Kimo TT 21 User manual

➢Connect the thermocouple probe(s).
➢Turn on the device by a long press on “On/Off” key.
➢Put the probe(s) on the required location.
The device displays the temperature measurement with the type of thermocouple and the selected unit below.
For a TT 22
➢Press “Selection” to change the channel channel 1, channel 2, delta T, return to channel 1.
The screen displays “1” for channel 1, “2” for channel 2 and “2-1” for delta T.
If no probe is connected on the channel, the device displays “---“.
THERMOCOUPLE THERMOMETERS
TT 21 - TT 22
DEVICE DESCRIPTION
Hold/Min/Max and On/Off key Selection and K/T thermocouple selection key
PERFORM A MEASUREMENT
° /°F unit selection and OK key
During a measurement
➢Press “Hold/min/max”.
“Hold” is displayed and the measurement is frozen.
From the frozen measurement
➢Press “Hold/min/max”.
“Min” is displayed and the device displays the minimum value since the last interrogation of the frozen channel.
HOLD THE MEASUREMENT, DISPLAY THE MINIMUM AND THE MAXIMUM
USER MANUAL

DEVICE CONFIGURATION
Select the thermocouple type
The device is on and the measurement is displayed.
Below the measured value, the device displays “K” for K thermocouple or “T“ for T thermocouple.
➢Carry out a long press on “K-T” to modify the thermocouple type.
➢Press again “Hold/min/max”.
“Max” is displayed and the device displays the maximum value since the last interrogation of the frozen channel.
➢Press again “Hold/min/max” to restore the measurement display.
For a TT 22:
➢Press ”Selection” to change the channel channel 1, channel 2, delta T, return to channel 1.
The screen displays “1” for channel 1, “2” for channel 2 and “2-1” for delta T.
➢Press “OK” to restore the measurement display.
Set the auto shut-off
The device is on and the measurement is displayed.
➢Carry out a long press on “OK” until “AUTO OFF” blinks.
➢Press“OK”.
The time before the device auto shut-off blinks.
➢Press “Selection” to select the required time before the device shut-off 5, 10, 15, 20, 25, 30 minutes or OFF.
➢Press “OK” to validate.
“AUTO OFF” blinks.
➢Carry out a long press on”OK” to restore the measurement display.
Select the temperature unit
The device is on and the measurement is displayed.
Below the measured value, the device displays the selected unit ”°C“ or ”°F”.
➢Press “° /°F” to modify the unit.
➢Remove the front part at the back of the device.
➢Replace the batteries by AAA LR03 1.5V batteries.
➢Replace the front.
REPLACE THE BATTERIES
To shut off the device
➢Carry out a long press on “On/Off”.
SHUT OFF THE DEVICE
NTang – TT21 – TT22 – 01/06/17 – RCS (24) Périgueux 349 282 095 Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.
Once returned to KIMO, required waste collection will be assured in the respect of the environment in accordance to 2002/96/CE guidelines relating to WEEE
SAFETY INSTRUCTIONS
In order to avoid a risk from a voltage on the element surface on which we want to perform a temperature measurement, the
thermocouple(s) must not be submitted to a voltage higher than 30V alternative or 60V direct relative to earth.
In order to avoid any risk of a device damaging, the voltage between the two thermocouples must not be higher than 0.5V.
