Superior ELITE TM-4500 User manual

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Warnock Hersey
Report No. 620-1058A
SUPERIOR
The Fireplace Company
®
This installation manual will enable you to ob-
tainasafe,efficientanddependableinstallation
of your fireplace system. Please read and un-
derstand these instructions before beginning
your installation.
Do not alter or modify the fireplace or its
components under any circumstances. Any
modification or alteration of the fireplace sys-
tem, including but not limited to the fireplace,
chimney components and accessories, may
voidthewarranty, listings and approvals of this
systemandcouldresultinanunsafeand poten-
tially dangerous installation.
PLEASE RETAIN THIS MANUAL FOR FUTURE
REFERENCE.
For Superior’s
TM And TMC
Series Fireplace
Models
TM-4500
And TMC-4500
I N S T A L L A T I O N I N S T R U C T I O N S

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
9. Always keep flue damper open when heat is
present in the fireplace.
10.Before servicing,allow the fireplaceto cool.
Always shut off any electricity or gas to the
fireplace while working on it. This will prevent
any possible electrical shock or burns.
11. This fireplace is not intended to heat an
entire home or be used as a primary heat
source. It is designed to ensure homeowner
comfort by providing supplemental heat to the
room.
12. Always ensure that an adequate supply of
replacement combustion air from the outside
of the house is accessible to the fire to support
normal combustion. Fireplaces consume large
volumes of air during the normal combustion
process. In the event the home is tightly sealed
withmodernenergyefficientfeatures,Superior’s
optional combustion air kit may not provide all
the air required to support combustion. Supe-
rior is not responsible for any smoking or
related problems that may result from the lack
of adequate combustion air. It is the responsi-
bility of the builder/contractor to ensure that
adequatecombustion air has been provided for
the fireplace.
IMPORTANT! PLEASE READ AND
UNDERSTAND THESE RULES TO
FOLLOW FOR SAFETY.
1. Before starting your fireplace installation,
read these installation instructions carefully to
besure youunderstand them completelyand in
theirentirety.Failuretofollowthemcouldcause
a fireplace malfunction resulting in serious
injury and/or property damage.
2. Always check your local building codes. The
installationmustcomplywithalllocal,regional,
state and national codes and regulations.
3. Superior Models TM-4500 and TMC-4500
must be installed with the Model TF10 [10"
(250mm) insidediameter]Thru-Flow Chimney
System only. These systems are intended for
useasresidentialtypeappliances.The chimney
system must always vent to the outside of the
building.
4. To ensure a safe fireplace system and to
prevent the build-up of soot and creosote,
inspect and clean the fireplace and chimney
prior to use and periodically during the heating
season.
5.Use solid fuel only. DO NOT use artificial wax
basedlogs,chemicalchimneycleanersorflame
colorants in your fireplace.
6. DO NOT use charcoal or coal under any
circumstances.
7. NEVER use gasoline, gasoline-type lantern
fuel, kerosene, charcoal lighter fluid, or similar
liquids to start or “freshen up” a fire in this
fireplace. Keep any flammable liquids a safe
distance from the fireplace.
8.NEVERleavechildrenunattendedwhenthere
is a fire burning in the fireplace.
Figure 1
TYPICAL INSTALLATION
TABLE OF CONTENTS
Safety Rules .................................... page 2
Tools and Building Supplies ............ page 3
Precautions ..................................... page 3
Introduction ..................................... page 3
General Information......................... page 3
Clearances/Height Requirements..... page 3
Chimney System ............................. page 3
Assembly Outline............................. page 4
Location of Fireplace ....................... page 4
Assembly Steps ............................... page 4
Installing the Fireplace ..................... page 5
To Install ......................................... page 5
Fireplace Specifications ................... page 6
Framing Specifications .................... page 7
Installing the Chimney System ........ page 8
Ten-foot Rule Summary .................. page 10
Multiple Terminations ...................... page 10
Chimney Component Calculations ... page 11
Special Offset Instructions............... page 11
Offset Calculations........................... page 11
Vertical Elevation Chart.................... page 12
Offset Elevation Chart ...................... page 12
To Install Offsets ............................. page 13
30°Offset through Floor or Ceiling .. page 14
Optional Equipment ......................... page 14
Glass Doors ..................................... page 14
Combustion Air Kits ........................ page 14
TF10-TMS Termination Shroud ....... page 15
Wiring for the TMC Fan Kit .............. page 15
Fan Operation .................................. page 15
Fan Maintenance.............................. page 15
Gas Line .......................................... page 15
Cold Climate Insulation.................... page 16
Fireplace Finishes ............................ page 16
Mantels and Trim............................. page 16
Hearth Extensions/Wall Shields ....... page 16
Finish to Your Taste......................... page 17
Accessories/Component List ........... page 18
Chimney
and
Termination
Chimney
Air Kit
(Canada Only)
Optional Position
Outside
Combustion
Air Kit
(Optional)
TM-4500
TMC-4500
2

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
13. DO NOT use a fireplace insert or any other
products not specified herein by Superior for
use with this fireplace. All gas log sets must be
operated with the damper clamped open, in-
cluding unlisted “vent free” log sets. Listed
“vent-free” logs sets may be operated with the
damper closed.
14. Superior Fireplace Company does not war-
ranty “smoke free” operation nor are we re-
sponsible for inadequate system draft caused
by mechanical systems, general construction
conditions, inadequate chimney heights, ad-
verse wind conditions and/or unusual environ-
mental factors or conditions beyond our con-
trol.
15. Never, under any circumstances, install a
fireplace, chimney component or any accesso-
ries, supplied by Superior Fireplace Company,
that has visible or suspected physical damage
as a result of handling or transportation. These
items should be inspected by a Superior dis-
tributor or qualified factory representative to
ensure safe condition. When in doubt, consult
your Superior distributor.
TOOLS AND BUILDING SUPPLIES
NORMALLY REQUIRED
Tools should include:
Phillips screwdriver
Hammer
Saw and/or sabersaw
Level
Measuring tape
Plumb line
Electric drill and bits
Pliers
Square
Building supplies:
Framing materials
Wall-finishing materials
Caulking materials (noncombustible)
Fireplace surround and hearth
extensionmaterials(noncombustible)
PRECAUTIONS
Note: These fireplace systems are not difficult
to install. However, in the interest of safety, it is
recommendedthatthe installerbe aqualified or
certified “tradesman” familiar with commonly
accepted fireplace installation and safety tech-
niques as well as prevailing local codes.
The most important areas of concern dealing
with the installation of factory-built fireplaces
areclearancestocombustiblematerials,proper
assembly of component parts, height of the
chimney system, the proper use of accessories
supplied by Superior and the techniques em-
ployed in using finishing materials applied to
the wall surrounding the fireplace, hearth ex-
tensions and wall shields. Each of these topics
will be covered in thorough detail throughout
this manual. Please give each your special
attention as you progress with your installa-
tion.
IMPORTANT:WHENINSTALLINGINCANADA,
THE CHIMNEY AIR KIT MUST BE INSTALLED
PER THE WARNOCK HERSEY INC. LISTING.
IMPORTANT: THE MINIMUM AIR SPACE TO
COMBUSTIBLES FOR THE CHIMNEY SYSTEM
IS 2" (51 MM).
INTRODUCTION
General Information
The TMC Series is a wood-burning fireplace
featuring a self contained heat-circulating sys-
tem with a built-in fan kit. The TM Series is a
traditionalradiant-heatwood-burningfireplace.
A steel bar grate is included with both models
to properly position the fire. An outside com-
bustion air kit and decorative glass doors are
available as optional equipment.
Note: Illustrations shown reflect “typical” in-
stallationswithnominaldimensions andarefor
design and framing reference only. Actual in-
stallations may vary due to individual design
preferences. However, always maintain mini-
mum clearances to combustible materials and
do not violate any specific installation require-
ments.
The TM and TMC Series fireplaces have been
tested and listed by Warnock Hersey Inc. (Re-
port No. 620-1058A) to U.L. 127 standard for
U.S. installations and U.L.C. S610 standard for
Canadianinstallations.Theseunitsareintended
for installation in residential homes and build-
ings of conventional construction, not in mo-
bile homes.
These fireplace systems are designed for in-
stallation in accordance with the National Fire
Protection Standard for chimneys, fireplaces
and solid fuel burning appliances; NFPA 211
andinaccordancewith codessuchastheBOCA
Basic/National Codes, the Standard Mechani-
cal Code, Uniform Building Codes and/or the
Canadian National Code.
WARNING: FAILURE TO USE PARTS
MANUFACTURED BY SUPERIOR FIRE-
PLACE COMPANY OR VARIATIONS IN
TECHNIQUES AND CONSTRUCTION MA-
TERIALS DESCRIBED IN THIS MANUAL
MAY CREATE A FIRE HAZARD AND VOID
SUPERIOR’S LIMITED WARRANTY.
The TM and TMC systems consist of six basic
“sub-systems”:
1. The Fireplace
2. The Chimney and Termination
3. The Optional Glass Doors
4. The Forced Air Kit (TMC-4500 only)
5. The Optional Combustion Air Kit
6. The Chimney Collar Enclosure Kit (Canada
Only)
CLEARANCES AND HEIGHT
REQUIREMENTS
The fireplace may be placed on or near normal
construction materials*. The combustion air
kit, firestop spacer and roof flashings (not
chase flashings) may be placed directly on or
against normal construction materials*. The
chimney requires a minimum 2" (51 mm) air
space to combustibles. A combustible mantle
may be installed a minimum of 12" (305 mm)
above the opening of the fireplace as per NFPA
211, Section 7-3.3.3. In Canada the minimum
is 24" (610 mm) above the opening.
The fireplace and chimney system must be
enclosed when installed in or passing through
aliving areawhere combustibles orpeople may
come in contact with it. This is important to
prevent possible personal injury or fire hazard.
For questions, please call your distributor or
Superior Fireplace Company. Special restric-
tions apply to the front and facing of the fire-
place and nearby walls (See pages 16 and 17 ).
CHIMNEY SYSTEM
Superior-manufactured fireplace Models
TM-4500andTMC-4500aredesignedandcode-
listed for use with Superior’s TF10 Thru-Flow
Chimney System only. Always use Superior’s
Thru-Flow chimney components with these
fireplaces. Do not modify or alter these compo-
nents as this may cause a potential serious
hazard and void Superior’s Limited Warranty.
*Construction Materials:
• framing materials • paneling
• particle board • flooring
• millboard • dry wall
• plywood • etc.
3

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 3
Carefully consider the position of the fireplace
opening with respect to the location of adjacent
or nearby stairwells, bath or kitchen exhaust
fans and/or return air registers for forced air
furnaces/air conditioners that could cause a
smoking fireplace condition if the house is
tightly insulated.
If there is a continuous perpendicular side wall
closer than 18" (457 mm) from the nearest side
of the fireplace opening, it must be protected
with a 40" x 40" x ¹⁄₂" (1016 mm x 1016 mm x 13
mm) wall shield constructed of millboard or a
durable noncombustible material with equal or
greater insulating value than .84k (see page
16). A continuous perpendicular side wall can-
not be closer than 12" (305 mm) from the
fireplace opening under any circumstances,
even if protected.
ASSEMBLY STEPS
Note: Thefollowing steps represent thenormal
sequence of installation. Each installation is
unique, however, and might require a different
sequence.
1. Position firebox prior to framing or into
prepared framing.
2. Install chimney air kit (Canada only).
3. Install the chimney system.
4. Install optional outside combustion air kit.
5. Field wire main power supply to fireplace for
fankitforModel TMC-4500.(Electricalconnec-
tions should only be performed by an experi-
enced, licensed/certified tradesman.)
6. Plumb gas line if a decorative gas appliance
will be used. (Gas connections should only be
performed by an experienced, licensed/certi-
fied tradesman.)
CHIMNEY HEIGHT
The total height of your TM or TMC fireplace
system from the surface the fireplace rests on
tothechimneytopmustnotexceed80'(24.4m)
and must also meet minimum height require-
ments. Refer to the minimum system height
chart.
Minimum System Height
TM-4500
TMC-4500
Vertical 16' 0"
Installation (4.8 m)
One 18' 6"
Offset (5.6 m)
Two 22' 0"
Offsets (6.7 m)
CHASE ENCLOSURE
A chase is a vertical box-like structure con-
structedtosurroundthefireplaceand chimney.
Refer to Figure 2 for a typical chase configura-
tion. As with all chimney installations, avoid
overhead obstructions such as trees, power
lines, etc. A chase should be constructed and
insulated just like any outside wall. In a cold
climate, we recommend the base of the chase
should also be insulated between the solid
continuous floor beneath the fireplace and the
chase bottom. Chase insulation in a cold cli-
mate installation is not required for safety.
ASSEMBLY OUTLINE
Before You Start
Checkyour inventory list to be sure you have all
the necessary parts supplied in good usable
condition. Check also for any concealed dam-
age.
Check the operation of the damper. The flue
damper handle extends down from the inside
top of the fireplace; push in to close, pull out to
open — takes firm pressure to lock closed.
LOCATION OF FIREPLACE
Carefully select the proper location for heat
circulation, aesthetics, chimney obstructions
and clearance to side wall(s). With proper pre-
planning, a slight adjustment of a few inches
can save considerable time and expense later
during construction and assembly ( Figure 3 ).
Figure 2
WARNING: IF INSULATION IS USED, THE
FIREPLACE MUST NOT BE PLACED
AGAINST IT. INSULATION OR VAPOR
BARRIERS,IF USED, MUSTBE SECURED
TO ASSURE INSULATION AND VAPOR
BARRIERS REMAIN IN PLACE.
WARNING: DO NOT PACK OR FILL RE-
QUIRED AIR SPACES WITH INSULATION
OR OTHER MATERIAL. NO MATERIAL OF
ANYKINDISALLOWEDINTHESEAREAS.
Note: Do not insulate the chase cavity with
blown or fill type insulation materials.
Note:Local codes may notrequire firestopping
at the ceiling levels for outside chase installa-
tions. However, it is recommended for safety
and the reduction of heat loss.
Insulate Joists
Same as Ceiling
Draft Stops
10FS-2 Firestop
TF10-CTDT
Termination
Note: Non-
Combustible
Chase
Flashing
Must be
Used to
Cover
Chase
Opening
Optional
Insulation
in Outside
Walls of
Chase
Solid
Continuous
Surface
Outside
Base
Insulation
(Thermal Barrier)
8'
(2.4m)
Level
Hearth
Hearth
Optional
Outside
Chase
4

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TO INSTALL
Step 1. Slide the fireplace into prepared fram-
ing or position fireplace in its final position and
frame later.
Step 2. Insert the metal safety strips, packaged
with the fireplace, beneath the fireplace as
illustrated ( Figures 4 and 5 ). The safety strips
should overlap 1" (25 mm) for continual cover-
age of the floor.
Note: Safety strips are not required when fire-
place rests on a noncombustible surface.
Figure 4
Figure 5
Note: Install the hearth extension only as illus-
trated.
The safety strips should extend from front and
sides of the fireplace 2" (51 mm). In the event a
wooden support is used to elevate the fireplace
abovethefloor,a “Z”type safetystrip shouldbe
fabricated and used to protect the front surface
ofthe woodsupport as wellas the floorbeneath
the hearth extension ( Figures 6 and 7 ). The
safety strips should be tacked down to prevent
possible movement.
Note: The “Z” type safety strip is not supplied
by Superior.
Figure 6
Figure 7
Step 3. Refer to fireplace drawings and speci-
fications on pages 6 and 7 for framing dimen-
sions and details. Framing header may be posi-
tioned directly on the fireplace top spacers.
IMPORTANT: UNDER NO CIRCUMSTANCES
CAN THE FIREPLACE TOP SPACERS BE RE-
MOVEDORMODIFIED, NORMAY YOUNOTCH
THE HEADER TO FIT AROUND OR BE IN-
STALLED LOWER THAN THE SPACERS. THE
HEADER MAY BE IN DIRECT CONTACT WITH
THE TOP SPACERS BUT MAY NOT BE SUP-
PORTED BY THEM.
Step 4. Fireplace may be anchored to floor.
Bend down four (4) anchor tabs located at the
base of the fireplace and secure to the floor by
nailing with 8d nails ( Figure 8 ).
Figure 8
7. Complete finish wall material, surround and
hearth extension to your individual taste.
8. Assemble and attach optional glass door
assembly.
Studythethree dimensional illustration (
Figure
1 ) to get a general idea of each element of your
fireplace system.
INSTALLING THE FIREPLACE
The fireplace may be installed directly on a
combustible floor or raised on a platform of an
appropriate height. Do not place fireplace on
carpeting, vinyl or other soft floor coverings. It
may, however, be placed on flat wood, ply-
wood, particle board or other hard surfaces. Be
sure fireplace rests on a solid continuous floor-
ing or platform with appropriate framing for
support and so that no cold air can enter room
from under the fireplace.
The fireplace may be positioned and then the
framing built around it, or the framing may be
constructed and the fireplace positioned into
the opening.
Usually, no special floor support is needed for
the fireplace. However, to be certain:
1. Estimate the total weight of the fireplace
system and surround materials such as brick,
stone,etc., tobe installed. Shippingweights for
the fireplace and chimney may be found in the
Suggested List Prices.
2. Measure the square footage of the floor
space to be occupied by the system, surrounds
and hearth extensions.
3.Notethefloorconstruction,i.e.2x6’s, 2x8’s
or 2 x 10’s (51 x 152 mm, 51 x 203 mm or 51
x 250 mm), single or double joists, type and
thickness of floor boards.
4. Use this information and consult your local
building code to determine if you need addi-
tional support.
CAUTION: DO NOT BLOCK THE BOTTOM
FRONT HEAT-CIRCULATING AIR INLETS AND
OUTLETS ON MODEL TMC-4500. DOING SO
MAY RESULT IN A POTENTIAL FIRE HAZARD.
If you plan to raise the fireplace and hearth
extension, build the platform assembly then
position fireplace and hearth extension on top.
Secure the platform to the floor to prevent
possible shifting.
Anchor Tab
Combustible
Wall
Metal Safety Strip
Hearth
Extension
Floor
1"
(25mm)
Zero Clearence
to Rear and
Side Spacers
Combustible
Wall
Metal Safety Strip
Hearth
Extension
Floor
Platform
1"
(25mm)
Metal Safety Strips
with 1" (25mm) Overlap
2"
(51mm)
Special “Z” Metal Safety Strips
with 1" (25mm) Overlap
2"
(51mm)
Blocking
Platform
5

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Note: If you will be installing glass doors, refer to page 19 for clearance requirements.
FIREPLACE DIMENSIONS
Figure 9 Figure 10
Figure 13
Figure 11 Figure 12
TM-4500 TMC-4500
Left Side Right Side
Top View
15" O.D.
(381mm)
6 ⁹⁄₁₆"
(167mm)
1 ⁵⁄₁₆"
(33mm) 45 ¹⁄₄"
(1149mm)
29"
(737mm)
42 ⁹⁄₁₆"
(1081mm)
7"
(178mm)
15" O.D.
(381mm)
6 ⁹⁄₁₆"
(167mm)
1 ⁵⁄₁₆"
(33mm) 45 ¹⁄₄"
(1149mm)
29"
(737mm)
42 ⁹⁄₁₆"
(1081mm)
7"
(178mm)
2 ³⁄₈"
(60mm)
66 ¹⁄₁₆"
(1678mm)
17 ¹₂"
(445mm) 47 ¹⁄₈"
(1197mm)
10 ⁵⁄₈"
(270mm)
8 ³⁄₄"
(222mm) 13 ¹⁄₄"
(337mm)
66 ¹⁄₁₆"
(1678mm)
4 ¹⁄₂"
(114mm)
47 ¹⁄₈"
(1197mm)
10 ⁵⁄₈"
(270mm)
8 ³⁄₄"
(222mm)
4 ¹⁄₈"
(105mm)
37 ¹⁄₄"
(946mm)
11"
(279mm)
29 ⁷⁄₁₆"
(748mm)
47 ⁷⁄₈"
(1216mm)
6

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
FRAMING DIMENSIONS
Pitch C D*
0/12 19" 19"
(483 mm) (483 mm)
6/12 19" 22"
(483 mm) (559 mm)
12/12 19" 27"
(483 mm) (686 mm)
*Perpendicular to roof ridge
Figure 19
C
D
Roof Framing
Framing Dimensions for Roof
A
B
1
B
2
Header
False Header
Fireplace Framing
Figure 18
A
B
Ceiling Framing
Flue Type A B
TF10 Vertical 19" 19"
(483 mm) (483 mm)
TF10 30°Offset 19" 29"
(483 mm) (737 mm)
Framing Dimensions for Ceiling
Figure 14
CAK-4 Combustion
Air Kit
G
A
J
Outside Chase
Back Wall of Chase/Enclosure
Including Finishing Materials
if any
Rough Framing Face
(Unfinished Shown)
Figure 15
ATO Adapter
G
A
HH
CAK-4
Inside Chase
Back Wall of Chase/Enclosure
Including Finishing Materials
if any
Rough Framing Face
(Unfinished Shown)
Figure 16
A
E
G
F
D
C
K
CAK-4
Back Wall of Chase/Enclosure
Including Finishing Materials if any
Rough
Framing Face
(Unfinished Shown)
Corner Installation
Figure 17
A48"
(1219 mm)
B147 ¹⁄₄"
(1200 mm)
B266 ¹⁄₂"
(1689 mm)
C37 ¹⁄₄"
(946 mm)
D18 ⁵⁄₈"
(473 mm)
E94 ⁷⁄₈"
(2410 mm)
F47 ⁷⁄₁₆"
(1205 mm)
G28 ¹³⁄₁₆"
(732 mm)
J17 ¹⁄₂"
(445 mm)
K67"
(1702 mm)
TM and TMC
Framing Dimensions
7

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Step 5. Fireplace should be secured to side
framingmembers usingnailing flanges. Use8d
nails (
Figure 20 ).
Figure 20
Note: The nailing flange and the area directly
behind the nailing flange is exempt from the
clearancesdescribed on the fireplaceclearance
label.
For Canadian Installations
Proceed with Steps 6–9
Step 6. Remove one of the knockouts from the
fireplace transition and attach the 4" (102 mm)
collar from the air kit to the transition with four
(4) No. 8 x ¹⁄₂" screws provided ( Figure 21 ).
Figure 21
Step 7. Connect the 4" (102 mm) Class 0 air
duct to the collar withtwo (2) No. 6 x ³⁄₈"screws
provided in the hardware kit.
Step 8. Route the Class 0 air duct out the back
wall or side wall, up through the ceiling or floor
joists to an outside wall. The air duct should be
located above snow level.
Note: If the fireplace is installed against an
inside wall, the Class 0 air duct may be ex-
tended into a ventilated attic space at least 18"
(457 mm) above the attic floor. Secure the duct
hood to a vertical post with the inlet positioned
downward. Ensure nothing blocks the hood
opening. This air duct must never terminate
higher than the chimney.
Figure 22
Step 3. Position appropriate firestop spacer at
ceiling and nail temporarily with two (2) 8d
nails. Use flat firestop spacer, Model 10FS-2, if
chimney penetrates ceiling vertically. If chim-
neypenetratesceilingat30°angle(offsetchim-
ney),use 30°firestopspacer, Model10FS30-2.
Use one nail on opposite sides to hold firestop
spacer in position. Nail permanently, using at
least two (2) more 8d nails, after chimney
sections have been assembled through the
firestop spacer and after any necessary adjust-
ments have been made. Firestop spacer must
be secured by at least four (4) 8d nails when
completely installed.
Note: If there is a room above ceiling level,
firestop spacer must be installed on the bottom
side of the ceiling. If an attic is above ceiling
level, firestop spacer must be installed on top
side of ceiling joist (Figures 23 and 24 ).
Figure 23
Figure 24
Step 9. Cut or frame hole through the outside
wall for the installation of the duct inlet hood. A
4¹⁄₂"(114 mm) diameterhole is sufficient. Feed
the loose end of the flexible duct through the
holecutfortheinlethoodandattachtocollaron
inlet hood using two (2) No. 6 x ³⁄₈" screws
provided. Insert hood into opening. Secure
hood in place with the No. 8 x 1 ¹⁄₂" screws
provided or with nails driven through holes in
hood flange. Seal with noncombustible water-
proof silicon type caulking. If additional duct is
needed, use Class 0 metallic duct.
INSTALLING THE CHIMNEY SYSTEM
Step 1. Check flue damper for proper opera-
tion. When the damper is in the fully closed
position, the damper control lever is pushed all
the way to the rear of the firebox. When the
damper is in the fully open position the damper
control lever is pulled all the way to the front of
the firebox.
Step 2. Using standard construction framing
techniques,constructopeningforchimneyroute
upthroughtheceiling(s)androoforthroughan
outside chase.
Framing must maintain adequate minimum air
space clearance at all times.
CAUTION: ALLOW MINIMUM 2" (51 MM)
CHIMNEY AIR SPACE TO COMBUSTIBLE
FRAMING MEMBERS THROUGHOUT VERTI-
CAL OR OFFSET CHIMNEY INSTALLATION.
A minimum 2" (51 mm) air space must be
reserved for all combustible materials ex-
tending for any continuous length surround-
ing the chimney.
Reference
Figures 18 and 19 and charts Fram-
ing Dimensions for Ceiling and Roof, which
specify minimum ceiling and roof dimensions.
In new construction, to determine chimney
center line, use plumb line from roof or ceiling
above fireplace to center of flue collar on fire-
place.
For remodeling, plumb to center of flue collar
from ceiling above, drive nail through ceiling
frombelow to mark position, then mark and cut
to passage from above ceiling (around nail)
( Figure 22 ). Then plumb from ceiling or roof
level directly above hole which has just been
completed.
Nailing Tab
8d Nail
Framing Stud
Plumb Line
10FS-2
Firestop Spacer
Attic Above
10FS-2
Firestop Spacer
Room Above
Optional
Connection
Chimney
Air Kit
8

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
For Canada Only
When installing the chimney system through
an open attic space, the attic shield assembly-
firestop spacer must be used ( Figure 25 ). This
installation procedure is Warnock Hersey Inc.
listed only for use in Canada.
Figure 25
Step4. Note:Chimneysectionsareconstructed
with a unique locking tab design which ensures
an immediate, tight assembly between sec-
tions. Plan your chimney requirements care-
fully before assembly as chimney is difficult to
disassembleafterinstallation.If disassembled,
the tabs might become damaged. Be certain
tabsareproperlyformedto ensure locking tabs
engage properly.
The TF10 chimney system is two-piece chim-
ney, which snaps together from the fireplace
up. Start with the inner flue section. With the
lanced end up, snap-lock it into the matching
collar on top of the fireplace. At all subsequent
joints, the upper flue section fits into the pre-
ceding flue section. Each piece snaps together
by means of locking tabs (9 locking tabs per
joint). Check each piece by pulling up slightly
from the top to ensure proper engagement
before installing succeeding sections. If the
flue has been installed correctly, it will not
separate when you test it. Also, the inner flue
joint where each section is joined should be
tight and flat without gaps ( Figure 26 ).
Figure 26
Outer pipe section installs in just the opposite
way; the lanced end goes down and each new
section goes OVER the outside of the previous
section installed ( Figure 27 ).
Figure 27
Note: Assemble one component of chimney at
a time (inner section first, then outer section
last) before proceeding with the next complete
section.
Continue to assemble the chimney up through
framedopening.Assemblejustenoughtopene-
trate the roof flashing openings ( Figure 28 ).
Alwaysmaintain2"(51mm)minimumairspace
to combustible materials and always check
each chimney joint (inner and outer) to ensure
proper engagement. Check vertical alignment
of chimney so that it projects from the roof in
true vertical position.
Figure 28
Superior chimney sections should not be
screwed together and it is not required for
additional reinforcement.
Step 5. The height of vertical chimney pipe
supported only by the fireplace must not ex-
ceed 30' (9.1 m) Chimney heights above 30'
(9.1m) must be supported by a Model TF10-S4
stabilizer installed at 30' (9.1 m) intervals.
Note: The Model TF10-S4 adds 3" (76 mm) net
effective height to the total chimney system.
Install the Model TF10-S4 stabilizer by fitting
inner section into inner section of preceding
flue pipe and locking outer stabilizer section
intoplaceovertheouterchimney pipe.Position
stabilizer in framed opening retaining proper
clearance. Nail straps securely (under tension
in “shear”) on framing use 8d nails.
Figure 29
Attach next chimney section directly to stabi-
lizer using same techniques as described in
Step 4.
Note: Do not apply excessive pressure to any
subsequent chimney sections following the
stabilizer when installing. Ensure each subse-
quent chimney section is securely attached by
testing as noted in Step 4.
Step 6. Select proper Superior roof flashing
based on pitch of roof. Use chart below for
selection:
Roof Pitch TF10
Flat to 6/12 10-F6
6/12 to 12/12 10-F12
Next,slideroofflashingoverextendedchimney
sectionthatpreviouslyhasbeeninstalledabove
the roof opening in Step 4. Slide flashing all the
way down until the flashing base rests flat on
the roof. Again, check the vertical position of
the chimney and the 2" (51 mm) minimum air
space to combustibles.
Step 7. Secure flashing by nailing along the
perimeter into roof using 8d nails. If shingled
roof, slide upper end and sides of roof flashing
under shingles (trim if necessary), seal the top
and both sides of the flashing to the roof with
roof caulking. Cover nail heads with roof caulk-
ing (
Figure 30 ).
Figure 30
Open Attic Space
Lanced
End
Locking
Tabs
2" (51mm) Min. Air Space
to Combustibles
Stabilizer
9

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Step 8. The standard Superior roof flashing
assemblies include a storm collar. Slide storm
collar over outer chimney, align with top sur-
face of flashing, insert tab in slot, pull tight and
bend tab back over slot. Seal storm collar to
outer chimney with roof caulking or mastic
around entire circumference of pipe. Also add
extra roof caulking to the tab/slot area to seal
completely against water penetration (
Figure
31
). Check all joints very carefully to ensure no
water intrusion can take place.
Figure 31
Step9. Superior locking bands, Model LB, may
be required if the chimney extends too high
above the roof flashing. As a general rule, if the
chimney extends more than 6' (1.8 m) above
the roof flashing, the use of locking bands is
advisable to strengthen the chimney assembly.
Align the locking band at the chimney joint.
Locking bands wrap around pipe joints equally
covering the joints of both pipe sections. Use
nutprovidedandTIGHTENsnugly.Donotover-
tighten as this might damage chimney section
( Figure 31 )
Note: If chimney extends more than 8' (2.4 m)
above roof surface, guy wires are also recom-
mended. Use three (3) guy wires, attach to
locking band assembly, extend and secure to
roof in a triangular pattern (Figure 32 ). Guy
wires are not supplied by Superior.
Figure 32
Step 10. Using the TF10-CTDTM Round
Termination:
1.HoldCTDTMovertop oflastchimneysection
( Figure 33 ).
2. Center inner slip section in inner flue pipe-
slip down.
3. Center outer locking section over outer flue
pipe. Push down until locking tabs are firmly
engaged.
4. Pull up slightly on CTDTM to ensure locking
joint has firmly engaged.
Figure 33
Using a CT2 Chase Termination
Refertospecificinstallationinstructionincluded
with the CT2 chase termination for clearance
statements and installation details.
Figure 34
Note: It is recommended that all exterior ex-
posedrelatedmetalfireplacecomponents;such
as terminations, flashings, storm collars and/
orfluebepainted withapremium-quality, high-
temperature, rust-preventative paint designed
for metal. This is especially important when
installationsaremadein abnormally adverse or
corrosive environments; such as near lakes,
oceans or in areas with consistently high-hu-
midity conditions. Consult the paint manufac-
turers instructions for proper preparation and
application.
Roof Ridge
120°
20"
(508mm)
ForCanadianinstallations,allchimneyinstalled
outside the building must be galvalume (outer
sections only), effective January 1, 1992. The
appropriate model designations (with a “C”
suffix) are located in the back of this manual.
TEN-FOOT RULE SUMMARY
The minimum chimney height above the roof
and/or to adjacent walls and buildings is speci-
fied by all major building codes.
If the horizontal distance from the peak of the
roof is less then 10' (3 m), the top of the
chimney must be at least 2' (610 mm) above
the peak of the roof.
If the horizontal distance from the chimney
edge to the peak of the roof is more than 10'
(3 m), a chimney height reference point is
established on the roof surface 10' (3 m) hori-
zontally from the chimney edge. The top of the
chimney must be at least 2' (610 mm) above
this reference point. In all cases, the chimney
cannot be less than 3' (914 mm) above the roof
at the edge of the chimney.
The 2' in 10' rule is necessary in the interest of
safety, but does not ensure smoke-free opera-
tion. Trees, buildings, adjoining roof lines, ad-
verse wind conditions, etc., may require a taller
chimney should the fireplace not draft properly
( Figure 36 ).
MULTIPLE TERMINATIONS
If more than one termination is located in the
samechase or within the same general proxim-
ity, we suggest they should be separated in
distance at least 24" (610 mm) horizontally
from flue center to flue center and stacked or
staggeredverticallyatleast18"(457mm)apart,
from the termination of one smoke exit to the
termination of another smoke exit ( Figure 35 ).
Figure 35
This suggestion is provided in the interest of
better operation. If the terminations are located
too close to each other, smoke may migrate
from one flue into the other.
18"
(457mm)
18"
(457mm)
24"
(610mm)
Locking Band Mastic
TF10-CT2RS
Termination 2" (51mm) Min. Air Space to
Combustibles
Studs Above
Roof
10

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Maximumoffsetofchimneysystemis30°.Two
offsets must not be assembled to form a 60°
offset. However, two sets of offset and return
elbows may be used on a single flue system,
provided the total height of the system exceeds
22' (6.7 m) ( Figure 42 ).
Return elbow support straps must be securely
attached under tension (in shear) to structural
framing members above. Do not substitute a
TF10-30 offset elbow in place of a TF10-E30
return elbow.
Figure 37
Figure 38
OFFSET CALCULATIONS
1. Use Offset Chart to determine amount of
horizontal offset (A) and height (B) for various
chimney section assemblies.
2. Use“HeightofChimneyOnly”columninThe
Vertical Elevation Chart to determine combina-
tions of chimney used above return elbow to
achieve desired heights. Reference Compo-
nentsEffectiveHeightChartinverticalelevation
chart section.
3. Use Elevation Chart as job estimator only.
Add necessary firestop spacers and stabilizers
as required. Firestop spacers must be used as
shown in Figures 23 and 24 and stabilizers as
shown in Figure 29 .
3' Min.
(916mm)
Less Than 10' (3m)
2' Min. (610mm) 2' Min. (610mm)
2' Min.
(610mm)
TF10 CHIMNEY COMPONENT
CALCULATIONS
The minimum installed height of the TM-4500
and TMC-4500 Series fireplace system is 16'0"
(4.8 m). The maximum system height is 80'0"
(24.38 m)
To determine the number of chimney sections
andchimneycomponentsrequired,followthese
steps:
1. Determine total vertical height of the fire-
place installation. This dimension is the dis-
tance from the surface the fireplace sets on to
the point where smoke exits from the termina-
tion.
2. Determine the number of chimney compo-
nents required, except chimney sections. This
wouldincludefirestopspacers,stabilizers,roof
flashing, etc.
3. The effective heights of the components are:
TM/TMC Fireplaces = 65 ¹⁄₄" (1657 mm)
TF10-12 = 10 ¹⁄₄" (260 mm)
TF10-18 = 16 ¹⁄₄" (413 mm)
TF10-36 = 34 ¹⁄₄" (870 mm)
CTDTM Termination = 10" (254 mm)
CT2 Termination = 15" to 23"
(381–584 mm)
S4 Stabilizer * = 3" (76 mm)*
* Required for every 30' (9.1 m) of vertical
chimney and/or 10' of offset chimney.
4. Determine amount of chimney height re-
quired by subtracting total combined height of
all pre-selected components (fireplace and
chimneycomponentsfromtotaldesiredheight.)
Reference Vertical Elevation Chart and deter-
minethe number of chimney sections(quantity
and length) required.
SPECIAL OFFSET INSTRUCTIONS
To clear any overhead obstructions, you may
offsetyour chimney systemusingSuperior 30°
offset and return elbows. Use two elbows - an
offset elbow to initiate the offset and a return
elbow to terminate it. A 30°offset elbow, an-
gling in any direction, may be the first compo-
nent used off the top of the fireplace flue collar.
The offset and return elbows may be attached
together, or a section or sections of chimney
may be used between, but must not exceed 20'
(6.1 m) in total length between elbows (
Figure
39 ). If sections of pipe exceed 10' (3 m) be-
tween elbows, a chimney stabilizer must be
used at the midpoint. The stabilizer support
strapsmustbeattachedundertension(inshear)
to structural framing members above. When
two sets of elbows are used, the maximum
combined length of chimney used between
elbows cannot exceed 20' (6.1 m) ( Figure 41 ).
Example:IfC1=10'(3m)thenC2cannotexceed
10' (3 m).
If an offset exceeds 6' (1.8 m) in length, each
chimney joint beyond the first 6' (1.8 m) of
offset to the return elbow, must be secured by
a No. 8 x ¹⁄₂" sheet metal screw located at the
underside of the joint ( Figure 37 ).
A ¹⁄₈" (13 mm) diameter hole must be drilled in
the chimney joint using a ¹⁄₈" (13 mm) diameter
drill. Hole should be drilled in center of joint
overlap( Figure38 ).Besuretodrillonlythrough
the outer chimney casting. Do not puncture the
inner flue.
Figure 36
TF10 Chimney
Joints
No. 8 x ¹⁄₂" SMS
Screws Required at
Every Joint Past 6'
No Screws Required in
Joints for First 6' of Offset
4' (1.2m)
6' (1.8m)
Underside of Chimney
11

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
397 ¹⁄₄ 33 1 ¹⁄₄ 2011
403 ¹⁄₄ 33 7 ¹⁄₄ 1111
411 34 3 0 0 12
421 ¹⁄₄ 35 1 ¹⁄₄ 1012
427 ¹⁄₄ 35 7 ¹⁄₄ 0112
431 ¹⁄₂ 35 11 ¹⁄₂ 2012
437 ¹⁄₂ 36 5 ¹⁄₂ 1112
445 ¹⁄₄ 37 1 ¹⁄₄ 0013
455 ¹⁄₂ 37 11 ¹⁄₂ 1013
461 ¹⁄₂ 38 5 ¹⁄₂ 0113
465 ¹⁄₂ 38 9 ¹⁄₂ 2013
471 ¹⁄₂ 39 3 ¹⁄₂ 1113
479 ¹⁄₂ 39 11 ¹⁄₂ 0014
489 ¹⁄₂ 40 9 ¹⁄₂ 1014
495 ¹⁄₂ 41 3 ¹⁄₂ 0114
499 ³⁄₄ 41 7 ³⁄₄ 2014
505 ³⁄₄ 42 1 ³⁄₄ 1114
513 ¹⁄₂ 42 9 ¹⁄₂ 0015
523 ³⁄₄ 43 7 ³⁄₄ 1015
529 ³⁄₄ 44 1 ³⁄₄ 0115
Height Of Number Of TF10
Chimney Only Chimney Lengths
Inches Feet/Inches 12" 18" 36"
11 0 11 1 0 0
17 1 5 0 1 0
21 ¹⁄₄ 19¹⁄₄ 200
27 ¹⁄₄ 23¹⁄₄ 110
33 ¹⁄₄ 29¹⁄₄ 020
35 2 11 0 0 1
37 ¹⁄₄ 31¹⁄₄ 210
43 ¹⁄₄ 37¹⁄₄ 120
51 ¹⁄₄ 43¹⁄₄ 011
55 ¹⁄₄ 47¹⁄₄ 201
61 ¹⁄₄ 51¹⁄₄ 111
67 ¹⁄₄ 57¹⁄₄ 021
69 ¹⁄₄ 59¹⁄₄ 002
79 ¹⁄₄ 67¹⁄₄ 102
85 ¹⁄₄ 71¹⁄₄ 012
89 ¹⁄₂ 75¹⁄₂ 202
95 ¹⁄₂ 711¹⁄₂ 112
103 ¹⁄₄ 87¹⁄₄ 003
113 ¹⁄₂ 95¹⁄₂ 103
119 ¹⁄₂ 911¹⁄₂ 013
Height Of Number Of TF10
Chimney Only Chimney Lengths
Inches Feet/Inches 12" 18" 36"
260 ¹⁄₂ 21 8 ¹⁄₂ 207
266 ¹⁄₂ 22 2 ¹⁄₂ 117
274 ¹⁄₄ 22 10 ¹⁄₄ 008
284 ¹⁄₂ 23 8 ¹⁄₂ 108
290 ¹⁄₂ 24 2 ¹⁄₂ 018
294 ³⁄₄ 24 6 ³⁄₄ 208
300 ³⁄₄ 25 0 ³⁄₄ 118
308 ¹⁄₂ 25 8 ¹⁄₂ 009
318 ³⁄₄ 26 8 ³⁄₄ 109
324 ³⁄₄ 27 0 ³⁄₄ 019
328 ³⁄₄ 27 4 ³⁄₄ 209
334 ³⁄₄ 27 10 ³⁄₄ 119
342 ³⁄₄ 28 6 ³⁄₄ 0010
352 ³⁄₄ 29 4 ³⁄₄ 1010
358 ³⁄₄ 29 10 ³⁄₄ 0110
363 30 3 2 0 10
369 30 9 1 1 10
376 ³⁄₄ 31 4 ³⁄₄ 0011
387 32 3 1 0 11
393 32 9 0 1 11
TF10 VERTICAL ELEVATION CHART
Height Of Number Of TF10
Chimney Only Chimney Lengths
Inches Feet/Inches 12" 18" 36"
Height Of Number Of TF10
Chimney Only Chimney Lengths
Inches Feet/Inches 12" 18" 36"
123 ³⁄₄ 10 3 ³⁄₄ 203
129 ³⁄₄ 10 9 ³⁄₄ 113
137 ¹⁄₂ 11 5 ¹⁄₂ 004
147 ³⁄₄ 12 3 ³⁄₄ 104
153 ³⁄₄ 12 9 ³⁄₄ 014
158 13 2 2 0 4
164 13 8 1 1 4
171 ³⁄₄ 14 3 ³⁄₄ 005
182 15 2 1 0 5
188 15 8 0 1 5
192 16 0 2 0 5
198 16 6 1 1 5
206 17 2 0 0 6
215 ³⁄₄ 17 11 ³⁄₄ 106
222 18 6 0 1 6
226 ¹⁄₄ 18 10 ¹⁄₄ 206
232 ¹⁄₄ 19 4 ¹⁄₄ 116
240 20 0 0 0 7
250 ¹⁄₄ 20 10 ¹⁄₄ 107
256 ¹⁄₄ 21 4 ¹⁄₄ 017
TF10 OFFSET ELEVATION CHART
A B TF10-ES30 Number of TF10 A B
Offset Height Offset/Return TF10-S4 Chimney Sections Offset Height
(Inches) (Inches) Elbow Set Stabilizer 12" 18" 36" (mm) (mm)
415³⁄₄ 1 0 0 0 0 102 400
924¹⁄₂ 1 0 1 0 0 229 622
12 29 ³⁄₄ 1 0 0 1 0 305 756
14 ¹⁄₄ 33 ¹⁄₂ 1 0 2 0 0 362 851
17 ¹⁄₄ 38 ¹⁄₂ 1 0 1 1 0 438 978
20 ¹⁄₄ 43 ³⁄₄ 1 0 0 2 0 514 1111
21 45 ¹⁄₄ 1 0 0 0 1 533 1149
22 ¹⁄₄ 47 ¹⁄₂ 1 0 2 1 0 565 1207
25 ¹⁄₄ 52 ¹⁄₂ 1 0 1 2 0 641 1334
26 ¹⁄₄ 54 ¹⁄₄ 1 0 1 0 1 667 1378
28 ¹⁄₄ 57 ³⁄₄ 1 0 0 3 0 718 1467
29 ¹⁄₄ 59 ¹⁄₄ 1 0 0 1 1 743 1505
31 ¹⁄₄ 63 1 0 2 0 1 794 1600
32 ¹⁄₂ 65 1 0 4 1 0 826 1651
34 ¹⁄₄ 68 ¹⁄₄ 1 0 1 1 1 870 1734
36 ¹⁄₄ 71 ³⁄₄ 1 0 3 0 1 921 1822
37 ¹⁄₄ 73 ¹⁄₄ 1 0 0 2 1 946 1861
38 ¹⁄₄ 75 1 0 0 0 2 972 1905
39 ¹⁄₄ 77 1 0 2 1 1 997 1956
41 ¹⁄₂ 80 ¹⁄₂ 1 0 1 4 0 1054 2045
43 ¹⁄₄ 83 ³⁄₄ 1 0 1 0 2 1099 2127
44 ¹⁄₂ 85 ³⁄₄ 1 0 3 1 1 1130 2178
45 ¹⁄₄ 87 ¹⁄₂ 1 0 0 3 1 1149 2223
46 ¹⁄₄ 89 1 0 0 1 2 1175 2261
48 ¹⁄₄ 91 ¹⁄₂ 1 0 2 0 2 1226 2324
49 ¹⁄₂ 94 ¹⁄₂ 1 0 1 5 0 1257 2400
51 ¹⁄₄ 97 ³⁄₄ 1 0 1 1 2 1302 2483
54 ¹⁄₄ 103 1 0 0 2 2 1378 2616
55 ¹⁄₄ 104 ¹⁄₂ 1 0 0 0 3 1403 2654
56 ¹⁄₂ 106 ¹⁄₂ 1 0 2 1 2 1435 2705
59 ¹⁄₂ 111 ³⁄₄ 1 0 1 2 2 1511 2838
62 ¹⁄₂ 116 ³⁄₄ 1 1 1 0 3 1588 2965
65 ³⁄₄ 122 1 1 0 1 3 1664 3099
67 ³⁄₄ 125 ¹⁄₂ 1 1 2 0 3 1721 3188
69 ³⁄₄ 128 ¹⁄₂ 1 1 1 3 2 1772 3264
70 ³⁄₄ 130 ³⁄₄ 1 1 1 1 3 1797 3321
73 ³⁄₄ 136 1 1 0 2 3 1873 3454
75 ³⁄₄ 139 ¹⁄₂ 1 1 2 1 3 1924 3543
79 ³⁄₄ 146 ¹⁄₄ 1 1 1 0 4 2026 3715
81 148 ¹⁄₄ 1 1 3 1 3 2057 3766
82 ³⁄₄ 151 ¹⁄₂ 1 1 0 1 4 2102 3848
87 ³⁄₄ 160 ¹⁄₄ 1 1 1 1 4 2229 4070
A B TF10-ES30 Number of TF10 A B
Offset Height Offset/Return TF10-S4 Chimney Sections Offset Height
(Inches) (Inches) Elbow Set Stabilizer 12" 18" 36" (mm) (mm)
12

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Step 3. Centerouter-locking sectionover outer
chimneypipe.Pushdownuntillockingjointhas
firmly engaged.
Step 4. Pull up slightly on return elbow to
ensure locking joint has firmly engaged.
Step5.Securesupportstrapsto framingmem-
bers by nailing under tension in sheer.
Figure 43
Note: The return elbow assembly performs the
same function as a stabilizer. Consider this
when determining the need for a stabilizer.
Note: Do not apply excessive pressure to any
subsequent chimney section following return
elbow assembly when installing. Ensure that
each subsequent chimney section is securely
attached by testing as noted above.
TF10-OR15 OFFSET/RETURN ELBOW
Primarily used when fireplace penetrates a 6"
(152 mm) thick wall. Refer to installation in-
structions packed with the TF10-OR15 for
proper usage.
TO INSTALL OFFSETS
First, review Offset Elevation Chart and Figure
40 for reference.
Figure 40
Step 1. Determine the offset distance where
chimney is to pass through the first ceiling-
dimension “A.” To find this point on your
ceiling, first determine the center point for a
vertical chimney following the instructions for
vertical installation.
Measure height to the ceiling from the top of
fireplace-dimension “B.” Use Offset Elevation
Chart to find dimension “A.” Mark point where
you will drive your nail to show the center point
for your offset ceiling cut.
Step2.ProceedbyusingtheStraightUpInstal-
lation Instructions for cutting and framing ceil-
ing and roof openings.
Note:See Framing and DimensionChart for the
sizes of the ceiling and roof openings. The size
of the roof opening varies with the degree of
pitch of the roof.
OFFSET ELBOW ASSEMBLY
Offset elbows install the same as chimney
sections. First, snap the inner section INTO the
preceding inner section of flue. Check connec-
tion by pulling up slightly to ensure a tight fit.
Next, the outer sections snap lock OVER the
preceding outer section of chimney. Again,
check outer section by pulling up slightly to
ensure proper connection is made.
RETURN ELBOW ASSEMBLY
Return elbows install the same way as round
terminations and stabilizers:
Step 1. Hold return elbow over top of last
chimney section.
Step 2. Center inner slip section into inner flue
pipe-slip down.
Figure 39 Figure 41 Figure 42
A
1
C
1
B
1
B
2
C
2
A
2
A
1
C
1
B
1
B
2
C
2
A
2
Stabilizer
A1
20' Max.
(6m)
B1
10' Max.
(3m)
TF10-E30*
Return Elbow
TF10 Chimney
Section (s)
TF10-30*
Offset Elbow
A
B
65 ¹⁄₄"
(1657mm)
* Part of Offset/Return Package, Model TF10-ES30
Return Elbow
13

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
CHIMNEY OFFSET 30°THROUGH FLOOR
OR CEILING
It may be necessary to assemble the chimney
at30°when passing throughthe floor orceiling
area. Use 30°angled firestop spacer, Model
10FS30-2, as shown in
Figures 44 and 45 .
Supportthe chimney at floor or ceiling penetra-
tion with a stabilizer if distance of chimney
below ceiling is 10' (3 m) or more. Maintain 2"
(51 mm) minimum air space to combustibles
from chimney sections.
Figure 44
Figure 45
OPTIONAL EQUIPMENT
Glass Doors
Ifglass doors are to be installed on this system,
refertospecificinstallation instructionspacked
with the glass doors. Superior glass doors
Models 45BF-ABR, 45BF-SPB, 45BF-BR and
Sonata 45 are for use only with Superior’s
TM-4500andTMC-4500factory-builtfireplaces.
Use of other non-listed glass door on these
fireplacesmay constitute a potential fire hazard
and are not recommended.
CAUTION: DO NOT ATTEMPT TO TOUCH THE
DOORSWITH YOUR HANDSWHILETHE FIRE-
PLACE IS IN USE. ALWAYS USE DOOR
HANDLES. DOORS WILL BECOME VERY HOT
WHEN FIREPLACE IS IN USE.
WARNING:FIREPLACESEQUIPPEDWITH
DOORS SHOULD BE OPERATED ONLY
WITHTHEDOORSFULLYOPENORFULLY
CLOSED.
Figure 46
CAUTION: CERTAIN GLASS DOORS OVERLAP
THE BLACK METAL FACING OF THE FIRE-
PLACE. IF THE FIREPLACE HAS BEEN FACED
WITHNONCOMBUSTIBLEMATERIALS,THERE
MIGHT NOT BE SUFFICIENT CLEARANCE TO
INSTALL THE GLASS DOORS OF YOUR
CHOICE. ENSURE ADEQUATE CLEARANCE IS
MAINTAINED AT ALL TIMES SO AS NOT TO
INTERFERE WITH THE INSTALLATION AND
OPERATION OF GLASS DOORS.
Combustion Air Kits
Use combustion air kit, Model CAK-4 or Model
CAK-4LD, with the TM and TMC Series fire-
places.Refertoinstallationinstructionspacked
with the air kit for specific installation informa-
tion.The outside air kit must be installedbefore
the fireplace is framed and enclosed in the
finished walls.
Outside air drawn into the fireplace supplies air
to the fire for combustion. Only one combus-
tion air duct on the left side of the fireplace is
necessary if installed.
Figure 47
If additional length of duct is necessary, pur-
chase locally available U.L. Class 0 or Class 1
metallic duct. The duct may extend up to 50'
(15.24 m) in any direction.
Note: When installing the air duct vertically,
DO NOT terminate the duct closer than 3'
(914mm) below the chimney top.
There is a one-hand operated shut-off valve
located in the left side of the fireplace opening
behind the screen. To open, pull out all the way.
The combustion air damper should be fully
open when the fireplace is in use and fully
closed when the fireplace is not in operation to
prevent outside air from entering your home.
CAUTION: NEVER LOCATE INLET WHERE IT
CANBEBLOCKEDBYSHRUBS,SNOWDRIFTS,
ETC. NEVER LOCATE INLET IN GARAGE OR
ANY AREA WHERE THERE IS ANOTHER FUEL-
BURNING APPLIANCE OR PRODUCTS EMIT-
TING COMBUSTIBLE GASES SUCH AS PAINT,
GASOLINE, ETC. IN COLD CLIMATES IT IS
RECOMMENDEDTHECOMBUSTIONAIRDUCT
BE INSULATED.
Outside combustion air ducting may be run
upwards or vertically through framing and ceil-
ing joists, with the hood installed through an
outside wall and 3' (914 mm) below the termi-
nation. Ducting may also be run downward
through floor joists and under the home to a
ventilated crawlspace not considered part of
the living area of the home.
Note: Do not terminate combustion air kit in
attic space under any circumstances.
A take-off boot adapter, Model TOB, may be
usedin conjunctionwith the airkit toreducethe
framing dimensions when installing the fire-
place diagonally in a corner ( Figure 48 ). Refer
toinstallation instructions packed with the TOB
for specific installation information.
Figure 48
Fully Open or
Fully Closed
TOB Adapter
Firestop Spacer
Stabilizer
2" (51mm)
Min. Air
Space
30°Firestop
and Attic Above
10' (3m) Max.
Attic Space
2" (51mm)
Min. Air
Space
Provision for
Outside Air
13 ¹⁄₂"
(343mm)
17 ¹⁄₂" (445mm)
Firestop Spacer
Stabilizer
30°Firestop
and Room Above
10' (3m) Max.
2" (51mm)
Min. Air
Space
2" (51mm)
Min. Air
Space
Room Above
14

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TF10-TMS TERMINATION SHROUD
An optional termination shroud is available to
partially conceal the TF10-CTDTM when in-
stalled on a chase. Model TF10-TMS is adjust-
able for chases measuring a minimum of 27" x
27" (686 mm x 686 mm) up to a maximum of
40 ¹⁄₂" x 40 ¹⁄₂" (1029 mm x 1029 mm). Consult
the TF10-TMS installation instruction for spe-
cific installation information.
WIRING FOR THE TMC FAN KIT
The TMC-4500 comes standard with a fan
assembly and variable speed switch mounted
behind the removable front access cover. The
fan is located in the center behind the cover.
The “J” box has been pre-wired at the factory.
The fireplace must, however, be connected to
themainpowersupplyatthetimeofinstallation
before the fireplace is framed and enclosed in
the finished walls.
To wire, remove the external “J” box cover
( Figure 49 ) by removing the hex-head screw.
The junction box cover has a ⁷⁄₈" (22 mm)
diameter knockout for connection with a con-
duit bushing. Wire with a minimum 60°C wire
in accordance with prevailing codes ( Figure
50 ). Fan draws 120Vac, 60Hz.
Figure 49
Figure 50
CAUTION: ELECTRICAL CONNECTIONS
SHOULD ONLY BE PERFORMED BY A QUALI-
FIED,LICENSEDELECTRICIAN.MAINPOWER
MUST BE OFF WHEN CONNECTING FANS TO
MAIN ELECTRICAL POWER SUPPLY OR PER-
FORMING SERVICE.
Connect ground wire to ground screw located
inside “J” box ( Figure 51 ). An optional U.L.
listed ON/OFF wall switch (not provided) rated
at 1 amp minimum, 120Vac may be used in-
stead of the built-in switch. When connections
have been made, place “J” box cover back into
the side access opening and secure with hex-
head screw.
Figure 51
Fan Operation
Insert fingertips through the inlet above the
front access cover. Rotate knob on the built-in
variablespeedswitchclockwise.Thefan motor
will then run at a slow speed. To run the fan at
afasterspeed, continuetoturnknobclockwise.
To turn fan off, rotate knob fully counterclock-
wise ( Figure 52 ).
Figure 52
Fan Maintenance
Thefanmotorshouldbeservicedyearlybyoiling
and cleaning. To remove the fan assembly first
remove the lower access cover by lifting slightly
and then pulling straight out. Disconnect the
power plug from the “J” box receptacle and
remove the fan assembly. The compartment
under the fireplace should be inspected and
cleared of lint or other debris. The motor should
then be oiled with a good quality light motor oil.
The oil holes are located on the top and bottom
of the fan motors. Replace all components be
reversing the procedure.
GAS LINE
The TM/TMC Series fireplaces have been ap-
proved to accept a ¹⁄₂" (13 mm) gas line for an
approvedgasappliance.Alwayshavetheappli-
ance installed by a qualified, licensed plumber
in accordance with all local building codes. The
gas line may enter either side of the fireplace.
CAUTION:PLUMBINGCONNECTIONSSHOULD
ONLY BE PERFORMED BY A QUALIFIED, LI-
CENSEDPLUMBER.MAINGASSUPPLYMUST
BE OFF WHEN PLUMBING GAS LINE TO FIRE-
PLACE OR PERFORMING SERVICE.
Ifyou’reinstallingagasline,connectitbeforethe
fireplace is framed and enclosed in the finished
wall. The gas knockout is determined by a 1 ¹⁄₈"
(29mm)roundindentationlocatedatthebottom
and slightly off center in the side refractories.
THE KNOCKOUT IS ALWAYS REMOVED FROM
INSIDETHE FIREPLACE.DONOT REMOVETHE
KNOCKOUT UNLESS YOU ARE INSTALLING A
GASLINE.Ifremovalisattemptedfromtheouter
wrapper, side-refractory damage may occur.
With a medium-sized hammer, lightly tap the
surface of the indentation. The refractory mate-
rialis very thin in this area and is easily removed.
Once a small hole has been made, continue
tapping until you have reached sufficient diam-
eter for the gas line to fit through. The entire
knockout does not have to be removed. Remove
insulation in the gas line channel.
Install only a ¹⁄₂" (13 mm) black iron pipe
through fireplace wall for connection to a deco-
rativegas appliance inside the firebox. Outside,
the iron pipe connects to a gas shut-off valve
recessed flush into the wall or floor. The valve
should be controlled by a removable valve key
for safety.
Always plumb gas line installation per local
codes. Check all connections with soap suds;
leaks will bubble. Never test any gas line con-
nection with a match or open flame.
IMPORTANT: RE-PACK INSULATION MATE-
RIAL IN SQUARE HOLE AROUND GAS LINE;
INTERIOR AND EXTERIOR, TO SEAL.
This provision is intended only for connection
to a decorative gas appliance incorporating an
automatic shut-off device and complying with
the standard for Decorative Gas Appliances for
installation in vented fireplaces, ANSI Z21.60.
Install in accordance with the National Fuel Gas
Code, ANSI Z223.1. This complies with the
revised U.L. 127 standard.
CAUTION: WHEN USING A DECORATIVE GAS
APPLIANCE, THE FIREPLACE DAMPER MUST
BE SET IN THE FULLY OPEN POSITION.
J Box Cover
Fan
Convenience
Plug
120Vac
60H
Z
Junction Box
Receptical
White
Black
Control Knob
Optional ON/OFF Switch
To Fuse or
Circuit Breaker
Factory Supplied
Not Supplied
ON
L
O
W
Access Cover
Fan Control Knob
J Box (Inside)
Ground
Screw
Receptacle
Speed
Switch
15

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
COLD CLIMATE INSULATION
If you live in a cold climate, it is especially
importantto seal all cracks around the fireplace
opening with noncombustible material and
wherever cold air could enter the room. Sur-
rounding materials must be caulked where it
meets the black metal facing of the fireplace to
avoid cold air intrusion. Use noncombustible
caulking material only on fireplace facing to
seal. Also, the outside air inlet duct should be
wrapped with noncombustible insulation to
minimize the formation of condensation. Do
not place insulation materials against chimney
sections.
Note:A2"(51mm) airspacemustbepreserved
for all combustible materials extending for any
continuous length adjacent to the chimney.
It is especially important to insulate between
the studs of an outside chase cavity and under
the floor if the floor is above ground level. Do
not place insulation directly against the fire-
place or chimney system
FIREPLACE FINISHES
Mantels and Trim
In Canada, the minimum height for a combus-
tiblemantel is24" (610 mm)above the fireplace
opening. Figure 53 shows typical Canadian
installation. In installations other than Canada,
combustible mantels and trim may be installed
12" (305 mm) above the fireplace opening as
per NFPA 211; Section 7-3.3.3. and Figure 54 .
If a mantel is of a noncombustible material, it is
exempt from these requirements as long as it
doesnot interferewith the installationor opera-
tion of glass doors.
Figure 53
Figure 54
Hearth Extensions and Wall Shields
A hearth extension must be installed with all
fireplaces. Its purpose is twofold. It protects a
combustible floor in front of the fireplace from
both radiant heat and sparks and it distin-
guishes the prescribed hearth extension area
from other nonprotected surfaces. The hearth
extension must extend beyond the front at
least 20" (508 mm) and both sides at least 12"
(305mm).Usethehearthextensionconstructed
ofadurablenoncombustiblematerialhavingan
equal or greater insulating value of:
k = .84BTU IN/FT2HR °F
or a thermal resistance that equals or exceeds
r = 1.19 HR °F FT2/BTU IN. A minimum ³⁄₈"
(10 mm) thick noncombustible material is all
that is required over a noncombustible or slab
floor.
Note: Any noncombustible material whose 1"
(25 mm) k value is less than .84 or whose r
value is more than 1.19 is acceptable.
If the fireplace is installed on a combustible
floor, use the metal safety strips (provided) on
the floor extending half under the fireplace and
half under the hearth extension.
Secure the hearth extension to the floor to
prevent possible shifting.
Ifa continuousperpendicularside walliscloser
than 18" (457 mm) to the fireplace opening, a
wall shield is required. Use a 40" x 40" x ¹⁄₂"
(1016 mm x 1016 mm x 13 mm) wall shield
constructed of millboard or a durable noncom-
bustible material with equal or greater insulat-
ing value than k = .84 BTU IN/FT2HR °F. In
no case shall a continuous perpendicular side
wall be closer to the fireplace opening than 12"
(305 mm).
If fireplace is installed diagonally across a 90°
corner; no wall shields are required.
Hearth Extension Dimensions
A20" (508 mm)
B36" (914 mm)
C12" (305 mm)
D60" (1524 mm)
Figure 55
Figure 56
MethodsofDeterminingHearthExtension
and Wall Shield Equivalents
To determine the thickness required for any
desired material when either the k or r values
are known:
TM= Thickness of desired material in inches
kM= k value of desired material
rM= r value of desired material
T = Minimum listed thickness
Example: Micore CV230 is to be used with the
TM fireplace. How thick must this material be?
Combustible
Mantel
Spacer
Noncombustible
Wall Covering
Finished
Wall
Canadian Installation
Fireplace
Opening
Facing
Flush
24" Min.
(610mm)
8" Max.
(203mm)
Fireplace
Opening
Typical Installation
6 ⁹⁄₁₆"
(167mm)
12"
(305mm)
Min.
Combustible
Mantel
and Trim Spacer
Noncombustible
Wall Covering
Finished
Wall
12"
(305mm)
Max.
1 ¹⁄₂" (38mm)
Wall Shield
Required if
less than
18" (457mm)
40"
(1016mm)
40"
(1016mm)
C
C
B
A
A
C
B
C
D
16

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Using the k formula:
Desired k value of desired Min. thickness
Required = material (per inch) x of Listed
Thickness k value of listed Material
material (per inch)
TM(Inches) = kmx TL
.84
TM(inches) = 0.43* x 1" **
.84
Answer using k = 0.51 x 1" = 0.51 = ¹⁄₂".
Using the r formula:
Desired r value of listed Min. thickness
Required = material (per inch) x of Listed
Thickness r value of desired Material
material (per inch)
TM(inches) = 1.19 x TL
rM
TM(inches) = 1.19 x 1"**
2.33*
Answer using r = 0.51 x 1" = 0.51 = ¹⁄₂"
Alternative Hearth Extension
and Wall Shield Materials
Listed Values Min. Thick
Material k r TL
Millboard 0.84 1.19 1"
Alternative Values Min. Thick
Materials k r TM
Common brick 5.00 0.20 6"
Cement mortar 5.00 0.20 6"
Ceramic tile 12.5 0.08 15"
Marble 11.0 0.09 13"
Micore CV230 0.43 2.33 ¹⁄₂"
(U.S. Gypsum)
Ceraform 126 0.27 3.70 ¹⁄₂"
(Johns-Manville)
At times it is important to know what combina-
tions of materials are acceptable for use as
hearth extensions. The “R values” are used to
determine acceptable combinations of materi-
als because “R values” are additive where r and
k values are not.
“R value” = 1 = r x thickness ofmaterial used
k
Example: Given that the required “R value” for
a suitable hearth extension used with the
TM-4500 be equal to or greater than “R” = r x TL
= 1.19 x 1" = 1.19. It is desired to elevate a
marble hearth extension to a level of 6 ³⁄₄" or
more above the floor surface. What combina-
tion of noncombustible materials can be used
to accomplish this?
If two common bricks are used so that the 3 ¹⁄₄"
flat dimension is the height, “R” for the com-
mon brick becomes:
“R”M= r x TM= 0.20 x 5 ¹⁄₂" = .1.10
Using ¹⁄₄" of mortar to set the brick, “R” for the
mortar becomes:
“R”M= r x TM= 0.20 x ¹⁄₄" = .05
A ³⁄₄" marble slab set in ¹⁄₄" mortar covers the
brick, “R” for the marble and mortar becomes:
“R”M= r x TM= 0.09 x ³⁄₄" = .068
“R”M= r x TM= 0.20 x ¹⁄₄" = .05
The sum of all "R values" is:
1.1 + .05 + .068 + .05 = 1.268
This would be an acceptable combination of
material for the hearth extension since the total
calculated “R value” of the materials used ex-
ceeds the required “R value” of 1.19.
WARNING: THE CRACK BETWEEN THE
FIREPLACE AND THE HEARTH EXTEN-
SION MUST BE SEALED WITH A NON-
COMBUSTIBLE MATERIAL.
WARNING: WHEN INSTALLING THE
HEARTH EXTENSION, BE CAREFUL NOT
TO BLOCK THE LOWER HEAT-CIRCULAT-
ING AIR GRILL ON MODEL TMC-4500.
WARNING: FIREPLACE MUST BE RAISED
IF HEIGHT OF HEARTH EXTENSION EX-
CEEDS 7" (178 MM) FOR THE TM-4500
OR 2 ³⁄₈" (60 MM) FOR THE TMC-4500
( FIGURES 57 AND 58 ).
Figure 57
Figure 58
FINISH TO YOUR TASTE
There are a wide variety of “finished looks” for
your TM and TMC Series from formal wall
decor with elaborate mantels to rustic wood
paneling or warm brick facings.
Only noncombustible materials like stone, tile,
brick, etc. may overlap the black front facing,
but be sure not to interfere with the installation
and operation of glass doors or block the lower
air grille on the TMC-4500. Seal all joints be-
tween the black facing and wall surrounds to
preventairintrusion.Usenoncombustiblecaulk-
ing material only to seal the black metal facing
to the surround material on the finished wall.
Combustible materials may project beyond the
sides of the fireplace opening as long as they
are kept within the shaded areas illustrated in
Figure 59 .
Figure 59
7" Max.
(178mm)
Max. Thickness of Hearth Extension
when TM Fireplace is on the Floor
Max. Thickness of Hearth Extension
when TMC Fireplace is on the Floor
2 ³⁄₈" Max.
(60mm)
* value taken from chart
** minimum thickness per listing
4 ³⁄₄"
(121mm)
3 ¹⁄₄"
(83mm)
18" (457mm)
Min. Distance to
Unprotected Side Wall
12" (305mm)
Min. Distance to
Protected Side Wall
Fireplace
¹⁄₂"
(13mm)
Combustible
Materials Allowed
in Shaded Areas
15°
17

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
SUPERIOR ACCESSORY PARTS AND
COMPONENT LIST FOR TM AND TMC
SERIES FIREPLACES
Thefollowingaccessorypartsandcomponents
are to be used only with your Superior fireplace
system. Separate installation instructions are
packagedwithallcombustionairkits andchim-
ney terminations.
If you encounter any problems or have ques-
tions concerning the installation or application
of this system, please contact your distributor.
For the name of your nearest distributor call:
SUPERIOR FIREPLACE COMPANY
4325 Artesia Ave.
Fullerton, California 92633
714-521-7302
Model Part Number Weight
TM-4500 P/N 018351 450 lbs.
TMC-4500 P/N 027301 500 lbs.
P/N 010297 TF10-12
P/N 010298 TF10-18
P/N 010299 TF10-36
P/N 040657 TF10-18C
Chimney Section P/N 040652 TF10-36C
Offset/Return Package P/N 022153 TF10-ES30
15°
Offset/Return Elbow P/N 014882 TF10-OR15
Stabilizer P/N 010292 TF10-S4
Firestop Spacer (Flat) P/N 020121 10FS-2
Firestop Spacer (30°) P/N 010299 10FS30-2
Round Termination P/N 020001 TF10-CTDTM
Chase Termination P/N 015603 TF10-CT2RS
Termination Shroud P/N 026771 TF10-TMS
Locking Band P/N 002400 LB
Storm Collar P/N 002013 SC
Attic Shield Assembly
Firestop Spacer P/N 037372 TF10-FSAS
P/N 002050 10F12
Flashing P/N 002000 10F6
18

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Chimney Air Kit
(Canada Only)
Combustion Air Kit P/N 008373 CAK-4
(Less Duct) P/N 045341 CAK-4LD
Take Off Boot P/N 011771 TOB
Air Take Off P/N 008613 ATO-4
Refractory Patch Kit P/N 010405 RPK
Refractory Tint Kit P/N 008988 RTK
Note: The Bi-Fold Series glass doors overlap the frame
around the fireplace. Allow 1/16" clearance; top, bottom
and each side when applying facing materials.
Aluminum
Bi-Fold Glass Door P/N 043981 45BF-BR
P/N 027636 45BF-ABR
Bi-Fold Glass Door P/N 026964 45BF-SPB
Note: Allow 1/16" clearance; top, bottom and each side
when applying facing materials.
Solid Brass
Twin-Pane Door P/N 097273 Sonata 45
19

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Superior reserves the right to make changes at any time, without notice, in design,
materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
Printed in U.S.A. © 1985 by Superior Fireplace Company
P/N 092964 REV. P 12/95
SUPERIOR
The Fireplace Company
®
4325 Artesia Avenue • Fullerton, CA 92633-2522
[phone]
Plants in Fullerton, CA • Union City, TN
