VENTILATOR USER GUIDE MODEL 724EXP

USER GUIDE
This manual covers the description, cautions, operation and maintenance of Super Vac explosion proof electric PPV ventilators.
Please take the time to read this manual before operating the ventilator.
Save this guide for future reference.
CONTENTS
1. Breakage or Damage During Shipment ................................................................................................................................................................................ 2
2. General Description and Specifications................................................................................................................................................................................ 3
3. Product Safety Precautions.................................................................................................................................................................................................. 4
4. Before Operating Ventilator ................................................................................................................................................................................................ 4
5. Operation............................................................................................................................................................................................................................ 5
6. Maintenance and Repair...................................................................................................................................................................................................... 5
7. Troubleshooting Motor Overheating Problems..................................................................................................................................................................... 6
8. Extension Cords...................................................................................................................................................................................................................7
9. Warranty............................................................................................................................................................................................................................. 8
10. Contact Information .......................................................................................................................................................................................................... 9
11. Parts List..........................................................................................................................................................................................................................10
12. Exploded View ................................................................................................................................................................................................................ 11

User Guide
2
1. Breakage or Damage During Shipment
The transportation company is fully responsible for all shipping damage and will resolve problems promptly if you handle it
correctly. Please read these instructions carefully.
Examine the contents of all shipping cases. If you find any damage, call your transportation agent at once and have them make a
description on the freight or express bill describing the damage and the number of pieces. Then write us and we will send you
the original bill of lading. Get a claim blank from the express or truck company. Fill the claim form out. Attach the claim blank
to the original bill of lading together with a copy of our invoice. Attach a memo on which you show the value of the damaged
goods. Mail or hand these papers to your local transportation agent. They will process your claim with reasonable promptness.
Please note, we cannot and will not enter claims for damages. If we filed claim here, it would be sent to your local freight agent
for verification and investigation. This time can be saved by your filing the claim directly. Every consignee is on the ground
floor and in contact with the local agent who inspects the damaged goods, and thus, each claim can be given individual
attention.
Since our goods are packed to comply with the regulations of all railroad, truck, and express companies, we cannot allow
deduction from any invoice because of any damage, however, be sure to file your claim promptly. Our goods are sold F.O.B.
factory. We take receipt from the transportation company certifying that the goods were delivered to them in good order, and
our responsibility ceases.
It is seldom that any breakage or damage occurs in any of our shipments, and in no case will the customer be out any expense if
they follow the above instructions.
Be sure to keep all damaged goods subject to examination of the truck or express company inspector, who may call on you
some time later. These damaged goods, of course, will belong to them, and they will inform you what to do with them. If you
dispose of these damaged goods, your claim may not be paid.

ELECTRIC VENTILATOR
3
724EXP_PPVentilatorUserGuide-Electric-EXP.doc
REV
03/20/03
2. General Description and Specifications
Super Vac ventilators are specifically designed to provide a convenient and portable source of fresh air. Refer to decal affixed to
ventilator to determine proper operating voltage requirements. Super Vac electric ventilators are single speed, fresh air
ventilators, for use in extreme conditions.
Specifications1
1Specifications are subject to change without notification. Refer to model decal affixed to ventilator to
determine actual specifications.
2EXP = Explosion proof motor, Class 1 group D, Class 2 Group E;F;G
This ventilator is designed for high powered air movement. Super Vac’s patented propeller produces a greater intake of air and
eliminates turbulence at the tips. The high velocity screw action sweeps air back over the motor, enabling it to run cooler. The
patented 7-Blade propeller is cast from aluminum alloy. Each blade is statically balanced for high efficiency and long life.
Explosion proof motors are U.L. rated, not the entire ventilator assembly.

User Guide
4
3. Product Safety Precautions
ØDo not use the ventilator for purposes other than its’ intended use.
ØDo not disassemble or modify the ventilator in any way. Doing so may lead to mechanical failure or personal injury.
ØDo not wear loose clothing that could become entangled in the operating ventilator.
ØDo not operate ventilator without proper inlet or outlet guards in place. If guards are missing or damaged, contact factory
for replacements.
ØDo not place fingers or other foreign objects through inlet or outlet guards. Should a foreign object enter the ventilator,
immediately disconnect power source. Be certain all mechanical motion has stopped before removing foreign object.
ØDo not use with any power voltage other than the indicated voltage.
ØDo not place or operate ventilator on unsteady tables, slanted surfaces or other unstable surfaces.
ØNever handle energized power cords with wet hands.
ØNever let extension cords or plug connection lay in water. Locate the ventilator so that it cannot fall into water
inadvertently.
4. Before Operating Ventilator
§Always operate this ventilator from a proper AC power source supplied through a ground fault interrupter receptacle.
Test receptacle for ground fault before plugging in the ventilator power cord.
§A complete inspection of the ventilator should be made prior to operation.
§Never use power cords with frayed, cut, or brittle insulation.
§Inspect power cord plug for sound connections to the ground fault interrupter circuit.
§Check all threaded fasteners for proper tightness.
§Inspect inlet and outlet guards for damage or missing pieces. Replace damaged or missing guards before operating
ventilator.

ELECTRIC VENTILATOR
5
724EXP_PPVentilatorUserGuide-Electric-EXP.doc
REV
03/20/03
5. Operation
Check ventilator inlet and outlet guards for obstructions. Check and remove from immediate surrounding area any objects that
could be drawn into the ventilator intake.
Place ventilator in desired location before connecting to power supply.
Extend and place any flexible duct as required. Use caution not to direct toxic fumes into confined spaces with the ventilator.
Please refer to the Super Vac Training Manual for Smoke Ventilation for comprehensive instruction on effective ventilation
practices.
Insert power cord plug into AC power receptacle. Pull out switch rod to begin ventilation.
To stop ventilation push in switch rod, remove power cord plug from AC power receptacle.
6. Maintenance and Repair
Maintenance should only be performed by experienced and trained personnel.
Be sure the ventilator is disconnected from the power source before performing any maintenance or repair.
The motor is of heavy duty ball bearing construction. The unit is completely sealed and requires no lubrication for the life of the
motor.
The ventilator blade should be specially checked for build-up of material or dirt which may cause an imbalance. Excessive
imbalance can lead to accelerated wear on motor bearings and vibration. Remove ventilator guards. Clean blade and inside
housing with mild detergent and water. Do not use abrasives, sharp instruments or caustic solvents that may scratch or damage
the aluminum alloy blade..
Intake and exhaust guards are not interchangeable. When replacing guards after cleaning, position them with the rings to the
outside with the row of spot welds holding the rings on the bottom.

User Guide
6
7. Troubleshooting Motor Overheating Problems
CAUTION: Motors are equipped with thermal overload protection. When internal motor temperature exceeds design limits, the
motor will automatically shut off. Motor will automatically restart when it cools sufficiently after overheating. Remove power
cord plug from AC receptacle before examining or working on a motor which has stopped because of overheating. Thermal
overload protection sensitivity increases with frequency. Take preventative steps to correct cause of overheating to assure long
motor life. Most overheating problems are associated with the use of portable power generators as the ventilator power supply.
Common causes of motor overheating:
§Power generator not providing constant voltage. Ventilators are equipped with AC motors designed to operate
on power that falls between ±3% of design specifications.
§Using too small gauge of extension cord.
§Exceeding maximum length extension cord.
§Insufficient unobstructed distance on exhaust side of ventilator. Please refer to the Super Vac Training
Manual for Smoke Ventilation for recommended ventilator placement.
§Insufficient wattage generator. When running multiple ventilators on one generator, plug ventilators in one at
a time. Wait until first ventilator is running at full speed before connecting next ventilator to generator. Do not
exceed generator capacity.
§Using accessory ducting of too small a diameter or excessive length.
§Incorrect amperage circuit breaker for circuit load
§Using reeled or coiled extension cords.

ELECTRIC VENTILATOR
7
724EXP_PPVentilatorUserGuide-Electric-EXP.doc
REV
03/20/03
8. Extension Cords
Do not use reeled or coiled cable. Reeled or coiled cable can produce a counter EMF (electromotive force). The counter EMF
can reduce the current carrying capability of an extension cord. This counter EMF will result in a voltage drop within the motor
instigating a thermal overload condition. Power supply must handle wattage requirements. When conditions require the use of
reeled cable, unreel all cable and place on the ground in very loose overlapping non-uniform coils.
Units1WATTS2Minimum Wire Gauge Maximum Cable Length (feet)
12000 14 150
24000 12 250
36000 10 350
1Multiple units powered by one extension cord.
2Minimum running wattage for multiple units. Startup amperage draw is much higher.

User Guide
8
9. Warranty
Limited Warranty
Five Years
Super Vacuum Manufacturing Company warrants that the equipment is free from defects in materials and workmanship when used and operated for a
period of five years. The responsibility of Super Vacuum Manufacturing Company under this limited warranty is limited to the repair and replacement
of any parts which are found defective and which are returned to Super Vacuum Manufacturing Company at 1303 East 11th Street, Loveland,
Colorado 80537 with transportation charges prepaid (C.O.D. shipments will not be accepted).
Prior to returning defective parts to SUPER VACUUM MANUFACTURING COMPANY, the original purchaser shall make a claim in writing to
SUPER VACUUM MANUFACTURING COMPANY at the above address indicating the model number and type of defect. No parts or equipment
will be received by SUPER VACUUM MANUFACTURING COMPANY for repair or replacement under this warranty without specific written
authority from it in advance.
Any parts damaged by improper installation, overloading, abuse or accident of any type or cause are not covered by this warranty.
All equipment manufactured by us is pre-run and tested before leaving our plant, and is shipped in good working order and condition. We therefore
extend to the original purchasers the following Limited Warranty for the period of five years from the original date of purchase:
1. This warranty does not apply to defects caused by accident, misuse, neglect, or wear and tear, nor can we be held responsible for
incidental and consequential expense and loss, nor does this warranty apply to equipment where alterations have been executed without
our knowledge or consent. These conditions are readily discernable when the equipment is returned to us for inspection.
2. On all component parts not manufactured by SUPER VACUUM MANUFACTURING COMPANY, their warranty is to the extent that
the manufacturer of such component warrants them to SUPER VACUUM MANUFACTURING COMPANY, if at all. Look in your
local business phone directory for the nearest repair station for the brand of parts you have or write to us for the address.
3. If equipment received is found to have been damaged in transit, a claim should be made against the carrier within three days, as we
assume no responsibility for such damage.
4. Any service other than our Authorized Service voids this warranty.
5. This warranty is in lieu of and is intended to exclude all other warranties, express or implied, oral or written, including any warranties of
MERCHANTIBILITY or FITNESS for a particular purpose.

ELECTRIC VENTILATOR
9
724EXP_PPVentilatorUserGuide-Electric-EXP.doc
REV
03/20/03
10. Contact Information
For parts or service information,
contact:
Super Vacuum Manufacturing Company,
Inc.
PO Box 87
Loveland CO 80539
Phone: [phone]
970-667-5146
FAX: [phone]
Internet: www.supervac.com

User Guide
10
11. Parts List
1012-10282 1GUARD 724 24" FRONT-PAINTED
2032-15540 810-24 X 1/2 PHIL PH MS W/TEFLON PATCH BL
3032-10745 21/4 - 20 X 1” HEX CS ZINC
4032-10754 21/4” LOCK WASHER ZINC
5008-10193 1KEYSTOCK 3/16” X 1 3/8” SQUARE
6008-14145 1BUSHING BLADE MAUREY HQ X 5/8"
7003-10050 1BLADE 24" 7 BLADE GAS FINISHED
8018-14026 1SHROUD, 724E, W/GUARD, PAINTED
9021-14920 1MOTOR FOR 720EXP 1HP TEFC BI-DIR
10 019-15062 1724E, MOTOR MOUNT COMPLETE, PAINTED
11 032-14565 23/8-16 X 4 1/2" SOCKET BUTTON HEAD ZINC
12 005-10136 4BUSHING REDUCER 3/4” X 1/2”
13 008-13373 2WHEEL PNEUMATIC DW414 3" HUB CENTER
14 032-11129 23/8” FLAT WASHER USS ZINC
15 032-11133 23/8-16 NYLOK HEX NUT ZINC
16 008-14622 1VENTILATOR BRAKE MOUNT 1
17 008-14631 1724, BRAKE BAR, FINISHED
18 008-14623 2VENTILATOR BRAKE MOUNT 2
19 032-10725 31/4-20 X 5/8 PHIL RH MS
20 024-13473 2FEET RUBBER CONE SHAPE VBM-4002
21 032-13052 25/16-24 NYLOK HEX NUT ZINC
22 008-10189 6PLUG FINISHING SQ RIBBED, BLACK 1"
23 018-10408 1TUBE FRAME 24” PAINTED
24 018-15016 2724 SHROUD SUPPORT BRACKET
25 032-14564 23/8-16 X 2 1/2” SOCKET BUTTON HEAD CS ZN
26 008-10212 2WASHER FLAT #17W14930 MICRO-PLASTIC
27 032-11129 23/8” FLAT WASHERUSS ZINC
28 032-11133 23/8-16 NYLOK HEX NUT ZINC
29 008-10192 2SPRING A-180-S VALCO
30 032-14564 23/8-16 X 2 1/2” SOCKET BUTTON HEAD CS ZN
31 032-11129 23/8” FLAT WASHERUSS ZINC
32 019-10461 1724 HANDLE PAINTED
33 032-11133 23/8-16 NYLOK HEX NUT ZINC
34 008-14586 2STOCK CAP COVER FOR 724 HANDLE TAB
35 032-10750 21/4-20 NYLOK HEX NUT ZINC
36 032-10752 21/4” FLAT WASHER USS ZINC
37 032-10752 21/4” FLAT WASHER USS ZINC
38 032-10723 21/4-20 X 1/2” PHIL PH MS ZINC
39 024-13284 1SPRING SADDLE ISC #0198 W.DBL GRIND
40 032-11133 23/8-16 NYLOK HEX NUT ZINC
41 024-13284 1SPRING SADDLE ISC #0198 W.DBL GRIND
42 008-10211 1STOCK CAP 3TG .250” X 1.0” X 4" OAL BLK
43 019-15000 1724, TILT LEVER, PAINTED
44 005-10120 1CORD 14-3 SO 10' MOLDED
45 021-14921 1APPLETON EXP SWITCH 1- 2 HP
46 032-10790 45/16-18 NYLOK HEX NUT ZINC
47 032-10770 45/16-18 X 1 1/2” HEX CS ZINC
48 032-10786 45/16” FLAT WASHER ZINC
49 025-10544 1DECAL CAUTION GUARDS REMOVED
50 025-13413 1DECAL 724EXP YELLOW SAFETY
51 025-13411 1DECAL 724EXP SER# GREY
52 025-15255 1DECAL SUPER VAC RED W/WHITE

ELECTRIC VENTILATOR
11
724EXP_PPVentilatorUserGuide-Electric-EXP.doc
REV
03/20/03
CAUTION
CONSULT ENGINE
OWNERSMANUAL
BEFORE OPERATING
Model 724EXP
12. Exploded View
