Supermicro SUPER X5DPL-8GM Installation and operating instructions

Pin
Number
1
2
3
Definition
+5V Standby
Ground
Wake-up
Wake-On-LAN Pin
Definitions (WOL)
Wake-On-LAN
The Wake-On-LAN header is des-
ignated WOL. See the table on the
right for pin definitions. You must
enable the LAN Wake-Up setting in
BIOS to use this feature. You
must also have a LAN card with a
Wake-on-LAN connector and
cable.
Wake-On-Ring
The Wake-On-Ring header is des-
ignated JWOR1. This function al-
lows your computer to receive
and "wake-up" by an incoming call
to the modem when in suspend
state. See the table on the right
for pin definitions. You must have
a Wake-On-Ring card and cable to
use this feature.
Wake-on-Ring
Pin Definitions
(JWOR1)
Pin
Number
1
2
Definition
Ground
Wake-up
Keylock
The keyboard lock connection is
designated on JL1. Utilizing this
header allows you to inhibit any
actions made on the keyboard, ef-
fectively "locking" it.
SMB
A System Management Bus
header is located above the IPMI
connector. Connect the appropri-
ate cable here to utilize SMB on
your system. (*SMB signal is
3.3V.)
SMB Header
Pin Definitions
Pin
Number
1
2
3
4
Definition
Data
Ground
Clock
No Connection
Addendum-X5DPL-8GM/X5DPL-iGM (Rev. 1.1)
add-X5DPL-8MG-4/08/04
