SV3C HX Series User manual

US Email address [e-mail]
UK Email address: [e-mail]
:

About Camera
Connect Camera
Add Camera via LAN cable
Add Camera without LAN Cable
Set Micro SD Card Recording
View on PC
Reboot and Restore Factory Setting
More Info
01
02
03
08
10
13
16
16
1.1 Product should contain:
IP Camera * 1 Power adapter * 1
User manual * 1 Network cable * 1
WiFi antenna * 1 Screws bag * 1
1.2 Product interface
1.3 How to fit Waterproof lid.

2.Connect Camera 3.Add Camera via LAN cable
2.1 Connect network cable to router and plug in power
adapter.
The router must be able to connect to the Internet!
Please use the standard power supply.
2.2 Connect LAN cable and power to camera, it needs
about one minute to self checking and then start
working.
Network indicator light (green): always flashing
means network data transmission is normal.
3.1 Download “CamHipro” from Google Play (Android Phone) /
App Store (iPhone) or scan the QR code below to get APP
information.
3.2 Add Camera
Please click “Device in use” to add a camera via UID
number if you have connected the camera on other
devices, UID is in this format ZZZZ-123456-ABCDE.

Pan up/ down/ left/ right button,
Only available for PTZ cam using!
8.Custom camera
name
3.3 Add a sharing device
Share camera, please click “Add a sharing device” to scan
camera UID QR code, then you can add the camera on a
different device.
3.4 View Camera

3.5 WI-FI Setting
1. WIFI Name (SSID) can not include special characters
such as @ # $ % & blank etc.
2. WIFI Password: length should be within 8-31 bits
and no special characters as well.
3. Dual Band WIFI router: camera only supports 2.4ghz
WIFI but not 5ghz. If you are using a dual band WIFI
router, please either disable 5ghz or set the WIFI
name be distinguishable for 2.4ghz and 5ghz so you
can choose different WIFI for different devices.
4. If you can not set up camera successfully by wired
connection way, please refer to “AP Mode Setting” (wifi
hot spot connection) on next page.
Note:

AP Mode Wifi Hotspot Connection
If it is not easy to connect LAN cable with the camera to setup
WiFi, or no available network port, please use AP mode to
connect and setup the camera as following:
1, please supply power for the camera, DO NOT connect
network cable.
2, reset camera: Long press the reset button which is next to
the power port for 8~15 seconds, then the camera will
start to reset.
3, please wait about 1 minute and run "CamHipro" APP to
connect the camera. Camera’s SSID in AP Mode is in a format:
IPCAM-XXXXXX. Please add the camera via AP mode as below.
(Default password: 01234567)
Note: If you still can not set up camera successfully,
please contact customer service as below:
US Email address:
UK Email address:
[e-mail]
[e-mail]
4. Add Camera without LAN Cable

5.Set Micro SD Card Recording
5.1 SD Card Setting and Alarm Setting
1. Alarm push: Enable “Receive alarm push” if you need
text notification.
2. Humanoid Alarm: Please turn on “Motion detection alarm”,
“Humanoid Alarm”.
Linkage trigger: This function is triggered only when the camera
detects human form and is moving.
Alone Linkage: Can be triggered by People or other objects moving.
4.Adjust motion detection: Enable “Motion detection alarm” to make
motion detection work.
5.Motion detection alarm recording is recommended when the Micro
SD card is small.
3.Action with Alarm:
If you need motion detection recordings, enable “Alarm recording to
SD card” after format the SD card .
If you need Email alert with pictures, please enable “Alarm capture
sent to Email” , click “Configure Email” to complete Email settings,
for more detailed settings, please refer to the instruction on SV3C
website or contact SV3C customer service.
If you need to save motion detection recordings and pictures to FTP
server, please enable “Alarm recording to FTP” and “Alarm capture
saved to FTP”, click “Configure FTP” to complete FTP settings, please
refer to the FTP instruction on SV3C website.
Click “Adjust motion detection” to adjust the detection area and
sensitivity. Drag the frame to change the motion detection zone. You
can adjust the sensitivity from 1 to 50, 1 is the lowest setting. Select
“Easy setup”, if you need the motion detection work all days. Click
“advanced” button to set motion detection schedule for the camera.

5.2 Schedule Recording Setting
If you select “Easy setup”, the camera will record for 7/24
all days. Please click “advanced settings” to set recording
schedule for the camera.
5.3 Playback Record
5.4 Set Camera Time Zone
Note: When your time is DST(daylight saving time), please turn
on DST button, otherwise the recording time will beincorrect.
6.View on PC
6.1 Software Login
If you need to view the camera on PC, we recommend you
to use the HiP2P PC Client software.
Open HIP2P Client, click any one of the icons such as “ ”
then below Interface pop up, please click “OK” to log in
(Password is empty).
1. Click here to set
camera time zone
manually.

6.2 Add the camera on HiP2P PC Client software
6.3. Change the camera password
1. Click here
2.Click “Search”
4.First tick the UID
number and click
“Add”, add the cam
successfully.
3.UID number appears,
need to tick it.
1, Double click the
UID number, will
pop-up the right
setting page.
2.Change password here.
Default password is admin
Note: Please click “OK” after you enter the new
password. And must close the software, then open
it again, the new password will be updated.
6.4 Connect and manage multiple cameras at the same time
via P2P PC Client software on windows and MAC PC!
Please download the correct P2P PC Client software
for Windows and MAC PC on SV3C website:
https://sv3c.com/pc-software-hx-series-download/
Please confirm the camera and your computer are
connected with the same network , otherwise the
camera cannot be found successfully.
Any doubts about P2P function, pls contact customer
service as below:
US Email address:
UK Email address:
[e-mail]
[e-mail]

7.Reboot and Restore Factory Setting
7.1 Reconnect the power to restart the camera.
7.2 Press and hold the reset button for 8-10 seconds
and the camera will restore to factory settings.
You can also restart or reset the camera via mobile phone
or PC.
8.More Info
This manual is to help customers to know and use the
camera quickly, For detailed instructions and video
tutorials please refer to SV3C website www.sv3c.com.
This manual may have descriptions and operations that
do not match the product, If you have any questions or
need technical support Please feel free to contact us.
US Email address: [e-mail]
UK Email address: [e-mail]
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Any Changes
or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. Theselimits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
FCC Warning:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which thereceiver is connected.
