Supco LIT6P User manual

1
LIT6P
Infrared Thermoneter
With Probe
User
Manual

2
1
. Introduction
Th
e LIT6P is a convenient non
contact
infra
red thermometer with probe.
It
combines two precision thermometers in one
unit: a non
contact infra
red thermometer and
a
thermal penetration probe. The non
contact
mode can be used for quick scans of a surface
temperature, while the probe mode is used to
accurately measure internal temperatures.
2
. SafetyInformation
·
Please read the following information
carefully before using the meter.
Warning:Do not point laser directlyat
an eye or reflective surfaces.
Caution:
When
ambie
nt temperature changes quickly,
allow 30 minutes for the meter to acclimate
before taking measurements
.
Avoid
Electro Magnetic Fields (EMF)
from
arc weld
ing, induction furnaces, etc…
Do
not leave the unit on or near high
temperature objects.

3
3
. Instrument Description
LCD display
②
°F /°C selection button
③
Scan button
④
Infrared sensor
⑤
Laser targeting aperture
⑥
Probe sensor
⑦
Battery cover
SCAN
¡ãC/¡ãF
1
2
3
4
5
6
7

4
LCD
Display
Infrared measurement indication
②
Laser indication
③
Data hold indication
④
Probe measurement indication
⑤
Low battery indication
⑥
°C temperature unit
⑦
°F temperature unit
4
. Specifications
·
Infra red:
Range: 4℉to 518℉( 20℃to270℃)
Resolution: 0.1℉/ 0.1℃
Accuracy:
± 9℉ for 4℉ to 32℉(±5℃ for 20℃ to
0
℃)
±1.5% of reading +5℉(3℃) for 32℉ to 518
℉
1
2
3
4
5
6
7
6
7

5
(0℃ to 270℃)
Field of view: 6:1
Typical Distance to Target: up to 3 ft. (1 m)
Laser power: <1mW
Emissivity: 0.97
Over range indication: “OL” or “ OL”
·
Probe:
Range: 58℉ to 518℉ (50℃ to 270℃)
Resolution:
0.2℉(0.1℃) for 58℉to 392℉ ( 50℃ to
200℃)
2℉(1℃) for 392℉ to 518℉ (200℃
to
270
℃)
Accuracy:
58℉ to 4℉( 50℃ to 20℃): ±1.5% of rdng +2℉(1℃)
4℉ to 392℉ ( 20℃ to 200℃): ±1.0% of rdng +2℉
(1℃)
392℉ to 518℉(200℃ to 270℃): ±2.0% of rdng +7℉
(4℃)
Measurement Period: every 2 sec.
·
Operating environment:
Infra red: 32℉ to 104℉(0℃ to 40℃),10 to
90%RH
Probe: 32℉ to 122 ℉(0 ℃ to 50 ℃) ,10
to
90%RH
Storage environment:
14℉ to 140℉ ( 10℃ to 60℃),≤75%RH
·
Auto power off: After 30 seconds
·
Battery: 3 AAA (1.5V)
·
Dimensions:
7.16”x1.93”x1.7”
(
182mm×49mm×43mm)
·
Weight: 4.23 oz. (120g) Approx.

6
5
. Operating Instructions
5
-1. Infra-Red Temperature Measurement
Point the infra
red sensor at
the object, and
press the “SCAN” button
.
Release the
“SCAN” button
and
the measured result will
hold auto
matically.
5
-2. Temperature Probe Measurement
Open the probe. (
Both the Infrared and
probe
will be turned on).
Auto power off will be disabled.
Insert the probe at least ½” (12mm)
into the
target
.
OTE:
The probe tip must be sterilized before
and between
measurements of food s
amples
to avoid cross contamination.
5
-3.TemperatureUnits
Press the
“ /℉” key during measurement to
switch the temperature unit
s from ℃ to ℉
Warning:Do not point laser directlyat
eyesor
indirectlyoff reflective
surfaces.

7
6
. D:S ratio
The th
ermometer has a visual angle and visual
spot size
as follows:
Make sure that the target is larger than the
unit’s visual spot size. The smaller the target,
the closer you should be to it. The relationship
between distance and spot size is
6:1, the
drawing as following:
7
. CLEANING INSTRUCTIONS
The meter may be wiped down with a wet
sponge or cloth using a mild, water based
detergent.
NOTE:
This unit is not designed for complete

8
submersion or washing in water.
8 Replace batteries
If the sign
“
” appears on the LCD
display, it indicates that
the batteries
should be
replaced. Remove the battery cover,
and
r
eplace the exhausted batteries
with new
one
s.
WARRANTY
Sealed Unit Parts Co., Inc. warra
nts that it will
repair or furnish without charge a similar product to
replace any product which, within the specified
warranty term after the date of sale by the
Wholesaler, is proved to the satisfaction of Sealed
Unit Parts Co., Inc. , to have been defec
tive at the
time it was sold. Said warranty is in effect only

9
when said item is used in accordance with the
instructions and recommendations of Sealed Unit
Parts Co., Inc.
This warranty applies only to products which after
shipment from the factory, have
not been altered,
changed, repaired, or treated in any manner
whatsoever.
This warranty to repair or replace is the only
warranty either expressed, implied or statutory and
is the only warranty being issued herein; Sealed
Unit Parts Co., Inc.'s liability
in connection with its
products is expressly limited to the repair or
replacement of defective parts. All other damages
and warranties, statutory or otherwise, are being
expressly excluded.
No representative of Sealed Unit Parts Co., Inc.
has authority to
change this warranty in any

10
manner whatsoever. No attempt to repair or
promise to repair or improve any part covered by
this warranty by any representative of this
company shall be effective unless signed by a
properly authorized officer of Sealed Unit Pa
rts Co.,
Inc.
Sealed Unit Parts Company, Inc. (SUPCO)
2230 Landmark Place
Allenwood, NJ 08720 USA
www.supco.com
[e-mail]
