INSTALLATION INSTRUCTIONS CB-3012 SERIES CABINET LOCK
I. Order Information
Item Contents LED Lock Status Sensor Door Status Sensor Lock mode (Default)
CB-3012S\LD 12VDC or 24VDC ○ ○ ○ Fail-Secure (Power to open)
CB-3012S\L 12VDC or 24VDC ○ ○ × Fail-Secure (Power to open)
CB-3012F\LD 12VDC or 24VDC ○ ○ ○ Fail-Safe (Power to lock)
CB-3012F\L 12VDC or 24VDC ○ ○ ×Fail-Safe (Power to lock)
II. Specifications
Power input 12VDC 24VDC Stable PSU recommended
Current 0.28A 0.14A Changeable by power input and higher outer temp.
Door Status Sensor (DSS) Max.3W; Max.30VDC;Max.0.2A COM., NO.
Lock Status Sensor (LSS) Max.30VDC;Max1A COM., NO., NC.
III. Contents V. Power input setting
1234
1234
Lock body x1
Cover Plate x1
Screws x6 Magnet x1
(Only DSS)
Strike x1
Twin adhesive x1
V. Changing lock mode of operation (Fail Secure to Fail Safe)
Turned the chassis upside down.Opened the housing.
Fail-Secure
(Power to open)
Fail-Safe
(Power to lock)
I. Wiring diagram
．Fail-Secure (Power to open) mode
Wiring diagram A: Fail-Secure (Power to open)
Without (X)
COM.
NC.
NO.
COM.
NO.
NC. COM.
NO.
NC.
(Lock +)
COM.
NC.
NO.
RELAY
NC.NO.NC.NO.
V+
V-
(Lock +)
V+
V-
(LED)(LED)
Power on
Power off
LED/ Emitted Color
Green
Black
(PowerOFF)
Red
Orange
Yellow
White
Green
Blue
LSS
DSS
RELAY
Black
(PowerOFF)
Red
Orange
Yellow
White
Green
Blue
LSS
DSS
Wiring diagram B: Fail-Secure (Power to open)
Power on
Power off
LED/ Emitted Color
Red
Green
CB-3012 Ver.01-100930 - 1 - Patent No. M 384227
A. 12VDC input setting :
．Jumper setting as
shown on below-
PIN-1 and PIN-2 closed
PIN-3 and PIN-4 closed
B. 24VDC input setting :
．Jumper setting as
shown on below-
PIN-3 and PIN-4 closed
RoHS

．Fail-Safe (Power to lock) mode
Power on
Power off
LED/ Emitted Color
Red
Green
COM.
NO.
NC.
COM.
NC.
NO.
COM.
NO.
NC.
NC.
COM.
NC.
NO.
NO.
V+
V-
NC.NO.
V+
V-
(Lock +)(Lock +) (LED)(LED)
RELAY
Wiring diagram C: Fail-Safe (Power to lock)
Power on
Power off
LED/ Emitted Color
Without (X)
(PowerON)
LSS
DSS
Black
Red
Orange
Yellow
White
Green
Blue
Green
Wiring diagram D: Fail-Safe (Power to lock)
RELAY
(PowerON)
LSS
DSS
Black
Red
Orange
Yellow
White
Green
Blue
VII. Dimension
Door statussensor
Fail-Secure
Fail-Safe
Unit:: mm Door status sensor Door status sensor
VIII. Installation Diagram
A Drawer.
UNIT: mm
