Swann SWIFI-FLOCAM2 User manual

1
EN
Wi-Fi Floodlight Security Camera
Cámara de Seguridad Wi-Fi con Reflector
Caméra de Sécurité Wi-Fi à Projection
Telecamera di Sicurezza Wi-Fi con Faretti
Wi-Fi-Überwachungskamera mit Flutlicht
EN Quck Start Gude ES Guía de Inco Rápdo FR Gude de Démarrage Rapde
IT Guda Rapda DE Schnellstartanletung
SWIFI-FLOCAM2

2
EN
IMPORTANT SAFETY INSTRUCTIONS
• All electrical connections and wiring of this product must be carried out by a licensed electrician
in accordance with local and national wiring rules (e.g., AS/NZS 3000 Electrical Installations).
Check with local authorities for applicable requirements.
• The product must be mounted on a flat vertical surface capable of supporting the full weight of the
product.
• Ensure the voltage marked on the product is the same as the electrical power supply to be used.
• Do not connect to a dimmer switch or timer.
• Always turn off electricity at the main circuit breaker or fuse box before installation. Failing to do so
could result in serious injury, electrical shock, and/or risk of fire.
• Do not rely on wall switch alone to turn off the power.
• Do not open or disassemble the product. There are no user-serviceable parts inside.

3
EN
• Before you begin the installation of the product, it is important that you confirm the availability of
Wi-Fi as well as the signal level at the desired installation location.
• Note that Wi-Fi quality can vary significantly at different locations around the home due to
environmental factors such as home construction type and wireless interference from other
electronic devices.
TO CHECK WIFI COVERAGE
1Connect your phone to the 2.4GHz Wi-Fi network band of your internet/broadband router.
Note: The Swann Floodlight Security Camera will only connect to a 2.4GHz network.
2Place your phone where you are planning to install the floodlight unit. If you have Wi-Fi connection
on your phone, the camera will also likely be able to obtain Wi-Fi connection. Check the Wi-Fi icon
on your phone. We recommend a minimum of 1 bar showing on your phone's Wi-Fi icon as shown
below. Further testing should be performed if the Wi-Fi signal strength is only 1 bar.
PREINSTALLATION CHECK
WIFI COVERAGE AVAILABILITY
0 1
!X
Number of bars indicate
Wi-Fi signal strength
ExcellentGoodFairPoorNo connection
2 3 4

4
EN
PREINSTALLATION CHECK
3To avoid any potential Wi-Fi connection issues later, try playing a video on a media streaming
service app, for example, YouTube™or Netflix™, through your phone. If possible, temporarily pause
activities like online gaming and video streaming on other devices connected to your network
while you perform testing, as this can affect the connection speed and quality.
4If you don't experience any video streaming issues (buffering, stuttering, etc), you can proceed with
the installation of the product. There are also Wi-Fi surveying and speed tools available online that
can help you analyze and test the quality of your Wi-Fi connection including download and upload
speeds (minimum internet upload speed of 1 Mbps is recommended for optimal video streaming).
5If you still have any concerns about your Wi-Fi coverage, consult a licensed electrician on
connecting the Floodlight wiring to a temporary plug and running an extension cord to a wall
outlet so you can power the camera onsite to test Wi-Fi pairing and live video streaming directly
via the Swann Security app. For camera pairing instructions, see page 9.
WIFI WEAK OR OUT OF RANGE
• If you're getting a weak Wi-Fi signal or you can’t connect to Wi-Fi at all on your phone at the
installation site, we recommend moving your router closer, installing a Wi-Fi extender (which can
help improve signal reception) or selecting another location.
• Do not proceed with the installation of this product until you have thoroughly tested and
confirmed the availability and reliability of the Wi-Fi connection at your desired location.

5
EN
GET THE APP
1Download the latest version of the Swann Security app from the Apple App Store® or Google
Play™ Store on your iOS or Android device. Simply search for "Swann Security".
2Open the app, create your Swann Security account, and sign in. You will need to activate your
account by confirming the email sent to the email account you provided before you can sign in.
GET THE SWANN SECURITY APP

6
EN
INSTALLATION EXAMPLE DIAGRAM
Microphone
Washer
Cap
Night Detection Sensor
Adjustment KnobLocking NutFoam Gasket
Junction Box
Cable Clamp
Cable
Grommet
Terminal Block
LED Indicator
Speaker (Siren)
Slow Blinking Blue Wi-Fi Pairing Mode Solid Red Live streaming/Motion recording
Fast Blinking Blue Connecting to Wi-Fi Blinking Purple Low Wi-Fi signal
LED Indicator Guide
Resetting the Camera
Open the port cover on the back of the camera. Press and hold the Reset button for 10 seconds.
(Active)
(Neutral)
(Earth)
Brown
Blue
Green/Yellow
Floodlight wiring
True Detect™
Passive Infrared (PIR)
Motion Sensor
Locking Collar
Reset Button
Infrared LEDs
QR Code
(for device pairing)

7
EN
INSTALLATION INSTRUCTIONS
This unit is designed to be mounted on a standard wiring junction box and requires connection to a
100-240VAC power supply. For optimum results, install the unit at least 2.4m (8ft) above the ground.
Read "IMPORTANT SAFETY INSTRUCTIONS" and "PRE-INSTALLATION CHECK", and make sure the
installation site is Wi-Fi ready before installing the unit.
INSTALLATION AND WIRING MUST BE CARRIED OUT BY A LICENSED ELECTRICIAN.
IMPORTANT! TURN POWER OFF AT CIRCUIT BREAKER OR FUSE BOX.
When installing the unit refer to the Installation Example Diagram on page 6.
1Cut a small entry hole in the cable grommet enabling the electrical supply cable to enter the
provided junction box. Make sure the supply cable coming from the wall is long enough to route
through the cable grommet to the terminal block.
2Attach the junction box securely to the wall using the appropriate fixings for the wall type.
3Peel the backing off the adhesive foam gasket and stick it to the back of the floodlight unit.
4Unscrew the cable clamp from the junction box. Connect the active, neutral, and earth wires to the
terminal block in the junction box as marked according to the connection diagram as shown on the
next page. Make sure each wire is firmly screwed to its corresponding terminal.

8
EN
INSTALLATION INSTRUCTIONS
Earth
Live
N
L
Neutral
Brown Floodlight Wire Brown (Active Supply Wire)
Green/Yellow Floodlight Wire Green/Yellow (Earth Supply Wire)
Blue Floodlight Wire Blue (Neutral Supply Wire)
TERMINAL BLOCK
5Fasten the electrical supply cable to the junction box using the cable clamp. Screw the cable
clamp down tightly.
6Place the floodlight unit (make sure the “UP” arrow on the back is pointing up) against the junction
box, aligning the center mounting holes and lock it securely with the provided long mounting
screw and washer.
7Insert the provided screw cap firmly into the center mounting hole on the floodlight unit.
8Apply silicone weather sealant (not included) around the back of the junction box and mounting
surface for moisture seal. Installation is complete. Remove the protective film from the camera.
9Turn the electricity back on and allow the camera to power up. This can take up to a minute.
When the camera starts blinking blue, it is ready to be paired with your Wi-Fi network.
TIP If you have a light switch that controls the floodlight unit, remember not to turn off the switch
as this will also turn off the camera. The camera needs to be powered at all times to stay connected
to your Wi-Fi. Put a sticker label on the light switch so that people know not to turn it off.

9
EN
Learn more about using your camera to view live video and recorded clips as well as camera settings
to adjust floodlight brightness and siren duration, by downloading the Swann Security manual from the
app menu .
SET UP THE CAMERA
Open the Swann Security app on your phone and sign in. Tap the Pair Device button on the screen (or
open Menu and select Pair Device) and follow the in-app instructions to set up your new camera.

10
EN
TIPS
Angle Adjustments
To adjust the direction of the lamps and the camera, loosen the corresponding adjustment knob or locking nut/collar.
Less
sensitive
More
sensitive
Motion Detection
• The camera's motion sensor is more sensitive to
the movement of heat across the coverage area
and less sensitive to movement directly towards
or away from it.
• Position the camera tilted slightly downwards so
that the likely approach path occurs across the
coverage area (see figure on right). When walking
directly towards or away from the motion sensor
the detection range will be reduced. Note that
detection range may also alter with changes in
ambient temperature.
