Super SUPERSAW C100 User manual

SUPERSAWTM MANUAL
Cut any Surface!

To reduce the risk of injury to your
eyes never operate your power tool
unless wearing goggles or, or
properly fitted protective glasses with
adequate top and side protection complying
with ANSI Z87 "+" (or your applicable
national standard). If there is a risk of injury
to your face, SuperbrandTools
recommends that you also wear a face
shield or face screen over your goggles or
protective glasses.
Wear an approved safety hard hat to
reduce the risk of injury to your head. Wear
sound barriers to help protect your hearing.
Continual and regular users should have
their hearing checked regularly.
Be particularly alert and cautious when
wearing hearing protection because your
ability to hear warnings (shouts, alarms,
etc.) is restricted.
THE SUPERSAW
For illustrations and definitions of chain saw
parts see page 11.
WARNING: Never modify this chain
saw in any way. Only attachments
supplied by SuperBrandTools or expressly
approved by SuperBrandTools for use
with the specific SuperBrandTools model
are authorized. Although certain
unauthorized attachments are useable with
SuperBrandTools chain saws, their use
may, in fact, be extremely dangerous.
WARNING: Never operate your
chain saw if it is damaged,
improperly adjusted or maintained, or not
completely and securely assembled.
If this chain saw is subjected to unusually
high loads for which it was not designed (e.g.
heavy impact or a fall), always check that it is
in good condition before continuing work.
Check in particular that the controls and
safety devices are working properly. Do not
continue operating this machine if it is
damaged. In case of doubt, have it checked
by an expert.
THE USE OF THE SUPERSAW
Transporting the SuperSaw
WARNING: Always switch off the motor,
move front hand guard before putting the
chain saw down.
Accidental acceleration of the motor can
cause the saw chain to rotate.
By hand: When transporting your chain
saw by hand, the battery must be removed
and the chain saw must be in the proper
position.
WARNING: Do not carry the chain saw by
the blade.
Before Operation
Take off the chain guard and inspect the
chain saw for proper condition and
operation.
WARNING: Proper tension of the
saw chain is extremely important. In
order to avoid improper setting, make sure
the chain is tightened securely reference
the manual and instructional video for
proper procedure. Seek expert assistance if
you do not have experience operating a
chainsaw.
Always make sure the hexagonal nut(s) for
the sprocket cover is(are) tightened
securely after tensioning the saw chain in
order to secure the bar.
Never start the chain saw with the sprocket
cover loose. Check saw chain tension once
more after having tightened the nut(s) and
SUPERSAWTM

WARNING: To reduce the risk of
personal injury from fire and
explosion, do not use the chain saw in the
presence of flammable liquids or gases.
The sparks from an electric chain saw
may be a source of ignition!
WARNING: Inspect the battery
before and after each use for signs
of damage or aging. In order to reduce the
risk of serious injury from electrocution,
never use your chain saw if the battery,
cracked, worn or damaged.
WARNING: To reduce the risk of
personal injury from fire and
explosion, do not use the chain saw in the
presence of flammable liquids or gases.
The sparks from an electric chain saw
may be a source of ignition!
Holding and Controlling the SuperSaw
Always hold the chain saw firmly when
you are working.
Left-handers should follow these
instructions too. Wrap your fingers tightly
around the handles, keeping the handles
cradled between your thumb and
forefinger. With your hands in this position,
you can best oppose and absorb the push,
pull and kickback forces of your saw
without losing control.
WARNING: To reduce the risk of
cut injuries, keep hands and feet
away from the cutting tool. Never touch a
moving cutting tool with your hand or any
other part of your body.
WARNING: Keep proper footing
and balance at all times. Special
care must be taken in slippery conditions
(wet ground, snow) and in difficult,
overgrown terrain. Be extremely cautious
thereafter at regular intervals (whenever
the saw is shut off). If the saw chain
becomes loose while cutting, switch off the
motor, disconnect the chain saw from the
power supply and then tighten. Never try to
adjust the saw chain while the battery is
connected!
WARNING: After adjusting a saw
chain, start the chain saw, let it run
for a while, then switch motor off and
recheck saw chain tension. Proper saw
chain tension is very important at all times.
Keep the handles clean and dry at all times;
it is particularly important to keep them free
of moisture, pitch, oil, grease or resin in
order for you to maintain a firm grip and
properly control your chain saw.
WARNING: Be sure that the guide
bar and saw chain are clear of you
and all other obstructions and objects,
including the ground. If the upper quadrant
of the tip of the bar touches any object, it
may cause kickback to occur. Never
attempt to engage the chain saw when the
guide bar is in a cut.
Electric Precautions
Special precautions for electric chain saws
must be observed to reduce the risk of
personal injury and property damage from
fire and electric shock.
WARNING: To reduce risk of serious
or fatal injury from electrocution,
never use your chain saw if casing around
motor is cracked or damaged.
WARNING: To reduce the risk of &
electrocution never work in rain or
wet places — the electric motor is not
waterproof! Do not leave the chain saw
outdoors in the rain and do not operate it if
it shows any signs of dampness.
SUPERSAWTM

Working Conditions
Operate your chain saw only under good
visibility and daylight conditions. Work
carefully.
WARNING: Your chain saw is a
one-person machine. Do not allow
other persons in the general work area.
Stop the motor immediately if you are
approached.
WARNING: Even though bystanders
should be kept away from the
running chain saw, never work alone.
Keep within calling distance of others in
case help is needed.
WARNING: To reduce the risk of
injury to bystanders and damage to
property, never let your chain saw run
unattended. When it is not in use (e.g.
during a work break), switch it off and
make sure that unauthorized persons do
not use it. To do this, completely remove
battery and store securely away from saw.
Always store saw in safe location.
WARNING: Use of this chain saw
(including sharpening the saw
chain) can generate dust, mist and fumes
containing chemicals that are known to
cause respiratory problems, cancer, birth
defects, or other reproductive harm. If you
are unfamiliar with the risks associated
with
WARNING: Use of this chain saw
(including sharpening the saw
chain) can generate dust, mist and fumes
containing chemicals that are known to
cause respiratory problems, cancer, birth
defects, or other reproductive harm. If you
are unfamiliar with the risks associated
with the particular dust, mist or fume at
when working on slopes or uneven ground.
Watch for hidden obstacles such as tree
stumps, roots, rocks, holes and ditches to
avoid stumbling.
There is increased danger of slipping on
freshly debarked logs. For better footing,
clear away fallen branches, scrub and
cuttings. Use extreme caution when cutting
small-size brush, branches and saplings
because slender material may catch the
saw chain and be whipped toward you or
pull you off balance.
WARNING: Take extreme care in
wet and freezing weather (rain,
snow, ice). Put off the work when the
weather is windy, stormy or rainfall is
present.
WARNING: To reduce the risk of
injury from loss of control, never
work on a ladder or any other insecure
support. Never hold the machine above
shoulder height. Do not overreach.
Position the chain saw in such a way that
your body is clear of the cutting attachment
whenever the motor is running. Stand to the
left of cut while bucking.
Never put pressure on the chain saw when
reaching the end of a cut. The pressure
may cause the bar and rotating saw chain
to pop out of the cut or kerf, go out of control
and strike the operator or some other
object. If the rotating saw chain strikes
some other object, a reactive force may
cause the moving saw chain to strike the
operator.
SUPER BRAND TOOLS recommends that
first-time users should cut logs on a
sawhorse — see "Cutting small logs." And
or see advice and instruction from a trained
professional.
SUPERSAWTM

issue, consult your employer, governmental
agencies such as OSHA and NIOSH and
other sources on hazardous materials.
California and some other authorities, for
instance, have published lists of
substances known to cause cancer,
reproductive toxicity, etc.
WARNING: Inhalation of certain
dusts, especially organic dusts such
as mold or pollen, can cause susceptible
persons to have an allergic or asthmatic
reaction. Substantial or repeated inhalation
of dust and other airborne contaminants, in
particular those with a smaller particle size,
may cause respiratory or other illnesses.
This includes wood dust, especially from
hardwoods, but also from some softwoods
such as Western Red Cedar. Control dust
(such as saw dust) and mists (such as oil
mist from chain lubrication) at the source
where possible. Use good work practices,
such as always cutting with a properly
sharpened saw chain (which produces
wood chips rather than fine dust) and
operating the unit so that the wind or
operating process directs any dust raised
by the chain saw away from the operator.
Follow the recommendations of
EPA/OSHA/NIOSH and occupational and
trade associations with respect to dust
("particulate matter"). When the inhalation
of dust cannot be substantially controlled,
i.e., kept at or near the ambient
(background) level, the operator and any
bystanders should wear a respirator
approved by NIOSH / MSHA for the type of
dust encountered.
WARNING: Breathing asbestos dust
is dangerous and can cause severe
or fatal injury, respiratory illness or cancer.
The use and disposal of
asbestos-containing products have been
strictly regulated by OSHA and the
Environmental Protection Agency. Do not
use your chain saw to cut or disturb
asbestos or asbestos-containing products.
If you have any reason to believe that you
might be cutting asbestos, immediately
stop cutting and contact your employer or a
local OSHA representative.
Operating Instructions
WARNING: Never touch a saw
chain with your hand or any part of
your body when the motor is running, even
when the chain is not rotating.
In the event of an emergency, disengage
off the motor immediately and remove the
battery.
down.
WARNING: Always remove the
battery before putting the saw
WARNING: The saw chain
continues to move for a short period
after the trigger switch is fully released.
WARNING: Your chain saw is
equipped with a chain guard. It is
designed to reduce the risk of personal
injury in the event of a thrown or broken
chain. From time to time, the guard may be
damaged or removed. To reduce the risk of
personal injury, do not operate a chain saw
with a damaged or missing chain guard.
If this chain saw is subjected to unusually
high loads for which it was not designed
(e.g. heavy impact or a fall), always check
that it is in good condition before continuing
work. Check in particular that the controls
and safety devices are working properly. Do
not continue operating this chain saw if it is
damaged.
Your chain saw is not designed for prying or
shoveling away limbs, roots or other
objects. Such use could damage the cutting
attachment.
SUPERSAWTM

WARNING: When sawing, make
sure that the saw chain does not
touch any foreign materials such as rocks,
fences, nails and the like. Such objects may
be flung off, damage the saw chain or
cause the chain saw to kickback.
WARNING: If the rotating saw chain
strikes a rock or other hard object,
sparks may be created, which can ignite
flammable materials under certain
circumstances. Flammable materials can
include dry vegetation and brush,
particularly when weather conditions are
hot and dry. Do not use your chain saw
around flammable materials or around dry
vegetation or brush when there is a risk of
fire or wildfire. Contact your local fire
authorities or the U.S. Forestry Service if
you have any question about whether
vegetation and weather conditions are
suitable for the use of a chain saw.
WARNING: Take special care when
cutting shattered wood because of
the risk of injury from slivers being caught
and thrown in your direction.
Check the cutting attachment at regular
short intervals during operation, or
immediately if there is a noticeable change
in cutting behavior:
- Switch off the motor.
- Remove battery
The motor is not waterproof. Never
work with the chain saw in the rain
or in wet or very damp locations.
Do not leave the machine outdoors in the
rain.
SUPERSAWTM
A DANGER
Do not rely on the SuperSaw’s
insulation against electric shock. To
reduce the risk of electrocution, never
operate this chain saw in the vicinity of any
wires or cables (power, etc.) which may be
carrying electric current. To reduce risk of
electrocution, take extra precautions when
cutting near power lines. Have the power
switched off before starting cutting work in
the immediate vicinity of power lines.
REACTIVE FORCES
INCLUDING KICKBACK
WARNING: Reactive forces may occur any
time the chain is rotating. Reactive forces
can cause serious personal injury.
The powerful force used to cut wood can be
reversed and work against the operator. If
the rotating saw chain is suddenly and
significantly slowed or stopped by contact
with any solid object such as a log or
branch or is pinched, the reactive forces
may occur instantly.
These reactive forces may result in loss of
control, which, in turn, may cause serious
or fatal injury. An understanding of the
causes of these reactive forces may help
you avoid the element of surprise and loss
of control. Surprise contributes to
accidents.
The most common reactive forces are:
- kickback,
- pushback,
- pull-in.
WARNING: Kickback: Kickback may
occur when the moving saw
chain near the upper quadrant of the bar
nose contacts a solid object or is pinched.
When this occurs, the energy driving the
saw chain can create a force that moves

the chain saw in a direction opposite to the
saw chain movement at the point where the
saw chain is slowed or stopped. This may
fling the bar up and back in a lightning fast
reaction mainly in the plane of the bar and
can cause severe or fatal injury to the
operator.
Kickback may occur, for example, when the
saw chain near the upper quadrant of the
bar nose contacts the wood or is pinched
during limbing or when it is incorrectly used
to begin a plunge or boring cut.
The greater the force of the kickback
reaction, the more difficult it becomes for
the operator to control the chain saw. Many
factors influence the occurrence and force
of the kickback reaction.
These include saw chain speed, the speed
at which the bar and saw chain contact the
object, the angle of contact, the condition of
the saw chain and other factors.
The type of bar and saw chain you use is an
important factor in the occurrence and force
of the kickback reaction.
SuperSaw recommends the use of reduced
kickback bars and low kickback chains.
WARNING: The computer derived
angles of the chain saw standards
may bear no relationship to actual kickback
bar rotation angles that may occur in real
life cutting situations.
In addition, features designed to reduce
kickback injuries may lose some of their
effectiveness when they are no longer in
their original condition, especially if they
have been improperly maintained.
WARNING: An improperly maintained
chain brake may increase the time
needed to stop the saw chain after
activation, or may not activate at all.
Product safety
Attn: California residents, pursuant
to CA Prop. 65, we are required to
warn you of the following:
WARNING: Some dust created by
power sanding, sawing, grinding,
drilling and other construction activities
contains chemicals known to the state of
California to cause cancer, birth defects or
other reproductive harm. Some examples
of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement
and other masonry products and
• Arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies,
depending on how often you do this type of
work. To reduce your exposure to these
chemicals: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
WARNING: This product can expose
you to chemicals including lead,
phthalate or bisphenol A which are known
to the State of California to cause cancer,
birth defects or other reproductive harm.
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING: Read all safety warnings
and instructions. Failure to follow the
warnings and instructions may result in serious
harm, including but not unlimited to injury,
electric shock, and fire. Save all warnings and
instructions for future reference.
1. WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
SUPERSAWTM

b) Do not operate power tools in explosive
environments, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
c) Keep others away while operating.
Operate only in an appropriate safety zone
with adequate space between you and
others.
2. ELECTRICAL SAFETY
a) Power tool plugs must match the
outlet. Never modify the plug in any way.
Do not use any adapter plugs with
grounded power tools. Unmodified plugs
and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with grounded
surfaces such as pipes, radiators,
ranges and refrigerators while holding
the Super Saw plugged in. There is an
increased risk of electric shock if your body
is grounded.
c) Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electric shock
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use marked “W-A”
or “W”. Use of a cord suitable for outdoor
use reduces the risk of electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a Ground
Fault Circuit Interrupter (GFCI)
protected supply. Use of a GFCI reduces
the risk of electric shock.
3. PERSONAL SAFETY
a) Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the
influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, gloves, eye and
hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger
on the switch or energising power tools that
have the switch on invites accidents
d) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool
in unexpected situations.
e) Dress properly. Do not wear loose
clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught
in moving parts
POWER TOOL USE AND CARE
a) Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the
influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing
protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger
SUPERSAWTM

on the switch or energising power tools that
have the switch on invites accidents.
d) Do not let familiarity gained from
frequent use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause
severe injury within a fraction of a second.
5. BATTERY TOOL USE AND
CARE
a) Recharge only with the charger
specified by the manufacturer. A charger
that is suitable for one type of battery pac
may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws or
other small metal objects, that can make
a connection from one terminal to
another. Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions, liquid may
be ejected from the battery; avoid
contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid
ejected from the battery may cause
irritation or burns.
e) Do not use a battery pack or tool that
is damaged or modified. Damaged or
modified batteries may exhibit
unpredictable behaviour resulting in fire,
explosion or risk of injury.
f) Do not expose a battery pack or tool to
fire or excessive temperature. Exposure
to fire or temperature above 130 °C may
cause explosion.
g) Follow all charging instructions and
do not charge the battery pack or tool
outside the temperature range specified
in the instructions. Charging improperly
or at temperatures outside the specified
range may damage the battery and
increase the risk of fire
6. SERVICE
a) Have your power tool serviced by a
qualified repair person using only
original replacement parts. This will
ensure that the safety of the power tool is
maintained.
b) Never service damaged battery
packs. Service of battery packs should only
be performed by the manufacturer or
authorized service providers.
c) If you need other spare parts, please
use the original product, SUPER BRAND
TOOLS can provide you with high
quality parts. Repair attempts by third
parties or unauthorized persons will
void all warranty claims.
SUPERSAW SAFETY
WARNINGS
1. Hold SuperSaw by insulated gripping
surfaces, when performing an operation
where the cutting accessory may
contact hidden wiring. Cutting accessory
contacting a “live” wire may make exposed
metal parts of the power tool “live” and
could give the operator an electric shock.
2. Use clamps or another practical way
to secure and support the workpiece to
a stable platform. Holding the workpiece
by hand or against your body leaves it
unstable and may lead to loss of control.
3. Keep out of reach of children.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred
battery pack.
b) Do not expose battery pack to heat or
fire. Avoid storage in direct sunlight.
c) Do not short-circuit a battery pack. Do
not store battery packs haphazardly in a
box or drawer where they may short-
SUPERSAWTM

SUPERSAWTM
for future reference.
u) Use only the battery pack in the
application for which it was intended.
v) Remove the battery pack from the
equipment when not in use.
w) Dispose of properly.
circuit each other or be short-circuited
by other metal objects.
When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or fire.
i) Keep battery pack out of the reach of
children.
j) Seek medical advice immediately if a
cell or battery has been swallowed.
k) Always purchase the battery pack
recommended by the device
manufacturer for the equipment.
l) Keep battery pack clean and dry.
m) Wipe the battery pack terminals with
a clean dry cloth if they become dirty.
n) Battery pack need to be charged
before use. Always use the correct
charger and refer to the manufacturer’s
instructions or equipment manual for
proper charging instructions.
o) Do not leave battery pack on
prolonged charge when not in use.
p) After extended periods of storage, it
may be necessary to charge and
discharge the battery pack several times
to obtain maximum performance.
q) Battery pack gives its best
performance when it is operated at
normal room temperature (20 °C ± 5 °C).
r) When disposing of battery packs,
keep battery packs of different
electrochemical systems separate from
each other.
s) Recharge only with the original
charger. Do not use any charger other
than that specifically provided for use
with the equipment. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.
t) Retain the original product literature

SUPERSAWTM
ACCESSORIES
Wrench
Original battery
Screwdriver
Original charger
Only use the appropriate accessories
intended for this tool.
Indicator lightState
red
green
charging
charching completed
1
2
3
4
56
7
8
COMPONENT LIST
1. GUIDE CHAIN
2. COMPRESSION NUT
3. GLAND NUT
4. SIDE COVER
5. POWER SWITCH
6. NON-SLIP HANDLE
7. LITHIUM BATTERY
8. GUIDE PLATE
Inspect all components and
accessories prior to first use to
ensure there are no missing parts
or visible damage/defect
*Only use the appropriate accessories
intended for this tool.

SUPERSAWTM
OPERATING STEPS
Loosen the screw nut
counterclockwise and
remove the side cover
Install the side cover and
tighten the screw gland nut
Adjust Chain Tension Twist
the Adjusting Screw Clockwise
to tighten tension. Make sure
the chain is not loose on the guide plate.
Align the hole, then install
the guide plate and chain
1
2
3
4
Insert the battery pack
5
12
3
4
5
Note regarding Step #3: Tightening to an extreme level can cause contact between the side cover and chain.
This can lead to strain on the motor during operation causing reduced perfomance and or damage to the motor.

WORKING HINTS FOR YOUR CORDLESS
RECIPROCATING SAW
If your power tool becomes too hot, run no-load
for 2-3 minutes to cool the motor. Avoid
prolonged usage at very low speeds.
Always use a blade suited to the material
and material thickness to be cut.
Always ensure the work-piece is firmly held
or clamped to prevent movement.
Any movement of the material may affect the
quality of the cut. The blade cuts on the upward
stroke and may chip the uppermost surface or
edges of your work piece when cutting.
MAINTENANCE AND SERVICING
Remove the battery pack from the tool before
carrying out any adjustment, servicing or
maintenance.
Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth.
Always store your power tool in a dry place.
Keep the motor ventilation slots clean. Keep all
working controls free of dust. Occasionally you
may see sparks through the ventilation
slots.This is normal and will not damage your
power tool.
FOR BATTERY TOOLS:
The ambient temperature range for tool and
batteryuse and storage is 0°C-45°C.
The recommended ambient temperature range
for the charging system during charging is
0°C-40°C.z
Note: The new chain will be stretched in the
early stage of use. Please check and adjust to
the appropriate tension frequently, because
over time the chain can loosen and derail. This
may lead to rapid wear of the chain and guide
plate.
The chain must be installed in the correct
direction and aligned with the guide plate. After
installation, please check it again to verify
correct installation.
SUPERSAWTM
Model
Supply voltage V
The most powerful mm
Rated Voltage (V)
Force Voltage (V)
Charging current (A)
Battery Types
(Ah) Yung Shing
C100
120-140
60-80 mm
Li-ion
1.5 - 3. 0/2.0 - 4.0
100 - 240 V AC, 50 - 60 Hz
DC 21/24
1
SUPERBRANDTOOLS.COM
