SWG WC-2053 User manual

counter top
Wine Cellar
Instruction Booklet
Model: WC-2053
Booklet_WC-2053_EN.qxd:Salton Booklet 3/20/09 3:02 PM Page 1

IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be followed to
reduce the risk of fire, electric shock and injury to persons, including the following:
1. Read all instructions. Use this appliance only as described in this manual.
Other uses not recommended may cause fire, electric shock or personal injury.
2. To protect against electrical hazards, do not immerse cord, plugs, or the
appliance in water or other liquid.
3. This unit is designed to be freestanding only. Do not recess into cabinets.
Follow the instructions in the Installation section.
4. It is recommended that a separate circuit, serving only this unit be provided.
Use receptacles that cannot be turned off by a switch or pull chain.
5. Unplug from outlet when not in use, before moving, servicing or cleaning.
Failure to unplug the unit from the wall outlet can result in electrical shock or
death.
6. To unplug from the outlet, grip the plug and pull it from the wall outlet. Never
pull by the cord.
7. Never connect or disconnect the plug from the outlet when your hands are wet.
8. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return appliance
to SWG Canada for examination, repair or adjustment. See Warranty. Do not
attempt to repair or replace any part of the Wine Cellar unless it is specifically
recommended in this manual. All servicing should be referred to a qualified
technician. See Warranty section.
9. The use of attachments not recommended by the manufacturer may be
hazardous.
10. Close supervision is necessary when any appliance is used by or near children.
11. Do not operate the appliance in the presence of explosives and/or flammable
fumes.
12. Do not place the appliance or any of its parts near an open flame, cooking or
other heating appliance.
13. Place the unit on a dry level surface. Follow the instructions in the Installation
section.
14. Do not place heavy objects on top of the unit.
15. Empty contents before moving the unit.
2
Booklet_WC-2053_EN.qxd:Salton Booklet 3/20/09 3:02 PM Page 2

16. Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion. Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance. The fumes can create
a fire hazard or explosion.
WARNING: RISK OF CHILD ENTRAPMENT
• DANGER OR WARNING: Child entrapment and suffocation are not
problems of the past. Junked or abandoned appliances are still
dangerous…even if they will “just sit in the garage a few days”
• Before you throw away your old Wine Cellar: Take off the door. Leave the
shelves in place so that children may not easily climb inside
• Never allow children to operate, play with, or crawl inside the appliance.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
GROUNDED PLUG
To reduce the risk of electric shock this appliance has a grounded plug (2 blades
and 1 pin). If the plug does not fit fully into the electrical outlet contact a
qualified electrician. DO NOT modify the plug in any way or use an adaptor.
BOTTLE STORAGE
Many bottles may differ in size and dimensions. As such the actual number of
bottles you may be able to store may vary.
3
Booklet_WC-2053_EN.qxd:Salton Booklet 3/20/09 3:02 PM Page 3

DESCRIPTION OF PARTS
1. Glass Door
2. Control Panel
a) LED Display
b) On/Off Interior Light Control
c) Raise Temperature
d) Lower Temperature
3. Interior Light
4. Wine Racks
5. Leveling Legs
6. Evaporator (Inside back of
cavity)
BEFORE FIRST USE
• Remove the exterior and interior packaging.
• Ensure that you have 2 shelves (1 large, 1 small and the handle)
• Clean the interior surface with lukewarm water using a soft cloth.
INSTALLING THE HANDLE
1. Pull the door gasket to one side to reveal the two designated holes for the
handle.
2. Install the handle tightly as shown above with the two screws and flat
washers provided. NOTE: If the event that the screws have come loose from
the door during transit, extra screws and washers have been provided and
have been placed inside the Handle Bag.
3. Replace the door gasket.
INSTALLING
4
Booklet_WC-2053_EN.qxd:Salton Booklet 3/20/09 3:02 PM Page 4

1. The unit is designed to be free standing only and it should not be recessed
or built-in.
2. Place the Wine Cellar on a flat level surface that is strong enough to
support it when fully loaded.
3. To ensure that your wine cooler works at the maximum efficiency, the
recommended clearance is 4” (10cm) in the back and on both sides.
4. Do no place the unit in direct sunlight or near sources of heat (stove,
heater, radiator, etc.). DO NOT place next to any appliance that emits large
amounts of heat, such as a dishwasher, microwave, oven, toaster, etc. or in
direct sunlight. Direct sunlight may affect the acrylic coating and heat
sources may increase electrical consumption.
5. Extreme cold ambient temperatures may also cause the appliance not to
perform properly.
6. To help with door closure, position leveling legs with a 1/8" (3 mm) tilt to
the back. Raise the leveling legs (the 2 front legs) by turning clockwise or
lower by turning counterclockwise.
7. Gently slide the racks into the unit.
8. Let the Wine Cellar stand upright for approximately 2 hours before
plugging into the power source. This will reduce the possibility of a
malfunction in the cooling system from handling during
transportation.
HOW TO USE
1. After the Wine Cellar has been left in an upright position for 2 hours (see
Installation section), plug the Wine Cellar into an exclusive, properly
installed grounded wall outlet.
2. The LED will display the current internal cabinet temperature.
3. Allow the unit to run for at least 30 minutes before making any
adjustments.
4. The Wine Cellar has an electronic Temperature Control on the upper door
frame. The temperature range is 4 – 18 °C (39.2 – 64.4°F)
NOTE: To switch he display between Celsius and Fahrenheit press both
arrow buttons simultaneously and hold for 3 seconds.
5. To select the desired temperature press the up arrow button (▲) to
increase the temperature or the down arrow button (▼) to lower the
temperature. The display will increase or decrease in 1° increments.
6. The Display will show the set temperature for 5 seconds then revert back
to the current internal cabinet temperature. The unit will gradually work
toward the temperature you have set.
7. Do not fill with wine until the Wine Cellar has been running for
2 – 3 hours.
5
Booklet_WC-2053_EN.qxd:Salton Booklet 3/20/09 3:02 PM Page 5

STORAGE CAPACITY
You can place 15 standard bottles in the Wine Cellar. Many bottles may differ in
size and dimensions. As such, the actual number of bottles you may be able to
store may vary.
CARE AND CLEANING
Defrosting
1. Defrost the Wine Cellar when the frost accumulated on the evaporator is
about 5mm (1/5 inch) thick. NOTE: The Evaporator is at the back of the
inside cavity.
2. Unplug the power cord and allow the unit to defrost. Defrosting usually
takes a few hours. To defrost quickly, remove wine from the Wine Cellar
and leave the door open. Never use a knife or other metal instrument to
scrape ice/frost from the evaporator.
3. After defrosting, reset the desired temperature.
Cleaning
1. Always unplug the unit from the wall outlet before cleaning.
2. Empty the cavity.
3. Wash the Wine Racks in mild soap and water. Rinse and dry.
4. Wash the inside cavity with a warm water and baking soda solution. Mix
approximately 2 tbsp. (30 ml) of baking soda with 1 quart (litre) of water.
5. The outside of the Wine Cellar can be wiped with a damp cloth. Dry.
NOTE: Use caution when wiping over the Control Panel area so that water
does not enter the controls.
6. DO NOT use any abrasive cleaning products on the inside or outside of the
Wine Cellar.
CAUTION: Failure to unplug the appliance could result in electrical shock or
personal injury.
6
Booklet_WC-2053_EN.qxd:Salton Booklet 3/20/09 3:02 PM Page 6

Power Failure
Most power failures are corrected within a few hours and should not affect
the temperature of your appliance if you minimize the number of times the
door is opened.
NOTE: If the unit is unplugged, has lost power, or is turned off; you must wait
3 to 5 minutes before restarting the unit. If you attempt to restart before this
time delay, damage may occur and or the appliance may not start.
Vacations
•Short vacations: Leave the appliance operating during vacations of less
than three weeks.
•Long vacations: If the appliance will not be used for several months,
remove all items and unplug the power cord. Clean and dry the interior
thoroughly. To prevent odor and mold growth, leave the door open
slightly: blocking it open if necessary.
Moving your Wine Cellar
1. Remove all contents and store properly.
2. Securely tape down all loose items inside your appliance.
3. Turn the leveling screw up to the base to avoid damage.
4. Tape the doors shut.
5. Be sure the appliance stays secure in the upright position during
transportation. Also protect the outside of appliance with a blanket, or
similar item.
7
Booklet_WC-2053_EN.qxd:Salton Booklet 3/20/09 3:02 PM Page 7

TROUBLESHOOTING GUIDE
8
PROBLEM POSSIBLE CAUSE
Vibrations • Check to assure that the appliance is level.
The door will not close properly • The appliance is not level.
• The gasket is dirty.
• The shelves are out of position.
Unit has no power • Ensure that the outlet is not controlled by a wall
switch.
• Make sure that the circuit breaker has not been
tripped or the fuse blown.
• Unit is not plugged in
Fan always runs • The lower the temperature setting the longer the
fan will run.
Appliance is not cold enough. • Check the temperature control setting.
• The door is opened too often.
• The door is not closed completely.
• The door gasket does not seal properly.
The light does not work • Not plugged in.
• The circuit breaker tripped or a blown fuse.
• The bulb has burned out. See Warranty page and
contact our Service Dept.
• The switch is in the “OFF” position.
The Wine Cellar seems to make too
much noise.
• The rattling noise may come from the flow of the
refrigerant, which is normal.
• As each cycle ends, you may hear gurgling sounds
caused by the flow of refrigerant in your Wine
Cellar.
• Contraction and expansion of the inside walls may
cause popping and crackling noises.
• The Wine Cellar is not level.
Turns on and off frequently. • The room temperature is hotter than normal.
• The door is opened too often.
• The door is not closed completely.
• The temperature control is not set correctly.
• The door gasket does not seal properly.
• The Wine Cellar does not have the correct
clearances.
Booklet_WC-2053_EN.qxd:Salton Booklet 3/20/09 3:02 PM Page 8

9
Use an exclusive wall outlet. Do not connect your refrigerator to extension cords
or together with any other appliance in the same wall outlet. If the power cord is
too short, have a qualified electrician or service technician install an outlet near
the appliance.
LIMITED WARRANTY
SWG Canada warrants that this appliance shall be free from defects in material
and workmanship for a period of one year from the date of purchase. During this
‘in-warranty’ period, defective products will be repaired or replaced at the discretion
of the retailer and/or SWG Canada. This warranty covers normal domestic usage
and does not cover damage which occurs in shipment or failure which results
from alteration, accident, misuse, abuse, glass breakage, neglect, commercial use or
improper maintenance.
A defective product should be returned to the original place of purchase
within the retailer’s stipulated return/exchange period*. If you are unable to have
a defective product replaced under warranty by the retailer, please check our website
at “www.salton.com” for the service centre nearest you. You may also contact us for
assistance by mail, e-mail, fax or telephone as listed below.
To ensure prompt ‘in-warranty’ service securely package and return the product to us
prepaid. Be sure to include the original proof of purchase and a description of the
defect along with your address and postal code.
For repairs not covered by the warranty, please contact us for assistance.
SWG CANADA
Customer Service Department
81A Brunswick
Dollard-des-Ormeaux
Quebec, Canada H9B 2J5
Website: www.salton.com
E-mail: [email protected]
Fax: [phone]
Tel: [phone]
* Return/exchange policies at each retailer vary and may differ from the SWG Canada 1 year limited warranty
period.
®
Booklet_WC-2053_EN.qxd:Salton Booklet 3/20/09 3:02 PM Page 9
