Introduction
Thank you for purchasing the SUPCO Dual Input
thermometer (thermocouple). Please take a few
minutes to browse through this user manual before you
begin to operate the meter to ensure that you are fully
familiarized with how best to operate the meter as
accurately and safely as possible.
This meter can match any standard K-type or J-type
thermocouple sensor.
1.1 Precautions safety measures
To get the best performance from this meter, please
read this user's manual carefully and observe the
detailed safety precautions.
1.1.1 Maintaining the product
l Do not measure in high temperature, high humidity
locations.
l When not using the instrument for a long time,
please remove the battery and avoid storing in high
3
temperature and high humidity.
Features
. Display: 4 digit LCD Display
2. Resolution: 0. /0. ℃（below 832 ）
/ ℃（above 832 ）
3. Range:
K-type: -328 to ~2372 (-200℃ to 300℃)
J-type: -328 to 2 92 (-200℃ to 200℃)
4. Accuracy:
±(0.2% reading +2 ) for -328 to -48
±(0.% reading +.4 ) for - 48 to 2372
±(0.2%reading+ ℃) for -200 to - 00℃
±(0.% reading +0.7℃) for - 00 to 300℃
5. Sample rate: time /sec
6. Auto power off: 20 minutes (app.)
7. Low battery indicator
8. Operating environment:
32 to 22 (0℃ to 50 ℃); 0 to 80%RH
4
9. Storage environment:
-4 to 40 (-20℃ to 60℃); 0 to 80%RH
0. Dimensions:
4.76”(L) x 2.36”(W) x .8”(H)
2 mm(L) x 60mm(W) x 30mm(H)
. Weight:
6.35 oz (app.)
80 g (app.)
. Accessories:
K-type thermocouple wire (2)
Lanyard ()
AAA Batteries (3).
Users manual
5
Instrument Description
. Sensor cover
2. Thermocouple
input jacks
3. LCD display
4. Function key
l LCD Display
SHIFT MM
MOD HOLD
T1-T2
UNIT
ON/OFF LIMIT
TYP
Hi/Lo Light
Double ways
thermocouple meter
6
Symbol Designations：
. Data Hold Indicator
2. Indicates the high or low temperature setting
3. Indicates the second function key
4. Indicates type of thermocouple
5. Measurement Display area
6. Measurement Display area
7. T -T2/ Maximum / Minimum Indicator
8. Indicates backlight ON
9. Temperature units
0. Low Battery Indicator
. Operating Instructions
*NOTE: After abrupt ambient temperature changes,
allow instrument temperature to stabilize for 20
minutes for accurate measurements.
. Press the ON/ OFF key to turn the unit on
2. Plug one or both thermocouples into the inputs at
the top of the instrument. If there are no thermocouples
7
installed the instrument will display OL. Otherwise,
the display will show T and/ or T2, identifying which
thermocouple(s) is (are) installed.
3. Press the function key to change temperature units,
select T-T2/MAX/MIN/HOLD mode and K or J type
thermocouple, set Hi/Lo alarm, and store data. (refer to
“function keys”)
4. Press the key for more than 2 seconds to
turn the back light on or off.
5. Press the key for more than 2 seconds to
turn the power OFF.
More operations are described in the Function Key
directions below.
Function keys
1. key
ON/OFF power ON/OFF key: Press once to turn the
power ON. Press the key for more than 2 seconds to
SHIFT
ON/OFF
SHIFT
ON/OFF
HOLD
Light
8
turn the power OFF.
SHIFT second function key: Press the key to enable
the second function of any key, and a SHIFT icon will
display on the LCD.
The function of key:
SHIFT disable：MM、MOD 、UNIT
SHIFT enable：LIMIT、Hi/Lo、TYP
2. T1-T2 key
Press the key to enable the T-T2 function. The
T-T2 icon will display on the LCD.
3. key
MM function: Press the key to store the present
reading of T and T2. Up to five groups of data can be
stored.
In the MEM mode, press the T1-T2 or UNIT keys to
view the recorded data up and down, and press the
MM
LIMIT
9
MOD or HOLD keys to select T or T2.
When data is full (5 sets), the OU icon will be displayed.
To clear memory, press the MM key for more than 2
seconds. the CLER icon will be displayed.
Press LIMIT To enable the Hi/Lo alarm function.
Press SHIFT then press the LIMIT key to turn the
Hi/Lo alarm ON or OFF.
4. key
When pressed, a icon will be displayed and the
measurement is held. Press the key again to cancel
the hold function.
Press the key for more than 2seconds and the back
light will be turned on. The icon will be displayed.
Press the key again for more than 2 seconds and the
backlight will be turned off. (The icon will disappear.)
HOLD
Light
0
5. key
Press the UNIT key to select temperature units in
or ℃
To select thermocouple type:
When SHIFT is enabled, press the TYP key to select
K-type and J-type thermocouple.
6. key
Press the MOD key to alternate between
maximum/minimum measurement readout.
Hi/Lo key: The alarm Hi/Lo temperature setting
When the temperature is exceeds the Hi temperature
setting or goes lower than the Lo temperature setting,
the alarm will continue to sound.
Set Hi/Lo Limits: When SHIFT is enabled, press the
Hi/Lo key to enter the Hi/Lo temperature setting:
A. Use SHIFT key to select Hi or Lo setting.
B. Use MOD or HOLD key to change alarm
UNIT
TYP
MOD
Hi/Lo
setting.
C. Use TI-T2 or UNIT key to set temperature.
D. Use SHIFT key to complete the setting.
The Hi/Lo temperature setting
7. AUTO POWR OFF S TTING
The instrument is factory set for Auto Power Off. The
meter will power itself off after 20 minutes if no key is
pressed.
TYPE Hi Lo
K 300℃(2372 ) -200℃(-328 )
J 200℃(2 92 ) -200℃(-328 )
NORMAL
DISPLAY
SHIFT + Hi/Lo Hi
STTING
Lo
S TTING
SHIFT
SHIFT
MOD HOLD
T1-T2
UNIT
TYP
Hi/Lo Light
2
To cancel auto power off, press the HOLD key until the
LCD displays all icons and the buzzer sounds
continuously.
■. Maintenance
1. CL ANING INSTRUCTIONS
The meter may be wiped down with a wet sponge or
cloth using a mild, water based detergent.
NOT:
This unit is not designed for complete submersion or
washing in water.
2. BATT RY RPLAC MNT
Use the following procedure:
When the battery voltage drops below proper
operation range the symbol will appear on the
LCD display and the battery needs to be replaced.
∞ Press the battery cover towards the arrowhead to
open the battery cover.
∞ Replace the battery with three new AAA (.5V)
3
batteries.
∞ Replace the battery cover.
WARRANTY
Sealed Unit Parts Co., Inc. warrants that it will repair or
furnish without charge a similar product to replace any
product which, within the specified warranty term after the
date of sale by the Wholesaler, is proved to the satisfaction
of Sealed Unit Parts Co., Inc. , to have been defective at
the time it was sold. Said warranty is in effect only when
said item is used in accordance with the instructions and
recommendations of Sealed Unit Parts Co., Inc.
This warranty applies only to products which after
shipment from the factory, have not been altered, changed,
repaired, or treated in any manner whatsoever.
This warranty to repair or replace is the only warranty
either expressed, implied or statutory and is the only
4
warranty being issued herein; Sealed Unit Parts Co., Inc.'s
liability in connection with its products is expressly limited
to the repair or replacement of defective parts. All other
damages and warranties, statutory or otherwise, are being
expressly excluded.
No representative of Sealed Unit Parts Co., Inc. has
authority to change this warranty in any manner
whatsoever. No attempt to repair or promise to repair or
improve any part covered by this warranty by any
representative of this company shall be effective unless
signed by a properly authorized officer of Sealed Unit Parts
