Svan SVMW823GDX User manual

SAVE THESE INSTRUCTIONS CAREFULLY
Read these instructions carefully before using your
microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you with
many years of good service.
INSTRUCTION MANUAL
Microwave Oven
Model: SVMW823GDX

(a) Do not attempt to operate this oven with the door
open since this can result in harmful exposure to
microwave energy. It is important not to break or tamper
with the safety interlocks.
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect the
lifespan of the apparatus and lead to a dangerous situation.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
Specifications
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Rated Input Power(Grill):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
SVMW823GDX
230V~50Hz
1250W
800W
1000W
23L
ø 270mm
485 293mm
Approx14 kg
410
EN-2

To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
IMPORTANT SAFETY INSTRUCTIONS
WARNING
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.( For appliance with
type Y attachment)
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY".
4. If the supply cord is damaged, it must be replaced by
before replacing the lamp to avoid the possibility of
electric shock.
5. WARNING: Ensure that the appliance is switched off
1. Read and follow the specific:"PRECAUTIONS TO
3. Keep the appliance and its cord out of reach of children
less than 8 years.
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children unless they are older than 8
2. This appliance can be used by children aged from 8
and supervised. Children less than 8 years of age shall be
kept away unless continuously supervised.
EN-3

.ovens
and keep the door closed in order to stifle any flames.
delayed eruptive boiling, therefore care must be taken
when handling the container.
shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
12.The contents of feeding bottles and baby food jars
13. Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
deposits removed.
14. The oven should be cleaned regularly and any food
11. Microwave heating of beverages can result in
keep an eye on the oven due to the possibility of ignition.
in sealed containers since they are liable to explode.
could lead to deterioration of the surface that could
15. Failure to maintain the oven in a clean condition
7. WARNING: Liquids and other foods must not be heated
10. If smoke is emitted, switch off or unplug the appliance
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
6. WARNING: It is hazardous for anyone other than a
adversely affect the life of the appliance and possibly
result in a hazardous situation.
8. When heating food in plastic or paper containers,
9. Only use utensils that are suitable for use in microwave
EN-4

beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
21.The microwave oven is intended for heating food and
allowed during microwave cooking.
cleaner.
22. Metallic containers for food and beverages are not
23. The appliance shall not be cleaned with a steam
24.The appliance is intended to be used freestanding.
16. The appliance must not be installed behind a
decorative door in order to avoid overheating. (This is not
applicable for appliances with decorative door.)
17. Only use the temperature probe recommended for this
oven.(for ovens provided with a facility to use a
temperature-sensing probe.)
18. The microwave oven shall not be placed in a cabinet
unless it has been tested in a cabinet.
19. The microwave oven must be operated with the
decorative door open. (for ovens with a decorative door.)
20. This appliance is intended to be used in household
applications.
a wall.
25.The rear surface of appliances shall be placed against
EN-5

READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
means of an external timer or separate remote-control
system.
26.The appliances are not intended to be operated by
when the appliance is operating.
27. The temperature of accessible surfaces may be high
28.WARNING: When the appliance is operated in the
adult supervision due to the temperatures generated.
combination mode, children should only use the oven under
EN-6

To Reduce the Risk of Injury to Persons
Grounding Installation
DANGER
Electric Shock Hazard
Touching some of the
internal components can
cause serious personal
injury or death. Do not
disassemble this
appliance.
WARNING
Electric Shock Hazard
Improper use of the grounding
can
result in electric shock.
Do not plug into an outlet
until appliance is properly
installed and grounded.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the
risk of electric shock by
providing an escape wire
for the electric current.
This appliance is equipped
with a cord having a
grounding wire with
a grounding plug. The
plug must be plugged into
an outlet that is properly
installed and grounded.
Consult a qualified
electrician or serviceman
if the grounding instructions
are not completely
understood or if doubt exists
as to whether the appliance
is properly grounded.
If it is necessary to use an
extension cord, use only
a 3-wire
1. A short power-supply cord
is provided to reduce the risks
resulting from becoming
entangled in or tripping over a
longer cord.
2. If a long cord set or extension
cord is used:
1)The marked electrical rating
of the cord set or extension cord
should be at least as great as
the electrical rating of the
appliance.
2)The extension cord must be
a grounding-type 3-wire cord.
3)The long cord should be
arranged so that it will not drape
over the counter top or tabletop
where it can be pulled on
by children or tripped over
unintentionally.
extension cord.
EN-7

CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp
cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the
food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10
minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for
anyone other than a
competent person to
carry out any service
or repair operation that
involves the removal of
a cover which gives
protection against
exposure to microwave
energy.
Utensil T est:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
EN-8

Materials you can use in microwave oven
Utensils Remarks
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
EN-9

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
Grill Rack( Can not be used in microwave
function and must be placed on the glass tray )
EN-10

Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
Installation
1.Select a level surface that
provide enough open space
for the intake and/or outlet
vents.
(1) The minimum installation
height is 85cm.
(2) The rear surface of
appliance shall be placed
against a wall.
Leave a minimum clearance
of 30cm above the oven, a
minimum clearance of 20cm
is required between the oven
and any adjacent walls.
(3) Do not remove the legs
from the bottom of the oven.
(4) Blocking the intake and/
or outlet openings can
damage the oven.
(5) Place the oven as far
away from radios and TV
as possible. Operation of
microwave oven may
cause interference to your
radio or TV reception.
2. Plug your oven into a
standard household outlet.
Be sure the voltage and
the frequency is the same
as the voltage and the
frequency on the rating
label.
WARNING: Do not install
oven over a range cooktop
or other heat-producing
appliance. If installed near
or over a heat source, the
oven could be damaged
and the warranty would be
void.
20cm
30cm
20cm
min85cm
0cm
The accessible
surface may be
hot during operation.
EN-11

Operation Instructions
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
1. Clock Setting
When the microwave oven is electrified, the LED will display "0:00", buzzer will ring once.
1) Press "
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
Note: 1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press " ", the oven
will go back to the previous status automatically.
1) Press " " once, the screen display "P100".
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
2) Press " " once again or turn " " to choose 80%
microwave power.
2. Microwave Cooking
Press "" the LED will display "P100". Press
" " for
" confirm, and turn
" " to set cooking time from 0:05 to 95:00. Press
again to start cooking.
operate the oven as the following steps.
times or turn "
"
to choose the power you want, and
"P100", "P 80", "P 50", "P 30 for
each added press.Then
s
EN-12
" once to select clock function, the hour
figures will flash.
5) Press " " to finish clock setting. ":" will flash,
and the time will light.
Reloj/Temporizador de cocción
Reloj/Temporizador de cocción
Reloj/Temporizador de cocción
Parar/Cancelar
Micro./Grill/Combi.
Micro./Grill/Combi.
Inicio / +30SEC./confirmar
, "P10", "G" , "C-1" or "C-2" will display
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
press " " to
" "
Inicio / +30SEC./confirmar
Micro./Grill/Combi.
Micro./Grill/Combi.
5) Press " " to start cooking .
Inicio / +30SEC./confirmar
Inicio / +30SEC./confirmar

3. Grill or Combi. Cooking
Press "" the LED will display " ", and press
for times or turn
the " " to choose the power
you want,
for each added press. Then press
" " to confirm, and turn
" "
to set
cooking time
from
0:05 to
95:00
.
Press " "
again
to start
cooking.
Example: If you want to use 55% microwave power and 45% grill power(C-1) to cook
for 10 minutes, you can operate the oven as the following steps.
P100
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
"
"P100", "P 80", "P 50",
"P 30 , "P10", "G" , "C-1" or "C-2" will display
Order Microwave
Power
Display
1
2
3
4
5
6
7
8
100%
80%
50%
30%
10%
Grill
Power
100%
45%
64%
0%
55%
36%
" " Pad instructions
P100
P80
P50
P30
P10
G
C-1
C-2
1) Press " " once, the screen display " ".
2) Press " " for times or turn " " to choose combi. 1 mode.
s P100
EN-13
Micro./Grill/Combi.
Micro./Grill/Combi. "" Micro./Grill/Combi.
and
Inicio / +30SEC./confirmar
Inicio / +30SEC./confirmar
Micro./Grill/Combi.
Micro./Grill/Combi.

2) Turn " " to select the defrost time. The MAX time is 95 minutes.
2) Turn " " to select the weight of food from 100 to 2000 g.
1) Press "
2) Turn " " to enter the correct time.(The maximum cooking time is 95 minutes.)
4) When the kitchen time is reached, timer indicator will go out. The buzzer will ring 5 times.
If the clock be set (24-hour system), LED will display the current time.
Note: The kitchen Time is differ from 24-hour system,Kitchen Timer is a timer.
each added press will increase 30 seconds cooking time up to 95 minutes.
2) In microwave,grill,combination cooking or time defrost state, each press of
3) In waiting state, turn " " left to set cooking time with 100%
it will not be changed.
Note:If half the grill time passes, the oven sounds twice, and this is normal. In order
to have a better effect of grilling food, you should turn the food over,
close the door, and then press"
If no operation, the oven will continue working.
4) Turn " " to adjust the cooking time until the oven displays "10:00".
" to continue cooking.
4. Quick Start
5. Defrost By Weight
6. Defrost By Time
7. Kitchen Timer
EN-14
Inicio / +30SEC./confirmar
Inicio / +30SEC./confirmar
3) Press " " to confirm, and the screen displays "C-1".
5) Press " " to start cooking.
Inicio / +30SEC./confirmar
1) In waiting state, Press " " to start cooking with 100%
power,
Inicio / +30SEC./confirmar
" " can increase 30 seconds of cooking time.
Inicio / +30SEC./confirmar
microwave power, then press " " to start cooking.
Inicio / +30SEC./confirmar
1) Press " " once, and the oven will display "dEF1".
Peso/Tiempo Descongelar
3) Press " " to start defrosting.
Inicio / +30SEC./confirmar
1) Press " " twice, and the oven will display "dEF2".
Peso/Tiempo Descongelar
3) Press " " to start defrosting.The defrost power is P30 ,
and
Inicio / +30SEC./confirmar
Reloj/Temporizador de cocción "twice, LED will display 00:00, timer indicator will
light.
3) Press " " to confirm setting, timer indicator will flash.
Inicio / +30SEC./confirmar

1) Turn " " clockwise till "A-6" display.
Example: If you want to use "Auto Menu" to cook fish for 350g.
1) Turn " " right to choose the menu, and "A-1" to "A-8" will display.
3) Turn " " to choose the default weight as the menu chart.
3) Turn " " to select the weight of fish till "350" display.
first section, defrosting time counts down; buzzer will sound once again entering
the second cooking. when cooking finish, buzzer sounds five times.
2) Turn " " to select the defrost time till "5:00" display.
3) Press " " once, the screen display "P100".
5) Press " " to confirm, and the screen displays "P 80".
6) Turn " " to adjust the cooking time till the oven displays "7:00".
At most 2 sections can be set for cooking. In multi-section cooking, if one section is
defrosting, then defrosting shall be placed in the first section automatically.
Example: If you want to defrost food for 5 minutes and then cook with 80% microwave
power for 7 minutes, operate it as the following:
8. Multi-section cooking
9. Auto Menu
4) Press " " once again or turn " " to choose 80%
microwave power.
EN-15
1) Press " " twice, and the oven will display "dEF2".
Peso/Tiempo Descongelar
Micro./Grill/Combi.
Micro./Grill/Combi.
Inicio / +30SEC./confirmar
7) Press " " to start cooking, and buzzer will sound once for
the
Inicio / +30SEC./confirmar
2) Press " " to confirm.
4) Press " " to start cooking.
2) Press " " to confirm.
4) Press " " to start cooking.
Inicio / +30SEC./confirmar
Inicio / +30SEC./confirmar
Inicio / +30SEC./confirmar
Inicio / +30SEC./confirmar

11. Lock-out Function for Children
Lock: In waiting state, press " " for 3 seconds, there will be a long beep
denoting entering the children-lock state and current time will diplay if the time has
been set, otherwise, the LED will display " ".
Lock quitting: In locked state, press " " for 3 seconds, there will be a long
"beep" denoting that the lock is released.
Menu Weight Display
A-2
Meat
A-3
Vegetable
A-5
Potato
A-4
Pasta
A-6
Fish
A-8
Popcorn
200 g
400 g
250 g
350 g
450 g
200 g
300 g
400 g
50g(with 450 ml cold water)
100g(with 800 ml cold water)
200 g
400 g
600 g
250 g
350 g
450 g
1 cup(120 ml)
2 cups(240 ml)
3 cups(360ml)
50 g
85 g
100 g
A-1
Pizza
A-7
Beverage
200
400
250
350
450
200
300
400
50
100
200
400
600
250
350
450
1
2
3
50
85
100
The menu chart:
1) In states of microwave,grill and combination cooking, press " ", the
responding power will be displayed for 3 seconds. After 3 seconds, the oven will turn back
to the former state;
2) In cooking state, press "
display for 3 seconds.
10. Inquiring Function
EN-16
Micro./Grill/Combi.
Reloj/Temporizador de cocción
" to inquire the time and the time
will
Parar/Cancelar
Parar/Cancelar

According to W aste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.
It is forbidden to run the unit without any food inside.
It is very dangerous.
Trouble shooting
EN-17

Horno microondas
Lea atentamente estas instrucciones antes de utilizar el
horno microondas y guárdelas para futuras consultas.
GUARDE ESTAS INSTRUCCIONES EN UN LUGAR ADECUADO
Siguiendo estas instrucciones el horno le proporcionará
muchos años de buen funcionamiento.
MANUAL DE INSTRUCCIONES
MODELO: SVMW823GDX

PRECAUCIONES PARA EVITAR UNA POSIBLE EXPOSICIÓN
A UNA ENERGÍA DE MICROONDAS EXCESIVA
Especificaciones
(a) No intente utilizar el microondas con la puerta abierta, ya que
puede resultar en una exposición nociva a la energía de
microondas. Es importante no romper ni tratar de forzar los
elementos de cierre de seguridad de la puerta.
(b) No coloque ningún objeto entre la cara frontal y la puerta del
horno ni permita que se acumule suciedad o restos de limpiador
en las superficies de cierre hermético.
(c) ATENCIÓN: Si la puerta del horno o las superficies de cierre
están dañadas, no deberá utilizarse el horno hasta que haya sido
reparado por un técnico especializado.
Si el electrodoméstico no se mantiene en un buen estado de
limpieza, podría degradarse su superficie, lo cual afectaría a su
vida útil y crear situaciones de peligro.
Modelo:
Voltaje nominal: 230 V~~ 50 Hz
Potencia de entrada nominal (microondas): 1.250 W
Potencia de salida nominal (microondas): 800 W
Potencia de entrada nominal (grill): 1.000 W
Capacidad del horno: 23 L
Diámetro del plato: 270 mm
Dimensiones externas: 485 x 410 x 293 mm
Peso neto: Aprox. 14 kg
SVMW823GDX
~
podría
ES-2
