Superior GHC-6500 SERIES User manual

1
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicin-
ity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone.
Follow your gas suppliers instructions.
• Ifyourgassuppliercannotbereached,callthe
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
WARNING:IFTHEINFORMATIONINTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAM-
AGE, PERSONAL INJURY OR LOSS OF LIFE.
POURVOTRESÉCURITÉ: Nepasentreposerniutiliser
d'essencenid'autrevaperursouliquidesinflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Netouchezàaucuninterrupteur. Nepasvousservir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appeflez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installationetservicedoitêtreexécutéparunqualifié
installer, agence de service ou le fournisseur de gaz.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LESINSTRUCTIONSDONNÉDANSCETTENOTICEPOUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
B-VENT
GHC/GRD-6500 SERIES
MODELS
HOMEOWNER'S CARE AND
OPERATION INSTRUCTIONS
WH Report No. J20046564
B-VENTED GAS FIREPLACES
P/N 725,030M REV. D 07/2004
GHC-6500 SHOWN
tlovilliM sledoM cinortcelE sledoM
N0056-CHGNE0056-CHG
P0056-CHGPE0056-CHG
N0056-DRGNE0056-DRG
P0056-DRGPE0056-DRG

2NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TABLE OF CONTENTS
Introduction ..................................... page 2
General Information......................... page 2
Operation/Care of Your Appliance.... page 3
Gas Controls/Control
Compartment Access ...................... page 3
Combustion Air Controls ................. page 4
Maintenance .................................... page 5
Manual Limit Switch ........................ page 5
Burner Adjustments......................... page 5
Flame Appearance and Sooting..... page 5
Adjustment ................................... page 5
Maintenance Schedule..................... page 6
Log and Rockwool Placement ......... page 7
Millivolt Appliance Checkout............ page 7
Electronic Appliance Checkout......... page 7
Wiring Diagrams.............................. page 9
Warranty.......................................... page 9
Product Reference Information ....... page 9
Replacement Parts .......................... page 9
Lighting Instructions – Millivolt ....... page 10
Lighting Instructions – Electronic .... page 12
Troubleshooting Guide – Millivolt ..... page 14
Troubleshooting Guide – Electronic .. page 15
Accessory Components ................... page 16
Replacement Parts List ..................... page 17
These appliances are designed to operate on
naturalorpropanegasonly.Theuseofotherfuels
or combination of fuels will degrade the perfor-
mance of this system and may be dangerous.
For elevations of 0-2000 ft. (0-610 m.) the
GHC/GRD-6500 input is 27,000 BTU/HR for
both natural and propane gases.
WARNING: THESE FIREPLACES ARE
VENTEDDECORATIVEGASAPPLIANCES.
DO NOT BURN WOOD OR OTHER MATE-
RIAL IN THESE APPLIANCES.
CONGRATULATIONS!
In selecting this Superior B-vented gas appliance you have chosen the finest and most
dependable fireplace to be found anywhere. A beautiful, prestigious, alternative to a
wood burning fireplace. Welcome to a Family of tens of thousands of satisfied Superior
Fireplace Owners.
Please read and carefully follow all of the instructions found in this manual. Please pay
special attention to the safety instructions provided in this manual. The Homeowner's
Care and Operation Instructions included here will assure that you have many years of
dependable and enjoyable service from your Superior product.
INTRODUCTION
The millivolt appliances are designed to oper-
ateon either naturalor propanegas. A millivolt
gas control valve with piezo ignition system
provides safe, efficient operation.
The electronic appliances are designed to op-
erate on either natural or propane gas. An
electronic intermittent pilot system provides
safe, efficient operation. External electrical
power is required to operate these units.
These appliances comply with National Safety
Standards and are tested and listed by War-
nock Hersey (Report No. J20046564) to ANSI
ANSI Z21.50 - 2000 (in Canada, CSA 2.22 -
2000), and CAN/CGA-2.17-M91 in both USA
and Canada, as vented gas fireplaces.
Installation must conform to local codes. In
the absence of local codes, installation must
comply with the current National Fuel Gas
Code, ANSI Z223.1 (NFPA 54). (In Canada, the
currentCAN/CGAB149installationcode.) Elec-
trical wiring must comply with local codes. In
the absence of local codes, installation must
be in accordance with the National Electrical
Code, NFPA 70 - (latest edition). (In Canada,
thecurrentCSAC22.1CanadianElectricCode.)
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATION MAY VOID THE WARRANTY,
CERTIFICATIONANDLISTINGSOFTHISUNIT.
GENERAL INFORMATION
Note: Installation and repair should be per-
formedby aqualified serviceperson.The appli-
ance should be inspected annually by a quali-
fied professional service technician. More fre-
quent inspections and cleanings may be re-
quired due to excessive lint from carpeting,
bedding material, etc. It is imperative that the
control compartment, burners and circulating
airpassagewaysofthe appliancebe keptclean.
S'assurer que le brùleur et le compartiment
des commandes sont propres. Voir les in-
structions d'installation et d'utilisation qui
accompagnent l'apareil.
Provide adequate clearances around air open-
ings and adequate accessibility clearance for
service and proper operation. Never obstruct
the front openings of the appliance.
Duetohightemperaturestheappliance should
be located out of traffic and away from furni-
ture and draperies. Locate furniture and win-
dow coverings accordingly.
Nominal operating pressures for the manifold
side of the gas control system are; 3.5 inches
water column (6.54 MmHg) for natural gas
models and 10 inches water column (18.69
MmHg) for propane gas models.
Do not use these appliances if any part has
beenunder water.Immediately call aqualified,
professional service technician to inspect the
appliance and to replace any parts of the
control system and any gas control which
have been under water.
Ne pas se servir de cet appareil s'il a été
plongédansl'eau,complètementou enpartie.
Appeler un technicien qualifiépour inspecter
l'appareiletremplacertoute partiedusystème
de contrôle et toute commande qui ont été
plongés dans l'lau.
Millivolt appliances may be fitted at time of
manufacture with either a Robertshaw millivolt
gascontrol valve orRobertshaw electronic gas
control valve. Both valves have been tested
with and approved for use with these appli-
ances and are listed accordingly.
A ¹⁄₈" NPT test gage connection is provided on
either gas control valve adjacent to the outlet
to the main burner.
Minimuminlet gaspressure tothe applianceis
4.5 inches water column (8.55 MmHg) for
naturalgasand11incheswatercolumn(20.55
MmHg) for propane for the purpose of input
adjustment.
Table 1 shows the units' factory-installed
gasorificesizeforinstallationsat elevations
of 0-2000 feet (0-610 meters).
Table 1
WARNING: IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE INJURY
ORPROPERTYDAMAGE. REFERTOTHIS
MANUAL. FOR ASSISTANCE OR ADDI-
TIONAL INFORMATION CONSULT A
QUALIFIED INSTALLER, SERVICE
AGENCY OR THE GAS SUPPLIER.
CHG DRG seireS
ezisecifirO noitavelE teeF )sretem(
.taN.porP
0056 14#35# 0002-0 )016-0(

3
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Maximum inlet gas supply pressure to the
appliance is 10.5 inches water column (19.95
MmHg) for natural gas and 13.0 inches water
column (24.25 MmHg) for propane.
The appliance must be isolated from the gas
supply piping system (by closing its individual
manualshut-off valve) duringany pressure test-
ing of the gas supply piping system at test
pressures equal to orless than ¹⁄₂ psig(3.5 kPa).
The appliance and its individual shut-off valve
must be disconnected from the gas supply
piping system during any pressure testing of
that system at pressures in excess of ¹⁄₂ psig
(3.5 kPa).
These appliances must not be connected to a
chimney or flue serving a separate solid fuel
burning appliance.
WARNING: FAILURE TO COMPLY WITH
THEINSTALLATIONANDOPERATINGIN-
STRUCTIONS PROVIDED IN THIS DOCU-
MENT WILL RESULT IN AN IMPROP-
ERLY INSTALLED AND OPERATING AP-
PLIANCE,VOIDINGITSWARRANTY. ANY
CHANGE TO THIS APPLIANCE AND/OR
ITS OPERATING CONTROLS IS DANGER-
OUS. IMPROPERINSTALLATIONORUSE
OF THIS APPLIANCE CAN CAUSE SERI-
OUS INJURY OR DEATH FORM FIRE,
BURNS, EXPLOSION OR CARBON MON-
OXIDE POISONING.
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning are similar to
thefluwithheadaches,dizzinessand/ornau-
sea. If you have these signs, obtain fresh air
immediately. Turn off the gas supply to the
appliance and have it serviced by a qualified
professional, as it may not be operating
correctly.
WARNING: B-VENT APPLIANCES ARE
NOT DESIGNED TO OPERATE IN NEGA-
TIVELY PRESSURED ENVIRONMENTS
(PRESSURE WITHIN THE HOME IS LESS
THAN PRESSURES OUTSIDE). SIGNIFI-
CANT NEGATIVELY PRESSURED ENVI-
RONMENTS CAUSED BY WEATHER,
HOMEDESIGN,OROTHERDEVICES MAY
IMPACT THE OPERATION OF THESE AP-
PLIANCES. NEGATIVE PRESSURES MAY
RESULT IN POOR FLAME APPEARANCE,
SOOTING, DAMAGE TO PROPERTY AND/
OR SEVERE PERSONAL INJURY. DO NOT
OPERATE THESE APPLIANCES IN NEGA-
TIVELY PRESSURED ENVIRONMENTS.
WARNING: CHILDREN AND ADULTS
SHOULD BE ALERTED TO THE HAZARDS
OFHIGHSURFACETEMPERATURES.USE
CAUTION AROUND THE APPLIANCE TO
AVOID BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE IN
THE SAME ROOM AS THE APPLIANCE.
WARNING: DO NOT PLACE CLOTHING
OR OTHER FLAMMABLE MATERIALS
ON OR NEAR THIS APPLIANCE.
AVERTISSEMENT: SURVEILLER LES
ENFANTS. GARDER LES VÊTEMENTS,
LESMEUBLES,L'ESSENCEOU AUTRES
LIQUIDES ÀVAPEUR INFLAMMABLES
LIN DE L'APPAREIL.
OPERATION AND CARE OF YOUR
APPLIANCE
Applianceoperationmustbecontrolledthrough
a remotely located wall switch (factory-sup-
plied). Separate switches may provide inde-
pendent control for the remote controlled fire-
place operation (optional equipment).
Gas Control Compartment Access
See Figure 1 for the location of the gas control
valve and piezo ignitor (millivolt units) .
When the bottom edge of the access panel
swings out, cup it with the finger tips of both
hands. Lift with the finger tips, moving the panel
upand into theappliance. Pull thepanel top edge
out from the appliance with the thumbs to re-
move it from the lower compartment opening.
Control Compartment Access - GHC-6500
Units
The GHC lower control compartment access is
provided by removing the four louvers. To
removethe louvers, pullthem straight out from
the unit. To replace, tilt each of them with the
top edge over the top of each peg and snap the
lower edge to lock in place.
See Figure 3.
Figure 3 GHC-6500
Control Compartment Access - GRD-6500
Series units
Thelower controlcompartment accesspanel is
attached to each side of the fireplace by pins
that engage locking slots on the sides of the
panel (Figure 2 ) . To remove the panel push in
on it’s top edge with both thumbs, one on each
end of the panel.
Figure 1
Piezo
Ignitor
Millivolt
Gas Valve
1
2
Figure 2
GRD-6500
Louver
Pegs Louvers
Operation of millivolt and electronic gas con-
trol systems are different. Before lighting and
operating your appliance determine if you
have a millivolt or electronic appliance. Milli-
volt appliances will be fitted with the gas
control valve shown in Figure 4 . Appliances
with electronic systems will be fitted with the
electronic valve shown in Figure 5. Familiar-
ize yourself with the differing controls for the
valve your appliance uses.

4NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WARNING: DO NOT OPERATE THE
SHUTOFF LEVER UNLESS A COMPLETE
OUTSIDE AIR VENT SYSTEM HAS BEEN
INSTALLED WITH YOUR APPLIANCE.
Combustion Air Control Lever and
Extension on GHC-6500 Series Units
Figure 7
WARNING: DO NOT USE ABRASIVE
CLEANERS. NEVER CLEAN THE GLASS
WHEN IT IS HOT.
CAUTION: DO NOT ATTEMPT TO TOUCH THE
DOORSWITHYOURHANDSWHILETHEFIRE-
PLACE IS IN USE. ALWAYS USE DOOR
HANDLES. DOORS WILL BECOME VERY HOT
WHEN FIREPLACE IS IN USE.
Figure 5
Figure 4
To light millivolt appliances refer to the detailed
lighting instructions found in both English and
French on
pages 10 and 11 of these instruc-
tions respectively. Appliance lighting instruc-
tions may also be found on the pull-out label
located near the gas valve in the control
compartment. Refer to
Figure 1 for the piezo
ignitor location used with your appliance.
Your appliance comes supplied with remote
wall switch or can be used with an optional
remote control kit. The appliance main burner
may be turned on and off with the wall switch
or remote control.
Electronic Appliance Lighting
To light electronic appliances refer to the de-
tailed lighting instructions found in both En-
glish and French on
pages 12 and 13 of these
instructions respectively. Appliance lighting
instructions may also be found on the pull-
out label located near the gas valve in the
control compartment.
Your appliance comes supplied with remote
wall switch or can be used with an optional
remote control kit. The appliance main burner
may be turned on and off with the wall switch
or remote control.
1. When lit for the first time, this appliance will
emit a slight odor for an hour or two. This is
due to the “burn-in”of internal paints and
lubricants used in the manufacturing process.
2. Keep lower control compartment clean by
vacuuming or brushing at least twice a year.
Morefrequentcleaningmay berequireddue to
excessive lint from carpeting, bedding materi-
als, etc. It is important that control compart-
ments, burners and circulating air passage-
ways of the appliance be kept clean.
3. Always turn off gas to the pilot (millivolt
appliances)before cleaning.Before re-lighting,
refer to the lighting instructions in this manual.
Appliance lighting instructions may also be
found on the pull-out label located near the
gas valve in the control compartment.
4. Always keep the appliance area clear and
free from combustible materials, gasoline and
other flammable liquids.
5. Remember, Millivolt appliances have a con-
tinuous burning pilot flame. Exercise caution
when using products with combustible vapors.
6. Clean the optional glass doors only when
necessary. Wipe surface with clean, damp-
ened, soft cloth. Follow with dry, soft towel as
desired. Take care not to scratch the glass
surface.
Millivolt Appliance Lighting
WARNING: FIREPLACES EQUIPPED
WITH OPTIONAL ACCESSORY DOORS
SHOULDBE OPERATED ONLYWITHTHE
DOORSFULLY OPENORFULLYCLOSED
(FIGURE6). THISAPPLIANCEMAYONLY
BEFITTEDWITHDOORSCERTIFIEDFOR
USE WITH THE APPLIANCE.
AVERTISSEMENT: POUR UTILISATION
UNIQUEMENT AVEC LES PORTES EN
VERRE CERTIFIÊES AVEC L'APPAREIL.
Figure 6
Outside Combustion Air Controls
Appliances may be installed with an outside
(make-up air) vent system that is designed to
provide the appliance with outside make-up
air for combustion when in operation. The
shut-off lever for the outside air system is
standard on all appliances but should not be
operated if the complete system is not in-
stalled. Referto
Figure7 for GHC-6500series
units and Figure 8 on page 5 for GRD-6500
series units. When the complete outside air
vent system is installed, the installer will re-
move the cover from the shut-off lever located
in the left side of the firebox opening.
If your cover is not removed and you have
reason to believe that you have a complete
outside air system, contact your distributor to
have your appliance inspected for the presence
of the complete system. DO NOT assume that
you have this system in place.
The hand operated shut-off lever is located in
the left side of the fireplace opening behind the
screen. To open, pull all the way. The outside
air damper should be fully open when the
fireplace is in use and completely closed when
thefireplaceisnot beingused. Thiswillprevent
outside cold air from entering the dwelling.
(If an optional “All-Glass”enclosure panel has
beeninstalled onthe 6500 Series appliances,an
extension bar will have been attached to the
actuator lever as illustrated in
Figures 7 and 8 .
Bothversions of theactuator lever extensionbar
are packaged with the glass enclosure panel.)
CONTROL KNOB
MILLIVOLT GAS CONTROL VALVE
M
C
P
O N
O F F
ON/OFF SWITCH
ELECTRONIC GAS CONTROL VALVE
Glass Doors
Fully Open or
Fully Closed
(Bi-Fold Doors)
Extension Bar
Actuator Lever
Phillips Pan
Head Screw
#6-32 x ⁷⁄₃₂"
(6 mm)
OC

5
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Combustion Air Control Lever and
Extension on GRD-6500 Series Units
Figure 8
WARNING: AIR SHUTTER ADJUSTMENT
SHOULD ONLY BE PERFORMED BY A
QUALIFIED PROFESSIONAL SERVICE
TECHNICIAN.
Figure 10
Maintenance
The appliance and venting system should be
thoroughly inspected before initial use and at
least annually by a qualified service techni-
cian. Propermaintenance and usewill require
more frequent, less extensive inspections and
servicing by the homeowner.
Generally, annual inspections should be per-
formedbyaqualifiedservicetechnician. More
frequent periodic inspections and cleanings
should be performed by the homeowner. Any
discrepancies discovered by the homeowner
should result in a call to a qualified service
technician to effect the repair or correction.
Refer to the maintenance schedule for mainte-
nance tasks, procedures, periodicity and by
whom they should be performed.
IMPORTANT: TURNOFFGASANDANYELEC-
TRICAL POWER BEFORE SERVICING THE
APPLIANCE.
MANUALLY-RESET BLOCKED FLUE SAFETY
SWITCH
This appliance is equipped with a manually-
reset blocked flue safety switch. Refer to
Figure 9 for its location. If during appliance
operation, the flame goes out (independently
of the burner on/off wall switch), it may be due
to the operation of this safety limit switch.
First allow the appliance to cool. Then reset
the safety switch by pushing the red reset
button on the back of the switch.
CAUTION: THE ELECTRONIC APPLIANCE
SHOULD BE TURNED OFF BEFORE REMOV-
ING THE LIMIT SWITCH.
To access the safety limit switch reset button,
remove the two screws. Pull out limit switch
withlowvoltage wiresattached,push thereset
button, then reinstall the limit switch. At this
time turn the electronic appliance back on.
Adjustment
To adjust the flame, position the air shutter to
the nominal setting (Figure 10 ). Allow the
burner to operate for at least 30 minutes.
Observe the flame continuously. If it appears
weak or sooty as previously described, adjust
the air shutter open or closed until desired
effect is achieved.
The appliance should then relight and remain
lit. If this does not occur, turn off the appli-
ance and call a qualified service technician.
Burner Adjustments
Flame Appearance and Sooting
Proper flame appearance is a matter of taste.
Generally most people prefer the warm glow of
a yellow to orange flame. Appliances operated
with air shutter openings that are too large, or
with long vertical vent runs, will exhibit flames
that are blue and transparent. These weak, blue
and transparent flames are termed anemic.
If the air shutter opening is too small sooting
may develop. Sooting is indicated by black
puffs developing at the tips of very long orange
flames. Sooting results in black deposits form-
ing on the logs, appliance inside surfaces and
on exterior surfaces adjacent to the vent termi-
nation. Sooting is caused by incomplete com-
bustion in the flames and a lack of combustion
air entering the air shutter opening.
To achieve a warm yellow to orange flame with
an orange body that does not soot, the shutter
opening must be adjusted between these two
extremes. Nosmokeorsootshouldbepresent.
Reposition the log set if the flames impinge on
any of them.
If sooting conditions exist, the air shutter
opening on the main burner can be adjusted.
Normally, the more offsets in the vent system,
the greater the need for the air shutter to be
opened further.
Orifice
Air Shutter
Burner Tube
Adjusting
Set Screw
Nominal Air Shutter Settings:
Natural Gas - Closed
Propane Gas - 1/6 in. (1.59 mm) Open
Extension Bar
Actuator
Lever
Phillips Pan
Head Screw
#6-32 x ⁷⁄₃₂"
(6 mm)
OC
Figure 9
Limit
Switch
Screws
Manual Reset Limit Switch
Lintel Extention
Fireplace Front

6NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Periodically (After the Burning Season)
Maintenance Task Accomplishing Person Procedure
Cleaning Firebox Interior
Check Flame Patterns and Flame Height
Checking Vent System
Cleaning Optional Glass Doors
Homeowner
Homeowner
Homeowner
Homeowner
Carefullyremove logs, Rockwool and volcanic
stone if used. Vacuum out interior of the
firebox. Clean firebox walls and log grate.
Replace logs, Rockwool and volcanic stone as
detailed in this manual.
Refer to Figure 12 on page 7 and verify the
flame pattern and height displayed by the
appliance conforms to the picture. Flames
must not impinge on the logs.
Inspect the vent system at the top and at the
base (within the firebox) for signs of blockage
or obstruction. Look for any signs of disloca-
tion of the vent components.
Clean as necessary following the directions
provided in this manual. DO NOT TOUCH OR
ATTEMPT TO CLEAN DOORS WHILE THEY
ARE HOT.
Maintenance Schedule
Annually (Before the onset of the Burning Season)
Maintenance Task Accomplishing Person Procedure
Inspecting/Cleaning Burner, Logs
and Controls
Check Flame Patterns and Flame Height
Inspecting/Cleaning Pilot and Burner
Checking Vent System
Appliance Checkout
Replacing Rockwool Ember Materials
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Qualified Service Technician
Homeowner/Qualified Services Technician
Inspect valve and ensure it is properly operat-
ing. Check piping for leaks. Vacuum the
controlcompartment,fireplacelogsandburner
area.
Refer to Figure 12 on page 7 and verify the
flame pattern and height displayed by the
appliance conforms to the picture.
Refer to Figure 13 on page 7. Remove any
surface build-up on pilot and burner assem-
bly. Wipe the pilot nozzles, ignitor/flame rod
and hood. Ensure the pilot flame engulfs the
flame sensor as shown.
Inspect the vent system at the top and at the
base (within the firebox) for signs of blockage
or obstruction. Look for any signs of disloca-
tion of the vent components.
Perform the appropriate appliance checkout
procedure detailed in this manual.
Remove old ember materials and vacuum the
rockwoolplacementarea. Placenewrockwool
as described in this document.

7
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WARNING: THE SIZE AND POSITION OF
THELOG SETWASENGINEEREDTOGIVE
YOUR APPLIANCE A SAFE, RELIABLE
ANDATTRACTIVEFLAMEPATTERN. ANY
ATTEMPTTO USE A DIFFERENT LOG SET
INTHEFIREPLACEWILLVOIDTHEWAR-
RANTY AND WILL RESULT IN INCOM-
PLETE COMBUSTION, SOOTING, AND
POOR FLAME QUALITY.
WARNING: LOGS GET VERY HOT AND
WILL REMAIN HOT UP TO ONE HOUR
AFTER GAS SUPPLY IS TURNED OFF.
HANDLE ONLY WHEN LOGS ARE COOL.
TURN OFF ALL ELECTRICITY TO THE
APPLIANCE BEFORE YOU INSTALL
GRATE AND LOGS.
WARNING: THIS APPLIANCE IS NOT
MEANT TO BURN WOOD. ANY ATTEMPT
TO DO SO COULD CAUSE IRREPARABLE
DAMAGE TO YOUR APPLIANCE AND
PROVE HAZARDOUS TO YOUR SAFETY.
Logs and Rockwool (Glowing Embers)
Placement
The logs are packaged within the firebox. The
bag of rockwool is in the lower control com-
partment.Removetherockwoolfromthepack-
aging and tear into dime size pieces (Figure
11) . Spread across the burner in front of the
frontlog. See Figure12. Do not use morethan
is necessary to cover the burner. When prop-
erly positioned, the rockwool will unevenly
cover approximately 85% of the front of the
burner with no appreciable gaps.
These appliances are equipped with a beauti-
fully crafted six (6) piece ceramic fiber log set.
The logs, shown in Figure 14 on page 8 , are to
be positioned precisely as shown. Any modifi-
cation to the to the lay of these logs may result
insooting,propertydamageandinjuryordeath.
Figure 11
Figure 12
Millivolt Appliance Checkout
The gas control system on these appliances is
a millivolt standing pilot type. It consists of a
pilotburner, a piezo ignitor, a gas control valve,
a burner assembly and an ON/OFF wall switch.
A temperature limit switch is wired in series
with the millivolt wall switch and gas control
valve. If a higher than normal temperature is
sensed due to a blocked vent or prolonged
downdraft, the limit switch will open and cause
the burner to shut off.
The pilot flame should be steady, not lifting or
floating. Flame should be blue in color with
traces of orange at the outer edge.
The top ³⁄₈" (9 mm) at the pilot generator
(thermopile) should be engulfed in the pilot
flame
(Figure 13).
Figure 13
If the pilot flame pattern is not as shown in
Figure 12 , adjust it as follows:
1. Remove the pilot adjustment cap located on
the main gas valve.
2. Adjust the pilot screw to provide properly
sized pilot flame (Figure 13 ) . Turn counter
clockwise to enlarge pilot flame and clockwise
to reduce the pilot flame. DO NOT attempt to
adjust pilot flame more than one half turn.
3. Replace the pilot adjustment cap.
Replace logs if removed for pilot inspection.
To light the burner; rotate the gas valve control
knobcounterclockwisetothe“ON”positionand
then turn “ON”the remote wall switch.
Electronic Appliance Checkout
The gas control system on these appliances is
an electronic low voltage gas control valve with
an intermittent ignitor. It consists of a low
voltage gas control valve, an intermittent igni-
tionsystem,anelectroniccontrolmodule,trans-
former and a burner assembly. A temperature
limit switch is wired in series with the gas
control valve. If a higher than normal tempera-
ture is sensed, due to a blocked vent or pro-
longed downdraft, the limit switch will open
and cause the burner to shut off.
The pilot flame should be steady, not lifting or
floating. Flame should be blue in color with
traces of orange at the outer edge.
To light the burner, push the gas control lever
inand toward the leftto the “ON”position. Turn
‘ON’the remote wall switch. Ensure the ignitor
lights the pilot. The pilot flame should engulf
the ignitor.
WARNING: PILOT FLAME PATTERN
ADJUSTMENT SHOULD ONLY BE PER-
FORMED BY A QUALIFIED PROFES-
SIONAL SERVICE TECHNICIAN.
Rockwool
³⁄₈" (10 mm)

8NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Carefully position and center the fiber logs
onto the burner grate with the longer log in
front and the shorter log all the way to the
back of the fireplace. Place the four (4)
smaller fiber logs across the two (2) lower
logs in the manner illustrated (Figure 14) .
CAUTION: THESE CERAMIC FIBER LOGS
MUST BE HANDLED CAREFULLY. THEY
WILL STAND UP INDEFINITELY TO EX-
TREMETEMPERATURES.HOWEVER,THEY
AREVERYFRAGILEANDARESUSCEPTIBLE
TO CRUSHING AND/OR BREAKAGE IF
HANDLED ROUGHLY.
Figure 14
GHC/GRD-6500
LOG PLACEMENT
AB
CD
EF
.oNNOITPIRCSED.oNtraP
)etelpmoC(teSgoL1083M31
.AmottoB,raeR,goL1013M31
.BmottoB,tnorF,goL1043M31
.CtfeLpoT,elddiM,goL1053M31
.D poT,elddiM,goL thgiR 1063M31
.EtfeL,poT,goL1023M31
.FthgiR,poT,goL1033M31

9
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WIRING DIAGRAMS
WARRANTY
Yourgasapplianceiscoveredbyalimitedtwenty
year warranty. You will find a copy of the war-
ranty accompanying this manual. Please read
the warranty to be familiar with its coverage.
Retain this manual. File it with your other docu-
ments for future reference.
PRODUCT REFERENCE INFORMATION
We recommend that you record the following
important information about your fireplace.
Please contact your dealer for any questions
or concerns. For the number of your nearest
dealer, please call 800-731-8101
REPLACEMENT PARTS
A complete parts list is found at the end of this
manual. Use only parts supplied from the
manufacturer.
Normally, all parts should be ordered through
your distributor or dealer. Parts will be shipped
at prevailing prices at time of order.
If you encounter any problems or have any
questions concerning the installation or appli-
cation of this system, please contact your dis-
tributor, or LHP directly:
LHP
1110 West Taft Avenue •Orange, CA
92865
Your Fireplace's Model Number _______________________________________
Your Fireplace's Serial Number ________________________________________
The Date On Which Your Fireplace Was Installed __________________________
The Type of Gas Your Fireplace Uses ___________________________________
Your Dealer's Name_________________________________________________
When ordering repair parts, always give the
following information:
1. The model number of the appliance.
2. The serial number of the appliance.
3. The part number.
4. The description of the part.
5. The quantity required.
6. The installation date of the appliance.
Wiring diagrams are provided here for refer-
ence purposes only. This information is also
provided on schematics attached directly to
the appliance on a pullout panel located within
the control compartment.
CAUTION: LABEL ALL WIRES PRIOR TO DIS-
CONNECTION WHEN SERVICING CONTROLS.
WIRINGERRORSCANCAUSEIMPROPERAND
DANGEROUS APPLIANCE OPERATION.
Electronic System Wiring
(Without Forced Air Kit)
Electronic System Wiring
(With Forced Air Kit)
Electronic System Wiring
(Without Forced Air Kit)
Limit Switch
Thermopile
ON/OFF
Wall Switch
TH
TP TH
TP
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C –18 GA. wire.
2. 120V, 60Hz –Less than 3 amps.
LIMIT SW. ON/OFF SW
GND
Ignitor
Junction Box
Transf.
120 V.
W
BK
Gas Valve
MC
BL
BK
24 V
MV
TH
TR
GND
PV
IGN
Ignition Control
Factory Wired Field Wired
P
PV/MV
GND
WBL
BK W
GHC/GRD-6500
Robertshaw Ignition Control Equipped
24V
LOW
VOLTAGE
120 VAC
BK
BK W
GHC Series Only
Green
Ground
Screw
R
BK
R
1. If any of the original wire as supplied must be replaced,
1. it must be replaced with Type AWM 105°C –18 GA. wire.
2. 120V, 60Hz –Less than 3 amps.
LIMIT SW ON/OFF SW
GND
W
Ignitor
Junction Box
Transf.
120 V.
W
BK
Gas Valve
MC
BL
BK
24 V
MV
TH
TR
GND
PV
IGN
Ignition Control
Factory Wired Field Wired
P
PV/MV
GND
WBL
BK
W
GHC-6500
Robertshaw Ignition Control Equipped
24V
LOW
VOLTAGE
120 VAC
BK
BK
Opt
Blower
WALL BLOWER SW
BK
Green
Ground
Screw
Appliance
Ground Screw
R
BK
R
1. If any of the original wire as supplied must be replaced, it must be replaced
with Type AWM 105°C –18 GA. wire.
2. 120V, 60Hz –Less than 3 amps.
LIMIT SW ON/OFF SW
120 VAC. BK
GND
NEU. W
Ignitor
Junction Box
Transf.
120 V.
W
BK
Gas Valve
MC
BK
24 V
MV
24V
GND
PV
Ignition Control
Factory Wired Field Wired
P
PV/MV
G
BL
BK
W
GHC/GRD-6500
(Honeywell Ignition Module Equipped)
24V
Low Voltage
BK
GND
(Burner)
24V
TH-W
(OPT.)
SPARK
W
BL
R
Green
Ground
Screw
BK
R

10 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
LIGHTING INSTRUCTIONS –MILLIVOLT GAS VALVE
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY READ BEFORE LIGHTING
A. This appliance has a pilot which must be lighted with a piezo
ignitor. When lighting the pilot, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area for
gas. Be sure to smell next to the floor because some gas is
heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
TO TURN OFF GAS TO APPLIANCE
1. Turn remote wall switch “OFF.”The pilot will remain lit for
normal service.
2. For complete shutdown, turn remote wall switch to “OFF.”
3. Access the lower control compartment.
4. Depress gas control knob slightly and turn clockwise
to “OFF.”Do not force.
5. Close lower control compartment.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Access the lower control compartment.
3. Turn remote wall switch to “OFF.”
4. Verify main line shut-off valve is open.
5. Push in gas control knob slightly and turn clockwise
to “OFF.”
6. Wait five (5) minutes to clear out any gas. If you then smell gas,
STOP! Follow “B”in the safety information above on this page. If you
do not smell gas, go to the next step.
7. Push in gas control knob slightly and turn counterclockwise
to “PILOT.”
8. Push in control knob all the way and hold in. Immediately light the
pilot by triggering the spark ignitor (pushing the button) until pilot
lights. Continue to hold the control knob in for about 1 ¹⁄₂ minutes
after the pilot is lit. Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 5 through 8.
•If knob does not pop up when released,
stop and immediately call your service
technician or gas supplier.
•If pilot will not stay lit after several
tries, turn the control knob to “OFF”
and call your service technician or
gas supplier.
9. Turn gas control knob counterclockwise
to “ON.”
10. Close lower control compartment.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s phone.
•If your gas supplier cannot be reached, call the fire depart-
ment.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by hand,
do not try to repair it, call a qualified service technician.
Force or attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
Note: Knob cannot be turned from “PILOT”to “OFF”
unless the knob is pushed in slightly. Do not force.
CONTROL KNOB

12 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WARNING:IFYOUDONOTFOLLOWTHESEINSTRUCTIONSEXACTLY,AFIREOREXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
A. When lighting the appliance, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
•Do not use any phone in your building.
FOR YOUR SAFETY READ BEFORE LIGHTING
•Immediately call your gas supplier from a neighbor’s
phone.
•If your gas supplier cannot be reached, call the fire
department.
C. Use only your hand to turn the gas control lever. Never
use tools. If the lever will not turn by hand, do not try to
repair it, call a qualified service technician. Force or
attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
LIGHTING INSTRUCTIONS —ELECTRONIC
1. For complete shut-down, turn remote wall switch to
“OFF.”
2. Open lower control compartment door.
3. Push in gas control lever slightly and turn to “OFF”. Do
not force.
4. Close the main line shut-off valve.
5. Close lower control compartment door.
TO TURN OFF GAS TO APPLIANCE
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Turn remote wall switch to “OFF.”
3. Open lower control compartment door.
4. Verify main line shut-off valve is open.
5. Push in gas control lever slightly and turn to “OFF”. Do
not force.
6. Wait five (5) minutes to clear out any gas. If you then
smell gas, STOP! Follow “B”in the safety information
above on this page. If you do not smell gas, go to the
next step.
7. Push in gas control lever slightly and turn to “ON”. Do
not force.
8. Turn “ON”all electrical power to appliance (remote wall
switch).
9. Close lower control compartment door.
TO SHUT OFF
1. Turn off all electrical power to the appliance (remote wall
switch).
Note: Lever cannot be turne to "OFF" unless
lever is pushed in slightly. Do not force.
M
C
P
O N
O
F F
ON/OFF SWITCH

14 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM
Note: Before troubleshooting the gas control system, be sure external gas shut off valve (located at gas supply inlet) is in
the “ON”position.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
CORRECTIVE ACTION
SYMPTOM
A. Defective Ignitor
(no spark at electrode)
B. Defective or misaligned
electrode at pilot (spark at
electrode).
C. Gas supply pressure errant.
D. Pilot orifice plugged.
A. Defective pilot generator
(thermopile) or remote wall
switch wiring.
B. Defective automatic valve
operator.
C. Defective limit switch.
A. Wall switch or wires
defective.
B. Pilot generator may not be
generating sufficient
millivoltage.
C. Plugged burner orifice.
A. Pilot flame may be too low or
blowing (high) causing the pilot
safety to drop out.
Check for spark at electrode and pilot; if no spark and electrode wire
is properly connected, replace the ignitor.
Using a match, light pilot. If pilot lights, turn off pilot and trigger the
red button again. If pilot lights an improper gas mixture caused the
bad lighting and a longer purge period is recommended. If pilot will
not light check gap at electrode and pilot - should be ¹⁄₈"
(3 mm) to have a strong spark. If gap measures ¹⁄₈", replace pilot
assembly
(Figure 13 on page 7) .
Check inlet gas pressure. It should be within the limits as marked on
the rating plate.
Clean or replace pilot orifice.
Check pilot flame. It must impinge on pilot generator
(Figure 13 on
page 7) . Clean and/or adjust pilot for maximum flame impingement
on generator.
Be sure wire connections from generator at gas valve terminals are
tight and generator is fully inserted into the pilot bracket.
One of the wall switch wires may be grounded. Remove wall switch
wires from valve terminals. If pilot now stays lit, trace wall switch
wires for a ground. May be grounded to appliance or gas supply.
With pilot operating (lit), check pilot generator with a millivolt meter.
Take reading at generator terminals of gas valve. Should read 325
millivolts minimum while holding valve knob depressed in pilot
position and wall switch “OFF.”Replace faulty generator if reading is
below specified minimum.
Turn knob to “ON,”place wall switch to “ON.”Millivolt meter should
read greater than 100mV. If reading is OK and the burner does not
come on, replace the gas valve.
Reset the limit switch button. If still not working, isolate the limit
switch. Disconnect the wires from the “ON/OFF”switch and the valve
(label wires for reattachment). Test for continuity with a multimeter.
If continuity is not indicated, switch is defective and must be replaced.
Check wall switch and wires for proper connections. Place jumper
wires across terminals at wall switch. If burner comes on, replace
defective wall switch. If OK, place jumper wires across wall switch
wires at gas valve. If burner comes on, wires are defective or
connections are bad.
Re-check Symptom #2.
Check burner orifice for blockage and remove.
Clean/adjust pilot flame for maximum impingement on pilot genera-
tor
(Figure 12 on page 7) .
POSSIBLE CAUSES
1. Spark ignitor will not
light pilot after repeated
triggering of red button.
2. Pilot will not stay lit
after carefully following
lighting instructions.
3. Pilot burning, no gas to
burner, valve knob “ON,”
wall switch “ON.”
4. Frequent pilot outage
problem.

15
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
TROUBLESHOOTING THE ELECTRONIC IGNITION SYSTEM
N ote: Before troubleshooting, be sure that the appliance main line gas shut-off valve, the gas control valve and the wall switch are in
the “ON”position.
Important: “ON/OFF”switch must be “OFF”before performing continuity test. Adjust multimeter to the ohm setting when performing continuity tests.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
Confirm 24Vac output from transformer (red and blue leads). If no, then replace
transformer.
Note: Before replacing transformer check wiring for loose connections or broken wires
and repair as needed. Turn off power before replacing transformer.
Disconnect the two black wires from the two red wires attached to the limit switch and
transformer (label wires for correct reattachment). Test “ON/OFF”wall switch for
continuity with a multimeter. If continuity is not indicated, switch is defective and must
be replaced.
Note: Before replacing “ON/OFF”switch be sure to check switch wiring for loose
connections or broken wires and repair as needed.
Resetthelimit switch button. If still not working,isolatethelimit switch in the same manner
as the “ON/OFF”switch (label wires for correct reattachment) and test for continuity with
a multimeter. If continuity is not indicated, switch is defective and must be replaced.
If reading is not 24V at “TH”and “TR”terminals on ignition control, replace ignition
control module.
Check for availability of gas at control. Check that manual valve upstream of gas control
and manual valve on gas control are in the full “ON”position. Check for plugged pilot
orifice or plugged pilot tubing. Also check pilot key adjustment at gas control valve.
Confirm 24Vac at gas valve terminals “C”and “P”of the gas valve. If yes, valve is OK. If
no voltage, check the wiring. If wiring tests OK, check ignition control module.
Confirm24Vacat “PV”and “PV/MV”on ignition control module. If no,replacetheignition
control.
Check if pilot line and pilot orifice are plugged. Clean or replace as necessary. Adjust pilot
flame if necessary.
Confirm that the igniter is sparking at the pilot assembly when the “ON/OFF”switch is
activated. If not, undertake the following steps:
With“ON/OFF”switch “OFF,”remove wire at “TR”terminalat the ignition control module.
Disconnect the electrode wire “IGN”at the ignition control. Connect one end of a jumper
wire to the metal blade of a small screwdriver. Attach the other end of the jumper wire to
any metal part of the chassis. Reconnect the “TR”terminal. Position end of metal blade
approximately ¹⁄₈" (3 mm) from the “IGN”terminal. Activate the “ON/OFF”switch.
Sparking should occur between the “IGN”terminal and screwdriver blade. If sparking
does occur, the ignition control module is OK, but either the electrode wire of the igniter
is faulty and the pilot and electrode assembly should be replaced.
Electrode tip needs to be realigned to correct location. ³⁄₃₂" to ¹⁄₈" (2 –3 mm) gap between
electrode tip and pilot hood is desired.
Pilot and electrode igniter must be properly aligned so that the pilot flame impinges the
top ³⁄₄" (19 mm) of the electrode igniter. The electrode igniter must be pushed all the way
into the pilot bracket. Adjust pilot flame if necessary.
Check main burner orifice(s) for stoppage. Clean or replace.
Check for 24 volts at gas operator terminals “M”and “C.”If there is a 24V reading and the
burner does not come on, the valve operator is defective and the gas valve must be
replaced.
Adjust pilot flame and/or check location of electrode igniter.
SYMPTOM CORRECTIVE ACTION
1. No spark and no pilot gas.
2. Spark but no pilot gas
(no solenoid valve click).
3. Spark but no pilot gas
(solenoid valve click).
4. Pilot gas available, but
pilot does not light
(solenoid click).
5. Pilot burning but main
burners will not come on.
Note: Wait at least 90
seconds after pilot lights
before doing the checkout
for possible causes.
6. Burners come “ON”but go
“OFF.”
A. Faulty transformer.
B. “ON/OFF”switch defective.
C. Limit switch defective.
D. Ignitioncontrolmoduledefective.
A. No gas supplied to pilot valve.
B. Faulty gas valve.
C. Ignitioncontrolmoduledefective.
A. Gas supply to pilot restricted.
A. Ignition control or igniter
defective.
B. Sparking, but not at proper
location.
A. Low pilot flame or improper
alignment of electrode igniter in
pilot flame.
B. Burner orifice(s) plugged.
C. Gas valve defective.
A. Low pilot flame or electrode
igniter not correctly positioned.
POSSIBLE CAUSES

16 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ACCESSORY COMPONENTS
Remote Control System (Standard) H0249 RCL
Standard Remote Control System
(Model RCL)
The Model RCL (Standard) Remote Control
System, features a simplistic on/off control
function for the fireplace. This model includes
a hand-held transmitter, a remote receiver
with wall-mount coverplate and all hardware
required to install the unit. The remote re-
ceiver can be wall or hearth mounted.
The transmitter has ON and OFF functions that
are activated by pressing either button on the
face of the transmitter. When a button on the
transmitter is pressed, a signal light illuminates
briefly to verify that a signal has been sent.
The Model RCL is designed to operate with all
millivolt ignition systems, as well as electronic
ignition systems. It may be installed with use for
either natural or propane gas appliances. The
RCL offers ease of installation and allows you to
execute on-off commands to the fireplace
effortlessly with one simple motion.
The Model RCL comes complete with detailed
operating instructions.
Forced Air Kit 051331 FAB-1600
with Variable Speed Wall Switch
Forced Air Kit
If the optional forced air kit, Model FAB-1600,
is to be used on the GHC-6500 Series appli-
ances, refer to the installation instructions
packed with the fan kit. The GHC-6500 Series
appliances have been pre-wired at the factory
to accept the forced air kit at some later time.
The appliance, must however, be connected to
the main power supply at the time of installa-
tion if the FAB-1600 forced air kit is to be
installed later. The kit comes with a variable
speed wall switch.
Horizontal Trim Installation
There are two (2) optional horizontal trim kits,
Models 41HTK-PB, 41HTK-SPB available for
use with the GHC Series appliance. The 41
HTK-SPB kit's trim is solid polished brass, as
opposed to the 41HTK-PB kit's trim which has
a polished brass coating. Refer to the specific
installation instructions packed with each trim
kit for their proper usage and installation.
Horizontal Trim Kit 051251 41HTK-SPB
Horizontal Trim Kit 051252 41HTK-PB
Bi-Fold Doors 12M07 38ABF
12M08 38ABF-BB
12M09 38ABF-BS
Aluminum-Framed Bi-Fold Doors
Your appliance can be fitted with beautiful
aluminum-framed bi-fold doors. Model 38ABF
doors are available for use with these appli-
ances. Doors are easily fitted to the fireplace
opening. Model 38ABF doors come with stan-
dard black finish. Model 38ABF-BB doors have
abeautifulbrassfinish. Model38ABF-BSdoors
have a brushed stainless finish.
Aluminum-Framed Twin Pane Door
Your appliance can be fitted with beautiful
aluminum-framed twin pane doors. Models
38TBA-BB and 40TBA-BB doors are available
for use with these appliances. Doors are easily
fitted to the fireplace opening. Both models
come with a beautiful bright brass finish.
Glass Enclosure Panels
Your appliance can be fitted with beautiful
glass enclosure panels. Model 38AGEP and
40AGEP doors are available for use with these
appliances. Doors are easily fitted to the fire-
place opening. Model 38AGEP and 40AGEP
doorscome with astandard black finish. Model
38AGEP-BB and 40AGEP-BB doors come with
beautiful bright brass finish.
Twin Pane Door 12M45 40TBA-BB
Twin Pane Door 12M44 38TBA-BB
Glass Enclosure Panels 12M51 38AGEP
12M52 38AGEP-BB
12M53 40AGEP
12M54 40AGEP-BB
To ensure warranty and to prevent a potential
fire hazard, do not use any other doors on
these appliances.

17
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
GAS CONTROLS—ROBERTSHAW MILLIVOLT
REPLACEMENT PARTS LIST
MILLIVOLT SYSTEM
.oNNOITPIRCSED
0056-CHG enaporPdnalarutaN 0056-DRG enaporPdnalarutaN
.oNtraP.ytQ.oNtraP.ytQ
.1)kcalB(revuoL,raBB71969-BL5--
.2poT,raBB60969-BL1--
.3rewoL/reppU,mirT2906202--
.4lluP/neercS,lenaP97039029703902
.5neercS,doR28311022831102
.6mottoB,yrotcafeR23434012343401
.7)etelpmoC(teSgoL1083M3111083M311
.amottoB,raeR,goL1013M3111013M311
.bmottoB,tnorF,goL1043M3111043M311
.ctfeLpoT,elddiM,goL1053M3111053M311
.dthgiRpoT,elddiM,goL1063M3111063M311
.etfeL,poT,goL1023M3111023M311
.fthgiR,poT,goL1033M3111033M311
.883KSD-FBS-tiKpotSrooD24683012468301
.9dleihSytsedoM3832301--
.01ylbmessArenruB11695011169501
.11llaW,hctiwSlortnoCFFO/NO27952012795201
.21lenaPnialecroP50143015014301
.oNNOITPIRCSED
0056-DRG/CHG larutaN 0056-DRG/HCG enaporP
.oNtraP.ytQ.oNtraP.ytQ
.02)CLRVM0007(saG,evlaV73790011773901
.12ozeiP,rotingI10319011031901
.22)etelpmoC(lortnoC,lenaP18595012859501
.32timiL,hctiwS89600918960091
.42).taN(14#,ecifirO /).porP(35#13400912340091
tiKgnitareD,ecifirO61915017191501
.52elipomrehT72549017254901
.62ylbmessatoliP16739012673901

18 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
REPLACEMENT PARTS —MILLIVOLT
10
6
22
24
26
21
20
25
23
2
1
1
3
8
5
4
9
GRD-6500
GHC-6500
26
25
11
12
12
7b
7e 7a
7d
7f
7c

19
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
GAS CONTROLS—ROBERTSHAW ELECTRONIC
REPLACEMENT PARTS LIST
ELECTRONIC SYSTEM
.oNNOITPIRCSED
0056-DRG/CHG larutaN 0056-DRG/HCG enaporP
.oNtraP.ytQ.oNtraP.ytQ
.02)REPI0027(saG,evlaV40289015328901
.12ylbmessatoliP16289012628901
.22)wahstreboR(lortnoCnoitingI30289013028901
.32)llewyenoH(lortnoCnoitingI51740915174091
.42)4102-NART-NIC(-yssAremrofsnarT31404013140401
.52)etelpmoC(lortnoC,lenaP18695012869501
.62timiL,hctiwS89600918960091
.72).porP(35#/).taN(14#,ecifirO13400912340091
tiKgnitareDecifirO61915017191501
.oNNOITPIRCSED
0056-CHG enaporPdnalarutaN 0056-DRG enaporPdnalarutaN
.oNtraP.ytQ.oNtraP.ytQ
.1)kcalB(revuoL,raBB71969-BL5--
.2poT,raBB60969-BL1--
.3rewoL/reppU,mirT2906202--
.4lluP/neercS,lenaP97039029703902
.5neercS,doR28311022831102
.6mottoB,yrotcafeR23434012343401
.7)etelpmoC(teSgoL1083M3111083M311
.amottoB,raeR,goL1013M3111013M311
.bmottoB,tnorF,goL1043M3111043M311
.ctfeLpoT,elddiM,goL1053M3111053M311
.dthgiRpoT,elddiM,goL1063M3111063M311
.etfeL,poT,goL1023M3111023M311
.fthgiR,poT,goL1033M3111033M311
.883KSD-FBS-tiKpotSrooD24683012468301
.9dleihSytsedoM3832301--
.01ylbmessArenruB11695011169501
.11llaW,hctiwSlortnoCFFO/NO27952012795201
.21lenaPnialecroP50143015014301

20 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
REPLACEMENT PARTS —ELECTRONIC
Printed in U.S.A. © 2001 by Lennox Hearth Products
P/N 725,030M REV. D 07/2004
The manufacturer reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
1110 West Taft Avenue •Orange, CA 92865
Manufactured by LHP
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
26
10
25
11
6
27 21
20
22
2
1
1
3
24
8
9
GRD-6500
GHC-6500
23
12
12
7b
7e 7a
7d
7f
7c 5
4
21
(REF)
