Swann PRO-750 User manual

Control the Camera Remotely*
TV EASILY CONNECT TO TV OR DVR
ROTATION CONTROLLABLE BY PTZ
CONTROLLER OR SMARTPHONE*
BNC CABLE 60FT / 18M
IP67 DURABLE WEATHERPROOF METAL CASING
DETER
VISIBLE CAMERA & 4 STICKERS DETER CRIME
SUPER CRYSTAL CLEAR COLOR
700TVL SONY CCD VIDEO
700TVL
SEE MORE WITH ADJUSTABLE FOCUS & 3x ZOOM
Pro quality 700TVL for peace of mind 24/7
• Know what’s happening by using the Pan-Tilt-Zoom controller to direct
the dome camera
• State-of-the-art technology includes Sony components, super-high
resolution 700 TVL CCD video image sensor & smart programming
• Ready to go with flexible mounting options to fix to your wall or ceiling.
Installation accessories & cable included
• No more ‘blind-spots’ as the Dome Camera rotates a full 360° & 90° up
& down
• Amazing zoom capabilities with 3x (4–9mm) optical zoom ensures you
can see fine details such as people’s faces
• Focus on the key locations with up to 32 preset viewing points &
16 programmable viewing tours
• Smartphone viewing* & controls when combined with a Swann
networking DVR* & free SwannView app
• Cut the cost of crime with this professional quality dome surveillance
camera, at an affordable price with no ongoing fees
Pan Tilt Zoom
Dome Camera
PRO-750™ Super High
Resolution 700TVL
CAMERA
SWPRO-750CAM
For more information on this product visit www.swann.com
y
*

2XU3URPLVH
Swann stands by its Lifetime Support promise to make
advanced security easy to use, install and maintain.
Everything is in the pack but if you need it, Swann’s help
desk is available with extended hours for the life of the
product. Swann products are also backed by a 12 month
manufacturer’s warranty.
promise to mak
e
T
H
E
S
W
A
N
N
P
R
O
M
I
S
E
T
H
E
S
W
A
N
N
P
R
O
M
I
S
E
Pan Tilt Zoom Dome Camera
PRO-750™ Super High Resolution 700TVL
*Mobile & DVR not included. Not all handsets supported. Smartphone viewing & controls when combined
with a Swann networking DVR (eg 1200, 1300, 2550, 2600, 3000 or 4000 series) and free SwannView app.
Note: Trademarks are properties of their respective owners
For more information on this product visit
www.swann.com
Installation is easy
Do-it-Yourself
Installing this Swann product is simple.
For instructions, tips and videos see the
operating instructions in this pack or visit
www.swann.com
Professional Installation
Need extra help?
We have an installer in your region!
For more visit
www.swann.com
Select the channel for the dome
camera then use the arrows to
control what you see
360°
viewing
When the PRO-750™ camera
is connected to a Swann
networking DVR* you can you
use the free SwannView app
on your Smartphone or tablet*
to move the camera left and
right (pan), up and down (tilt)
and zoom in and out
Control the dome on your phone
What’s in the box
All installation accessories included
• Pro-750™ PTZ Dome
• Wall Mount Arm
• Ceiling Mount Arm/Bracket
• PTZ Controller
• Remote Controller (includes 2 x
AAA batteries)
• 3-in-1 BNC/RS-485 Cable 60ft /18m
• BNC to RCA Adapter
• Mounting Screws
• Accessories
• Operating Instructions
Specifications
Video
Image Sensor 1/3” Sony CCD
Video Quality 700 TV Lines
Number of Effective Pixels NTSC: 768 x 494 / PAL: 752 x 582
Minimum Illumination 0.01 Lux
Day/Night Mode Color during day /
switches to B&W in low light conditions
White Balance Automatic
Signal / Noise Ratio > 50dB
Electronic Shutter 1/60 - 1/100,000 NTSC
1/50 - 1/100,000 PAL
Gain Control Automatic
Backlight Compensation Yes
Lens Vari-focal 4 – 9mm
Viewing Angle 30 – 60 degrees
Zoom 3x optical
PTZ Features
Dome Type 4” PTZ Dome
Baudrate 1200/2400/4800/9600 bps
Pan Rotation 360°
Tilt Rotation 0° ~ 90°
Preset Points Up to 32 points
Preset Panning Speed 35° per second
Preset Panning Accuracy +/- 3°
Programmable Pattern Up to 16 preset points
PTZ Controller
Interface type RS-485
Protocol Full function Pelco-P/D
Address 0-255
Remote Control Yes
Remote Control Batteries 2 x AAA batteries (included)
General
Operating Power DC 12V
Operating Temperature 23°F ~ 140°F / -5°C ~ 60°C
Body Construction ABS Plastic
Dimensions – Camera 5.9” x 4.9” x 4.9”
150mm x 125mm x 125mm
Dimensions – Stand 4.5” x 3.1” x 5.3”
115mm x 80mm x 135mm
Dimensions – Controller 3.1” x 2.8” x 1.1”
80mm x 72mm x 28mm
Weight – Camera 500g / 1.1lbs
Weight – Camera & Stand 700g / 1.5lbs
Weight – Controller 85g / 3oz
Codes
Swann Code SWPRO-750CAM
UPC 815849013179
x
•
Operatin
g
Instructio
ns
Advanced, easy mounting options
Ceiling Mount Arm/Bracket
1.7” / 44mm
C
1
Ceiling Mount
1.7” / 44mm
5.3” /
135mm
Choose wall or ceiling mounting with screws included
4.5” /
115mm
Wall Mount
3.15” / 80mm 3.9” / 100mm
Wall-Mount Arm
