superbrightleds PLMB-W4BK User manual

LED Low Voltage Landscape Light
Important: Read all instructions prior to installation. PLMB-W4BK
Parts Included
1. Install the lamp head (A) to the threaded center tube (C).
2. Install the bottom ring (D) to the main tube (B) and ground stake (E) to the threaded center tube (C).
3. Toinstall,loosenthegroundwithashovel(notincluded)and/orsoftenthesoilwithwater,thenpressthextureintothe  
 ground.Donotuseahammer.Donotexertexcessiveforceonthexturewhileinstallingasthismaycausethexturetobreak.
4. Remove the quick connector cap (F) from the quick connector base (H). Set the connector block (G) aside.
Beforebeginningassembly,installationoroperationofproduct,makesureall
parts are present. Compare parts with package contents list and diagram on
previouspage.Ifanypartismissingordamaged,donotattempttoassemble,
install or operate the product. Contact customer service for replacement parts.
Estimated Assembly Time: 15 minutes. Helpful tools: Trowel/Shovel.
Preparation Instructions
Assembly Instructions
Instruction Sheet
Part Number:
4400 Earth City Expy, St. Louis MO 63045 866-590-3533 [email protected]
12
A - Lamp Head
B - Main Tube
C - Center Tube
D - Bottom Ring
E - Ground Stake
AA-AdapterTrays
(F,G,H) - Threaded
Connector
5. Four(4)adaptertrays(AA)areincluded.Eachismarkedaccordingly:12AWG,14AWG,16AWGand18AWG.Selecttheadapter
 tray(AA)thatmatchestheguageofthepowercable(notincluded).
6. Placethepowercableontheadaptertray(AA).Alignwiththegroovesinthequickconnectorbase(H)followedbytheconnector 
 block(G).NOTE:Toensureuniformbrightness,therstxtureshouldbeaminimumof10ft.(3m)fromthepowerpack/transformer
(not included).
7. Install the quick connector cap (F) onto the quick connector base (H). Screw the quick connector cap (F) until it is secure, making
sure not to overtighten.

4400 Earth City Expy, St. Louis MO 63045 866-590-3533 [email protected]
Care and Maintenance: To clean, unplug lamp and wipe with a damp, non-abrasive cloth.
Troubleshooting
Warranty
Warning
PROBLEM
LED light will not turn on
LEDlightickers
POSSIBLECAUSE
1. No power.
2. Loose wire to the connector
3. Connector not making contact with
 primarycable.
4. Powerpack/transformer’sphoto
 cellsensorisexposedtounwanted
light source.
1. Wattageofpowerpack/transformer
 maybeexceeded.
CORRECTION ACTION
1. Wattageofpowerpack/transformermaybe
 exceeded.
2. Make sure brass contact pins pierce the plastic
wire insulation and are touching the copper
wires inside.
3. Make sure cover is tight. If problem persists,
 repeatsteps3to6ontheinstructions.
4. Makesurethatpowerpack/transformer’sphoto
 cellsensorisnotexposedtolights.
1. Checkmanufacturer’sspecicationfor 
 maximumwattage.
Themanufacturerwarrantsallofitsproductsagainstdefectsinmaterialsandworkmanshipforthree(3)yearsfromthedateofpurchase.
Ifwithinthisperiodtheproductisfoundtobedefectiveinmaterialorworkmanship,pleasecontactthemanufacturer,acopyofthe
original sales receipt will be required as proof of purchase. The manufacturer will, at its option, repair or replace the product. This
warrantydoesnotcoverproductsbecomingdefectiveduetomisuse,accidentaldamage,improperhandlingand/orinstallationand
specicallyexcludesliabilityfordirect,incidentalorconsequentialdamages.Assomestatesdonotallowexclusionsorlimitationsonan
impliedwarranty,theaboveexclusionsandlimitationsmaynotapplytoyou.Thiswarrantygivesyouspeciclegalrights,andyoumay
haveotherrightsthatvaryfromstatetostate.
• Riskofreorelectricalshock.Readallofthese
instructionsthoroughlybeforeuse.Keepthisinstruction
manual in a safe place for future reference.
• Do not install or connect wires with wet bands.
• Donotinstallthisproductwithin10ft.fromapool,spa,
fountain,orotherbodyofwater.
• Thexturewireandprimarycablesareintendedfor
shallowburial-maximumdepthmustnotexceed3in.
• Forlow-voltagelandscapelightingsystemsonly.
• Do not step on or drive over the branch cable or power
cable.
Caution
• Thislightingxtureisonlysuitablefora12~15volt
powersupply.
• ThisLEDlampisahighlyefcient,extremelylow
wattage,energy-savingproduct.However,itisnot
recommended to use a power pack/transformer over
100watts.
• Useshieldedcableforoutdooruseinthefollowing
sizes:18G,16G,14G,12G.
• Do not submerge in water.
• Donotrepairormodifythisproduct.
