Surefire 2211 Signature User manual

2211
®SigNAturE
USER MANUAL
RECHARGEABLE VARIABLE-OUTPUT LED WRISTLIGHT + WATCH
300
LUMENS 4h
60
LUMENS
OUTPUT OUTPUT RUNTIME
MVB
13h
15
LUMENS
OUTPUT RUNTIME MAXVISION
BEAM™
1h
RUNTIME
HIGH MED LOW
ANSI / FL 1 STANDARD
FUEL GUAGERECHARGEABLE

2211
®SigNAtURE
RECHARGEABLE VARIABLE-OUTPUT LED WRISTLIGHT + WATCH
RUGGED
POLYMER BODY
PUSHBUTTON
SWITCH
PUSHBUTTON
SWITCH
NYLON
WRISTBAND
MAXVISION
MULTIFACTED
REFLECTOR
WHITE-LIGHT LED
Kit Contents:
• 2211 Signature Wristlight • Micro-USB cable
INTEGRAL
RECHARGEABLE
LITHIUM-ION
BATTERY
1

Kit Contents:
• 2211 Signature Wristlight • Micro-USB cable
MICRO-USB
CHARGING PORT
OUTPUT
RUNTIME*
WEIGHT (w/battery)
SWITCHING
DIMENSIONS
MATERIALS
COLOR
POWER SOURCE
High: 300 lumens Med: 60 lumens Low: 15 lumens
High: 1.0 hours Med: 4.0 hours Low: 13.0 hours
3.75 oz (106 g)
Ambidextrous pushbutton
2.36” L x 2.02” W x 1.03” H
(6.1 cm x 5.1 cm x 2.8 cm)
Polymer body; nylon wristband
Black
Rechargeable lithium-ion battery
*All performance claims tested to ANSI/NEMA FL1-2009 Standard.
2211 SIGNATURE WRISTLIGHT + WATCH //
FUEL GAUGE MaxVision Beam™(MVB) is a
smooth, broad light pattern perfect
for close- to mid-range tasks
WWW.SUREFIRE.COM
2

LIGHT ACTIVATION
High Output: Pressing either pushbutton switch once will activate the high output. Pressing
either switch individually again after 0.5 seconds will turn the light off.
Medium Output: Pressing either pushbutton switch twice within 0.5 seconds will activate the
high output and then the medium output. To turn the light off, press either switch again.
Low Output: Pressing either pushbutton switch three times within 0.5 seconds will activate
the high output, medium output and then the low output. To turn the light off, press
either switch again.
When using the WristLight with a handgun, When using the WristLight with a handgun,
activate light—strapped to your support (non-gun) wrist—before drawing pistol from
holster. Deactivate light after safely holstering pistol. Do not activate, deactivate, or adjust
your 2211 Signature while holding a firearm.
PROGRAMMING THE 2211 SIGNATURE’S ACTIVATION SEQUENCE
The 2211 SIGNATURE’S default activation sequence goes from high to medium to low output and then
off; however, it can also be programmed by the user to reverse this sequence—low-med-high-off—to
accommodate personal preference. The 2211 Signature must be plugged into its charger to program the
activation sequence. Once programmed and removed from its charger, the activation sequence will not
change unless the 2211 Signature is reprogrammed to its default sequence.
To reverse the 2211 Signature’s default activation sequence:
1. Plug 2211 Signature into its charger
2. Press and release one of the pushbuttons three times until low output is activated
3. Wait 5 or more seconds, then press one of the pushbuttons once more, turning the 2211 Signature off
4. Remove 2211 Signature from its charger and test activation sequence — it should now be low-med-high-off
3

To restore 2211 Signature’ activation sequence to its default setting (high-med-low-off), repeat the above
procedure with the following exception in Step #2: Press and release pushbutton three times until HIGH
output is activated.
FUEL GAUGE
The 2211 Signature is equipped with an LED that lets you monitor the battery charge status, both during
use and while charging. See FUEL GAUGE KEY for an explanation of the LED colors and their meanings.
BATTERY CHARGING
The 2211 Signature is powered by an integral lithium-ion battery that will provide years of service,
depending on use. The included micro-USB charger can be plugged into a wall socket, or, after removing
the USB cable from the AC plug, into a USB port.
To charge the lithium-ion rechargeable battery:
1. Insert micro-USB charging plug into 2211 Signature charging port receptacle.
2. Insert wall charger plug into AC outlet, or USB plug into USB port of a computer or
some other device that will provide power to the 2211 Signature.
3. When fuel gauge LED turns green, the light is charged to more than 90% of battery capacity.
NOTE: Charging a fully depleted battery can take up to three hours. The light may be left plugged into the
charger without damaging the battery.
FUEL GAUGE KEY
Full
Battery charge low.
Reduce output level
or recharge battery.
Empty. Recharge
battery immediately.
WWW.SUREFIRE.COM
4

Do not attempt to remove or replace the 2211 Signature battery. Doing so will void the warranty. If battery
needs repair or replacement, contact SureFire at 714-545-9444.
WATCH OPERATION & CARE
Read the enclosed manual for instructions on how to operate and care for the
watch movement of the 2211 Signature watch and WristLight.
The watch is powered by its own battery and can be replaced by a watchmaker following these steps:
1. Remove two Allen screws on top of 2211 Signature with a 5/64” hex key.
2. Remove two small set screws adjacent to crown using a 0.050” hex key and remove watch from
WristLight body.
3. Carefully remove back plate of watch.
4. Replace spent battery with new one, 377 Silver Oxide.
5. Install back plate to watch.
6. Secure watch to body by reversing steps 1 and 2. ADVISORY: Limit tightening of top screws to finger
tight then an additional 1/2 turn to keep from damaging the watch module.
BATTERY INFORMATION & WARNINGS
Before replacing batteries, read the enclosed BATTERY INFORMATION/WARNING insert in your
original packaging. For additional battery safety, handling, and product information, visit
www.surefire.com/batteries.
MAINTENANCE
Use a clean, dry cloth to wipe off body and window. For additional tips on maintaining your SureFire
illumination tool, visit www.surefire.com/faqs-maintenance.
5

THE SUREFIRE NO-HASSLE GUARANTEE
We’ll do what it takes to keep your SureFire gear running smoothly.
SureFire warrants that if you — our customer — purchase one of our products, and we determine
that it is defective in material and/or workmanship during your lifetime, we will repair or replace it for
free or refund your money — no hassle! There are just a few exceptions. For complete details, visit
www.surefire.com/warranty.
WARRANTY CLAIMS
For claims, contact Customer Service at 714-545-9444 to obtain a Return Merchandise Authorization
number (RMA#). Then package the unit carefully and send to (no CODs):
SureFire, LLC.
Repairs Department, RMA#___
17680 Newhope Street, Suite B
Fountain Valley, CA 92708
SureFire will pay any reasonable shipping costs to return the unit to you.
WWW.SUREFIRE.COM
6

Revision C 2-2018
71-01-995
2211-B-BK-SF
18300 MT. BALDY CIRCLE
FOUNTAIN VALLEY, CA 92708-6122
WWW.SUREFIRE.COM
Patents: 9,155,168, D758,628
