SureCall SC-288W User manual

SureCall Wide Band Outdoor Omni Antenna
SC-288W User Guide
•Wide Band (698 – 2700 MHz)
Broadband
•2G/3G/4G and WLAN systems
•Designed for outdoor use only
•Omni-directional antenna 3-4 dB Gain
SC-288W
SureCall | 48346 Milmont Drive, Fremont CA 94538 | 1-888-365-6283 | [email protected]
Frequency 698-960 / 1700-2700 MHz
Input Impedance 50 Ohm
Antenna Gain 2-3 dBi / 3-4 dBi
VSWR ≤1.8
Power Rating 10 W
Polarization Type Vertical
Radiation Omni-directional
Maximum Power 100 Watt
Connector type N-Female
Dimension 9.5” x 3.9”
Color White
Mount
-22°F to +176°
Operating Temperature
E:72 H:92/ E:50 H:80
Beamwidth Groundplane
Mounts to ceiling
Material Fiberglass
Overview
The SC-288W wide band fiberglass antenna is an omni-directional antenna that can receive
and send signals from 360° and does not need to be pointed toward a cellular tower. Range
of antenna is approximately 30 miles to and from cellular towers free of obstructions.
Besides the antenna itself, parts include mounting equipment for either a flat horizontal
surface or a wall. It should be mounted in an upright position for best results.
Specifications
Installation
Place antenna through the hole on the top of the L-Bracket.
Attached 3 screws through the L-Bracket and into holes on the base of the antenna.
Place the 2 U-bolt ends with the J-Mount (not included) inside, through the U-Bolt base and then through the L-
Bracket.
Attach the 3 lock washers to the ends of the U-Bolts on the back of the L-Bracket and tighten with the provided
Hex nuts.
2017 V1.2
Mounts on the roof or wall
U-Bolt J-Mount
(not included)
L-Bracket
