responsibility, please follow the user manual for the standardized
operation to use the device.
2. Don’t disassemble the product, don’t use alcohol、Thinner or benzene to
scrubbing products
3. Don't use the device one of the place of prohibit to use electronic
equipment in regional (such as the plane)
4. Please don't using the Tablet PC when you in driving or walking down
the street,
5. USB just only be used for data transmission
1

Tablet Part
Name function
1 Rear Camera 2M pixel rear camera
2 Power and lock Key Hold and press to turn on or turn off the
unit,Briefly press to turn on or turn off the screen.
3 Earphone Jack To connect your earphone
4 MINI HDMI Connect to TV output Via a HDMI cable
5 Micro USB Connect to a computer via a USB cable to
transfer data (music,videos,photo,ect.),USB
OTG,supports mouse, Keyboard, USB flash
disk,etc,with a converting cable.
6 Power jack(DC in –
Put)
Connect to a 5V output adaptor as included in
the accessories
7 ESC key Press the “ESC” to go back
8 TF card slot To insert your TF card
9 Microphone Microphone
10 Reset Press to reset the tablet if it freezes or behaves
abnormal
11 Speaker Speaker
2

Specifications
Display: 8 inch 1024X768 (4:3) Capacitive multi-touch screen
CPU: A20 Dual-Core A7 1.2GHZ
RAM: 1GB DDR III
GPU Mali-400@450Mhz
Internal Storage: 8 GB
Expansion Memory: Micro SD card up to 32GB (not supplied)
Built-In Wireless: 802.11b/g/n
BLUETOOTH
Micro USB 2.0 / OTG
TV Port: mini HDMI 1,.4
Front camera 0,3 Mpixels
Rear camera 2Mpixels
Battery : 4500mAh
AC Adapter: DC 5V-2A
Operating System: Android 4.2.2“Jelly Bean”
Made in China
What’s Inside The box
Tablet – 1pc
Power Adapter -1pc
USB Cable-1pc
OTG Cable-1pc
Instruction manual - 1pc
Warranty card 1pc
3

Getting Started
Battery Charging
The tablet has a built-in rechargeable Li-polymer battery.
2. To charge the unit, connect the AC power adapter to the micro USB jack
on the right side of the tablet.
3. The battery icon shows the battery status and charging status
4. The tablet can be used even if the battery is being charged.
the above icons indicate the different level of electricity left in the battery
5. No replacement of battery without authorization.
6. Recharge it for at least half hour if it has been idle for long time and fails
to start itself.
7. Regularly recharge it at least once a month.
8. Between 5°—40° is the optimum temperature for recharging battery or
the battery performance might slightly deteriorate.
4

Disposal
The battery might contain the polluting material, please give it to the official
recycling-station before disposal of the tablet pc, and do not litter.
Power ON/OFF
ON:
press the button for continuous 5 seconds until the tablet turns“ON”.
OFF:
1.Press the button for continuous 5 seconds and it will appear
2.Click Power off to power off the tablet
Screen Lock
This feature locks the screen, at the same time turn OFF the screen’s backlight
after a few seconds.
Screen locks when:
1. System is idle.
2. Manually activate it by pressing the Power button once.
Screen unlock :
Home screen
The Home screen will look similar to the picture below. It is actually five
screens, each of which can have a different layout of icons. To switch between
screens, simply slide your finger left or right across the display.
The status bar and navigation buttons are always visible, no matter which
Home screen you can currently viewing.
5

The Desktop contains shortcuts to your most-used applications and widgets
Touch the screen icon to quickly search the World Wide Web using Google.
The icon will launch the Application menu.
The status bar displays system information, such as current time and battery.
Touch to Expand the status bar for more detailed information.
The button moves back one step to the previous menu/page.
The buttons returns immediately to the Android desktop.
The button display a menu of recently opened applications.
The button to screenshot current interface
6

The button decrease the volume.
The button increase the volume,
Settings Menu
The settings menu allows you to adjust Tablet system configuration.
To change settings:
1. Touch the "Settings" menu icon on the Application menu.The
Settings menu will open.
2. Guide your finger up or down the left side of the screen to scroll through
the list of available categories.
3. Touch a category title to view further options on the right side of the
screen.
Wi-Fi - Connect to /disconnect from wireless networks, view connection status
Bluetooth: To connect or disconnect from devices to send photos / music…
Data usage - Enable / disable mobile data, view current usage, set mobile data
limit (note: this function is available only on devices supplied with 3G card)
Sound - Change volume, touch sound, screen lock sounds etc
Display - Change brightness, wallpaper, sleep settings, font size etc
Storage - Manage NAND and Micro SD card, view available capacity etc
Battery - See battery status and powered-on time
Apps - Manage applications, running services etc
Accounts & sync - Switch synchronization on /off, manage accounts etc
Location services - Change approximate location detection, improve search
results
Security - Change screen lock type, encryption, password, credential storage
etc
Language & input Select language, add to the dictionary, edit on-screen
keyboard settings, vocal search, etc
7

Backup & reset - Backup & restore data, perform factory reset, etc
Date & time - Set date, time zone, time, clock format etc
Accessibility - Set up large text, auto-rotate screen, speak password etc
Developer options - Advanced functions for Android developers - debugging,
HDCP check etc
About tablet - Information about your Android device
How to Use TF card
1. Insert the TF card into the TF card slot. Gently push TF card into slot until it
clicks into place.
2. A prompt will be seen on the screen saying“ Preparing SD card“
Removing TF card
1. Close all applications and documents which have been opened from the
TF card.
2. Select“Setting”and find“ Storage” then click“Unmount SD card”.
3. A prompt will be seen on the screen saying “ SD card safe to remove”
4. Gently press the TF card to remove and pull out the TF card.
Note: Insert the TF card in correct position, otherwise it will damage the card
and the slot.
Software Keyboard
The tablet has a software keyboard which automatically show up when
you tap the place on screen where text or number are to be entered.
Touch Screen
The touch screen responds to finger touch.
Note:Do not place any object on the touch screen because it may damage or
crush the screen.
8

Single Click: single click one icon to choose the icon or option you want.
Long Press: press and hold one icon to make appear a menu related to the
executed function (if available).
Drag: drag on the screen and you can move between magic cube sides or
drag the application icons into the shortcut bar.
How to connect with computer
Note: Turn on your Tablet before connect the Tablet to PC by USB cable.
1. Use USB cable to connect MID with computer. System will notice USB
connected on bottom of screen.
2. Press USB connected to pop up, then click Turn on USB storage, click OK.
3. Then the USB connection has been successfully.
9

Connection to Internet
Wireless:
1. Select“ Settings”
2. Select “Wi-Fi”and slide OFF to ON status.
3. All detected wireless networks in the area will be listed, Click to select
desired wireless connection.
4. Enter WEP key or network key if necessary.
5. Once connected to a wireless network, settings will be saved
6. Wireless icon will appear on the taskbar when connected successfully.
Note: when the tablet detects the same wireless network in the future, the
device will connect automatically to the network
Web Browsing
Connect to the internet and launch the browser.
10

Connection to Bluetooth
1- Select“Settings”
2- Select “Bluetooth” and slide OFF to ON status.
3-All detected Bluetooth device in the area will be listed, tap to select the
device
connection.
4- When your select the device must enter code and permission key if
necessarytopairing.
5-On the other device must accept the permissions to connect between
them.
6- Now, your can sent photos / Music…
11

Camera
Touch the icon to enter camera mode and the interface is shown as
follows:
1.Touch the icon in the middle to take photo
2. Touch the icon and you can switch camera mode to camera recording
mode.
3. Touch the icon to change of the front to the back camera.
12

Trouble Shooting
Close Application
All running applications take up system memory and will slow down the
systems response. Please shut down all idle applications to free memory and
get the system speed back to normal.
To close the application, click the icon on the shortcut bar to
enter the system configuration interface. Select the Application →Running
services and the interface is shown as follows:
Tap the application you want to close. A pop-up window will be displayed.
Tap “Stop” to close that application.
13

MandatoryPoweroff
1. Press and hold the power button for 5 seconds and the device will be
powered off.
2. Press the reset button on the back and the device will be forced to be
powered off.
Restore Default Setting
If you want to reset the factory setting and erase all materials, please press
Settings →Backup & Reset →Factory data reset.
** Warning: A factory data reset will delete your data, configuration of the
system and applications that you have installed.
**Pleaseusethisfunctioncarefully.
-RecoverymodeFunction.TAB87DCBT
How to enter in recovery mode.
Please follow these steps.
To enter in the recovery mode first you should power off the device,
Then long-press the “ON-OFF”key and “Return” Key at the same time
until the Recovery mode has appeared, pls try it.
After a new menu will appear and then you must use the touch
panel to select “Wipe data/ factory reset” then press “Power” and
then select “Yes delete all user data”
Then press “power” again. The unit will then begin the recovery
mode.(this process may last for a few minutes).
14

When it finishes select“reboot system now”press the “power
button” and the unit will re-start itself. (this process may last for a
few minutes
__________________________________________________
-How to download the software using the unit.
IMPORTANT: When you download the software, all data will be
deleted as photos, videos and Apps that you have been
installed.
Do not interrupt this process please make sure the battery is fully
charged.
Please, follow these steps.
1- Open browser and search and open this link:
www.sunstech.es/download/
2- Select the model of the tablet that you have and download the
software.(This software is installed In the INTERNAL SD).
3- When it finished the download, select the App " update " in your
unit.
4-Select "Local Update", "download".
5-Select the software / Download and wait until the process is
finished.
15

Warranty conditions
- The warranty of this product is for 2 years since the purchase date.
- The warranty will exclude breakdowns caused by bad use of the product,
wrong installation or installation in not desirable places for a proper
maintenance of the product, rips, updates of the products that are not the
supplied by the brand, pieces wore away for its use or for not domestic or
inappropriate use. Also are excluded breakdowns caused for manipulations of
the products by people or companies alien to our company.
- For any request regarding the warranty terms, the purchase receipt must be
attached.
Correct disposal of this Product
(Waste Electrical & Electronic Equipment(WEEE)
Your product is designed and manufactured with
high quality materials and
components which can be recycled and reused.
This symbol means that electrical and electronic
equipment, at their endof-life should be disposed of
separately from your household waste.
Please dispose of this equipment at your local
community waste collection/recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.Please help us to conserve
the environment we live in!

1. DO NOT place objects on top of the
device, as objects may scratch the
device.
2. DO NOT expose the device to dirty
or
dusty environments.
3. DO NOT place the device on an
uneven
or unstable surface.
4. DO NOT insert any foreign objects
into the device.
5. DO NOT expose the device to strong
magnetic or electrical field.
6. DO NOT expose the device to direct

sunlight as it can damage the device. Keep it away from
heat sources.
7. DO NOT store your device in
temperatures higher than 40°C(104°F).
The internal operating temperature for
this device is from 20°C(68°F) to
60°C(140°F).
8. DO NOT use the device in the rain.
9. Please check with your Local
Authority or retailer for proper
disposal of electronic products.
10. The device and adaptor may
product some heat during normal
operation of charging. To prevent
discomfort or injury from heat exposure, DO NOT leave

the device on your lap.
11. POWER INPUT RATING:
Refer to the rating label on the
device and be sure that the
power adaptor complies with
the rating. Only use accessories specified by the
manufacturer.
12. Clean the device with a soft cloth.
If needed, dampen the cloth slightly
before cleaning. Never use abrasives or cleaning
solutions.
13. Always power off the device to install
or remove external devices that do not
support hot-plug.
14. Disconnect the device from an
