Super Vac 720WT User manual

VENTILATOR USER GUIDE MODEL 720WT

2
VentilatorUserGuide-720WT.doc Revised 11-2022
This manual covers the description, cautions, operation and maintenance of the Super Vac Hydraulic Positive Pressure Ventilator
Model 720WT
Read this manual before operating the ventilator.
Save this guide for future reference.
CONTENTS
1. BREAKAGE OR DAMAGE DURING SHIPMENT................................................................................................................................................... 3
2. GENERAL DESCRIPTION AND SPECIFICATIONS ............................................................................................................................................... 4
3. PRODUCT SAFETY PRECAUTIONS .................................................................................................................................................................. 5
4. BEFORE OPERATING VENTILATOR ................................................................................................................................................................ 5
5. OPERATION ................................................................................................................................................................................................ 6
6. INLET AND DISCHARGE POSITION............................................................................................................................................................... 8
7. PARTS LIST ............................................................................................................................................................................................... 8
7. PARTS LIST ................................................................................................................................................................................................ 9
8. EXPLODED VIEW DRAWING .........................................................................................................................................................................10
9. WARRANTY ...............................................................................................................................................................................................11
10. CONTACT INFORMATION ...........................................................................................................................................................................12

1. Breakage or Damage During Shipment
The transportation company is fully responsible for all shipping damage and will resolve problems promptly if you handle it
correctly. Please read these instructions carefully.
Examine the contents of all shipping cases. If you find any damage, call your transportation agent at once and have them make a
description on the freight or express bill describing the damage and the number of pieces. Then write us and we will send you the
original bill of lading. Get a claim blank from the express or truck company. Fill the claim form out. Attach the claim blank to the
original bill of lading together with a copy of our invoice. Attach a memo on which you show the value of the damaged goods.
Mail or hand these papers to your local transportation agent. They will process your claim with reasonable promptness.
Please note, we cannot and will not enter claims for damages. If we filed claim here, it would be sent to your local freight agent
for verification and investigation. This time can be saved by your filing the claim directly. Every consignee is on the ground floor
and in contact with the local agent who inspects the damaged goods, and thus, each claim can be given individual attention.
Since our goods are packed to comply with the regulations of all railroad, truck, and express companies, we cannot allow
deduction from any invoice because of any damage, however, be sure to file your claim promptly. Our goods are sold F.O.B.
factory. We take receipt from the transportation company certifying that the goods were delivered to them in good order, and our
responsibility ceases.
It is seldom that any breakage or damage occurs in any of our shipments, and in no case will the customer be out any expense if
they follow the above instructions.
Be sure to keep all damaged goods subject to examination of the truck or express company inspector, who may call on you some
time later. These damaged goods, of course, will belong to them, and they will inform you what to do with them. If you dispose
of these damaged goods, your claim may not be paid.
3
VentilatorUserGuide-720WT.doc Revised 11-2022

4
VentilatorUserGuide-720WT.doc Revised 11-2022
2. General Description and Specifications
Super Vac ventilators are specifically designed to provide a convenient and portable source of air. Super Vac positive pressure
ventilators are tested to AMCA PPV Standard 240-95, for use in extreme conditions.
Specifications
1
Model# Engine HP Height x Width x Depth Weight (lbs.)
720WT POK 5.5 25.50” X 25.50” X 18.75” 78 (36 Kg)
1
Specifications are subject to change without notification. Refer to model decal affixed to ventilator to determine
actual specifications.
This ventilator is designed for high powered air movement. Super Vac’s propeller produces a greater intake of air and eliminates
turbulence at the tips. Each blade is statically balanced for high efficiency and long life.
This document is designed to function as a quick start guide and not an in-depth comprehensive instructional manual. Please read
all accompanying documents shipped with your ventilator. Due to the many features of powered equipment thorough familiarity
with the operating controls is essential to assure safe and trouble free operation.

3. Product Safety Precautions
¾Do not use the ventilator for purposes other than its’ intended use.
¾Wear eye and ear protection when operating the ventilator.
¾Never operate ventilator while fatigued.
¾Do not disassemble or modify the ventilator in any way. Doing so may lead to mechanical failure or personal injury.
¾Do not wear loose clothing that could become entangled in the operating ventilator.
¾Never permit anyone to operate ventilator without proper instruction.
¾Do not operate ventilator without proper inlet or outlet guards in place. If guards are missing or damaged, contact factory
for replacements.
¾Do not place fingers or other foreign objects through inlet or outlet guards. Should a foreign object enter the ventilator,
immediately stop engine. Be certain all mechanical motion has stopped.
¾Do not place or operate ventilator on unsteady tables, slanted surfaces or other unstable surfaces.
¾Do not use chock blocks to increase the angle of the ventilator, severe injury could occur.
4. Before Operating Ventilator
A complete inspection of the ventilator should be made prior to operation.
Check all threaded fasteners for proper tightness.
Inspect inlet and outlet guards for damage or missing pieces. Replace damaged or missing guards before
operating ventilator.
5
VentilatorUserGuide-720WT.doc Revised 11-2022

6
VentilatorUserGuide-720WT.doc Revised 11-2022
5. Operation
Check ventilator inlet and outlet guards for
obstructions. Check and remove from immediate
surrounding area any objects that could be drawn
into the ventilator intake.
Place ventilator in desired location before starting.
The two graphs allow you to establish with
precision the best utilization of the apparatus.
Graph 1 depicts rotational speed and water
consumption depending on input feed pressure.
Graph 2 depicts the usable horsepower depending on
the driving torque.
Example: If the inlet pressure of the water supplied
to the motor is 174 psi, and the resisting torque
of the driven machine is 7.4 lb/ft, the rotational
speed is 4560 rpm, water consumption is 117 gpm
(graph 1) and the usable power is 5.5 HP (graph 2)

Inlet Pressure Water Flow Air Flow
BAR PSI GPM LPM CFM CMH
3.3 50 55 208 5168 8781
6.7 100 78 295 10112 17179
10.0 150 98 371 16178 27487
13.3 200 110 416 19100 32450
16.7 250 130 492 22470 38177
The maximum feed pressure is 300 psi (20 bar).
7
VentilatorUserGuide-720WT.doc Revised 11-2022

8
VentilatorUserGuide-720WT.doc Revised 11-2022
6. Inlet and Discharge Position
As delivered, the standard position of the inlet and discharge connections on your 720WT allow for easier connection of water supply lines. This
positioning does not allow full range of tilt positions.
If your application requires the use of the two back tilt positions the inlet and discharge blocks on the water turbine motor may be rotated 90 degrees.
Using a 3mm hex key (not supplied) remove the 4 screws on the block , turning the block to the desired location , reinstalling the 4 screws. Use care to
assure the o-ring is in place for proper seal. Torque screws to 3 lbs./in ( .33 N-m), check for leaks, re-torque as required.
STANDARD POSITION ROTATED POSITION

7. Parts List
MODEL HP BLADE DEPTH X WIDTH X
HEIGHT
720WT 5.5 18” X 7 18.75” X 22” X 20.75”
ITEM PART NUMBER QTY DESCRIPTION ITEM PART NUMBER QTY DESCRIPTION
1 012-00281 1 GUARD 720 24" FRONT-PAINTED
2 032-15540 8 10-24 X 1/2 PHIL PH MS W/TEFLON PATCH BL
3 003-10047 1 BLADE 20" 7 BLADE GAS FINISHED
4 018-14024 1 SHROUD 20" W/GUARD-PAINTED
5 008-10193 4 M6 X 16 X 40 HEX CS ZINC
6 008-14145 4 M6 LOCK WASHER ZINC
7 019-15058 1 MOUNT, MOTOR, WATER TURBINE, 720
8 032-14565 2 3/8-16 X 4 1/2" SOCKET BUTTON HEAD ZINC
9 032-11133 2 3/8-16 NYLOK HEX NUT ZINC
10 018-10404 1 TUBE FRAME 18" PAINTED
11 024-13473 2 FEET RUBBER CONE SHAPE VBM-4002
12 032-13052 2 5/16-24 NYLOK HEX NUT ZINC
13 008-10189 4 PLUG FINISHING SQ RIBBED, BLACK 1"
14 008-13373 2 WHEEL PNEUMATIC DW414 3" HUB
15 032-14565 2 3/8-16 X 4 1/2" SOCKET BUTTON HEAD ZINC
16 008-14145 4 BUSHING REDUCER 3/4” X 1/2”
17 032-11133 2 3/8-16 NYLOK HEX NUT ZINC
18 008-14624 1 720, BRAKE BAR, FINISHED
19 008-14622 1 VENTILATOR BRAKE MOUNT 1
20 008-14623 2 VENTILATOR BRAKE MOUNT 2
21 019-16020 2 SUPPORT, SHROUD, 720
22 032-14563 2 3/8-16X1-3/4 SKT BUTTON HEAD SCREW ZN
23 032-11133 2 3/8-16 NYLOK HEX NUT ZINC
24 032-11129 2 3/8 FLAT WASHERS SAE
25 019-15000 1 720 1/4” X 1” X 12 3/4” TILT LEVER
26 008-10211 1 STOCK CAP 3TG .250” X 1.0” X 4" OAL
27 024-13284 2 SPRING SADDLE ISC #0198 W.DBL GRIND
28 032-11133 2 3/8-16 NYLOK HEX NUT ZINC
29 019-15001 1 HANDLE PAINTED 720
30 032-14568 2 3/8-16 X 2 3/4 SKTHEAD BOLT ZINC
31 032-11129 2 3/8 FLAT WASHERS SAE
32 032-11133 2 3/8-16 NYLOK HEX NUT ZINC
33 008-14536 2 SPRING DUAL SNAP BUTTON ZINC PLATED
34 021-10500 1 MOTOR, POK, WATER TURBINE, 5.5HP, 1.5 NST
35 025-13384 1 DECAL 720WT YELLOW SAFETY
36 025-13383 1 DECAL 720WT SER# GREY
37 025-13426 2 DECAL SUPERVAC VERTICAL LETTER
L1 008-14145 1 BUSHING, TAPERLOCK, MAUREY
L2 008-10193 1 3/16 X 1-3/8 KEYSTOCK
L3 032-10745 2 1/4-20 X 1 HEX HD CAP SCREW
L4 032-10754 2 1/4 LOCK WASHER, SPLIT RING
9
VentilatorUserGuide-720WT.doc Revised 11-2022

8. Exploded View Drawing
10
VentilatorUserGuide-720WT.doc Revised 11-2022

9. Warranty
Limited Warranty
Five Years
Super Vacuum Manufacturing Company warrants that the equipment is free from defects in materials and workmanship when used and operated for a
period of five years. The responsibility of Super Vacuum Manufacturing Company under this limited warranty is limited to the repair and replacement
of any parts which are found defective and which are returned to Super Vacuum Manufacturing Company at 3842 Redman Dr, Fort Collins, CO 80524
with transportation charges prepaid (C.O.D. shipments will not be accepted).
Prior to returning defective parts to SUPER VACUUM MANUFACTURING COMPANY, the original purchaser shall make a claim in writing to
SUPER VACUUM MANUFACTURING COMPANY at the above address indicating the model number and type of defect. No parts or equipment will
be received by SUPER VACUUM MANUFACTURING COMPANY for repair or replacement under this warranty without specific written authority
from it in advance.
Any parts damaged by improper installation, overloading, abuse or accident of any type or cause are not covered by this warranty.
All equipment manufactured by us is pre-run and tested before leaving our plant, and is shipped in good working order and condition. We therefore
extend to the original purchasers the following Limited Warranty for the period of five years from the original date of purchase:
1. This warranty does not apply to defects caused by accident, misuse, neglect, or wear and tear, nor can we be held responsible for incidental
and consequential expense and loss, nor does this warranty apply to equipment where alterations have been executed without our
knowledge or consent. These conditions are readily discernable when the equipment is returned to us for inspection.
2. On all component parts not manufactured by SUPER VACUUM MANUFACTURING COMPANY, their warranty is to the extent that the
manufacturer of such component warrants them to SUPER VACUUM MANUFACTURING COMPANY, if at all. Look in your local
business phone directory for the nearest repair station for the brand of parts you have or write to us for the address.
3. If equipment received is found to have been damaged in transit, a claim should be made against the carrier within three days, as we assume
no responsibility for such damage.
4. Any service other than our Authorized Service voids this warranty.
5. This warranty is in lieu of and is intended to exclude all other warranties, express or implied, oral or written, including any warranties of
MERCHANTIBILITY or FITNESS for a particular purpose.
11
VentilatorUserGuide-720WT.doc Revised 11-2022

10. Contact Information
For parts or service information, contact:
Super Vacuum Manufacturing Company, Inc.
3842 Redman Dr
Fort Collins, CO 80524
Phone: [phone]
970-297-7100
FAX: [phone]
Internet: www.supervac.com
