SureSTAT DT10 User manual

SureStat DT10 Thermostat
User Manual
Copyright©ACF Greenhouses
All rights reserved. No part of this document may be reproduced without prior written permission.

DT10 User Manual
2
Contents
1. Overview.............................................................................................................3
What BHK-300 can do?........................................................................................3
Key features.......................................................................................................3
2. Specification ........................................................................................................4
3. Key Instruction.....................................................................................................5
4. Key Operation Instruction ......................................................................................6
4.1 Enquiry Set Point ..........................................................................................6
4.2 How to Set Parameters ..................................................................................6
4.3 Setup Flow Chart...........................................................................................7
5. Menu Instruction ..................................................................................................7
5.1 Temperature Control Range Setting (TS, HD, CD)..............................................8
5.2 Alarm High/Low Limit Setting (AH, AL).............................................................8
5.3 Compressor Delay (PT) ..................................................................................9
5.4 Temperature Calibration (CA) .........................................................................9
5.5 Display in Fahrenheit or Centigrade unit (CF)....................................................9
6. Error Description ................................................................................................ 10
Sensor Fault Alarm ........................................................................................... 10
Over-temperature Alarm.................................................................................... 10
7. Technical Assistance and Warranty ....................................................................... 11
7.1 Technical Assistance .................................................................................... 11
7.2 Warranty.................................................................................................... 11

DT10 User Manual
3
1. Overview
What can the DT10 do?
This is a dual relay output temperature controller which can be used as over-temperature protection and
automatic temperature control system for electrical appliances for home-brew, aquarium, pet breeding,
incubation, seedling heat mat, oven, terrestrial heat pad/lamp, heating pump, home fermentation, electric
radiator, electric oven etc.
The temperature controller is equipped with a dual relay to connect with both refrigeration and heating equipment
to get the desired temperature. The dual LED displays and offers display switch between Centigrade and
Fahrenheit. With its 1800 watt capacity, can handle most any 120 volt appliance.
The DT10 is designed with compressor delay protection for refrigeration, high and low temperature alarm and
sensor fault alarm. Functions such as temperature calibration, separately set differential for refrigeration and
heating, enable more accurate temperature control.
Main Features
Plug and play design, easy to use;
Dual relay output, be able to connect with refrigeration and heating equipment at the same time;
Support reading with Centigrade or Fahrenheit;
Maximum output: 1800W 15A.
Dual display window to display measured temperature and set temperature at the same time;
Temperature calibration;
Compressor delay protection for refrigeration control;
High and low temperature alarms are available;
Over-temperature and sensor fault alarm;
Heating/cooling differential function can be set separately for refrigeration and heating.

DT10 User Manual
4
2. Specification
Temperature Control Range
-50~99 °C / -50~210 ° F
Temperature Resolution
0.1 ° C / 0.1° F
Temperature Accuracy
±1°C (-50 ~ 70°C) / ±1°F (-50 ~ 160° F)
Temperature Control Mode
On/Off Control, Heating and Cooling
Input Power
115V
Output
Max. 1800 watts, 15A, 115V
Buzzer Alarm
High and Low Temperature Alarm
Sensor Type
NTC sensor (Included)
Sensor Length
2m / 6.56ft
Relay Contact Capacity
Cooling (15A, 115V)
Heating (15A, 115V)
Input Power Cable Length
1.5m (5ft)
Output Power Cable Length
1.5m (5ft)
Dimensions
Main Body: 145x68x30mm (5.5x2.7x1.3 inch)
Socket : 83x43x25mm (3.3x1.7x1.0 inch)
Ambient Temperature
-30~ 75 ° C / -22~ 167 ° F
Storage
Temperature -20~ 60 ° C / -4~ 140 ° F
Humidity 20~85% (No Condensate)
Warranty
1Year

DT10 User Manual
5
3. Keys Instruction
1. PV: Process Value. under running mode, display current measured temperature; under setting mode, display
menu code.
2. SV: Setting Value. under running mode, display setting temperature; under setting mode, display setting
value.
3. Cooling indicator: when the light is on, start refrigeration; when the light is flickering, the compressor is under
delay protection.
4. Heating Indicator: when the light is on, start heating.
5. SET key: press SET key for 3 seconds to enter menu for function setting. During the setting process, press
SET key for 3 seconds to quit and save setting changes.
6. DECRESE key: under running mode, press DECRESE key to inquiry CD value; under setting mode, press
DECRESE key to decrease value.
7. INCREASE key: under running mode, press INCREASE key to inquiry HD value; under setting mode, press
INCREASE key to increase value.
8. Heating Device Socket: this socket is for heating output.
9. Cooling Device Socket: the socket is for refrigeration output.

DT10 User Manual
6
4. Key Operation Instructions
4.1 Enquiry Set Point
When the controller is working, short press the “UP” key for one time, the heating
differential (HD) will be displayed; short press the “ DOWN ” key for one time, then the
cooling differential (CD) will be displayed. The screen will return to normal display mode
after 2 seconds without any operate.
4.2 How to Set Parameters
When the controller is working normally, press “SET” key for over 3 seconds to enter into
parameters set up mode. “SET” indicator will be on. PV window displays the first menu code
“TS”, while SV window displays according setting value. Press “SET” key to go to next menu
and display according menu code, press “UP” key or “DOWN”key to set current
parameter value. After setting done, press “SET” key for 3 seconds at any time to save the
parameters change and return to normal temperature display mode. During setting, if there
is no operation for 10 seconds, the system will quit setting mode and return to normal
temperature display mode without saving the parameters change.
4.3 Setup Flow Chart

DT10 User Manual
7
5. Menu Instruction
When the temperature is displayed in Centigrade
Menu code
Function
Setting range
Default setting
Remarks
TS
Temperature Set Value
-50～99.9℃
25℃
5.1
HD
Heating Differential Value
0.3～15℃
2.0℃
CD
Cooling Differential Value
0.3～15℃
2.0℃
AH
Alarm High Limit
-50～99.9℃
90℃
5.2
AL
Alarm Low Limit
-50～99.9℃
-40℃
PT
Compressor Delay
0～10 minutes
3 minutes
5.3
CA
Temperature Calibration
-15℃～15℃
0℃
5.4
CF
Display in Fahrenheit or
Centigrade
C
5.5
When the temperature is displayed in Fahrenheit
Menu code
Function
Setting range
Default setting
Remarks
TS
Temperature Set Value
-50～210℉
77℉
5.1
HD
Heating Differential Value
1～30℉
3℉
CD
Cooling Differential Value
1～30℉
3℉
AH
Alarm High Limit
-50～210℉
200℉
5.2
AL
Alarm Low Limit
-50～210℉
-40℉
PT
Compressor Delay
0～10 minutes
3 minutes
5.3
CA
Temperature Calibration
-15℃～15℉
0℉
5.4
CF
Display in Fahrenheit or
Centigrade
F
5.5

DT10 User Manual
8
5.1 Temperature Control Range Setting (TS, HD, CD)
When the controller is working normally, the LED displays current measured temperature
(PV), and will automatically identify and switch between refrigeration and heating working
modes.
When the measured temperature PV ≥ TS (temperature you set) + CD (cooling differential
value), system enters refrigeration status, the cool indicator will be on, and refrigeration
relay starts to work; when the cool indicator is flickering, it means the refrigeration
equipment is under compressor delay protection status. When the measured temperature
PV≤TS (temperature set value), the cool indicator will be off, and the refrigeration relay
stops working.
When the measured temperature PV≤TS (temperature set value)-HD (heating differential
value), system enter heating status, the heat indicator will be on and heating relay starts to
work; when the measured temperature PV≥ TS (temperature setting), the heat indicator will
be off, then heating relay stops working.
For example, if set TS=75°F, CD=2°F and HD=3°F, then when measured temperature is
higher than or equal to 77°F（TS+CD), system enters refrigeration status; when
temperature decline to 75°F (TS), stop refrigeration; when measured temperature is lower
or equal to 72°F（TS-HD), system enters heating status; when the temperature raised to
75°F (TS), stop heating. Repeat that so as to get the desired temperature range we want.
In case the time interval between two refrigeration is less than PT, please refer to 5.3.
5.2 Alarm High/Low Limit Setting (AH, AL)
When measured temperature is higher or equal to AH, high temperature alarm will be
triggered, buzzer will alarm with tone “bi-bi-Biii” until the temperature is lower than AH or
any key is pressed.
When measured temperature is lower or equal to AL, low temperature alarm will be
triggered, buzzer will alarm with tone “bi-bi-Biii” until the temperature >AL or any key is
pressed.
5.3 Compressor Delay (PT)
Under refrigeration mode, after power on, if the measured temperature is higher than set
temperature (TS) plus cooling differential (CD), the equipment won’t start refrigeration
immediately but waiting for a delay time.
When the time interval between two refrigeration operation is larger than preset delay, the
equipment will start refrigeration immediately; when the time interval between two
refrigeration is less than preset delay, the equipment won’t start refrigeration until preset
delay is satisfied.
Delay time will be calculated right after the moment the refrigeration stops.

DT10 User Manual
9
5.4 Temperature Calibration (CA)
If there is deviation between measured temperature and actual temperature, use
temperature calibration function to align the measured temperature and actual temperature.
5.5 Display in Fahrenheit or Centigrade unit (CF)
Customers can set the temperature display in Fahrenheit or Centigrade according to their
own habit. Default display is in Centigrade temperature. To display in Fahrenheit, set CF
value as F.
Attention: when CF value changed, all the setting value will be recovered to factory settings.
6. Error Description
Sensor Fault Alarm: when temperature sensor is in short circuit or open loop, the
controller will initiate sensor fault mode, and cancel all the actions. The buzzer will alarm,
LED displays ER. Buzzer alarm could be dismissed by pressing any key. After faults solved,
the system will return to normal working mode.
Over-temperature Alarm: when measured temperature exceeds the measuring range
(less than -50°C /-58° F or higher than 99 °C/210 ° F), the controller will initiate over-
temperature alarm mode, and cancel all the actions. The buzzer will alarm, LED displays HL.
Buzzer alarm could be dismissed by pressing any key. When temperature returns to
measuring range, the system will return to normal working status.
