Supermicro SuperWorkstation 7033A-T User manual

SuperWorkstaion 7033A-T Serverboard Components
31
32
33
34
6
47
48
49
50
51
52
53
54
55
56
14
JP36: Power supply fail alarm reset switch
JOH1: Overheat LED
JP37: Watch dog
JWOR1: Wake-on-Ring header
Battery
ICH4 chipset
JP39: System bus speed
DIMM #4 socket
DIMM #3 socket
DIMM #2 socket
DIMM #1 socket
JP9: Power fail alarm En/Disable
JP8: Third power supply fail header
J15: CPU power connector
ATX power connector
58
57
Super X5DAL-TG2 serverboard
Serial ATA port #4
Serial ATA port #3
Serial ATA port #2
Serial ATA port #1
JPA1: SATA #1/#2 Enable/Disable
JPA2: SATA #3/#4 Enable/Disable
JL1: Chassis intrusion header
JSLED: SATA LED header
WOL1: Wake-on-LAN header
FPUSB 0/1/2/3: Front panel USB headers
Floppy connector
IDE#2 connector
IDE#1 connector
Chassis fan2
JBT1: CMOS clear
JF2: Front control panel connector
Chassis fan1
JD1: PWR LED/speaker header
MCH
CPU1 socket
CPU2 socket
JPUSB: USB wake-up
35
36
37
JPWAKE: Keyboard wake-up
Keyboard & mouse
USB 0/1 port
COM1 port
Parallel port
COM2 port
CPU fan1
Gigabit LAN 1/2 ports
CPU fan2
Overheat fan
JP38: Thermal fan control
J30: Power conn.(for use w/AGP Pro cards)
8xAGP 1.5V
PCI #2/33MHz
PCI #1/33MHz
PCI-X #2/100MHz
PCI-X #1/66MHz
J12: IR/CIR header
JPL1: Gigabit Enable/Disable
48
49
50
51
52
53
54
55
56
57
58
46, 47
1. Front bezel lock
2. 4 x 1" hot-swap SATA drive bays
3. SATA activity LED
4. Reset: use the reset button to reboot the system
5. Front side USB access
6. Main power button
7. Floppy drive
8. 2 x 5.25" drive bays
9. Power: Indicates power is being supplied to the system.
HDD: Indicates IDE hard disk/CD-ROM drive activity.
NIC: Indicates network activity on GLAN port.
Overheat: Indicates an overheat condition in either one of the processors.
10.
11.
12.

X5DAL-TG2 Quick Reference
Jumpers Description  Default Setting
JBT1 CMOS Clear Pad
JP9 Power Fail Alarm En/Disable Open (Disabled)
JP37 Watch Dog Pins 2-3 (NMI)
JP38 Thermal Fan Control Closed (Full Speed)
JP39 System Bus Speed Pins 1-2 (Auto)
JPA1 SATA #1/#2 Enable/Disable Pins 1-2 (Enabled)
JPA2 SATA #3/#4 Enable/Disable Pins 1-2 (Enabled)
JPL1 GLAN Enable/Disable Pins 1-2 (Enabled)
JPUSB USB Wake-up Pins 1-2 (Disabled)
JPWAKE Keyboard Wake-up Pins 1-2 (Disabled)
1. Power supply
2. Alarm reset button
3. 12cm exhaust fan
4. Mouse & keyboard ports
5. USB ports
6. COM1 port
7. COM2 port
8. Ethernet ports
9. Paralllel port
10. PCI expansion slots
Supermicro SuperWorkstation System)
SuperWorkstation
dual Xeon processor server solutions.
REV 1.00
LBL-0098
2003 Super Micro Computer Inc. Specifications subject to change without notice. All other brands and names are the property of their respective owners.
