superbrightleds MZ-RGB-REMOTE User manual

MiBoxer 2.4 GHz Wi-Fi Multi Zone RGBW
Controller and Remote
Important: Read all instructions prior to installation.
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V2.1 03/03/2020
User Manual
LDRF-RGB-MZ
Controller: RGB-MZ
Remote: MZ-RGB-REMOTE
1 - 2.4GHz Wi-Fi Compatable RGB Controller
1 - 2.4GHz Sync-able Multizone RF Touch Color Remote
1 - Double-sided Tape
LDRF-RGB-MZ three channel RGB (Red, Green, and Blue) LED controller
with color touchwheel for directly selecting a wide range of colors.
Control up to four separate “zones” of RGB lights to be linked and
controlled by one wireless remote.
O󰀨ers 9 dynamic modes with adjustable brightness, speed and mode
retention (controller resumes modes with the settings previously selected).
1. For all zones, press and hold the “Master ON
button”, until LEDs turn white. Brightness is
adjustable and master mode is active.
2. For individual zones, press and hold the “Zone
ON button” for the zone you want to control,
until LEDs turn white. Brightness is adjustable
and the last zone turned white is active.
1. For all zones, press the “Master ON button”
once, to activate master mode. Use the
color wheel to directly select a color.
Brightness is adjustable.
2. For individual zones, press the “Zone ON
button” once for the zone you want to
control. Use the color wheel to directly select
a color. Brightness is adjustable.
The LDRF-RGB-MZ features RF remote to controller device pairing
to help eliminate interference from other nearby units. If you wish
to control several controller devices from a single RF remote, the
controllers rst must be re-programmed.
The easiest and fastest way to re-program several controller devices
at once is to have them share a power supply or all plug in to a
single power strip.
Once programmed you can provide power as you would otherwise,
sharing is only needed for the programming phase to ease the
process -- Re-programming can be done one device at a time also.
Controller Pairing:
Pairing a remote to a controller:
1. Wire all controllers to one power supply or power
strip and turn the power o󰀨.
2. Turn on the power supply or power strip and press
the “Zone ON button” once within 3 seconds for the
zone you wish to pair.
3. If successful the LED product will ash twice
slowly.
4. If the LED product ashes nine times quickly or not
at all, repeat steps one and two.
Unpairing a remote to a controller:
1. Wire the controller to a power supply or power strip
and turn the power o󰀨.
2. Turn on the power supply or power strip and press
and hold the “Zone ON button” once within 3
seconds for the zone you wish to unpair.
3. If successful the LED product will ash nine times
quickly.
4. If the LED product ashes twice slowly or not at all,
repeat steps one and two.
Pairing Note:
1. One remote can be paired to any number of
controllers.
2. One controller can be paired to up to four remotes.
ON
1.
2. ON
ON
OFF
OFF
ZONE
ZONE
OFF
MASTER
Parts Included
General Description
RF Remote
Instructions
White Mode
Static Color Mode
Controller Pairing
12 3 4
S-
S+
M
X
X
Pre-test & Congure
May be used with RGB strips, bars, modules or other LED products.
Connect LEDs to power supply and controller (see “Method 1” diagram).
Turn on LEDs using the included remote controller to ensure proper operation
of the LEDs, power supply, controller, and remote.
Choose a suitable dry location for the power supply and controller. Before
double-sided tape is used on controller, ensure all surfaces are clean and dry.
Button Functions
Master On(-)/O󰀨(O)
A master On(-)/O󰀨(O) control for all zone-linked
RGB LEDs. Also activates the “Master” function,
which allows control of all zones.
COLOR WHEEL Directly select color on wheel from any mode
or color selection by touching the color wheel.
Rotate nger around to ne tune desired color.
BRIGHTNESS +/- Brightness Touch Slider - Increase(Right
Side)/Decrease (Left Side)
Increases (right side) or decreases (left side)
the brightness level. Changing the active mode
resets the brightness level to full.
SPEED +/- Mode Speed - Increase(S+)/Decrease (S-)
Increases (S+)/Decreases(S-) the tempo of the
mode pattern currently active.
MODE +/- Mode Start/Scroll (M)
Modes feature di󰀨erent color combinations, light
transitions, and patterns, with 9 distinct modes.
This button initiates the Mode function and
scrolls through the modes in rotating order.
Zone ON(I) / OFF(O)
Allows up to four “zones” (i.e. channels) of RGB
LEDs to be separately linked and controlled
by the remote. Pressing one of the Zone ON(I)
buttons activates that zone; commands will
a󰀨ect only lights in that zone.
12 3 4
S-
S+
M
12 3 4
S-
S+
M
12 3 4
S-
S+
M
12 3 4
S-
S+
M
12 3 4
S-
S+
M

MiBoxer 2.4 GHz Wi-Fi Multi Zone RGBW
Controller and Remote
Important: Read all instructions prior to installation.
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V2.1 03/03/2020
User Manual
LDRF-RGB-MZ
Controller: RGB-MZ
Remote: MZ-RGB-REMOTE
DO NOT connect controller or LEDs directly to 120V AC power. This controller requires a 12V or 24V DC power supply.
DO NOT exceed max load of 18 Amps, overloading the controller may cause overheating, shorting, and possibly failure of controller.
Be sure the power supply is not plugged into an outlet before connecting or disconnecting any of the systems components.
DO NOT expose the controller or remote strip to direct or indirect moisture.
Always observe proper polarity when connecting power and load.
Mode 7 cycles through modes 1-9 starting with 8
Mode Function Brightness Speed Controls Description
1 RBGW Fade In/Out Adjustable Not adjustable Red, green, blue and white fade in/out in a set cycle.
2 Seven Color Flash Adjustable Adjustable Red, green, blue, yellow, magenta, cyan, and white
3 Disco Adjustable Adjustable Red, green, blue, white, purple, and yellow cylce in rotation with
random transitions
4 Red Fade In and Flash Adjustable Adjustable Red brightens to full brightness, then ashes 3 times
5 Green Fade In and Flash Adjustable Adjustable Green brightens to full brightness, then ashes 3 times
6 Blue Fade In and Flash Adjustable Adjustable Blue brightens to full brightness, then ashes 3 times
7 *Color Fade In/Out and Flash Adjustable Adjustable Multiple colors fade in/out and then ash randomly
8 Six Color Fade Adjustable Adjustable Red, green, blue, yellow, magenta, and cyan fade in/out
9White Fade In/Out Adjustable Adjustable White ashes continuously
*
Touch Control
RGB
B
Power
(wired)
Power
(CPS)
G
R
V+
-
+
CPS Power Supply (optional)
(Match voltage to LED voltage)
To Power Supply
RGB LED Flexible Light Strip
(Match voltage to LED voltage)
+
-
+
R
B
G
+
R
B
G
+
R
B
G
+
R
B
G
+
R
B
G
FCC Statement
Wiring
Modes List
Safety
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation. Any changes or modications in construction
of this device which are not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
Note: CPS terminal and screw terminals should not be used at the same time.
Type 3 Channel
Input Voltage 12~24 VDC
Output 6 Amps / Ch
Total Output 18 Amps
Max Wattage 216W (12V) / 432W (24V)
Operating Temp -25°C ~ 60°C
Controller Size L3.3in x W1.7in x D.9in (86 x 45 x 23mm)
Controller Weight 55g (1.94oz)
Frequency 2.4GHz
FCC ID 2AFRVFC24GRMT4
Batteries 2 x AAA
Specications
