SWEEX PU011 - QUICK_START_GUIDE Reference manual

English version
2
PU011 Sweex 1 Port Parallel PCI Express Card
Introduction
• Do not expose the PU011 to extreme temperatures. Do not place the device in direct sun light or close to heating elements.
• Do not use the PU011 in extremely dusty or moist environments.
• Prevent hard shocks or impacts of the device, as this can cause damage to the internal electronics.
Hardware Installation
1. Make sure the computer is turned off and that there is no power connected.
2. Also remove the printer and monitor cable, because these have their own power supply.
3. Now unscrew the computer casing.
4. Make sure that you undo yourself of possible static electricity. This can be done by grabbing a (naked) central heating pipe or
an unpainted water pipe. Pay attention not to use a magnetic screwdriver. Briefly touch the iron frame of the PC casing. Avoid
direct contact with the contact points of the PCIe slot and contact points on the graphics card.
5. Locate a free PCIe slot and remove the metal protection plate that is in the computer casing for the intended slot. Consult the
manual of your computer to find the PCIe slot.
6. When possible fasten the card with screws so it can not move.
7. When the card is mounted successfully, check if the other cards are still fitted properly in their expansion slot. It can happen
that when a new card is added the other cards rise a little with as result that the card, or even the entire computer, may not
work.
8. Close the computer casing and reconnect all cables properly.
9. Turn on the computer.

English version
3
Installation Windows 2000 and XP
After starting the computer this window will appear.
Choose “No not this time” and click “Next”.
Place the Sweex CD-ROM in the CD-ROM player. When the CD-ROM already was in the player, open the tray and close it again.
Windows will automatically install the drivers.
If windows can not find the drivers, choose “Install from a list or specific location” in the above window.
Click “Browse” and navigate to the Sweex CD-ROM to find the drivers. Press “Next”.

English version
4
It is possible that Windows will notify you that the driver is not certified. This is not a problem for correct functioning of the card.
All Sweex products and relevant drivers are tested thoroughly. Choose the option “Continue Anyway”.
Press “Finish” to complete the installation.
Installation Windows Vista
After starting the computer this window will appear.

English version
5
Click “Locate and install driver software”.
Place the Sweex CD-ROM in the CD-ROM player. When the CD-ROM already was in the player, open the tray and close it again.
Windows will automatically install the drivers.
When windows can not find the drivers, choose “I don’t have a disc. Show me other options.” in the above window.
Click “Browse my computer for driver software”.
Navigate to the Sweex CD-ROM to find the drivers.

English version
6
It is possible that Windows will notify you that the driver is not certified. This is not a problem for correct functioning of the card.
All Sweex products and relevant drivers are tested thoroughly. Choose the option “Install this driver software anyway”.
Follow the steps to complete the installation.
Port settings Parallel
The settings of the LPT port can be viewed and adjusted as follows:
Go to START -> settings -> control panel
In this window open “System”. Go to the tab “Hardware” -> “device manager”.
In the device manager open the “Ports (COM & LPT)” list and select: Sweex 1 Port Parallel PCIe Card
Open the settings by right clicking it.
The following screen appears:
Select the “Port settings” tab.
Here you can view or change your LPT port. Be aware that you do not choose a port that is already being used by the computer.
This can result in a conflict.
This product is not suitable for all hardware key dongles.

English version
7
Warranty
For most Sweex products a warranty period of 3 years applies. On Graphics Cards and Consumer Electronics Sweex offers 2 years
of warranty. We do not give support or warranty on supplied software, rechargeable batteries and batteries. Transaction of
warranty only takes place at the sales point where the product is bought.
All brand names and associated rights mentioned in this manual are and stay property of the rightful owner.
