SureShot Zoom User manual

mgigolf.com
USER MANUAL
VERSION 1

2
ZOOM with Pulse Technology USER MANUAL
mgigolf.com
Congratulations on your purchase of the Sureshot ZOOM with Pulse Technology.
The ZOOM with Pulse Technology is packed with features such as:
Intelligent Pin seeking technology. This advanced mode uses uniquely developed
software that ensures the closest object is chosen eliminating objects beyond the ag.
Pulse – The pulse feature provides a short vibration when the target is acquired.
Power On
Once activated, the LCD
display will remain active
and show the last distance
measured for 15 seconds
GETTING STARTED
Mode Button
1. Press and hold for 5 seconds
to toggle between Metres/
Yards
2. Quick press to cycle between:
– Scan Mode
– Pulse Mode
– Default Mode
Adjustable Eye Piece
Battery Door
Wrist Strap Connector

3
ZOOM with Pulse Technology USER MANUAL
mgigolf.com
CONTENTS OF BOX
• Sureshot ZOOM with Pulse Technology Laser
• Protective Pouch
• Quick Start Guide
• Lens Cloth
• Wrist Strap
• Long Life Lithium Battery
To begin using your ZOOM with Pulse Technology Laser, remove the protective plastic
from the battery and insert into the laser rangender. Please refer to page 2 to locate the
Battery Door.
STARTING YOUR ZOOM with Pulse Technology Laser
The ZOOM with Pulse Technology Laser has two buttons: the Power button and the Mode
button (refer to page 2).To turn on, press the Power button for one second, the ZOOM with
Pulse Technology Laser LCD screen will turn on.
ADJUSTING THE FOCUS
The ZOOM with Pulse Technology Laser is designed with an adjustable eyepiece (dioptre).
By adjusting the focus, people with far sighted or near sighted vision can use the ZOOM
with Pulse Technology Laser without glasses. Looking through the eyepiece, turn the
dioptre left or right until the view is focused for you.

4
ZOOM with Pulse Technology USER MANUAL
mgigolf.com
OPERATING INSTRUCTIONS
Hold the ZOOM with Pulse Technology Laser to your eye and depress the Power button
once to turn on.The LCD display will now show three lines and a small rectangular box.
Line the target up so it appears inside the rectangular box, then depress the Power button
once.The distance from you to the target will be displayed on the screen instantly.
PRIORITY LOC
The ZOOM with Pulse Technology Laser instinctively locks onto the nearest target, which
may be the smallest among multiple objects in the background giving you condence
you have the correct distance every time. Priority Loc intelligence delivers the rst and
closest target by scanning the area and displaying only the nearest distance.This feature
automatically works by pressing the Power button once.
DISPLAY LOC
Each time the Power button is pressed, the distance is displayed on screen for 15 seconds,
after which the screen automatically switches off.
PINLOC MODE ( )
PINLOC technology ensures even the smallest target is locked On from the longest
possible distance.This is important for delivering pinpoint accuracy.This feature is
automatically delivered when the Power Button is depressed quickly once.
SCAN MODE ( )
The Scan feature displays a continuous update of distances to various targets across a
panoramic area.To use the Scan feature, hold the Power Button down and pan across
the target area. Once complete, release your nger and resume using the ZOOM with
Pulse Technology Laser as usual.
DISTANCE M/Y
PULSE
LOW BATTERY INDICATOR
TARGET MARK
PINLOC
SCAN

5
ZOOM with Pulse Technology USER MANUAL
mgigolf.com
UNIT MEASUREMENT CHANGE
ThE ZOOM with Pulse Technology Laser can be used to measure distances in metres or
yards. Press the Mode button for 5 seconds to change the unit of measurement display .
AUTOMATIC POWER-SAVE
The ZOOM with Pulse Technology Laser will automatically switch off after 15 seconds of
inactivity.
BATTERY INDICATOR
A battery level warning will appear when the battery is running low.The battery will last
approximately 3000 actuations.The battery can be replaced by removing the battery
door (see diagram on page 2).
Any brand BCR2-3V lithium battery can be used.
ACCURACY
The ZOOM with Pulse Technology Laser delivers incredible accuracy at +1 or -1 metre/
yard.
The range is dependent on the reectivity of the target.The colour, surface, shape and
size of the target will affect reectivity and the range. For example, red is highly reective
and will give longer range as opposed to black which is the least reective colour. A shiny
surface will also provide more range than a dull one and likewise, a small target is more
difcult to range than a large target.The angle to which you set your target also affects
accuracy.A 90 degree angle will give you good range while a steep angle will provide
limited range. Please note lighting, rain and fog can also affect accuracy levels, the less
light the shorter the unit’s maximum range.
285

6
ZOOM with Pulse Technology USER MANUAL
mgigolf.com
REGISTERING
Follow the easy instructions at www.mgigolf.com/XXXX and enter the serial code found
on the box/unit.
The serial code starts with 5 and then an uppercase i eg. ZX...
WHY SHOULD I REGISTER MY LASER?
It is recommended that you register your ZOOM with Pulse Technology Laser for warranty
purposes. Registering your device helps you by allowing our customer service team to
quickly view which equipment you own, where you purchased it and if you misplace or
lose your sureshot and the unit is found.
CLEANING AND MAINTENANCE
Gently blow away any dust or debris on the lenses or use the lens cloth.To remove dirt or
ngerprints, rub in a circular motion. Use of a coarse cloth or unnecessary rubbing may
scratch the lens surface and eventually cause permanent damage. For a more thorough
cleaning, photographic lens tissue and photographic-type lens cleaning uid or isopropyl
alcohol may be used.Always apply the uid to the cleaning cloth – never directly on the
lens. For protection of your ZOOM with Pulse Technology Laser, always store in the
pouch provided.
IMPORTANT ADVICE
• Users need to change the battery when the battery icon displays empty.A low battery
can affect accuracy. If you do not use the ZOOM with Pulse Technology Laser for a long
period of time, please take the battery out to minimise drainage.
• Do not touch the eyepiece directly or disassemble the device for any reason.
• If the external lens is dirty, please clean it with the lens cloth or isoprohy alcohol.
• Impacts or high pressure should be avoided.
• This unit is water resistant only – it is not waterproof.
• Avoid prolonged exposure of the lens in direct sunlight as this may cause damage to
the optics of the device.
NEED HELP?
Our friendly team is available via our website, telephone or email. It is recommended that
you contact us rst rather than returning to the place of purchase for the fastest response
to your query.
Email: [e-mail]
Telephone: [phone]
Live Chat: Monday to Friday 9am to 5pm AEST
For further information please visit our website www.mgigolf.com

7
ZOOM with Pulse Technology USER MANUAL
mgigolf.com
SPECIFICATIONS
Product ZOOM with Pulse Technology
Low level battery indicator Yes
PINLOC Yes
Weight 185g
Range to Flag 300m
Measure Range 4.5m to 915m
Objective Lens 24mm
Magnication 6 X
Field of View 7˚
Exit Pupil Diameter 4.0mm
Working Temperature -10˚C – 50˚C
Battery CR2 3V lithium
Dimensions 104 x 40 x 73mm
Accuracy ± 1m
Display LCD
Water Resistant Yes
Auto Battery Saving Yes after 15 sec
Multi Coated Lens for Optimum Clarity Yes
The Sureshot Zoom Laser has an Auto Shut Off feature to preserve the battery, which will
automatically turn the display off after 15 seconds of inactivity.
It is always hard to tell how long a battery will last, however normally it will run for a couple
of 1000 actuations. *Batteries are a consumable item that will require replacement
periodically.
*The batteries supplied with the unit are not rechargeable.
The Lasers use a standard CR2 3v battery.

8
ZOOM with Pulse Technology USER MANUAL
mgigolf.com
WARRANTY
Limited Warranty
Sureshotgps™ Pty Ltd (“SS”) warrants that product delivered in this package will be free from material
defects for one (1) year following the date of purchase from SS or its authorised reseller, (2) year warranty
if you register on sureshotgps.com within 30 days of purchase (Australia only). Specications subject to
change without notice. For the purpose of this warranty,“material defect” means any defect in a SS product
that can be reproduced by SS and is a substantial nonconformity from the published specications for
such product. SS shall not be responsible for any loss or damage whatsoever resulting from any defect in
or associated with its products which occur or are notied by the purchaser to SS or its authorised repairer
more than one year from said date of purchase.This Limited Warranty does not apply to the battery, normal
wear and tear or if any component of the sureshot hardware is opened or repaired by an unauthorised
person or company, and does not cover repair or replacement of any sureshot hardware damaged by:
MISUSE, MOISTURE OR LIQUIDS, EXPOSURE TO HEAT,ACCIDENT, ABUSE OR NEGLECT. Dropping your sureshot
can permanently damage the laser, optical lenses and LCD, display which is not covered under the terms
of the Limited Warranty.This Limited Warranty does not cover physical damage to the surface of the SS,
including cracks or scratches on the LCD screen and Lenses.This Limited Warranty does not extend to any
defects which have been caused or contributed by neglect, misuse or accident, nor in respect of product
which has been altered by other than authorised SS personnel or its authorised repairers.The determination
as to whether the terms of this warranty are to apply to returned products is within the sole discretion of SS
or its authorised repairer. Provided any returned product is determined to be covered by this warranty, SS or
its authorised repairers shall at SS’s sole discretion, repair or replace, free of charge, any products or parts
thereof. In no event whatsoever shall SS be liable for any incidental, special or consequential loss or damage
resulting from the purchase and/or use of its products howsoever caused and howsoever claimed. Any
liability on SS under this warranty in respect of any repair and /or replacement and/or any action involving
any of its products shall be limited to and not exceed the purchase price of the product in question.The
terms of this warranty are subject to relevant provisions of any Federal, State or Municipal law.Any dispute or
action in relation to this warranty or the construction of it shall be subject to and conducted in accordance
with the laws of Victoria,Australia.
Before returning any product, contact the SS Customer Support Group and obtain an RA number.Visit
the sureshotgps™ website www.sureshotgps.com for support contact details. If the Customer Support
Group veries that the product is likely to be defective they will issue an RA number to place on the outer
package in which the product will be shipped. SS cannot accept any product without an RA number on the
package. Warranty returns must also be accompanied by a copy of the dated proof of purchase. Deliver
the product along with the RA number to SS. If you ship the product you must assume the risk of damage
or loss in transit.You must use the original container (or the equivalent) and pay the shipping charge. SS
may replace or repair the product with either a new or reconditioned product and the returned product
becomes SS’s property. SS warrants the repaired or replaced product to be free from material defects for a
period of the greater of (i) ninety (90) days from the return shipping date; or (ii) the period of time remaining
on the original one (1) year warranty. If there is any inconsistency between this Limited Warranty and any
Warranty included in the packaging of the sureshot, the provisions of this Limited Warranty shall apply.
