SUP’AIR Harness ACRO 3 User manual

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 1
User’s manual ACRO 3
hrfdh
Harness ACRO 3
ACRO 3 manual
SUP’AIR - VLD
34 rue Adrastée
Parc Altaïs
74650 CHAVANOD
FRANCE
45°54.024’N / 06°04.725’E
English
18/06/2013
All manuals and user guides at all-guides.com
all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 2
User’s manual ACRO 3
Photo by Julian Cisterna, Pilote : Félix Rodriguez
Thank you for your choice of an ACRO3 ! We are proud to
join you on your journey in our common passion : para-
gliding.
SUP’AIR has been designing, producing and selling ac-
cessories for free flying activities since 1984. By choosing
a SUP’AIR product you benefit from almost thirty years of
expertise, innovation and listening. This is also our philoso-
phy : working endlessly to develop better products and to
maintain a high quality production in Europe.
We trust that you will find this user’s manual comprehen-
sive, explicit and hopefully pleasant to read. We advise
you to read it carefully !
On our website www.supair.com, you will find the last up
to date information about this product. If you have any
further questions, feel free to ask one of our retailers. And
of course, the entire SUP'AIR team are at your disposal
through [e-mail]
We wish you many safe flying and enjoyable hours, and
happy landings
The SUP’AIR team
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 3
User’s manual ACRO 3
Introduction 4
Technical specifications 5
Size choice 6
Nomenclature 7
Harness overview 8
accessories assembly 9
Seat-plate 9
Carabiners distance (cm) 9
BUMPAIR assembly 10
Foot-rest 11
Holding sleeves 11
Front protection 12
Speed-bar system. 13
Installing the reserve parachutes 14
Handle / Pod connection 14
Risers / harness connection 15
Parachute installation inside the under-seat pocket.
16
Dorsal reserve parachute pocket 17
adjustments 18
Flight phases 19
Pre-Flight check. 19
Take-off 20
In flight 20
Speed-bar use 20
Landing 20
Using the reserve parachute. 21
Mandatory controls 21
Maintenance 22
Washing and harness maintenance. 22
Storage and transport. 22
Product longevity. 22
Repair 23
Materials 23
Recycling 23
Warranty 24
Disclaimer 24
Pilot’s gear 24
Complements/Accessories 25
Service Book 26
Table of contents
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 4
User’s manual ACRO 3 Introduction
Advice Caution ! Danger !!
If you are reading those lines, it is because you are eager to enter and seat
inside your new toy to defy gravity with series of spectacular daring maneuvers or
simply to escape the daily routine.
Before heading out, take the time to install your reserve parachute, and
properly adjust your harness. These steps are of vital importance. Follow them
before flying and for peace of mind.
After reading this manual, we suggest you check your harness by hanging in it
before flying.
N.B : Three important icons will help you when reading this manual
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 5
User’s manual ACRO 3
Model ACRO3
S
ACRO3
M
ACRO3
L
Pilot size 155 - 165 cm 160 - 190 cm 185 - 200 cm
Pilot weight <70 kg 65 - 85 kg 80 - 100 kg
Harness weight (+ carabiners+speedbar) 6,18 kg 6,29 kg 6,74 kg
Designed for ACRO Paragliding ( Aerobatics ).
Backrest height (cm) 70 73 78
Reclined seatting height (cm) 38 40 40
Seat length (cm) 42 42 45
Seat width (cm) 33 35 38
Carabiners height (cm) 43 45 48
Carabiners distance (cm) 41 - 52
Seat plate size 33 x 34 cm 35 x 37 cm 37 x 37 cm
Impact damping system : Airbag (Volume) No No No
Impact damping system : Bumpair (Thickness) Yes - 17 cm Yes- 17 cm Yes- 17 cm
Certification EN 1651 - LTF EN 1651 - LTF EN 1651 - LTF
Flight : tandem (Pilot- Passenger) No No No
Flight : acrobatic flying Yes Yes Yes
Take-off : Winching - towing Yes Yes Yes
Quick-out carabiners compatibility Yes Yes Yes
Technical specifications
A
B
C
D
E
F
A
B
C
D
E
F
Hauteur du dos
Hauteur réglage de
l'inclinaison du
dossier
Longueur d'assise
Largeur d'assise
Hauteur des points
Distance entre les
points
A
B
C
D
E
F
Backrest height (cm)
Reclined seating height (cm)
Seat length (cm)
Seat width (cm)
Carabiners height (cm)
Carabiners distance (cm)
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 6
User’s manual ACRO 3 Size choice
Choosing your harness size is important. You will find below a measurement chart to help with your
selection. Nonetheless we advise you to try out the harness under a hanging device and in different
sizes at one of our retailers in order to choose the correct size.
For a complete list of our retailers, please click here : www.supair.com
Size
Weight
1,45 m 1,50 m 1,55 m 1,60 m 1,65 m 1,70 m 1,75 m 1,80 m 1,85 m 1,90 m 1,95 m 2 m 2,05 m
50
55
60
65
70
75
80
85
90
95
100
105
110
M
Preliminary test
under hanging
device
S
L
All manuals and user guides at all-guides.com
all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 7
User’s manual ACRO 3
1
8
2
3
4
5
7
6
1
2
3
4
5
6
7
8
Nomenclature
1 Fiberglass reinforced
wooden seat plate (ref :
PLAACRO).
1 Reserve parachute han-
dle for pod located be-
neath the seat ( ref : A3 ).
2x 45 mm self-locking cara-
biners.
1 Split risers ( for reserve parachute
located beneath the seat ).
9
1 1 BUMPAIR 17 cm
1 ACRO3 harness
1 Long foot-rest
1 Strap protection kit
1 Dorsal reserve parachute
( ref : B2 )
6
9
2 Riser bridle adjustment
holding sleeves
10
5
4
Nomenclature
9
10
2
2
8
8
A single reserve parachute connection kit ( riser set + 2 Maillons Rapides® ) is included with the harness due to many pilots
using Rogallo type reserve parachutes as their main rescue backup system. If you wish to install two round Apex type reserve
parachutes inside your harness, you will need to order a second riser set + Maillons Rapides® .
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 8
User’s manual ACRO 3 Harness overview
8
1
2
3
4
5
7
6
1 2
1 1
1 0
9
8
1 0
7
1 3
Accelerator cord ( speed-bar system
) grommet entry.
1 4
Accelerator cord ( speed-bar system
) grommet exit.
1 5
Stowing the accelerator and/or the
foot-rest.
1 6
1 5
1 4
1 6
Velcro smoke-flare.
Small side storage pocket
17
Large dorsal storage pocket
18
17
18
1 3
1Chest strap quick release buckle.
2Safe-T-strap.
3Leg strap quick release buckle.
4
Chest strap adjustment.
5
Backrest tilt adjustment.
6
45 mm self-locking carabiners.
7
Dorsal reserve parachute pocket
Dorsal reserve parachute handle
1 0
Reserve parachute container located
beneath the seat.
9
Reserve parachute handle for a pod
located beneath the seat.
1 1
Reserve parachute risers connection.
1 2
Speed system pulleys.
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 9
User’s manual ACRO 3 Accessories assembly
A Installing the ACRO 3
seat-plate.
1. Face the front of the harness and grab
the rear section of the seating fabric
area to pull it toward yourself.
Pull the leg straps to extend them and
free up space to insert the seat-plate.
2. Place the front section of the seat-plate
forward and slide it between the loos-
ened leg-straps before pushing it fully to
the end of the receiving pocket.
Pilot's left side.
Pilot's right side.
Rear
( Rear section of the
seat ).
Front
Flight direction
B Installing the carabin-
ers.
1. To the main hooking point, followed
by the backrest angle adjustment strap.
Close the carabiner and lock its gate
securely facing forward.
2. Push the carabiner through the web-
bing loop found inside the lateral skirt. 3.
Push the carabiner all the way through
the skirt's opening to make certain the
hooking points are fully visible.
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 10
User’s manual ACRO 3
C BUMPAIR assembly
Accessing the Bumpair pocket.
1. Lift the Velcro® flap located above the shoulder strap.
2. Fully open the Zip found under the flap ( not to be mistaken for the storage dorsal pocket zip ).
3. Insert the Bumpair starting from its thickest section. Push it all the way in for a secured placement by following its contour by hand inside its housing.
4. Place the upper holding pocket hood over the Bumpair.
5. Fasten the Zip and finally the Velcro® flap.
Accessories assembly
Velcro®
Zip
The BUMPAIR is only installed once. There is no need to take it out of its container afterward unless in case of a severe impact
or water landing : it would then be necessary to inspect it for possible damage ( tear, ripped fabric or stitching, etc. ).
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 11
User’s manual ACRO 3 Accessories assembly
D Installing the foot-rest.
For each side, move the foot-rest strap
inside the strap buckles located to the front
and side of the seat, then through the ad-
justment buckles as seen in the following
diagram :
E Installing the ad-
justment bridles holding
sleeves.
Wrap the holding sleeve around the shoul-
der and the adjustable straps to prevent
potential annoying flapping of the materi-
als in flight.
12
1
2
All manuals and user guides at all-guides.com
all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 12
User’s manual ACRO 3 Accessories assembly
F Installing the ventral ( front ) protection.
Ventral bridle schematic ( viewed facing the pilot ).
Main right hooking point.
Main left hooking point.
Toward the right shoulder strap.
Female right buckle
Female left buckle.
Safe-T strap
Toward the left shoulder strap.
Protection kit.
For better explanations in the following sche-
matic, the protections were colored in red.
matic, the protections were colored in red.
B
A
1. Installing part « A ».
Part « A » is attached to the chest strap,
and left side of the pilot.
A. Push the female buckle
through the elasticated loop.
B. Wrap and close the Velcro®
around the horizontal strap between
the main left attachment location and
the shoulder strap.
A. Elastic B. Velcro®
2. Installing part « B ».
Part « A » is attached to the chest
strap, and right side of the pilot.
C. Wrap and close the Velcro®
around the horizontal strap on the
pilot's right side, behind the main at-
tachment location.
D. Wrap and close the Velcro®
around the horizontal strap between
the right shoulder strap and the ABS
strap. C. Velcro® D. Velcro®
ABS right strap.
Pilot's right side. Pilot's left side.
3. Closing the ventral ( chest strap ) strap.
Closing the buckles.
- Slide the part "B" excess in the elasticated loop found behind part "A" to tidy every-
thing up. As such, the protection will adapt itself to the chest strap.
( From the pilot's view point ).
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 13
User’s manual ACRO 3 Accessories assembly
1
2
3
4
G Installing the speed-bar system.
1. Push the accelerator cord through the grommet
located to the front, and right side of the seat. The cord
rides through inside the harness between the bridles
and the outer skirt.
2. Push the accelerator cord through pulley 2.
3. Pull the cord out though the grommet located be-
neath the main connection location.
4. Finally, hook the crimped clip to the cord and and
make the connection to the paraglider.
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 14
User’s manual ACRO 3 Reserves assembly
Warning before starting the installation pro-
cedure :
- The handle found to the pilot's right side, ex-
tracts the parachute located beneath the seat.
- The handle found to the pilot's left side, ex-
tracts the dorsal ( rear ) reserve parachute.
If you install two reserve parachutes :
- Right handed pilots : install the dorsal reserve
parachute first, then the other inside the con-
tainer beneath the seat.
- Left handed pilots : install the reserve para-
chute beneath the seat first, then the other
inside the dorsal reserve parachute container.
- If only one reserve parachute is installed :
- Right handed pilots : use the pocket beneath
the seat.
- Left handed pilots : use the dorsal pocket.
B Handle connection to the reserve parachute pod.
Thank you for carefully reading the following! We advise you to have the initial rescue parachute
installation done by someone knowledgeable with the process.
A Risers to rescue connection.
AReserve parachute handle :
BParachute properly packed in its pod.
CParachute lines.
DParachute risers ( standard or “Y” ).
A
B
C
D
1
2
1. « Y » risers : make a loop to loop configuration and connect the risers to the harness using the 6 mm or 7 mm ( x 2 ) stainless steel Maillons Rapides®
Standard risers : use a 7 mm stainless steel Maillon Rapide®.
2. Push the handle
through the central loop-
strap, and make a « loop
to loop » connection with
the handle.
3. Tighten securely the
“loop to loop” connection.
Attention : Use the handle ref. : A3 to install the reserve parachute
beneath the seat. And the handle ref. : B2 for a dorsal reserve
parachute installation.
1. The handle must be connected to one of the POD
buckles. For a dorsal parachute pocket installation : use
the central loop-strap. For an installation beneath the
seat : you can use either one ( the central loop-strap is
mostly used ).
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 15
User’s manual ACRO 3
B Rescue parachute riser connection.
1
2
3
Installing the reserve parachutes.
1. 1. Place the Maillon Rapide®
( locking gate toward the top,
facing outward ) and push it
through the bridle loop under
the flap. Place the O ring in the
Maillon and twist it in a figure 8
configuration.
2. 2. Push the riser through the
upper free “8” shaped toric
ring and connect it to the Mail-
lon Rapide®.
3. 3. Create a new twisted
loop with the O ring before
inserting it into the Maillon
Rapide®.
4. 4. Repeat procedures 1,2,3
with an additional O ring for
the connection to the harness.
Tighten the Maillon Rapide®
locking gate securely, with pli-
ers if necessarily.
5. 5. Tuck away the
risers excess under the
flaps.
Regarding the second reserve para-
chute : complete the installation of the
first rescue in its pocket. Repeat the
procedure with a new set of Maillons Rapides®,
by overlapping the second riser set on the initial
arrangement. Install first the reserve parachute
to which the handle is found opposed to your
predilection side.
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 16
User’s manual ACRO 3
B
E
A
1
4
7
H
E
G
E
2
5
8
G
B
F
3
6
J
I
A
C
E
Check the completed in-
stallation during a hang-
test.
B
C
E
D
F
A
I
G
H
J
A F
Harness-reserve para-
chute riser flap Lateral flap.
BG
Flexible flap. Handle (ref. : A3).
CH
Left cable.
Parachute properly
folded and packed
inside its pod.
D I
Right cable Additional reserve para-
chute risers.
EJ
Lower flap Harness/reserve para-
chute risers.
C Parachute installation inside the under-seat pocket.
1. 1. Place the risers har-
ness/reserve ( J ) under-
neath the flap ( A ).
2. Inside the reserve para-
chute pocket, tuck in first
the parachute line excess
« I », then the parachute
( inside its POD ) « H » ;
keep the handle outside
the container.
3. 3. Close the flap ( A )
and correctly position the
handle ( G ) then, fold
the flexible flap ( B ).
4. Using a small cord,
push the line « C » through
the left grommet of the
flexible flap « B », and
then through the grommet
of the lower left flap « E ».
5. Push the left handle
cable through the cord's
loop to secure it all in
place.
6. 6. Repeat the proce-
dures 4 and 5 with the
right grommets found on
flats B and E.
7. 7. Connect the handle (
G ) Velcro strip, to the flap
( E ) receiving Velcro strip
( male to female ).Tuck
away the handle extremi-
ties ( G ) in their respective
housing on flap ( E ).
8. 8. Tuck away the flap
( E ) “bumps” in their
respective housing.
Specifics for the parachute pocket
located beneath the seat :
- Lateral one flap pocket (+ one sup-
porting inner flap).
- Cable locking system.
- Right side handle (ref.: A3).
- Volume : 3 to 6,5 liters.
- Adapted to the SUP'AIR reserve
parachutes, or round Apex type res-
cues and Rogallo models.
All manuals and user guides at all-guides.com
all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 17
User’s manual ACRO 3
Check the completed
installation during a
hang-test.
B
CE
D
F
A
I
G
H
J
K
L
MA
F
Parachute riser flap.
Left lower flap grommet.
B
G
Upper left flexible riser
flap.
C
H
Lower left flexible riser
flap.
D
I
E
JParachute risers.
Dorsal reserve pocket's main features :
- 6 flap dorsal reserve pocket.
- Locked mode via safety pins.
- Left handed reserve parachute
handle ref. : B2 ).
- Volume : 3 to 5 liters.
SUP'AIR, or other round Apex type
reserve parachutes only ( no Rogallo
in this pocket ! ).
Upper right flexible flap.
Lower right flexible flap.
Right lower flap grom-
met.
Left upper flap grom-
met.
Right upper flap grom-
met.
K
L
MHandle ( ref : B2)
Excess reserve para-
chute lines.
Reserve in the POD.
1. Place the risers « J »
under flap « A ». Push
them through between
flap « B » and the upper
flap in order to stow
away the riser and lines
excess from the reserve
« K » to the bottom of
the pocket.
3. Keep the handle
outside the pocket. Us-
ing a small piece of line,
push the flap « D » cord
through the grommet
« E », then « G » and
finally « I ». Repeat the
sequence with the flap
« B » cord through the
grommets « C,F and H ».
E
D
I
G
2. Close and secure the
assembly by pushing
the safety pins in their
respective receiving loop-
cords, then tidying up the
handle bridle between
flaps « B » and « C »,
maintain it in place with
the help of the upper
« C » flap stitched strap.
4. Tuck away the re-
maining upper flap end
into the receiving neo-
prene pocket located
on the lower flap, and
fix the handle to the
Velcro® in order to tidy
up the assembly.
D Installing the reserve parachute inside the dorsale pocket.
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 18
User’s manual ACRO 3
2. Shoulder straps adjust-
ments.
Tighten the shoulder straps by pulling
cord « A » forward. Loosen by pulling
rearward on strap « B ».
Resting on the shoulder straps
contributes to the overall comfort level
and must be precisely adjusted ( not
too tight or too loose ).
b
a
3. Adjusting the seating pos-
ture angle.
Adjust the seating posture angle by
using the trims located on each side
of the harness.
Tightening the adjustment ( raises the
knees height ) by pulling the « C »
buckle downward.
Loosen the adjustment by pulling
buckle « D » upward.
dc
4. Adjusting the chest strap or ventral strap.
Tighten the chest strap by pulling the green cord ( tightening the ventral
strap increases stability but heightens the risk of experiencing a « twist ».
Do not overtighten the chest strap adjustment.
Loosen the chest strap ( ventral strap ) by pulling on the black buckle « F »
( loosening the ventral strap will upset the harness's stability but provide
refined piloting opportunities ).
d
c
Adjusting the seating area.
1. Backrest tilt adjustment.
Adjust the angle by puling the black
strap and bring the backrest closer to
a vertical setting, or on the green cord
to recline and pull away from the verti-
cal setting.
1
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 19
User’s manual ACRO 3
Flight phases
Pre-Flight check.
• Check that the harness and the carabiners did are not damaged.
• Check thoroughly that the rescue handle’s cable end has not got outside the snappers’ flaps
• Check that your personal settings have not been modified.
• Check that all zippers and buckles are properly closed.
• Check that the speed-bar is properly adjusted and connected to the wing ( refer to page 20 ).
• Check that no rigging line or other object comes in contact with the rescue parachute handle.
• After a thorough weather conditions analysis, when the decision to fly has been taken, put your harness on :
• Check for the carabiners to be securely locked.
1
2
3
4
1
2
3
4
1
23
4
Thigh strap quick-release buckles (female).
Thigh strap quick-release buckles (male). Chest strap quick-release buckles (female).
Safe-T-Bar
3
3
All manuals and user guides at all-guides.com

SUP'AIR manufactures its products in Europe. Most of the components used are Made in Europe.SUP’AIR _ACRO3 Page 20
User’s manual ACRO 3 Flight phases
Take-off
Check that you are securely fastened inside your harness with its speed-bar properly connected, so not to impede your running
phase.
Do not release your hands from the toggles when close to the ridge.
In flight
Please set the distance between the two carabiners according to aerology conditions and to the wing manufacturer's recommenda-
tions.
Tightening provides more stability but less harness piloting efficiency. Beware of the increased risk of riser twisting. On the contrary,
loosening the strap provides more efficiency but can be dangerous in turbulent aerology (increased risk of falling towards the col-
lapsed side of your glider).
Flight behavior : The ACRO3 is a harness specially made for paragliding acrobatics. It is a precis, stiff and reactive, giving you maxi-
mum control during acrobatic figures.
Keep in mind that we want to see you practice this specialty with peace of mind and for as long as possible. The best gear will not
protect you against over confidence or a cascade of mishaps.
Speed-bar use
We recommend a careful use of the speed-bar due to the increased risk a possible frontal collapse. Please carefully read your glid-
er's operation manual.
To use the speed-bar, maintain one foot on the footrest then with the other, place your foot onto the centering space and push the
first bar.
Landing
Straighten yourself in your harness and adopt a running posture to dissipate the horizontal speed.
Do not land whilst in the seated position, this is dangerous.
All manuals and user guides at all-guides.com
