Swann Big Dome Deterrent User manual

Big Dome Deterrent
Large indoor & outdoor dome
with aluminum wall mounting bracket
English
If this device does not work when you first plug it in,
do not take it back to the store.
Contact the Swann Helpdesk using our fast e-mail service
[email protected] or call us on one of the Toll-Free
numbers shown on the back cover of this booklet.
Most problems can be quickly and easily fixed with a simple
e-mail or a quick chat with one of our friendly technical staff.
(Toll-Free available in the US and Australia only)
Installation Guide
Swann Technical Support
All Countries E-mail: [email protected]
Telephone Helpdesk
UNITED STATES toll free
877-274-3695
(Sun-Thurs, 2pm-10.30pm PST)
800-627-2799
(Mon0Fri, 9am-1pm PST)
USA Exchange & Repairs
562-777-2551
(Mon-Fri, 9am-5pm PST)
AUSTRALIA toll free
1300 13 8324
(Mon-Fri, 9am-5.30pm Aus EST)
International
[phone]
(Mon-Fri, 9am-5.30pm Aus EST)
See http://www.worldtimeserver.com for information on different time zones
and the time in Melbourne Australia compare to your local time.
Swann Communications warrants this product against defects in workmanship and material for
a period of one (1) year from it’s original purchase date. You must present your receipt as
proof of date of purchase for warranty validation. Any unit which proves defective during the
stated period will be repaired without charge for parts or labour or replaced at the sole
discretion of Swann. The repair or replacement will be warranted for either ninety days or the
remainder of the original one year warranty period, whichever is longer. The end user is
responsible for all freight charges incurred to send the to Swann’s repair centres.
shipping from and to any country
other than the country of origin. The warranty does not cover any incidental, accidental or
consequential damages arising from the use of or the inability to use this . Any costs
associated with the fitting or removal of this product by a tradesman or other person or any
other costs associated with its use are the responsibility of the end user. This warranty applies
to the original purchaser of the only and is not transferrable to any third party.
Unauthorised end user or third party modifications to any component or evidence of misuse or
abuse of the device will render all warranties void.
product The
end user is responsible for all shipping costs incurred when
product
product
Help Desk / Support Details
Warranty Information
www.swannsecurity.com
FCC NOTICE
This device complies with Part 15 of FCC Rules.
Operation is subject to the following conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation

Instructions on how to attach a fixed camera and wall mounting bracket.
1. Firstly attach the camera onto the camera
bracket. Keep the orientation of the dome in
mind when mounting the camera.
3. Screw the camera bracket onto the bottom of
the dome using the bracket retainer.
4. Thread the AV cable through the wall
mounting bracket. Make sure the male DC plug
is passed through the bracket so it can be
connected to the camera. (See above image)
6. Fix the wall mounting bracket onto the dome
by screwing in the 3 holding screws in a
clockwise direction using a flat head screw
driver.
2. Adjust the camera bracket to suit your viewing
direction. Then secure the bracket into place by
screwing the locking screw in a clockwise
direction.
9. Align the dome cover and dome ring over the
holes. (See image above)
7. Connect the AV and DC cable onto the back
of the camera. This illustration shows how to
connect the cables into the back of a Swann
C500, but actual connections will vary
depending on your camera.
5. Now thread the cable into the bottom of the
dome.
8. We highly recommend you test the camera
now. Connect the other end of the AV cable into
you TV/monitor and power up the camera to see
if you get a picture. Make sure the camera is in
focus and all the appropriate settings are made.
If possible, temporarily mount the dome to the
desired location and check if the image is
viewable.
To mount the dome onto your wall, please visit your local hardware store for wall mounting bolts.
We recommend you get advice from your hardware store staff on the appropriate tools to use and
wall mounting bolts for your wall. Please keep in mind the dome and wall mounting bracket weighs
approximately 5.5 lb / 2.5 kg
Please make sure you remove the dark insert film if you wish to use this dome deterrent as a real
dome camera. (See image below)
10. Secure the dome cover to the dome body
using 3 screws supplied.
