Super Handy GUT099 User manual

Cordless 2 IN 1 Pole
Saw with Hedge Trimmer
Manual
REV 05/20/21
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.

1
Long Hair Alert. Failure to keep long hair away from the air intake could result
in personal injury.
Loose Clothing Alert. Failure to keep loose clothing away from the air intake
could result in personal injury.
Objects throw by the product could hit the user or other bystanders.
Always ensure that other people and pets remain at a safe distance from the
product when it is in operation. In general, children must not come near the
area where the product is working. Minimum distance 15m.
Sweeper Tubes. Do not operate without tubes in place.
Read the instruction manual completely and carefully before using the power
tool.
This marking indicates that this product should not be disposed of with other
household wastes. Follow the disposal instructions within this instruction
manual.
With this symbol the manufacturer confirms that this power tool is in
accordance with applicable European directives.
Do not expose to rain
Be careful!
Wear personal protective equipment. Always wear safety glasses or a face
shield, hearing protection and safety helmet.
Sharp blade can cut limbs.
Wear gloves for cutting protection.
Wear safety shoes for preventing slipping.
The sound power level indicates by LWA in dB.

2
TECHNICAL DATA
SKU
Voltage
No load speed
Blade length
Cutting Length
Battery Pack Charger
GUT099
DC20V
Hedge trimmer 1400PRM
Chain saw 18FT/s
Hedge trimmer 20 Inch
Chain saw bar 9.5 Inch
Hedge trimmer 18Inch
Chain saw bar 7Inch
DC 20V 2.0Ah
Output:22V /2.2A
PART LIST
2 Oil tank cap 11 Trigger switch 20 Oil level incator window
5 Lock tab 14 Assembly lock
6 Telescoping pole 15 Chain/sprocket end cover
sprocket end cover knob
8 Shoulder strap 17 Chain tensioner ring
1
2
3
4
5
6
7
8
910
11
12 13 14 15 16
17 18 19
20
21
22
23 Blade Guard
24 Blade
25 Rotational Button
26 Pin Cover
23
24
25
26

3
SAFETY INSTRUCTIONS
GENERAL SAFETY INSTRUCTIONS
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery pack-operated (cordless) power tool.
• This product is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
• Only use the product in the manner and for the functions described in these instructions.
Work area safety
• Keep work area clean and well lit. Cluttered or dark areas invite accidents
• Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
• Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
Electrical safety
• Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
• Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
• When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of electric shock.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• It is recommended that appliances should be supplied via a residual current device (RCD)
with a tripping current of not more than 30mA.
Personal safety
• Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious
personal injury.
• Use personal protective equipment. Always wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energizing power tools that have the switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.

4
• Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
Cordless garden tool use and care
• Do not force the garden tool. Use the correct garden tool for your application. The correct
garden tool will do the job better and safer at the rate for which it was designed.
• Do not use the garden tool if the switch does not turn it on and off. Any garden tool that
cannot be controlled with the switch is dangerous and must be repaired
• Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the
hands of untrained users.
• Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power tools.
• Keep cutting parts sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
SERVICE
Have your garden tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the garden tool is maintained.
Specific safety warnings for cordless pole chain saw
• Keep all parts of the body away when the saw is operating. Before starting the saw, ensure
that the saw chain is not touch anything. While working with a chain saw, one instant of
careless may result in clothing or body parts caught by the saw chain.
• The appliance is designed for two-handed operation. Always hold the chain saw with your
right hand at the rear handle and your left hand on the front handle.
• Keep the handles dry ,clean and free from oil and grease. Greasy and oily handles are
slippery and cause loss of control.
• Never start the appliance before the chain bar ,saw chain and sprocket chain wheel covering
are correctly assembled.
• Do not work with the appliance on a tree. There is risk of injuries when operating the saw on a
tree.
• Always ensure a stable stance and posture and use the chain saw only if you are standing on
a solid, safe and level floor.
• Reckon with the fact that while cutting a branch under tension, it is likely to recoil or rebound.
• Be particularly careful while cutting undergrowth and young trees. The thin material may get
caught in the saw chain and hit you or make you lose your balance.
• Carry the saw chain at the front handle when it is switched off so that the saw chain is turned
away from your body .Always pull the scabbard over the saw chain when transporting it or
storing it away.
• Follow the instructions for lubrication, tightening the chain and replacing accessories .A chain
that has not been tightened or lubricated properly may either snap or enhance the risk of a
rebound or recoil.
• Use the appliance to saw only wood. Do not use the chain saw for work that it is not designed
or intended for.

5
Specific safety warnings for cordless pole hedge trimmer
• Keep all parts of the body away from the cutter blade. Do not remove cut material or hold
material to be cut when blades are moving. Make sure the product is switched off when
clearing jammed material. A moment of inattention while operating the product may result in
serious personal injury.
• Carry the product by the handle with the cutter blade stopped. When transporting or storing
the product always fit the cutting device cover. Proper handling of the product will reduce
possible personal injury form the cutter blades.
• Hold the product by insulated gripping surfaces only, because the cutter blade may contact
hidden wiring of its own cord. Cutter blades contacting a “live” wire may make exposed metal
parts of the product “live” and could give the operator an electric shock.
• Check the hedge for foreign objects before operation, e.g., Wire fences.
• Hold the product properly, e.g. With both hands if two handles are provided. Loss of control
can cause personal injury.
Training
• Read the instructions carefully. Be familiar with the controls and the proper use of the
appliance.
• Never allow children to use the product.
• Never allow people unfamiliar with these instructions to use the appliance. Local regulations
may restrict the age of the operator.
• Never operate the appliance while people, especially children, or pets are nearby.
• The operator or user is responsible for accidents or hazards occurring to other people or their
property.
Preparation
• Wear safety goggles and ear muffs while operating.
• Always wear substantial footwear and long trousers. Do not operate the equipment when
barefoot or wearing open sandals.
• Always wear suitable working clothes during working, which allow freedom of movement.
• Never operate the appliance which is damaged, incomplete or changed without approval of
the manufacturer.
Operation
• Disconnect the battery from the product whenever you leave the product, before clearing a
blockage, before checking, cleaning or working on the product, if the product starts to vibrate
abnormally.
• Operate the product only in daylight or in good artificial light.
• Do not overreach and keep your balance at all times.
• Always be sure of your footing on slopes.
• Walk, never run.
• Keep all ventilation openings clear of debris.
MAINTENANCE AND STORAGE
1). Keep all nuts, bolts and screws tight to be sure the product is in safe working condition.
2). Check the collection bag frequently for wear or deterioration.
3). Replace worn or damaged parts.
4). Store the product only in a dry place.
5). Use only spare parts and accessories approved by the manufacturer.

RESIDUAL RISKS
Even if you are operating this product in accordance with the provisions, residual risks will
always still remain. The following dangers can arise in connection with the structure and design
of this product:
1). Health defects resulting from vibration emission if the product is being used over longer
period of time or not adequately managed and properly maintained.
2). Injuries and damage to property to due to broken accessories or hidden objects that are
suddenly dashed.
3). Injuries and damage to property to due to thrown and fallen objects.
This product produces an electromagnetic field during operation! This field may under some
circumstances interfere with active or passive medical implants! To reduce the risk of serious or
fatal injury, we recommend persons with medical implants to consult their physician and the
medical implant manufacturer before operating this product!
VIBRATION AND NOISE REDUCTION
To reduce the impact of noise and vibration emission, limit the time of operation, use low-vibra-
tion and low-noise operating modes as well as wear personal protective equipment.
EMERGENCY
Familiarise yourself with the use of this product by means of this instruction manual. Memorise
the safety directions and follow them to the letter. This will help to prevent risks and hazards.
1). Always be alert when using this product, so that you can recognize and handle risks early.
Fast intervention can prevent serious injury and damage to property.
2). Stop the motor and disconnect the battery from the product if there is any malfunction. Have
the product checked by a qualified professional and repaired, if necessary, before you put it
into operation again.
SAFETY WARNINGS AND INSTRUCTIONS: BATTERIES
• Do not disassemble or open, drop (mechanical abuse), crush, bend or deform, puncture, or
shred.
• Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or
expose to water or other liquids, or expose to fire, excessive heat including soldering irons, or
put in microwave oven.
• Only use the battery/tool with a charging system specified by the manufacturer/supplier.
• Do not short-circuit a battery or allow metallic or conductive objects to contact both battery
terminals simultaneously.
• Dispose of used batteries promptly according to the manufacturer/supplier’s instructions.
• Improper battery/tool use may result in a fire, explosion, or other hazard.
• Battery/tool usage by children should be supervised.
SAFETY WARNINGS AND INSTRUCTIONS: CHARGING
1. This manual contains important safety and operating instructions.
2. Before using battery charger, read all instructions and cautionary warnings on battery
charger and product using battery. CAUTION: To reduce the risk of injury, use this charger
only with this product. Batteries in other products may burst causing personal injury or
damage.
3. Do not expose charger to rain or snow.
4. Use of an attachment not recommended may result in a risk of fire, electric shock, or injury
to persons.
6

7
5. To reduce risk of damage to electric plug and cord, pull by plug rather than cord when
disconnecting charger.
6. Make sure cord is located so that it will not be stepped on, tripped over, or otherwise
subjected to damage or stress.
7. An extension cord should not be used unless absolutely necessary. Use of improper
extension cord could result in a risk of fire, electric shock or electrocution.
a. An extension cord must have adequate wire size (AWG or American Wire Gauge) for safety,
and to prevent loss of power and overheating. The smaller the gauge number of the wire, the
greater the capacity of the cable; that is, 16 gauge has more capacity than 18 gauge. When
using more than one extension to make up the total length, be sure each extension contains
at least the minimum wire size.
8. Use only the supplied charger when charging your tool. The use of any other charger could
damage the tool or create a hazardous condition.
9. Use only one charger when charging.
10. Do not attempt to open the charger.
11. DO NOT incinerate the tool or batteries even if they are severely damaged or completely
worn out. The batteries can explode in a fire. Toxic fumes and materials are created when
lithium ion battery packs are burned.
12. Do not charge or use battery in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Inserting or removing the battery from the charger may
ignite the dust or fumes.
13. If battery contents come into contact with the skin, immediately wash area with mild soap
and water. If battery liquid gets into the eye, rinse water over the open eye for three minutes
or until irritation ceases. If medical attention is needed, the battery electrolyte is composed of
a mixture of liquid organic carbonates and lithium salts.
Burn hazard. Battery liquid may be flammable if exposed to spark or flame.
CHARGER OPERATION
Charge only iON+ 20V lithium-ion battery packs with their compatible iON+ 20V lithium-ion
charger. Other types of batteries may cause personal injury and damage.To reduce the risk of
electric shock, do not allow water to flow into the charger's AC/DC plug.
When to Charge the iON+ 20V Lithium-Ion Batteries NOTE: The iON+ 20V lithium-ion
battery packs do not develop a "memory" when charged after only a partial discharge.
Therefore, it is not necessary to run down the battery packs before placing them into the
charger.
• Use the battery charge indicator lights to determine when to charge your iON+ 20V lithium-ion
battery packs.
• You can "top-off" your battery packs' charge before starting a big job or after a long day of
use.
Charging Procedure
IMPORTANT: The battery pack is not fully charged at the factory. Before attempting to charge
them, thoroughly read all of the safety instructions.
(1) To assure that the charger you use are applicable to the battery pack.
(2) Plug the charger plug into the charging hole of the battery pack.
(3) Plug the charger into any suitable standard outlet.
(4) Let the battery pack charge initially for the green light is twinkled. If the power lights are all
lighting, the battery pack is fully charged.

8
Recharge discharged batteries as soon as possible after use or battery life may be greatly
diminished. For longest battery life, do not discharge batteries fully.It is recommended that the
batteries be recharged after each use.
IMPORTANT CHARGING NOTES
1. Your tool was sent from the factory in an uncharged condition. Before attempting to use it, it
must be charged.
2. CAUTION: To reduce the risk of damage to the batteries, NEVER charge them in an air
temperature below 40°F (4.5°C) or above 105°F (40.5°C). Also, NEVER charge them if the
battery temperature is below 40°F (4.5°C) or above 105°F (40.5°C). Longest life and best
performance occur when batteries are charged with an air temperature of approximately
75°F (24°C). NOTE: The tool will not charge if the tool temperature is below approximately
32°F (0°C) or above 113°F (45°C).
3. While charging, the charger may hum and become warm to touch. This is a normal
phenomenon and does not indicate a problem.
4. If the batteries do not charge properly --(1) Check current at receptacle by plugging in a lamp
or other appliance. (2) Check to see if receptacle is connected to a light switch which turns
power off when you turn out the lights. (3) Move charger and tool to a surrounding air
temperature of 40°F (4.5°C) to 105°F (+40.5°C). (4) If the receptacle and temperature are
OK, and you do not get proper charging, take or send the tool and charger to us.
5. The tool should be recharged when it fails to produce sufficient power on jobs which were
easily done previously. Battery life may be greatly diminished if batteries are discharged
deeply. DO NOT CONTINUE using product with its batteries in a depleted condition.
Recharge discharged batteries promptly.
6. To maximize battery life:
a. Do not fully discharge batteries.
b. Fully recharge batteries after each use.
c. Store tool in a location where the surrounding air temperature is approximately 40°F-75°F
(4.5°C - 24°C).
d. Disconnect charger from tool after charge is complete.
Fire Hazard. When disconnecting the charger from the tool, be sure to unplug the charger from
the outlet first, then disconnect the charger cord from the tool.
FIRE HAZARD. When remove the batteries from the charger, be sure to unplug the
charger from the outlet first, then remove the batteries from the charger.
Charger plug Charging hole Power light

9
This charger does not automatically turn off when the batteries are fully charged. Please
take care not to leave the batteries in the charger. Switch off or unplug the charger at
the mains when charging is complete.
Charging a Hot or Cold Battery Pack
The green indicator lights on the charger base indicates that the battery packs' temperatures
are outside the charging range. Once the packs are within the acceptable range, normal
charging will take place and the red light will be continuous. Hot or cold battery packs may take
longer to charge.
SAFETY WARNINGS AND INSTRUCTIONS: CHARGING
1. This manual contains important safety and operating instructions.
2. Before using battery charger, read all instructions and cautionary warnings on battery
charger and product using battery. CAUTION: To reduce the risk of injury, use this charger
only with this product. Batteries in other products may burst causing personal injury or
damage.
3. Do not expose charger to rain or snow.
4. Use of an attachment not recommended may result in a risk of fire, electric shock, or injury
to persons.
OPERATION INSTRUCTIONS
Intend use
The pole hedge trimmer is designed for cutting and trimming of high and wide hedges,bushes
and shrubs in domestic gardens.
The maximum cutting capacity must be observed. Do not cut branches exceeding the stated
maximum capacity
The pole chain saw is designed for cutting the branches of standing trees but not intends for
cutting woods as normal chain saw.
The appliance is suitable for the private use in the garden only, not for continuous employment
in the commercial use.
The appliance is designed for use by adults. Young people over 16 years old may use the
appliance under supervision only.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their safety.
Unpacking
This product requires assembly.
Carefully remove the product and any accessories from the box. Make sure that all items listed
in the packing list are included.
Inspect the product carefully to make sure no breakage or damage occurred during shipping.
Do not discard the packing material until you have carefully inspected and satisfactorily
operated the product.

PACKING LIST
Pole hedge trimmer
Pole chain saw
Chain bar
Saw chain
Scabbard
Battery pack
Charger
Shoulder strap
Instruction manual
If any parts are damaged or missing, do not operate this product until the parts are replaced.
Failure to heed this warning could result in serious personal injury.
Do not attempt to modify this product or create accessories not recommended for use with this
product. Any such alteration or modification is misuse and could result in a hazardous condition
leading to possible serious personal injury.
Do not connect to power supply until assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
ASSEMBLY THE CHAIN BAR AND SAW CHAIN
Never start the motor before installing the guide bar, chain, and chain/sprocket
end cover. Without all these parts in place, the clutch can fly off or explode, exposing the user
to potentially serious injuries.
Installing/Replacing Guide Bar + Cutting Chain
Tools and supplies required:
• Hex key wrench (provided)
• Heavy-duty work gloves
NOTE: When replacing the guide bar and chain, use
only identical replacement parts. Makesure the pole
chain saw is disconnected with the battery before
proceeding with installation.
1. Remove the hex bolt by screwing it counterclockwise
with the hex key wrench (Fig. 1).
2. Screw the chain/sprocket end cover knob counterclockwise to release chain/sprocket end
cover (Figs.2-3).
3. Remove the bar and chain from the mounting surface (Fig. 4).
10
Chain/sprocket
end cover Chain/sprocket
end cover knob
Chain/sprocket
end cover
Fig. 2 Fig. 3
Chain/sprocket
end cover Hex bolt
Hex key wrench
Fig. 1

4. Remove the old chain from the bar.
5. Lay out the new saw chain in a loop and straighten
any kinks.
THE SHARP SIDE OF THE TEETH MUST FACE
AWAY FROM YOU IN THE DIRECTION OF THE
CHAIN ROTATION INDICATED ON THE GUIDE
BAR.
If the teeth face backwards, turn the loop over (Fig. 5).
6. Starting at the tip, mount the chain drive links into the
bar groove, leaving a loop at the back of the bar. The
chain will loosely fit until it is placed on the sprocket
(Figs. 6-7).
NOTE: Make certain of the direction of the chain .
If the chain is mounted backwards, the
saw will vibrate abnormally and will not cut.
7. Hold the chain in position on the bar and place
the loop around the sprocket. Fit the bar flush
against the mounting surface so that the bar studs
are in the long slot of the bar and the adjusting
pin is in the chain tension pin hole (Fig. 8).
8. Replace the chain/sprocket end cover by positioning
the cover onto the saw head. Tighten the end cover
knob, but leave the bar free to move for tension
adjustment. Put back the hex bolt by screwing it
clockwise with the hex key wrench.
9. Remove all slack from the chain by turning the chain tensioner ring clockwise until the chain
fits snug against the bar with the drive links in the bar groove (Fig. 9).
NOTE: The chain is correctly tensioned when there is no sag on the underside of the guide bar;
the chain is snug, but can be rotated by hand without binding. For more information on chain
tensioning,
11
Cutting chain
Guide bar
Fig. 4
Chain rotation
Sharp cutting edge
Chain drive link
Fig. 5
Fig. 6
Loop
Fig. 7
Fig. 8
Sprocket
Adjusting pin
Chain tension
pin hole
Chain/sprocket
end cover Chain tensioner
ring
Fig. 9

Connecting to the Telescoping Pole
1. Open the assembly lock on the telescoping pole, and push the chain saw head into the
opening on the end of the pole (Fig. 10).
2. When the lock tabs snap in, lock back the assembly
lock, the pole chain saw will be ready to use (Fig. 11).
3. To remove the chain saw head, release the On/Off
trigger switch and remove the battery. Unlock the
assembly lock. Push the lock tabs on both sides, and pull the chain saw head out (Fig. 11).
OPERATION
Starting and Stopping
1. Slide the battery into the battery compartment until it clicks to lock it into position (Fig. 12).
2. To turn the pole chain saw ON, push and hold the safety lock switch (located on the handle)
forward with your thumb and then squeeze the On/Off trigger switch with your fingers. Once
the tool is running, you can release the safety lock switch (Fig. 13).
3. To turn the tool OFF, release the On/Off trigger switch (Fig. 13).
12
Telescoping pole
Assembly lock
Fig. 10
Lock tab
Assembly lock
Fig. 11
Battery
Fig. 12
Safety lock
switch
On/Off trigger switch
Fig. 13

13
Using the shoulder strap
Always use the shoulder strap when working with the equipment. Switch off the equipment
before you take off the shoulder strap (risk of injury).
1. Hook the carabiner (2) into the strap holder.
2. Slip the shoulder strap (1) over your shoulder.
3. Adjust the length of the shoulder strap so that the strap attachment is at waist level.
4. The shoulder strap is equipped with a buckle. Press the hooks together (3) if you need to put
down the equipment quickly.
Adjusting the Telescoping Pole
This machine is equipped with a telescoping pole which provides up to 14 ft (4.3 m) of
overhead reach. To adjust the telescoping pole, follow the instructions below.
1. Disconnect the saw from the power supply by removing the battery from the compartment.
2. Unclip the telescoping lock to release the pole. Extend the pole to the desired length (Fig.
14).
NOTE: Push poles toward each other to shorten the pole or pull them away from each other to
lengthen the pole. Only extend the pole to the minimum length required to reach the limb.
3. Lock the pole in position by closing the telescoping lock (Fig. 15), and ensure that the pole is
secured.
Failure to lock the telescoping
lock as directed could result in
personal injury.
Adjusting the Multi-Angle Head
The pole chain saw head can be rotated for different cutting angles for 0º, 15º, and 30º (Fig.
16).
Follow the below instructions to adjust angles.
1. Rotate the chain saw head to the desired cutting angle while pressing the rotating buttons
located on both sides simultaneously (Fig. 17).
2. Release the buttons when the chain saw head is set to the desired angle.
NOTE: Failure to properly secure the chain saw head may result in personal injury and/or
property damage.WARNING! Always ensure the chain saw head is urely locked! Do not ttempt
to use the pole chain saw with the head in any other position or unlocked!
Pull Pull
Telescoping lock
Fig. 14
Telescoping lock
Fig. 15
0º
15º
30º
Fig. 16
Rotating button
Front Side
Back Side
Rotating button
Fig. 17

14
ANGLE ADJUSTMENT
To adjust the Trimmer angle, press both sides of the
Rotational Button (24), adjust the Hedge Trimmer
Blade (25) to the desired position and release
until it clicks into place.
ADDING CHAIN BAR AND CHAIN LUBRICANT
The pole chain saw is equipped with an oil automatic system. Chain bar and Chain must
always be oil lubricated when working. Non-observance of this will result in increased wear out
on the bar and saw chain.
NOTE: Pole chain saw comes from the factory with no chain oil added. Lubricant oil level
should also be checked after every 10 minutes of use and refilled as needed.
1. Remove oil tank cover.
2. Carefully pour the bar and chain Lubricant oil into the tank.
3. Wipe off excess oil.
4. Check and fill the oil tank when quick view oil indicator is below the MAX indicator line.
5. Repeat as needed.
NOTE: It is normal for oil to seep from the saw when not in use. To prevent seepage, empty the
oil tank after each use then run for one minute. When storing the unit for a long period of time
(three months or longer) be sure the chain is lightly lubricated; this will prevent rust on the
chain and bar sprocket.
STARTING AND STOPPING
• Wear non-slip gloves for maximum grip and protection.
• Maintain a proper grip on the unit whenever the motor is running. Use your right hand to firmly
grip the rear handle while your left hand has a firm grip on the pole shaft.
• Hold unit firmly with both hands. Always keep your left hand on the pole shaft and your right
hand on the rear handle, so your body is to the left of the chain line. Never use a left-handed
grip, or any stance that places your body or arm across the chain line.
• Never stand directly under the limb you are cutting.
• Be certain the trigger (8 &9) is fully tightened before operating equipment; check them
periodically for tightness during use to avoid serious injury.
• Remove the scabbard (25) from the blade before operation. To turn on the machine, you
should first push the switch lock button (4) and then press the switch handle(3). Release the
switch-handle will make the machine stop.
MAINTENANCE (pole chain saw)
When servicing, use only identical replacement parts. Use of any other parts may create
a hazard or cause product damage.
Always wear safety goggles or safety glasses with side shields during power tool
operation or when blowing dust.
Before inspecting, cleaning or servicing the unit, stop the motor, wait for all moving
parts to stop, and disconnect the battery pack. Failure to follow these instructions can
result in serious personal injury or property damage.

General Maintenance
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use clean clothes to
remove dirt, dust, oil, grease, etc.
Do not at any time let brake fluids, gasoline, petroleum-based products, penetrating oils, etc.,
come in contact with plastic parts. Chemicals can damage, weaken, or destroy plastic, which
may result in serious personal injury.
All chain saw service, other than the items listed in the instruction manual maintenance
instructions, should be performed by competent chain saw service personnel.
Chain Tension
To avoid possible serious injury, never touch or adjust the chain while the motor is running. The
saw chain is very sharp; always wear protective gloves when performing maintenance to the
chain.
Stop the motor and disconnect from power supply before setting the chain tension. Make sure
the guide bar nut is loose to finger tight, turn the chain tensioning screw clockwise to tension
the chain. Refer to Replacing the Bar and Chain for additional information.
NOTE: A cordless pole chain saw is correctly tensioned when there is no slack on the
underside of the guide bar, the chain is snug, but it can be turned by hand without binding.
Chain must be re-tensioned whenever the flats on the drive links hang out of the bar groove
During normal operation, the temperature of the chain will increase. The drive links of a
correctly tensioned warm chain will hang approximately .050 in. out of the bar groove
NOTE: New chain tends to stretch; check chain tension frequently and tension as required.
Chain tensioned while warm, may be too tight upon cooling. Check the “cold tension” before
next use.
Chain Oiler
Use Premium Bar and Chain Lubricant. It is designed for chains and chain oilers and is
formulated to perform over a wide temperature range with no dilution required.
Remove the cap and carefully pour approximately 2.54oz of bar and chain lubricant into the bar
lube reservoir.
Replace the cap and tighten securely.
Check and refill the bar lube reservoir every time the pole saw is used.
NOTE:Do not use dirty, used, or otherwise contaminated lubricants. Damage may occur to the
oil pump, bar, or chain.
Chain Maintenance
For smooth and fast cutting, the chain needs to be maintained properly. The following
conditions indicate that the chain requires sharpening:
Wood chips are small and powdery.
Chain must be forced through the wood during cutting.
Chain cuts to one side. During maintenance of the chain, consider the following:
Improper filing angle of the side plate can increase the risk of a severe kickback.
Depth gauge (or raker clearance) setting determines the height the cutter enters the wood and
the size of the wood chip that is removed. Too much clearance increases the potential for
kickback. Too little clearance decreases the size of the wood chip thus decreasing the chain’s
cutting ability.
If cutter teeth have hit hard objects such as nails and stones, or have been abraded by mud or
sand on the wood, have service dealer sharpen chain.
15

Dull or improperly sharpened chain can cause excessive motor speed during cutting which may
result in severe motor damage.
per chain sharpening increases the potential of kickback. Failure to replace or repair damaged
chain can cause serious injury.
STORING THE PRODUCT
Clean all foreign material from the product. Store idle unit indoors in a dry, well-ventilated area
that is inaccessible to children. Keep away from corrosive agents such as garden chemicals
and de-icing salts.
Always place the scabbard on the saw bar when transporting or storing the pole saw. The
scabbard is a snug fit and must be attached very carefully due to the sharp teeth on the saw
chain. This is best done by grasping the scabbard at one end, in the center
portion of the scabbard, and carefully sliding it over the chain as shown. Use caution to avoid
the sharp teeth of the chain.
NOTE: The saw chain is very sharp. Always wear protective gloves when handling the chain.
MAINTENANCE (pole hedge trimmer)
Chain cuts to one side. During maintenance of the chain, consider the following:
Improper filing angle of the side plate can increase the risk of a severe kickback.
Depth gauge (or raker clearance) setting determines the height the cutter enters the wood and
the size of the wood chip that is removed. Too much clearance increases the potential for
kickback. Too little clearance decreases the size of the wood chip thus decreasing the chain’s
cutting ability.
If cutter teeth have hit hard objects such as nails and stones, or have been abraded by mud or
sand on the wood, have service dealer sharpen chain.
When servicing, use only identical replacement parts. Use of any other parts may create a
hazard or cause product damage.
Always wear safety goggles or safety glasses with side shields during product operation.
Before inspecting, cleaning, or servicing the machine, disconnect the battery pack from
appliance and wait for all moving parts to stop. Failure to follow these instructions can result in
serious personal injury or property damage.
General Maintenance
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use clean cloths to
remove dirt, dust, oil, grease, etc.
Do not at any time let brake fluids, gasoline, petroleum-based products, penetrating oils, etc.,
come in contact with plastic parts.
Chemicals can damage, weaken, or destroy plastic which may result in serious personal injury.
Only the parts shown on the parts list are intended to be repaired or replaced by the customer.
All other parts should be replaced at an Authorised Service Center.
16

Lubricating The Blade
For easier operation and longer blade life, lubricate the hedge trimmer blade before and after
each use.
Stop the motor and disconnect from power supply.
Lay the hedge trimmer on a fl at surface. Apply light weight machine oil along the edge of the
top blade. If you will be using the hedge trimmer for an extended period, it is advisable to oil the
blade during use.
NOTE: Do not oil while the hedge trimmer is running.
Stop the motor and disconnect from power supply.
Lubricate the hedge trimmer as described above.
Reconnect to the power source and resume use.
Cleaning The Pole Hedge Trimmer
Stop the motor and disconnect from power supply.
Clean dirt and debris from the body of the hedge trimmer, using a damp cloth with a mild
detergent.
NOTE: Do not use any strong detergents on the plastic housing or the handle. They can be
damaged by certain aromatic oils such as pine and lemon, and by solvents such as kerosene.
Storing The Pole Hedge Trimmer
Clean all foreign material from the product.
Store it in a well-ventilated place that is inaccessible to children.
Keep away from corrosive agents such as garden chemicals and de-icing salts.
TROUBLESHOOTING
17
PROBLEM
Bar and chain running
hot and smoking.
Motor runs, but chain is
not rotating.
POSSIBLE CAUSE
Check chain tension for
overtightened condition
Bar lube reservoir
empty.
Chain tension too tight.
Check guide bar
and chain assembly.
Check guide bar and
chain for damage.
REMEDY
Tension chain. Refer to
Chain Tension earlier
in this manual. Check
bar lube reservoir.
Retention chain. Refer
to Chain Tension
earlier in this manual.
Refer to Replacing the
Bar and Chain earlier
in this manual.
Inspect guide bar and
chain

Great Circle USA
Support Line: 1-866-493-0524
[email protected]
www.greatcircleus.com
