OPERATION
MANUAL
SB-700
Soundbar with Wireless
Subwoofer

Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2018. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on “as is” terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
...............
2. PACKAGE CONTENTS............................................................. ............ ..
3. SAFETY PRECAUTIONS ..................................................
................... ..
4. TECHNICAL DESCRIPTION ....................................................
................ ..
5. PREPARATION AND OPERATION ..........................................
........................
6. TROUBLESHOOTING.................................
............................................... ..
7. TECHNICAL SPECIFICATIONS .................................................... ........... ..
2
3
3
3
5
8
8
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty
card has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
•Shipping and transportation equipment is permitted only in the original container.
•Does not require special conditions for realization.
•Dispose of in accordance with regulations for the disposal of household and computer equipment.
Technical support is on www.sven.fi.
ENG
2
Operation Manual SB-700

2. PACKAGE CONTENTS
•Subwoofer – 1 pc
•Soundbar (3 elements when unassembled: center control bar, left speaker, right speaker) – 1 pc
•Remote control – 1 pc
•AAA type batteries – 2 pcs
•Mini-jack to mini-jack signal cable – 1 pc
•Optical cable – 1 pc
•3.5mm jack - 2xRCA аdapter – 1 pc
•Power adapter – 1 pc
•Power cable – 1 pc
•Wall-mounting set – 2 pcs
•Operation manual – 1 pc
•Warranty card – 1 pc
3. SAFETY PRECAUTIONS
•To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service and
repairs should be performed only by qualified specialists in an authorized service center. The list of
authorized service centers is available on www.sven.fi
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, water and dust.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
•Do not place any open flame sources on or close to MSS.
•Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. When
operating the MSS, do not put any devices on it, do not cover it with cloth or other objects pre-
venting it from cooling.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
SB-700 soundbar with a wireless subwoofer provides virual surround sound. The device is
designed for playing music and sounding games, movies, etc. The soundbar is equipped with a
built-in power amplifier and an equalizer, and compatible with TVs and DVD/CD/Media players.
Remote control is included. Has built-in LED-display, Bluetooth-module, optical input and audio
player with USB-flash.
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.
ENG
3
Soundbar with Wireless
Subwoofer

ENG
4
Operation Manual SB-700
Fig. 1. Top control panel
Fig. 2. Rear control panel
Special features
•Wireless pairing with the subwoofer
•Optical input
•Bluetooth wireless signal transmission
•Support for multi-channel sound playback
•Play music from USB flush
•LED display
•LED display
•Wall mountable soundbar
Upper and rear soundbar controls
aDisplay
bPower button
cAudio source selection button
dPlay/Pause (short pressing in Player and
Bluetooth mode);
Disconnecting from the Bluetooth source (long
pressing in Bluetooth mode)
ePrevious track
(long pressing in Player and Bluetooth mode);
volume decrease (short pressing)
fNext track (long pressing in Player and
Bluetooth mode);
volume increase (short pressing)
gDC IN: power cable connection jack
hOptical input
i USB: port for a USB flash device containing
МР3 audio files
jAUX: jack to connect linear input
a
b c def
Optical USB AUX
g h i j

ENG
5
Soundbar with Wireless
Subwoofer
Fig. 3. Remote control
Remote control
a: POWER button
b: sound off/on button;
display brightness adjustment (in ST-BY mode)
cTR-/TR+: HF volume control
dVOL-/VOL+: volume control
ePrevious track in Player and Bluetooth mode
fPlay/Pause in Player and Bluetooth mode
gNext track in Player and Bluetooth mode
hSUB-/SUB+: subwoofer volume control
iSOURCE: the MSS mode selection (Bluetooth/USB/OPT/LINE)
jCIN/TV: Movie or TV mode
kSleep: Sleep mode
lReset: return to default settings
Battery Installation
•Open the battery compartment on the back of the remote control.
•Insert the included AAA batteries.
•Close the battery compartment.
Notes:
•Use the RC at an angle no more than 30° at a distance of no
more than 7 meters.
•Direct the remote control to the infrared receiver on the
subwoofer.
• If the remote control does not operate, check the batteries
or replace the discharged batteries with new ones.
• Remove the batteries from the RC if you don’t intend to use it for a long time (more than one
week).
5. PREPARATION AND OPERATION
Assembly and installation of the system
•The soundbar is delivered in disassembled form. Connect the left and right speakers to the
central control module: first connect the cables between the center module and the side satellites.
After connecting the satellites themselves to the central module and fix by turning around the axis.
A wireless subwoofer emits a non-directional sound, so it can be placed anywhere in the room in
which the subwoofer will sound best. Installation completed.
Note: It is recommended to hang the soundbar on the wall under the TV set using the wall mount set (included).
ab
c
c
d
d
e
f
g
hh
i
j
k
l

ENG
6
Operation Manual SB-700
MSS сonnecting and control
SB-700 soundbar with a wireless subwoofer can be connected to virtually any audio source:
DVD/CD player, TV, PC, laptop, etc. (see connection diagram in Fig. 4).
• Connect the power cable with the power adapter (included). Then connect it to the the DC IN h
jack of the soundbar (see Fig. 4). Connect the subwoofer power cable to the mains oulet.
• To connect the speakers to a PC, TV, mobile devices, etc., use the mini-jack signal cables to
the mini-jack (included).
• To connect Speaker System to PC and TV use optical cable (included).
• Connect the power adapter to the mains oulet. The power LED aon the front control panel will
light up. Then switch on the subwoofer with the POWER switch (ON position)on the subwoofer rear
panel.
• To switch on the soundbar, press button bon the control panel or button aon the remote
control. The LED display d will light up. To switch the soundbar off, press the Standby mode button
again.
• At the first turn on, the soundbar and subwoofer will automatically establish a connection
between themselves. As soon as the connection is installed, the LED on the rear panel of the
subwoofers will change the light from intermittent to permanent.
• Press the cbutton and select the signal source.
• Adjust the master volume with the VOL+ dand VOL- dbuttons on the RC.
• Adjust the subwoofer volume with the SUB+ hand SUB- hbuttons on the RC.
• Select the equalizer option (Cinema/TV), by pressing the jbutton on the RC.
• After using the MSS, mind to switch it off using button a on the RC, switch off the subwoofer
using the POWER switch (OFF position) on the subwoofer rear panel and unplug the power adapter
from the socket.
Fig. 4. Connection diagram
Subwoofer
PC
Power
adapter
TV
Mini-jack to mini-jack
signal cabl
Sockets
Optical cable
Optical USB AUX
TV
Mobile
device
Laptop
PC
USB-flash

ENG
7
Soundbar with Wireless
Subwoofer
Player mode
•The system will automatically switch to the Player mode if you install USB flash in the slot ior
use the cbutton on the top panel or the ibutton on the remote control. The selected mode is
displayed on the LED-display. Playback starts automatically.
Bluetooth mode
•To transmit a signal in this mode, at first connect the device to the signal source (see Fig. 6). To
do this, select the Bluetooth mode using the cbutton on the top of the soundbar or the ibutton
on the remote control. The MSS switches to the search mode, the display a displays «BLUE».
•It is necessary to select the search mode of devices with Bluetooth on a signal source (telephone,
notebook, smartphone, etc.). «SVEN SB-700», massage will be displayed on the screen which is to
be connected to*.
•If the connection is successful, the «BLUE» indicator has a steady glow. If the connection fails, the
«BLUE» indicator is intermittent. It is necessary to re-translate the system into the search mode
(turn it off and on again) **.
• During connection to the source, you can control the source player using the e-gbuttons on
the remote control.
SLEEP mode
•The «SLEEP» mode allows the product to be transferred to the «ST-BY» mode after the
user-selected time has elapsed. To switch to the «SLEEP» mode, press the kbutton on the remote
control. To exit the «SLEEP» mode, press the kbutton on the RC repeatedly until 0 appears.
Wireless connection between Soundbar and Subwoofer
•Automate connection.Connect subwoofer power cable to wall power. Turn on the power switch.
LED on rear of subwoofer will flash slowly to show it is waiting for pairing. Connect soundbar power
adapter to wall power and display will turn on. Soundbar and subwoofer will pair automatically.
If pairing successfully, LED on rear of subwoofer will always light up.
•Manual connection. Connect subwoofer power cable to wall power, turn on the power switch.
Press the button on rear of subwoofer. LED on rear of subwoofer will flash quickly to show
it is waiting for pairing. Connect soundbar power adapter to wall power and display will turn on,
soundbar and subwoofer will pair automatically. If pairing successfully, LED on rear of subwoofer
will always light up.
Note. Due to the constant development of the software, the actual MSS operation may
differ from that described in this manual. The most recent version of the manual is
available at www.sven.fi.
* You might have to enter “0000” code to connect some models of devices via Bluetooth.
** If the item has been already registered in the device list of a source, then the second search mode activation is not obligatory.
Choose the item name «SB-700» and the “connect” command on the source.

Parameter, measurement unit
Power, W
soundbar
subwoofer
Frequency response, Hz
soundbar
subwoofer
Speaker diameter, mm
soundbar
subwoofer
Voltage supply, V/Hz
Power adapter
Dimensions, mm
soundbar
subwoofer
Weight, kg
7. TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due to
the improvement of SVEN production.
Value
200 (140 + 2 × 30)
2 × 30
140
150 – 20,000
40 – 150
Ø 45
Ø 145
~230/50
DC 18V/2A
980 × 70 × 55
263 × 320 × 263
6.2
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
Problem
The system does
not turn on.
No sound or the
sound is too quiet.
Distortion of sound.
The remote control
is not working.
Cause
The system is not connected to a
mains outlet.
The power adapter is not connected.
Volume level is set at minimum value.
Improperly connected audio source.
Large amplitude of the input signal.
The battery is discharged.
Solution
Check the connection.
Connect the power adapter.
Adjust the volume control knob.
Connect the audio sources correctly.
Turn down the source volume
and the MSS volume.
Replace the battery with a new one.
6. TROUBLESHOOTING
ENG
8
Operation Manual SB-700

2.0 Multimedia Speaker System
Automatic Voltage Regulator
Стабилизатор напряженияСтабилизатор напряжения
Automatic Voltage Regulator
2.0 Multimedia Speaker System2.0 Multimedia Speaker System
SPS-619
SB-700
Soundbar with Wireless
Subwoofer
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№ 02-02, Singapore, 427447.
Produced under the control of Oy Sven Scandinavia Ltd.
15, Kotolahdentie, Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
9B0809
