Operator's Manual
REV 1.0
Mobility Scooter
WARNING:
Carefully review and understand all INSTRUCTIONS prior to operating this device. Failure to follow
the safety rules and other basic safety precautions may result in serious personal injury. Keep these
instructions in a safe place and accessible so that they can be reviewed as required. Keep these
instructions to assist in future servicing needs.

A mobility scooter is not a toy. It is an electrically powered scooter and failure
to follow safe operating procedures and safety warnings at all times could
result in serious personal injury or death in addition to the injury or death of
others.
The symbols below are used throughout this owner’s manual and on the scooter to identify
warnings and important information. It is very important for you to read them and understand
them completely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow
designated procedures can cause either personal injury, component damage, or
malfunction.
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause personal injury and/or equipment damage.
PROHIBITED! These actions are prohibited. These actions should not be
performed at any time or in any circumstances. Performing a prohibited action can
cause personal injury and/or equipment damage.
CALIFORNIA PROPOSITION 65 WARNING! This product may contain substances
which are known to the state of California to cause cancer and birth defects or other
reproductive harm. For more information, go to www.P65Warnings.ca.gov.
The scooter has been designed and engineered to be very safe during normal operation. As
with all cordless products, certain safety precautions should be taken.
Driving a mobility scooter requires a combination of healthy traits and abilities, including but not
limited to: good vision; strength; coordination; balance and concentration. If you have these
traits and abilities, you are on the right track.
UNDERSTAND THESE SAFETY PRECAUTIONS BEFORE OPERATING MACHINE.
FAILURE To PROPERLY FOLLOW THESE PRECAUTIONS MAY LEAD To A FIRE, EXPLO-
SION, OR ELECTRICAL SHOCK HAZARD.
INTENDED USE
The intended use of this Battery Powered Scooter is to provide mobility to persons with full use
of their upper and lower extremities and who are able to support themselves in an upright
position. This product is primarily for indoor use and the outdoor capabilities are limited to hard,
flat, and even surfaces such as concrete, black top, and other similar surfaces. While we
understand that the scooter’s outdoor capabilities are limited, when driving near uneven
obstacles, follow the safety guidelines outlined within the safety section of this manual.
* Non-Medical Device
This product is not a medical device and is not intended to assist, treat, diagnose or alleviate
any medical condition or disability.
1EN

SAFETY INTRODUCTION
1. SAFETY INSTRUCTIONS. The below instructions and tips will help you to operate your
Scooter safely.
PLEASE NOTE - The Scooter is designed to be used by one person at a time and is not
recommended for any person younger than 16 years old.
• Read this Manual and all safety and training instructions and all warning labels before
operating the Scooter.
• Do not carry passengers or exceed the maximum weight capacity.
• Do not mount or dismount the Scooter unless it is resting at a complete stop, on a level
surface, parking brake engaged and is turned off.
• Comply with all local laws and regulations while operating the Scooter.
• Check that all folding levers and clamps are securely locked before use.
• Always slow down before changing directions and turning.
• Always use both hands on the handlebar.
• Always keep your feet on the foot rests when driving the Scooter.
• Always approach small obstacles straight on and at slow speeds. Do not attempt to drive
over curbs, potholes, puddles or any other road hazards. Use common sense when
operating the Scooter. Reckless driving can result in an accident!
2. SAFE OPERATING CONDITIONS:
• Do not operate this scooter in traffic.
• Be very careful with inclines. Read below sections for details
• Do not operate this scooter on surfaces that are wet, frozen, oily, or unpaved.
• Never carry passengers or objects that can hinder your ability to safely operate this
scooter.
• Never use headphones or a cell phone to talk or text while riding.
• Do not exceed the maximum weight capacity.
3. PREGNANT OPERATORS: Pregnant women should not operate this scooter.
4. DRIVING IMPAIRED: Never use alcohol or drugs before or while operating this scooter. The
use of such hinders your ability to safely operate the scooter.
5. STUNTS: This scooter is not designed for stunts or tricks and should not be used as such.
High speeds, jumps, wheelies, and other trick maneuvers are dangerous and can result in
loss of control, accidents, and injury/death to self or others.
6. INCLINES: Never operate this scooter on steep inclines (inclines that have slopes steeper
than a standard handicap ramp). Always climb and descend inclines straight on and at slow
speeds. When climbing inclines, you may need to allow more power to the motor and
maintain your speed depending on the steepness of the hill and rider weight so that the
scooter does not lose momentum.
If the scooter loses momentum and comes to a stop on an uphill, quickly apply the hand
brake and put both feet on the ground. Get off the Scooter and walk the product either up or
down the incline.
The scooter has a short wheel base and a high center of gravity. It may become
unsteady at excessive speeds. Avoid excessive speeds that can be associated with
downhill rides. When going downhill, always actuate the brakes to control the speed. The
scooter has a mechanical brake. Always check the brake BEFORE beginning to go downhill.
Never go downhill without brake being enabled.
Failure to control your speed or attempting a sharp turn when descending a hill can
result in serious injury or death.
7. GUEST USE: Never permit a guest to use this scooter unless the guest has read the user
manual and all the warnings. Never allow more than one person at a time to ride the scooter.
Never exceed the maximum weight capacity.
EN 2

This product should not be used by persons unwilling or unable to take responsibility
for their own actions.
8. INSURANCE: YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR
ACCIDENTS INVOLVING THE USE OF THIS SCOOTER. TO DETERMINE IF COVERAGE
IS PROVIDED, CONTACT YOUR INSURANCE COMPANY OR AGENT BEFORE USING
THE SCOOTER.
9. OPERATOR AGE: Do not allow anyone under the age of 16 to operate this scooter. This
scooter is designed for operation by and the transport of only one person age 16 or older.
10. SURROUNDINGS: Ride your scooter in a controlled environment away from vehicles,
obstacles, and other hazards. Never operate the scooter near steps or swimming pools. Do
not drive the scooter on grass, gravel, or any other textured or bumpy surface.
11. INTENDED USE: This scooter is not designed or intended for stunt tricks, including but not
limited to jumps, back wheel wheelies, front wheel wheelies, or operating while standing on
the scooter. Always stay seated, keep both hands on the handlebar, both feet on the foot
pedal and all three wheels touching the ground while operating the scooter.
12. SPEED: The scooter’s maximum speed gives the scooter the most torque or power for
climbing inclines. For your safety, be careful to control your speed when descending hills or
turning. The scooter has a short wheel base and can become unsteady at excessive
downhill speeds or sharp turns.
Do not use maximum speed while making turns.
13. VISIBILITY: Do not ride your scooter at night or in conditions of poor visibility.
Riding at dawn, dusk, or at times of poor visibility without a lighting system that meets
state and local laws, and without approved reflectors, is illegal, dangerous, and can
result in serious injury or death.
14. TEMPERATURE: Do not use the scooter when the temperature is below 0ºC (32ºF).
15. WEATHER CONDITIONS: Avoid riding in wet or icy conditions. Stop the scooter and walk
it across rough or slippery road conditions.
Wet or icy weather impairs traction, braking, and visibility for riders and other vehicles
and pedestrians sharing the roads. The risk of accident is dramatically increased in wet
or icy conditions.
16. SURFACE CONDITIONS: The scooter is intended for use on hard, flat, dry paved surfaces
without loose debris such as sand, leaves, rocks or gravel. Wet, slick, bumps, uneven or
rough surfaces may impair traction and contribute to possible accidents. Do not ride your
scooter in mud, grass, gravel, sand, ice, or water. Watch out for potential obstacles that
could catch your wheel or force you to swerve suddenly or lose control. Avoid sharp
bumps, drainage grates and sudden surface changes. Stop the scooter and carefully walk
it across rough or slippery road conditions.
17. WATER RESISTANCE: Although some water resistance measures have been made,
riding the scooter through standing water, rain, wet or muddy conditions runs the risk of
severely damaging it. Do not immerse the scooter in water or directly spray the scooter
when cleaning. When parked outside where rain is possible, cover the handlebar controls
with water resistant materials to protect the electric controls.
EN3

18. SAFETY WHEN NOT RIDING: When the scooter is not being used for riding, place it in a
safe stable and secured environment, keep it away from fire, water and other hazards.
When the scooter is in its upright vertical self standing mode, especially in moving public
transportation or other crowded space, pay attention to its stability as accidental
tipping-over could cause personal injury as well as damage to the scooter. Always hold the
handlebar to prevent it from tipping over and falling to the ground.
To save the battery life, SWITCH OFF the power, or REMOVE the battery from scooter,
when reset.
TECHNICAL DETAILS
* Top speed and range per charge depends on rider weight, wind speed, temperature, riding
style, riding surface, battery condition, and other factors. Actual top speed and range per
charge may vary.
EN
Performance
Size & Weight
Tires
Motor
Detachable Battery
Charger
Load capacity
Forward speed
Revise speed
Range per charge
Unfolded dimension
Folded dimension
Handlebar-to-Ground height range
Seat-to-Ground height range
Frame weight
Detachable battery weight
Seat weight
Seat size
Ground clearance
Size
Brake
Brake distance
Input voltage
Type
Voltage
Capacity
Type
Continue working time per charge
Input voltage
Charging time
150kgs (330lbs)
7.5km/h* (4.6mph)
2.9km/h (1.8mph)
8.8km* (5.5miles)
1060x610x940mm (41.7" x 24" x 37")
700×610×430mm (27.5"×24"×16.9")
820~920mm (32.2" ~ 36.2")
520 ~ 580mm (20.5" ~ 22.8")
14.5kgs (32lbs)
0.9kgs (2.0lbs)
6.8kgs (15lbs)
450x480mm (17.7" x 19"）
85mm (3.3") at midframe
8" solid
Dual drum brake, manual
< 1.0m (39")
48V
Brushless hub motor
48V
2.0Ah
Li-ion battery
Up to 1h30min
100-240V
1.5h
SKU# GEUT087
4

8Armrest
6Front wheel
7Frame
13 Rear Wheel
10 Seat
11 Seat Post
9Backrest
12 Battery
Cover
5Turning Clutch
3Seat Post
Clamp
2
Handle Bar
1
Brake Handle
4
Middle Bar
Fig. 1
19 Battery LED
21 Handle Knob
16 Seat Post Clamp
15 Clevis Pin
22 Foot Pedal
20 Accelerator
17
Battery Housing
18 Motor Wheel
23 Folding Clasp
14
Handle
Knob
Fig. 2
CONTROLS AND FEATURES
EN5

Fig. 3
ASSEMBLY
For video instructions, please visit our website at www.greatcircleus.com. We encourage you to
view the video instructions prior to unfolding/folding operation to avoid damage to your scooter.
1. Unfolding Scooter (See Fig. 3)
Take scooter out of box. Loosed belt between foot petal and handle bar which fixed scooter
when transportation. Slowly turn the front wheel to forward till the folding clasp closed. Be
careful and make sure the wires moving smoothly wires inside frame tube, don’t clamp wires.
2. Assemble Handbar (See Fig. 4)
Insert handle bar to the frame. Use M6 bolts that
go through the holes of handle bar and frame,
and fix them with nuts.
HANDLE-BAR ANGLE ADJUSTMENT
2.1. Loosen the hand knob.
2.2. Lift the handle-bar up to a proper angle for
yourself.
2.3. Tighten the hand knob to fix the handle bar.
3. Assemble Seat (See Fig. 5)
Insert Clevis pin to hole of seat post which control
the height of seat, insert seat post to frame, make
pin fully inside notch, and then closed seat post
clamp. Adjust the screw if necessary to make
more tighten.
EN 6
Fig. 4
Fig. 5
Loosen
Tighten

4. Assemble Armrest (See Fig. 6)
Insert armrest to the fixing tube of seat post, and
screw it by handle knob.
5. If necessary, turning the brake handle forward, and
close the screw with Hex key. (See Fig. 7)
VERY IMPORTANT: Always make sure the
components are fixed very well before drive.
FOLDING SCOOTER (See Fig. 8)
1. Make sure power is off.
2. Release seat post clamp under seat, and remove
seat. Close foot pedal.
3. Push the button in folding clasp (1), and open the
clasp (2), slowly turn front wheel backward.
Close it in back frame.
4. Release upper seat post clamp in handlebar, go
down lowest position, and close seat post clamp.
Loosen the hand knob, lay down the handle bar,
and tighten the hand knob to fix handle bar.
5. The scooter can be kept in smallest size.
SEAT HEIGHT ADJUSTMENT
The seat can be repositioned to different heights.
1. Loosen the seat post clamp.
2. Remove seat and its attached seat post by twisting seat left/right, and remove from seat
frame.
3. Remove clevis pin from the seat post.
4. Raise or lower the seat and its attached seat post to the desired seat height.
5. While holding the seat at the desired height, align the adjustment holes of the seat post with
notch of seat frame.
6. Fully insert clevis pin.
7. Tighten the seat post clamp.
EN7
Fig. 6
Fig. 7
2
1
Fig. 8

HANDLE-BAR HEIGHT ADJUSTMENT
The handle-bar can be repositioned to different heights.
1. Loosen the upper seat post clamp.
2. Move up/down handle-bar to desired height.
3. Hold the handle-bar at the desired height, tighten the seat post clamp.
HANDLE-BAR ANGLE ADJUSTMENT
1. Loosen the hand knob.
2. Lift the handle-bar front or back to a proper angle for yourself.
3. Tighten the hand knob to fix the handle bar.
BASKET INSTALLATION
Your scooter has an optional basket. To install the basket, hooks across the handle-bar, and
hold in middle of handle-bar. Then carefully rotate the hooks and rest the hooks on the
handle-bar naturally. And close the Velcro band around the handle bar tube.
OVERVIEW SCOOTER
Power On/Off (See Fig. 9)
The red knob in left hand side is the power switch.
Push on it, power is On. Push on again, power is off.
Forward/Reverse (See Fig. 10)
Control knob also in left hand side. Push upward, scooter driving
direction is forward. Push downward, driving direction is reverse.
It is normal that you engage the scooter after one second when
switch between forward/reverse. This second is the protection
of electrical system.
Brake (See Fig. 11)
The left brake handle is controlled mechanical brake
which lock the drum brake in the right rear wheel.
When actuated brake handle, it will stop scooter
and cut power supply to the motor. Release brake
handle and accelerator, power will connect motor
again. Also, there is parking brake at front of handle.
While actuated brake handle, press the parking brake,
the right rear wheel is locked, and scooter is in
parking situation.
In a safe, controlled environment, please familiarize yourself with the braking distance of the
scooter at different speeds before operating near intersections, pedestrians and other
obstacles.
EN 8
Fig. 9
Fig. 10
Fig. 11

Accelerator (See Fig. 12)
The right thumb control is the accelerator. The further you press
the accelerator down, the more energy you will release to the
motor, the speed will be faster.
CAUTION – Do not make turns at high speeds or on steep
inclines. Your scooter may tip over.
Battery LED display (See Fig. 13)
LED display on handle-bar can show battery capacity easily.
Push the button, 3 LEDs will show the left capacity of battery.
3 LEDs on, capacity is 100%-70%; 2 LEDs on, capacity is
70%-30%; 1 LED on, capacity is less than 30%, it’s better
to charge battery if necessary.
Battery Cover (See Fig. 14)
The battery cover prevent battery from impact. As the
magnet slide at edge, it can close with housing.
Drum Brake (See Fig. 15)
The brake is controlled by brake handle. While actuated brake
handle, the rear wheels are not braked completely, you can
adjust the screw to tighten. Or if brake handle is hard to actuate,
loose the screw a little.
The scooter has two brakes, Fig.15 is shown the righe brake.
DO the same process for left brake that make brake tighten
or loosen
OPERATION
Just like learning to drive a car or ride a bicycle, operating any personal transportation device
inherently includes risk and takes practice. Therefore, use caution as you practice operating
the scooter in various situations. Keep the speed at a reduced level until you’re comfortable
controlling the scooter. The below instructions and practice steps will teach you to maneuver
through doorways, on and off lifts, and up and down ramps.When preparing for your first ride,
select an area that is flat, spacious, and away from traffic and other obstacles. Bring a friend
along to help you follow the instructions while you practice. Start driving with the lowest speed.
Please refer to the Overview section of this Manual for instructions.
EN9
Fig. 12
Fig. 13
Fig. 14
Fig. 15

EN
PRE-RIDE SAFETY CHECK
Get to know the feel of your scooter and its capabilities. We recommend that you perform a
safety check before each use to make sure your scooter operates smoothly and safely.
Perform the following inspections prior to using your scooter:
• Check the condition of the tires. Make sure they are not damaged or excessively worn.
• Check the folding clasp. Make sure it’s locked properly.
• Check all electrical connections. Make sure they are tight and not corroded.
• Check handle-bar and seat connections. Make sure they are secured properly.
• Check the brakes to ensure they operate properly.
• Check the battery LED display to ensure the battery is fully charged.
• Ensure the parking brake is engaged before sitting on the scooter.
BEFORE GETTING ONTO YOUR SCOOTER
• Have you fully charged the battery?
• Ensure the folding clasp is in the locked position.
• Ensure the parking brake is engaged.
• Ensure the power switch is in the “OFF” position.
• Ensure the air temperature is between 32ºF/0ºC to 120ºF/49ºC.
GETTING ONTO YOUR SCOOTER
1. Stand at the side of your scooter.
Never attempt to get onto or off your scooter with the scooter “ON”. Ensure parking
brake is engaged prior to sitting on the scooter.
2.Make certain that the seat is secured into position.
3.Position yourself comfortably and securely in the seat.
4.Make certain your feet are safely on the foot pedal.
OPERATING SCOOTER
The following can adversely affect steering and stability while operating your Scooter:
• Holding onto or attaching a leash to walk your pet.
• Carrying passengers (including pets).
• Hanging any article from the handle-bar.
• Towing or being pushed by another motorized vehicle.
Keep both hands on the handle-bar and your feet on the foot pedal at all times while
operating your Scooter. This driving position gives you the most control over your
vehicle.
1. Push power button on.
2. Release parking brake lever
3. Pull the appropriate side of the handle bar grips. Right if you want to go right, left if you want
to go left.
4. Always start in the lower speed. Lightly press accelerator, make scooter move forward
slowly, to be customed to speed of scooter before use maximum speed.
5. To go straight, move to the center position.
6. To go left, turn handle-bar left. To go right, turn handle-bar right.
7. To stop, release the accelerator and engage the brake handle.
10

GETTING OFF OF YOUR SCOOTER
1. Bring your Scooter to a complete stop.
Never attempt to get onto or off of your scooter with it still on. This will prevent the Scooter from
moving if accidental press accelerator.
2. Press power button to “OFF”.
3. Set the parking brake by engaging the handbrake lever and then engaging the parking brake
lever.
4. Carefully and safely get out of the seat and stand to the side of your Scooter.
TURNS
It is essential to slow down to a reasonably slow speed before initiating a turn. Use extreme
caution when turning on slanted or uneven surfaces. Occasionally you may find yourself
negotiating a curve or corner too fast and the inner rear wheel starts to lift off the ground. If this
happens, immediately reduce your speed, lessen the steering angle and shift your upper body
toward the wheel that is lifting off the ground.
INCLINES AND DECLINES
Incline conditions require special attention to avoid mishaps. The scooter is not designed to go
up steep or long inclines. Be aware that not all ramps are constructed according to government
standards. The government standard for wheelchair ramps is 1 inch (2.5cm) rise per foot
(30cm) (5º incline).
An incline that is too steep or long can create a dangerous situation. The scooter can lose
momentum causing it to slide backwards down the incline or tip over backwards. It is not
recommended to drive the scooter on any ramp, incline or hill that doesn't meet government
wheelchair ramp standards.
Tips for driving the scooter on inclines and declines:
• Never travel up or down on an incline that is potentially hazardous such as one that is wet,
icy, slippery, has loose gravel, etc.
• Always start an incline at the base of the hill and not at an angle.
• Shift your upper body towards the handle-bar to shift weight to the front wheel.
• Slowly press accelerator, to move the scooter forward.
• Never stop the scooter on an incline. Do not zigzag, but travel in a straight line to the top.
• If the scooter loses momentum, quickly apply the hand brake and put both feet on the ground.
Get off the scooter and control scooter either up or down the incline.
• Go very slowly while driving down a ramp. Do not go down the ramp or hill at a side angle.
Try to avoid turns while descending. Keep your hand on the brake handle and slowly apply
pressure if the scooter picks up too much speed.
CURBS
The scooter should not be driven over any curb. Apply the brake, turn off the scooter and get
off the scooter. Lift or walk the scooter around the curb prior to getting back on.
Attempting to drive over a curb can cause the product to tip over backwards resulting in
possible injury and will cause damage to the scooter. Also use caution when driving on
sidewalks near curbs to avoid one wheel falling off the curb. This will cause the scooter to tip
over and can result in serious injury or death.
11 EN

SPEEDBUMPS AND UNEVEN SURFACES
Generally, the scooter can handle slightly uneven surfaces. You should approach each at a
reduced speed and in a direct frontal position.
Please keep in mind that the small wheels cannot roll over objects higher than 2 inches (5cm)
and you may fall if you attempt to do so.
Attempting to drive over speed bumps or uneven surfaces can cause the product to tip over
backwards and can result in serious injury or death.
POTHOLES AND PUDDLES
Avoid all potholes and deep puddles.
Attempting to drive over potholes or deep puddles can cause the product to tip over backwards
and can result in serious injury or death.
INDOOR USE
Similar to an electric wheelchair, you are generally permitted to use the scooter inside of
buildings, airports, shopping malls, stores, theaters, etc. Doors can be a challenge when using
the scooter. Approach each door slowly making sure that the rear wheels will make it through
the door opening. The scooter cannot go into door narrower than 24 inches (62cm).
OUTDOOR USE
The scooter should only be ridden on smooth hard and flat surfaces. It is not designed for off
-road conditions. Do not use the scooter in rain or snow nor drive it through puddles of water.
Slightly uneven surfaces should be approached at a reduced speed and in a direct frontal
position and may require lifting or walking the scooter around the surface.
Please keep in mind that the small wheels cannot roll over objects higher than 2 inches (5cm)
and you may fall if you attempt to do so. You should not tow anything behind the scooter.
BATTERY AND CHARGER
BATTERY
Your scooter requires one 48 Volt Lithium-Ion battery that is easy detachable.
1. Fully charge the battery before first time operation or after a long period of non-usage.
2. For safety reasons, the battery is about 50% charged when shipped from the factory.
3. Before remove battery, make sure power is Off, and scooter stand at flat surface. Open
battery cover, press the grey button of battery, and then you can remove out battery.
4. Insert charger pin to the hole at middle of battery. In charging, the LED light on the charger is
solid red. When fully charged, LED turns solid green.
5. Always charge the battery in a clean, dry location, free of debris.
6. Charge the battery frequently. The battery can be recharged at any time. Do not think that
you need to fully deplete the battery before recharging it. In fact, frequent partial
discharge/charge cycles will prolong the battery life vs. fully discharge/charge cycles.
7. Fully charge the battery before storing the scooter for extended periods.
8. When not in use for long time, remove battery from scooter, and periodically recharge the
battery once every 8 months.
9. Battery damage due to water, collision, improper storage and other non-normal factors is not
covered by the limited manufacturer warranty.
BATTERY LEVEL INDICATOR
LED on battery also shows battery capacity. It’s a little different from LED indicator at
handle-bar.
12EN

1. One LED: 0~40% battery capacity;
2. Two LED: 40%~70% battery capacity;
3. Three LED: 70%~85% battery capacity;
4. Four LED: 85%~100% battery capacity.
Soft Riding Condition. When the battery is nearly depleted, a “soft” riding condition can occur.
A “soft” riding condition means the scooter can move forward at lower speed compared with
fully charged battery. When this happens, turn the scooter back on and drive the scooter under
low speed until you can recharge the battery, or exchange a new battery.
CHARGER
1. The battery is charging when the LED light on the charger is red. When the battery is 100%
charged, the light on the charger will turn solid green.
2. The provided charger has a built-in overcharge protection to prevent the battery from being
overcharged.
3. Charging time is approximately 1.5 hours for a fully discharged battery.
4. Regularly inspect the charger for damage to the cord, plug, enclosure and other parts. In the
event of such damage, the charger must not be used until it has been repaired or replaced.
5. Unplug the charger from the wall outlet when not in use. As a safety mechanism, when the
charger stops charging because the battery is full, the charger must be reset by
unplugging it from the wall outlet before it will resume charging.
6. Use only the charger supplied with this scooter or a recommended replacement
specified by GreatCircle.
Failure to confirm compatibility, properly install, operate and maintain any charger,
component or accessory can result in serious injury or death.
INSTRUCTIONS FOR CHARGING
1. Turn the scooter power off. Open the battery cover and get out battery.
2. Securely plug the charger into the charge port, and plug to power supply.
3. Insert charger pin to the hole at middle of battery.
4. A solid red light on the charger indicates the battery is charging. A solid green light
indicates the battery is fully charged.
5. Remove the plug from the power supply, then remove the battery from charger.
6. You will not damage the battery by riding the scooter until the battery is fully discharged and
the scooter motor shuts down.
BATTERY USE AND CARE WARNINGS
1. Battery must be fully charged before first use.
2. Plug the charger into a 110-240 AC outlet, a red light should appear on the charger. Charge
the battery until the light on the charger turns solid green.
3. Always charge the battery at room temperature. If the battery is used in a cold environment,
allow it to warm up for at least an hour before charging. Cold batteries will not be charged
completely and battery components may be damaged.
4. Only charge battery in well ventilated area away from flammable materials such as cloth or
carpeting.
5. To disconnect charger, remove the plug from outlet, then disconnect the charger from the
battery.
6. DO NOT leave the charger being connected to the battery for more than 24 hours.
7. The battery status indicator is mounted on the top of the battery to allow you to observe the
level of the battery power while in use. To check the charge level, simply press the indicator
button. The lights on the status indicator show the charge level of the battery.
13 EN

8. If battery becomes warm or hot during charging procedure, disconnect it from charger. Allow
battery to return to room temperature, and attempt to charge again. If this persists a second
time, disconnect battery from charger and contact customer service.
9. Battery Maintenance Responsibility: Fully charge and discharge the battery at least once
every 8 months to maintain battery’s health.
10. Store the battery on a full charge.
11. When battery pack is not in use, keep it away from other metal objects like paper clips,
coins, keys, nails, screws, or other small metal objects that can make a connection from
one terminal to another. Shorting the battery terminals together may cause burns or fire.
12. To save the battery life, SWITCH OFF the power of scooter, or REMOVE the battery from
scooter, when reset.
CLEANING, STORING, AND SERVICING
1. KEEP YOUR SCOOTER DRY: Do not ride your scooter in wet conditions unless unavoid-
able. Dry off your scooter immediately.
2. KEEP YOUR SCOOTER CLEAN: Remove dust and dirt from your scooter with a wrung-out,
damp rag. Dry immediately. Never use solvents. Do not spray your scooter down with water
or submerse it.
3. STORAGE: Battery performance is susceptible to temperature. Do not store your scooter in
direct sunlight or in a high temperature environment like inside of your car. Store your
scooter indoors, out of the elements. Room temperature is ideal for storage. Avoid storing
the scooter in wet environments. Recharge the battery in full after it has been completely
discharged and before storing the scooter for longer periods. Even in storage, please
monitor the battery level and recharge the battery fully at least once every 8 months.
4. SERVICE: Should your scooter require service, please contact customer service through our
website (www.greatcircleus.com) or support line: 1-866-493-0524. Your satisfaction is our
greatest priority!
WARRANTY
Twelve (12) months for workmanship of the product, except for wearing parts. Warranty period
starts from the product purchase date. Warranty covers material quality and workmanship only.
Warranty does not cover product for issues caused by improper usage or any operation not in
accordance with the specifications of this manual. Any modification or tampering with the
product in any way voids the warranty.
14EN

Problem
The scooter does
not operate.
The Scooter
Operates
Intermittently.
Short ride time
or runs slow.
Scooter is not
stopped after
actuate brake
handle, or, it
is hard to
actuate brake
handle.
Possible cause
The scooter is not turned on.
The battery is not charged.
The hand brake and parking brake
are inadvertently engaged.
The battery is not locked and secured.
Main circuit was broken.
The battery capacity is low and
cause soft riding condition.
The battery is not locked and
secured into its base.
Rider weight.
Carry dolly or heavy luggage.
Riding conditions.
Battery not fully charged.
Old/Damaged Battery.
Main circuit was not connecting
securely.
Drum brake is too loosed, or too
tighten
Solution
Turn on scooter by pressing power button.
Charge Battery.
Make sure hand brake and parking brake are
not engaged.
Secure battery by locking it in the housing.
Contact customer service at our website
(www.greatcircleus.com) or
support line: 1-866-493-0524
Recharge Battery.
Secure battery by locking it in the housing.
Do not exceed 275 lbs. (125 kg) maximum
weight limit.
Do not carry any dolly and luggage.
Use only on flat, dry surfaces. Avoid inclines
and areas with debris on surface.
Charge battery until full.
Replace Battery.
Contact customer service at our website
(www.greatcircleus.com) or
support line: 1-866-493-0524
Adjust the screw at drum brake at both sides.
TROUBLE SHOOTING
15
Great Circle USA
[email protected]
www.greatcircleus.com
www.greatcircleus.co.uk
EN

Betriebshandbuch
REV 1.0
Mobility Scooter
WARNUNG: Lesen Sie alle ANLEITUNGEN sorgfältig durch, bevor Sie dieses Gerät in Betrieb
nehmen. Die Nichteinhaltung der Sicherheitsregeln und anderer grundlegender Sicherheitsvorke-
hrungen kann zu schweren Verletzungen führen. Bewahren Sie diese Anweisungen an einem
sicheren und zugänglichen Ort auf, damit Sie sie bei Bedarf nachlesen können. Bewahren Sie
diese Anleitung auf, um bei zukünftigen Wartungsarbeiten darauf zurückgreifen zu können.

Ein Mobilitätsroller ist kein Spielzeug. Es ist ein elektrisch angetriebener
Roller und das Versäumnis, sichere Betriebsverfahren und
Sicherheitswarnungen jederzeit zu befolgen, kann zu schweren Verletzungen
oder zum Tod führen, zusätzlich zu den Verletzungen oder dem Tod anderer.
Die nachstehenden Symbole werden in dieser Betriebsanleitung und auf dem Roller
verwendet, um Warnungen und wichtige Informationen zu kennzeichnen. Es ist sehr wichtig,
dass Sie sie lesen und vollständig verstehen.
WARNUNG! Weist auf eine potenziell gefährliche Bedingung/Situation hin. Die
Nichtbeachtung der angegebenen Verfahren kann zu Verletzungen, Schäden an
Komponenten oder Fehlfunktionen führen.
VERPFLICHTET! Diese Maßnahmen müssen wie angegeben durchgeführt
werden. Die Nichteinhaltung der vorgeschriebenen Maßnahmen kann zu Verletzun-
gen und/oder Geräteschäden führen.
VERBOTEN! Diese Handlungen sind verboten. Diese Handlungen dürfen zu
keiner Zeit und unter keinen Umständen durchgeführt werden. Die Ausführung
einer verbotenen Handlung kann zu Verletzungen und/oder Geräteschäden führen.
KALIFORNISCHE PROPOSITION 65 WARNUNG! Dieses Produkt kann Stoffe
enthalten, die im Bundesstaat Kalifornien dafür bekannt sind, dass sie Krebs,
Geburtsfehler oder andere Fortpflanzungsschäden verursachen. Weitere
Informationen finden Sie unter www.P65Warnings.ca.gov.
Der Scooter wurde so konzipiert und konstruiert, dass er bei normalem Betrieb sehr sicher ist.
Wie bei allen kabellosen Produkten sollten bestimmte Sicherheitsvorkehrungen getroffen
werden.
Das Fahren eines Scooters erfordert eine Kombination gesunder Eigenschaften und
Fähigkeiten, einschließlich, aber nicht beschränkt auf: gutes Sehvermögen, Kraft, Koordination,
Gleichgewicht und Konzentration. Wenn Sie über diese Eigenschaften und Fähigkeiten
verfügen, sind Sie auf dem richtigen Weg.
MACHEN SIE SICH MIT DIESEN SICHERHEITSVORKEHRUNGEN VERTRAUT, BEVOR
SIE DAS GERÄT IN BETRIEB NEHMEN. DIE NICHTBEFOLGUNG DIESER
VORSICHTSMASSNAHMEN KANN ZU EINEM BRAND, EINER EXPLOSION ODER EINEM
ELEKTRISCHEN SCHLAG GEFÄHRDEN.
VERWENDUNGSZWECK
die ihre oberen und unteren Extremitäten voll nutzen können und in der Lage sind, sich in einer
aufrechten Position zu halten. Dieses Produkt ist in erster Linie für den Innenbereich und die
Outdoor-Fähigkeiten sind auf harte, flache und ebene Oberflächen wie Beton, schwarz Top,
und andere ähnliche Oberflächen beschränkt. Obwohl wir verstehen, dass die Fähigkeiten des
Rollers im Freien begrenzt sind, befolgen Sie beim Fahren in der Nähe von unebenen
Hindernissen die Sicherheitsrichtlinien, die im Sicherheitsabschnitt dieses Handbuchs
beschrieben sind.
* Nichtmedizinisches Gerät
Dieses Produkt ist kein medizinisches Gerät und dient nicht der Unterstützung, Behandlung,
Diagnose oder Linderung von Krankheiten oder Behinderungen.
1DE

EINFÜHRUNG IN DIE SICHERHEIT
1. SICHERHEITSHINWEISE. Die folgenden Hinweise und Tipps helfen Ihnen, Ihren Scooter
sicher zu bedienen.
BITTE BEACHTEN SIE - Der Scooter ist für die gleichzeitige Benutzung durch eine Person
ausgelegt und wird nicht für Personen unter 16 Jahren empfohlen.
• Lesen Sie dieses Handbuch und alle Sicherheits- und Schulungsanweisungen sowie alle
Warnhinweise, bevor Sie den Scooter in Betrieb nehmen.
• Befördern Sie keine Passagiere und überschreiten Sie nicht die maximale Tragfähigkeit.
• Steigen Sie nur dann auf den Scooter auf oder ab, wenn er vollständig zum Stillstand
gekommen ist, auf einer ebenen Fläche steht, die Feststellbremse angezogen und
ausgeschaltet ist.
• Halten Sie sich beim Betrieb des Scooters an alle örtlichen Gesetze und Vorschriften.
• Vergewissern Sie sich vor der Benutzung, dass alle Klapphebel und Klammern sicher
verriegelt sind.
•
Verlangsamen Sie immer die Geschwindigkeit, bevor Sie die Richtung ändern oder wenden.
• Halten Sie den Lenker immer mit beiden Händen fest.
• Stellen Sie Ihre Füße beim Fahren des Scooters immer auf die Fußstützen.
• Fahren Sie kleine Hindernisse immer geradeaus und mit langsamer Geschwindigkeit an.
Versuchen Sie nicht, über Bordsteine, Schlaglöcher, Pfützen oder andere Straßenhin-
dernisse zu fahren. Benutzen Sie Ihren gesunden Menschenverstand, wenn Sie den
Scooter bedienen. Rücksichtsloses Fahren kann zu einem Unfall führen!
2. SICHERE BETRIEBSBEDINGUNGEN:
• Fahren Sie diesen Roller nicht im Straßenverkehr.
• Seien Sie bei Steigungen sehr vorsichtig. Lesen Sie die folgenden Abschnitte für Details
•
Fahren Sie diesen Roller nicht auf nassen, gefrorenen, öligen oder unbefestigten Oberflächen.
• Nehmen Sie niemals Passagiere oder Gegenstände mit, die Ihre Fähigkeit, den
Roller sicher zu bedienen, beeinträchtigen könnten.
• Benutzen Sie während der Fahrt niemals Kopfhörer oder ein Handy, um zu telefonieren
oder SMS zu schreiben.
• Überschreiten Sie nicht die maximale Gewichtskapazität.
3. SCHWANGERE BENUTZER: Schwangere Frauen sollten diesen Scooter nicht bedienen.
4. FAHREN UNTER ALKOHOLEINFLUSS: Nehmen Sie niemals Alkohol oder Drogen vor
oder während des Betriebs dieses Rollers. Der Konsum solcher Mittel beeinträchtigt Ihre
Fähigkeit, den Roller sicher zu bedienen.
5. STUNKS: Dieser Roller ist nicht für Stunts oder Tricks ausgelegt und sollte nicht als
solche verwendet werden. Hohe Geschwindigkeiten, Sprünge, Wheelies und andere
Trickmanöver sind gefährlich und können zum Verlust der Kontrolle, zu Unfällen und
Verletzungen/Tod für sich selbst oder andere führen.
6. EINGESCHLOSSEN: Fahren Sie diesen Roller niemals auf steilen Steigungen
(Steigungen, die steiler sind als eine Standard-Behindertenrampe). Befahren Sie
Steigungen und Gefälle immer geradeaus und mit langsamer Geschwindigkeit. Wenn Sie
Steigungen erklimmen, müssen Sie möglicherweise mehr Kraft auf den Motor geben und
Ihre Geschwindigkeit beibehalten, abhängig von der Steilheit des Hügels und dem Gewicht
des Fahrers, damit der Roller nicht an Schwung verliert.
Wenn der Scooter den Schwung verliert und an einer Steigung zum Stehen kommt, ziehen
Sie schnell die Handbremse an und stellen Sie beide Füße auf den Boden. Steigen Sie vom
Scooter ab und gehen Sie mit dem Produkt entweder die Steigung hinauf oder hinunter.
Der Scooter hat einen kurzen Radstand und einen hohen Schwerpunkt. Er kann sich
unruhig bei zu hoher Geschwindigkeit. Vermeiden Sie überhöhte Geschwindigkeiten,
die mit Bergabfahrten verbunden sein können. Wenn Sie bergab fahren, betätigen Sie
immer die Bremsen, um die Geschwindigkeit zu kontrollieren. Der Scooter hat eine
mechanische Bremse. Prüfen Sie immer die Bremse, BEVOR Sie mit dem Bergabfahren
beginnen. Fahren Sie niemals bergab, ohne dass die Bremse aktiviert ist.
DE 2

Wenn Sie Ihre Geschwindigkeit nicht kontrollieren oder beim Bergabfahren eine scharfe
Kurve fahren, kann dies zu schweren Verletzungen oder zum Tod führen.
7. GASTBENUTZUNG: Erlauben Sie niemals einem Gast, diesen Roller zu benutzen, es sei
denn, der Gast hat die Gebrauchsanweisung und alle Warnhinweise gelesen. Erlauben Sie
nie mehr als einer Person auf einmal, den Roller zu fahren. Überschreiten Sie niemals die
maximale Gewichtskapazität.
Dieses Produkt sollte nicht von Personen verwendet werden, die nicht willens oder in
der Lage sind, Verantwortung für ihr eigenes Handeln zu übernehmen.
8. VERSICHERUNG: IHRE VERSICHERUNGSPOLICE DECKT MÖGLICHERWEISE KEINE
UNFÄLLE AB, DIE MIT DER VERWENDUNG DIESES SCOOTERS ZUSAMMENHÄNGEN.
WENDEN SIE SICH AN IHRE VERSICHERUNGSGESELLSCHAFT ODER IHREN
VERTRETER, BEVOR SIE DEN ROLLER BENUTZEN, UM FESTZUSTELLEN, OB
VERSICHERUNGSSCHUTZ BESTEHT.
9. BEDIENERALTER: Erlauben Sie niemandem unter 16 Jahren, diesen Roller zu bedienen.
Dieser Roller ist für den Betrieb durch und den Transport von nur einer Person im Alter von
16 oder älter konzipiert.
10. UMGEBUNG: Fahren Sie Ihren Scooter in einer kontrollierten Umgebung fern von
Fahrzeugen, Hindernissen und anderen Gefahren. Betreiben Sie den Roller niemals in der
Nähe von Treppen oder Schwimmbecken. Fahren Sie den Roller nicht auf Gras, Schotter
oder einer anderen strukturierten oder holprigen Oberfläche.
11. BESTIMMTER GEBRAUCH: Dieser Roller ist nicht für Stunt-Tricks, einschließlich, aber
nicht beschränkt auf Sprünge, Hinterrad Wheelies, Vorderrad Wheelies, oder Betrieb,
während auf dem Roller stehen, konzipiert oder vorgesehen. Bleiben Sie immer sitzen,
halten Sie beide Hände auf dem Lenker, beide Füße auf dem Fußpedal und alle drei Räder
den Boden berühren, während der Betrieb des Rollers.
12. GESCHWINDIGKEIT: Die Höchstgeschwindigkeit des Rollers gibt dem Roller das meiste
Drehmoment oder die meiste Kraft, um Steigungen zu überwinden. Achten Sie zu Ihrer
Sicherheit darauf, Ihre Geschwindigkeit zu kontrollieren, wenn Sie bergab fahren oder
wenden. Der Roller hat einen kurzen Radstand und kann bei übermäßiger Geschwindigkeit
bergab oder bei scharfen Kurven unruhig werden.
WARNUNG: Fahren Sie beim Abbiegen nicht mit Höchstgeschwindigkeit.
13.
SICHTBARKEIT: Fahren Sie nicht nachts oder bei schlechten Sichtverhältnissen mit Ihrem Scooter.
Das Fahren in der Dämmerung oder bei schlechten Sichtverhältnissen ohne ein
Beleuchtungssystem, das den staatlichen und örtlichen Gesetzen entspricht, und ohne
zugelassene Reflektoren ist illegal, gefährlich und kann zu schweren Verletzungen oder
zum Tod führen.
14.
TEMPERATUR: Benutzen Sie den Scooter nicht, wenn die Temperatur unter 0ºC (32ºF) liegt.
15. WETTERBEDINGUNGEN: Vermeiden Sie Fahrten bei Nässe oder Glätte. Halten Sie den
Roller an und gehen Sie ihn über raue oder rutschige Straßenverhältnisse.
Nasses oder eisiges Wetter beeinträchtigt die Traktion, das Bremsverhalten und die
Sicht für Fahrer, andere Fahrzeuge und Fußgänger auf den Straßen. Das Unfallrisiko ist
bei nassen oder vereisten Straßen drastisch erhöht.
16. OBERFLÄCHENBEDINGUNGEN: Der Roller ist für den Gebrauch auf harten, flachen,
trockenen, gepflasterten Oberflächen ohne losen Schutt wie Sand, Laub, Steine oder Kies
vorgesehen. Nasse, glatte, holprige, unebene oder raue Oberflächen können die Traktion
beeinträchtigen und zu möglichen Unfällen beitragen. Fahren Sie Ihren Roller nicht in
Schlamm, Gras, Kies, Sand, Eis oder Wasser. Achten Sie auf mögliche Hindernisse, die Ihr
DE3
