Swisher QUADBOSS QBFC14560-CA User manual

60” FAST FINISH
TRAIL MOWER
OWNER’S
MANUAL
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE, WARRENSBURG, MO 64093
PHONE [phone] FAX [phone]
MODEL NO.
QBFC14560
QBFC14560-CA
Manufacturing quality lawn care equipment since 1945
Assembly
Operation
Service and Adjustment
Repair Parts
18372 REV 17-045
STARTING SERIAL #:
L117-045001
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
IMPORTANT
ade I The
USA
of US and Global Parts

LIMITED WARRANTY
The manufacturer’s warranty to the original consumer purchaser is: This product is free from
defects in materials and workmanship for a period of one (1) year from the date of purchase
by the original consumer purchaser.
As required by CFR § 1060.120, the fuel system related components, which have been
certified to this equipment by SAI are to be free of defects in material and workmanship for a
period of two (2) years from the date of purchase by the original consumer purchaser.
We will repair or replace, at our discretion, parts found to be defective due to materials or
workmanship. This warranty is subject to the following limitations and exclusions:
1) Engine Warranty All engines utilized on our products has a separate warranty
extended to them by the individual engine manufacturer. Any
engine service difficulty is the responsibility of the engine
manufacturer and in no way is Swisher or its agents responsible
for the engine warranty. The Briggs & Stratton Engine Service
Hot Line is 1-800-233-3723.
2) Commercial Use This product is not intended for commercial use and carries no
commercial warranty.
3) Limitations This warranty applies only to products, which have been
properly assembled, adjusted, and operated in accordance with
the instructions contained within this manual. This warranty
does not apply to any product of Swisher that has been subject
to alteration, misuse, abuse, improper assembly or installation,
shipping damage, or to normal wear of the product.
4) Exclusions Excluded from this warranty are normal wear, normal
adjustments, and normal maintenance.
In the event you have a claim under this warranty, you must return the product to an
authorized service dealer. All transportation charges, damage, or loss incurred during
transportation of parts submitted for replacement or repair under this warranty shall be borne
by the purchaser. Should you have any questions concerning this warranty, please contact us
toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the
name of the authorized Swisher dealer from whom you purchased the mower will be needed
before any warranty claim can be processed.
THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME
PERIODS STATED HEREIN FOR ALL EXPRESSED WARRANTIES. Some states do not
allow the limitation of consequential damages or limitations on how long an implied warranty
may last, so the above limitations or exclusions may not apply to you. This warranty gives
you specific legal rights and you may have other rights, which vary from state-to-state. This is
a limited warranty as defined by the Magnuson-Moss Act of 1975.
2

SAFETY PRECAUTIONS
•Read the manual. Learn to operate this machine safely.
•Always disconnect the spark plug wire and place the wire where it cannot contact the spark plug, to prevent
accidental starting the engine when setting up, transporting, adjusting or making repairs.
•Keep all shields and guards in place.
•Understand the speed, steering and stability of this machine. Know the positions and operations of all
controls before you operate this machine. Check all of the controls in a safe area before starting to work
with this machine.
•Allow only responsible adults who are familiar with these instructions to operate this machine. Never allow
children to operate this machine.
•Clear the area of objects such as rocks, toys, wire, etc. that can be picked up and thrown by the blade.
•Be sure the area is clear of other people before mowing. Be aware of the mower discharge direction and do
not point at anyone. Stop the machine if anyone enters the mowing area. Children are often attracted to the
machine and the mowing activity. Never assume that children will remain where you last saw them.
Keep
children under the watchful care of another responsible adult.
•No riders!
•Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times.
•Do not mow in reverse. Always look down and behind before and while backing.
•Turn off the blades when not mowing. Before leaving the machine, turn off the blades and stop the engine.
•Watch for traffic when operating near or crossing roadways.
•Do not operate the mower if it has been dropped or damaged in any manner or if the mower vibrates
excessively. Excessive vibration is an indication of damage. Repair mower as necessary.
•Dress properly. Do not operate the mower when barefoot or wearing open sandals. Wear only solid shoes
with good traction when mowing.
•Do not operate the machine while under the influence of alcohol or drugs.
•Operate self-propelled machines up and down slopes. There is significant risk of overturns when operating
across slopes. Operate walk-behind machines across slopes. There is a significant risk of slipping under a
walk-behind machine when operating up and down slopes. Do not operate on slopes greater than 15 degrees.
•Never tamper with safety devices. Check their proper operation regularly.
•Stop and inspect the equipment if you strike an object. Repair, if necessary, before restarting.
•Never make adjustments or repairs with the engine running.
This Safety Alert Symbol indicates important messages in this
manual. When you see this symbol, carefully read the message that
follows and be alert to the possibility of personal injury.
Read this manual completely. This machine can amputate hands, feet, and throw
objects. Failure to observe the following safety instructions could result in serious
injury or death.
3

4
SAFETY DECALS
Replace decals immediately if damaged. Order by part number from Swisher.
OD45- Warning Decal
OD11- No step Decal
OD55- Triangle Danger Decal
OD33- Speed Decal
OD29- Danger Decal
OD43- Flying Debris Decal

5
*Battery cover not shown
Battery Mounting Detail
A U1 battery is required
(not included). Position
battery hold down
bracket as shown.
Tighten nuts so battery
will not shift position.
REQUIRED ASSEMBLY
FRONT WHEEL CASTER ASSEMBLY
1. Remove single nut and washers from caster shaft.
2. Place one washer (NB195) on the shaft of the caster/wheel subassembly.
3. Slide same shaft through the bearing/frame with wheel towards the ground.
4. Place the other washer (NB195) on the shaft; it should be resting on the top bearing.
5. Add thin washer (17x195).
6. Thread nyloc jam nut onto shaft.
7. Tighten nut snuggly, making sure shaft threads enter the nyloc of the nut. Over-
tightening
of this nut will bind caster.
8. Repeat process for other front side.
9. Push on plastic dust covers over nut and thin washer until it snaps into place.
REAR WHEEL ASSEMBLY
1. Remove cotter pin from axle and remove thin washer (NB149) from axle. Leave two
NB178 washers on axle.
2. If necessary (to take up space) slide extra washer (NB178) over axle, then wheel (with
valve stem out).
3. Slide on washer (NB149) and replace cotter pin in end of axle.
4. Bend cotter pin so it will not fall out.
5. Repeat process for other wheel.
OFFSET & CENTER TOW HITCH BAR ASSEMBLY
1. Lay out parts according to the diagram.
2. Insert part 661A into part 662 and pin with the hitch pin (H11).
3.
Insert part 661 into part 661A. Choose from the 3 holes to set the desired hitch length. Pin
with a hitch pin (H11).
4. Part 662 slides into the front tube of the frame. Again, choose from the 3 holes to arrange
desired offset. Pin with a hitch pin (H11).
5. Eliminate step 3 for hitching from the center bracket. Only one method can be used at a
time.

OPERATING YOUR TRAIL MOWER
INTENDED USE
This Trail Mower is designed to produce a quality finish cut on lawns, golf courses, etc. It is
not designed to clear brush or cut saplings. Your Trail Mower should be towed behind an
ATV, a golf cart, lawn tractor, or similar approved vehicle. It is not meant for speeds
exceeding 5 mph.
ATTACHING TRAIL MOWER TO TOW VEHICLE
•Place mower behind vehicle and back vehicle up to desired attaching position.
•When offsetting Trail Mower do so to side opposite the discharge of the tow vehicle.
•Attach tow hitch (661) to the swivel hitch with hitch pin (H11). Make certain hitch
pin goes completely through each piece and is clipped to prevent accidental
separation.
•Attach red safety tether (H9C) to both the towing vehicle and to the Trail Mower
toggle switch (685SP), located on the left battery side cover (17614). Its purpose is to
manually stop mower engine or to stop mower engine in case the two machines
become separated. (See Motor Base Detail page 14).
•It is extremely important the safety tether is secured properly to both the toggle
switch and the towing vehicle.
STARTING THE ENGINE
See engine manufacturer’s instructions for the type and amount of oil and fuel used. Trail
Mowers with electric start engines will need a battery (sold separately). Swisher
recommends using a standard “U 1 R” lawn & garden battery.
The operation of any mower can produce foreign objects to be thrown into the
eyes, resulting in severe eye damage. Always wear certified safety glasses or
wide-vision safety goggles over spectacles before starting any cutting machine and
while operating such a machine.
The operation of any cutter produces sound waves that are damaging to the
human ear. Ear protection is recommended.
CAUTION!
Tragic accidents can occur if the operator is not alert to the presence of
children. Children are often attracted to the machine and the mowing
activity. Never assume that children will remain where you last saw them.
6
IMPORTANT: This engine is not equipped with a spark arrester muffler. It is a violation of
California Public Resource Code Section 4442 to use or operate the engine on any forest-covered,
brush-covered, or grass-covered land. Other states or federal areas may have similar laws.

•
Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged.
•Check spark plug wire, oil, and fuel.
•Check all electrical connections (See Schematics).
•Make sure toggle switch is turned “ON” and the red tether is properly attached.
•Set engine idle to “CHOKE” position.
•With feet clear of mower deck, turn key switch to the “START” position and release when
engine begins to run.
•Set engine idle at desired RPM.
BREAKING IN YOUR MOWER
•Set vehicle parking brake or chock wheels to prevent accidental rolling.
•Start engine properly.
•Slowly, engage blade control.
•In a safe environment, i.e. no children, allow blades to rotate and engine to idle for 5
minutes. This breaks in the belts and the engine.
•Stop mower properly.
MOWER HEIGHT ADJUSTMENT
•Adjust while mower is not running.
•The cutting range is approximately 1.5” to 4.5”. The height has been measured from the
ground to the blade tip without the engine running.
•Rotate height adjust crank handles (H7N) in a clockwise direction
to lift the mower deck. A
counter-clockwise direction is used to lower the mower deck.
•Make sure the height adjustment is the same at side crank handles. For best results, see
“SUGGESTED PRACTICE” section. Graduated scales are for reference only, not the
actual cutter height.
•Place crank handle in a retracted position to maintain height adjustment.
STARTING TO MOW
•Adjust the cutting height.
•Double check vehicle to mower attachment.
•Start mower engine properly.
•Slowly, activate the blade engage lever (18976) by rotating it forward and left until the
lever locks into place.
•Carefully mount tow vehicle and start mowing slowly.
STOPPING THE MOWING SESSION
•Pull safety tether to shut toggle switch “OFF”. If the engine fails to stop or if the safety
tether has become inoperable, then use Alternative Stopping Method.
CAUTION!
SHUT OFF MOWER ENGINE AND REMOVE SPARK PLUG WIRE FROM
SPARK PLUG BEFORE MAKING ANY ADJUSTMENTS TO THE MOWER.
7

ALTERNATIVE STOPPING METHOD
•Bring vehicle to complete stop, shut off engine, and set parking brake.
•Disengage blade engage lever (18976).
•Manually shut toggle and key switches to their “OFF” positions.
•Always remember to remove keys to avoid irresponsible usage.
TRANSPORTING MOWER
•Stop mower properly.
•Place mower deck in its highest position.
•If transporting without the use of a tow vehicle, then remove spark plug wire and
place where it cannot contact the spark plug.
SUGGESTED MOWING PRACTICES
•Operate mower engine at full throttle to assure the best cutting performance and
maximum material discharge.
•Allow wet grass to dry. Clumps of wet grass will collect under the mowing deck.
•Mowing should be started with tow vehicle in low gear and increased only as safe
mowing conditions permit. This speed should not exceed 5 mph.
•
The average lawn should be cut to approximately 2.5” during the cool season and to
over 3” during the hot months.
•For a healthier lawn and better aesthetics, your lawn should be mowed often and
after moderate growth.
•When cutting high or dense grass areas go slowly. Some areas may need to be
mowed twice. The second cut should be at 90 degrees to the first, if possible.
•Mowing thick or high grass. Raise rear height crank handles to .5”-
.75” above the
other two handles.
•Creating a manicured lawn. Lower rear height crank handle to .25”-.5” below
front of deck. This allows grass blades to be cut twice. It also continually cuts
clippings to produce a mulching effect.
GENERAL TROUBLE SHOOTING
•The mower is not cutting level.
oLevel deck, making sure the side crank-handles are equal.
oCheck air pressure of all tires; make sure they are equal, and to
manufactures specifications.
oExamine blades for damage, while mower engine is not running.
•The engine will not start.
o
Disengage blades, turn toggle switch to “ON” position, check battery and all
other electrical connections, and inspect spark plug and wire.
oCheck for fuel in the engine.
•Engine runs poorly.
oSee engine manual.
oCheck throttle adjuster.
oReplace fuel, clean fuel filter and fuel line.
IF PROBLEMS PERSIST HAVE A QUALIFIED MECHANIC SERVICE THE
MOWER. NEVER ATTEMPT TO MAKE AN ADJUSTMENT THAT YOU ARE
NOT SURE IS CORRECT. DOING SO CAN CAUSE OTHER PROBLEMS.
8

MOWER MAINTENANCE
GENERAL RECOMMENDATIONS
The warranty on this Trail Mower does not cover items that have been subjected to operator abuse or negligence.
To receive full value from the warranty, operator must maintain unit as instructed in this manual.
Some adjustments will need to be made periodically to maintain your unit properly.
All adjustments in this manual should be checked at least once each season.
Periodically inspect and clean excessive debris inside the battery cover (17340) and belt covers (6025). Disconnect
spark plug wire before cleaning.
BEFORE EACH USE
•Check engine oil level on a level surface. Check twice to insure an accurate reading.
•Check condition of air filter; clean and replace as necessary.
•Check blade operation; keep blades in good condition.
•Check for loose fasteners and tighten them as needed.
AFTER EACH USE
•Keep blades sharp.
•Remove fresh grass clippings with garden hose.
•Grass clippings hardened to the underside should be scraped out with a putty knife.
•Keep fluids at proper levels.
•Cover unit to prevent rain or other debris buildup. Definitely cover the engine.
BEFORE AND/OR AFTER EACH SEASON
•Replace the spark plug.
•Clean or replace the air filter.
•A new spark plug and clean air filter assure proper air-fuel mixture and help your engine run better and last
longer.
•Check blades and belts for wear. Replace as necessary.
STORAGE RECOMMENDATIONS
CAUTION!
Do not store engine indoors or other poorly ventilated area. Keep engine away from gas appliances
where fumes could contact open flame, pilot lights, or sparks.
If engine is to be stored for 30 or more days, prepare unit as follows:
•Drain fuel outside into an approved container.
•Start engine properly and run until unit is out of fuel.
•Let engine cool.
•Remove remaining gasoline from carburetor and fuel tank to prevent gum deposits from forming within
the engine. Gum deposits can cause malfunction in the engine.
•Store mower with blades disengaged to prevent belts from being permanently stretched.
BLADE CARE AND SERVICE
For best results cutter blades must be kept sharp. The blades can be sharpened with a few strokes of a file or
grinding wheel. Do not attempt to sharpen blades while they are on the mower. Disconnect spark plug wire before
servicing unit.
Important: Replace blades that have been damaged or deeply nicked.
Important: Check blade and spindle hardware on a regular basis to make sure nuts are tight.
Only a qualified mechanic should be used for any
adjustments, disassembly or other kind of repairs.
9

10
FRAME ASSEMBLY
ITEM # QTY. PART NO. DESCRIPTION
1 1 3664 Bar - Right Sway
2 1 3665 Bar - Left Sway
3 1 17600* Weldment - T60 Frame
4 2 F4157WK Wheel/Tire 5/8" Bearing 13/5/6 NHS; Blk
5 1 662* Weldment - Tongue Offset Ext ension
6 1 661A* Weldment - Solid Stock Hitch
7 1 661* Weldment - Tongue Hitch Ext ension
8 2 -- See Caster/Wheel Assembly Detail
ITEM # QTY. PART NO. DESCRIPTION
9 6 NB126 Pin - 1/8" X 1" Cotter
10 4 T2PB Bushing - Plastic
11 4 NB178 Washer - 5/8 ID X 1 OD 10 GA
12 2 NB149 Washer - 5/8 ID X 1 OD 14 GA
13 4 H11 Pin - Safety Hitch
14 3 10579 Bushing -Stepped Height Adjust
15 3 H7N Assembly - Height Adjustment
16 3 10038 Bolt - Eye
ONLY INCLUDED ON “CA” MODELS
(FOR CALIFORNIA ONLY)
Item# Qty Description Part #
1 1 Carbon Canister - 2.50 Gallon, 3/16 Line 18224
2 2 Cable Tie - Carbon Canister 18219
3 4 Nut - 10-24 Nylon Lock 024900
4 2 Bracket - Carbon Canister, ZT 17127
5 4 Screw - 10-24 X3/4 Phil Truss Head ZP 024203
Item# Qty Description Part #
1 2 Ubolt - SQ , 3/8-16X2.437 X3 Lg GR 5 ZY 12447
2 2 Nut - Nylock 1/4-20 NB180
3 4 Nut - Nyloc 3/8-16 ZY NB182
4 1 Mount - For EPA/CARB Gas Tank 18331*
5 1 Fuel Tank - 2.5 Gallon, Carb 18214
6 1 Cap, Fuel - 2.50 Gallon, Carb Sealed 18221
7 1 Bracket - Fuel Tank 18225
8 2 Bolt - Serr Flange 1/4-20 X1 3/4 GR5 ZY 18236
GAS TANK
ASSEMBLY DETAIL
4
5
Part # Description
11782 Line - Fuel, Bulk, 1/4" Low Perm
18232 Line - Fuel, Bulk, 3/16" Low Perm
18223 Clamp - Fuel Line 13/32 OD, 3/16 ID Tube
AS021 Tie, Black 5 1/2"
Parts Not Shown
When ordering replacement parts
*USE PAINT CODE: GT=GREY TK=BLACK
SEE HEIGHT ADJUST
HANDLE DETAIL
SEE CASTER/WHEEL
ASSEMBLY DETAIL

11
OUTER BLADE DRIVER DETAIL
Blade Driver Assembly
(Includes shaft, housing and bearings)
Part # 9058, 5.75” Shaft (Center)
Part # 9018, 4.25” Shaft (Outer)
Part No. Torque (ft-lbs)
NB175 90
NB238N 35
NB524 20
NB216 35
Recommended Torque Specifications
CENTER BLADE DRIVER DETAIL
When ordering replacement parts
*USE PAINT CODE: GT=GREY TK=BLACK
ITEM # QTY. PART # DESCRIPTION
1 1 NB175 Nut - Jam 3/4-16
2 1 AS155 Washer - Bellville 1.5 X .761 X .098
3 1 6114 Pulley - 5.50"
4 3 NB179 Washer - 3/4 ID X 1 1/4 OD 18 Ga
5 2 B98 Bearing
6 4 NB690 Bolt - Serr Flange 1/4-20 X 3/4 Grade 5
7 1 9057* Housing - Bearing
8 4 NB524 Nut - Flange 1/4-20
9 1 9076 Shaft - L & R 4.25"
10 1 B98W Washer - Flat 3/4 ID X 1 3/4 OD
11 2 NB216 Nut - Lock, Two Way 3/8-24 ZY Gr A
12 1 9008 Plate - Blade Mount
13 1 20186 Blade - G6 Gator 20 1/2"
14 1 NB607 Washer - SP Bellvl. PLN .413 X.945 X.118
15 2 NB166 Bolt - 3/8-24 X 1 1/4 HCC GR5 ZY
16 1 NB238N Bolt - HHC 3/8-24 X 1 Gr 5 Locktite
ITEM # QTY. PART # DESCRIPTION
1 1 NB175 Nut - Jam 3/4-16 Grade 2
2 1 AS155 Washer - Belleville1.5 X .761 X .098
3 2 6114 Pulley - 5.50"
4 1 6065PM Spacer - 3/4 ID X 1-1/2
5 3 NB179 Washer - 3/4 ID X 1 1/4 OD 18 Ga
6 2 B98 Bearing
7 4 NB690 Bolt - Serrtd Flange 1/4-20 X 3/4 Gr 5
8 1 9057* Housing - Bearing
9 4 NB524 Nut - Flange1/4-20
10 1 9054 Shaft - Center 5.75"
11 1 B98W Washer - Flat 3/4 ID X 1 3/4 OD
12 2 NB216 Nut - Lock, Two Way 3/8-24 ZY Gr A
13 1 9008 Plate - Blade Mount
14 1 20186 Blade - G6 Gator, 20.5"
15 1 NB607 Washer - SP Bellvl. Pln. .413 X.945 X.118
16 2 NB166 Bolt - 3/8-24 X 1 1/4 HCC GR5 ZY
17 1 NB238N Bolt - HHC 3/8-24 X 1 Grade 5 Lockt ite

12
GRASS CHUTE &
SPRING DETAIL
ITEM # QTY. PART NO. DESCRIPTION
1 1 166X34 Spring - Torsion
2 1 NB182 Nut - Nyloc 3/8-16 zy
3 1 NB784 Bolt - HCC 3/8-16 x 7
4 1 092100 Chute - Discharge
ITEM # QTY PART NO DESCRIPTION
1 1 -- See Motor Base Detail
2 1 -- See Safety Switch Bracket Detail
3 2 -- See Out er Blade Driver Detail
4 1 -- See Center Blade Driver Detail
5 1 -- See Grass Chute & Spring Detail
6 1 -- See Engage Lever Detail
7 1 -- See Idler Detail
8 2 T2PB Bushing - Plastic
9 2 AS001 Roller - Ant i-Scalp 3/8 ID
10 1 NB707 Bolt - Carriage 3/8-16X4
11 1 NB207 Nut - Nyloc 3/8-16
12 11 NB596 Bolt - Serr Flange 5/16-18 X 3/4
13 13 NB170 Nut - Serr Flange 5/16-18 Z
14 4 26X249 Screw - .312-18X.75
15 1 NB132 Bolt -1/2-13 X 4 HCC
16 3 NB688 Nut - Nyloc Jam, 1/2-13 ZY
17 1 NB281 Nut - Nyloc 1/2-13 ZY
18 2 NB121 Nut - Jam Lock 1/2-13 2-Way
19 2 3511 Wheel - Gauge
20 1 18383* Bracket - Middle Roller
21 1 18384* Bracket - Deck Hanger
22 2 18391 Cover - Belt, Black Composite
23 2 NB577 Bolt -1/2-13 X 3 1/2
24 1 092104* Bracket - Deflector
25 1 15780* Bracket - Wheel Right
26 1 15779* Bracket - Left Wheel
27 1 18382*
Deck - Weldment T60 Roundback
28 1 NB509 Bolt - 1/2-13 X 2 HCC
29 2 NB106 Bolt - 5/16-18 X 2 3/4 HCC
30 2 NB181 Nut - Nyloc 5/16-18
31 8 18531 Washer - Bent .25" ID X 18GA
32 8 NB703 Screw - MSC, 10-24 X 1 1/4
33 8 18532 Nut - Clip, 10-24
CASTER / WHEEL
ASSEMBLY DETAIL
ITEM # QTY. PART NO. DESCRIPTION
1 2 B98 Bearing
2 1 17X195 Washer - Flat
3 1 094618 Cap
4 2 NB195 Washer - 13/16 ID X 1 1/4 OD X 1/8
5 1 663L Spacer
6 1 NB595 Nut - Locking Jam, 2 Way 5/8-11
7 2 NB178 Washer - 5/8 ID X 1 OD 10 GA
8 1 665* Weldment - Caster
9 1 F4157WK Tire/Wheel - 5/8 Bearing 13x5x6 NHS, Blk
10 1 NB122 Nut - Nyloc Jam 3/4-16
11
1
NB624
Bolt - 5/8"-16 X 7" HCC ZY Grade 5
MOWER DECK DETAIL
When ordering replacement parts
*USE PAINT CODE: GT=GREY TK=BLACK

13
Slide plastic tube snug
Against toggle switch.
18057 Harness - Wiring, Briggs (13-20 hp)
BCSR Cable - Battery (10" Red)
BCLB Cable - Battery (19 1/2"or 20" Black)
KSK Keys - For Key Switch (set of t wo)
BCBT Boot - Rubber, Small, Battery Cable
PARTS NOT SHOWN
ITEM # QTY . PART NO. DESCRIPTION
1 1 NB220 Bolt - Shlder, 1/2 X 1-9/16 W3/4 Gr2 ZY
2 1 18387* Motor Base - Weldment
3 2 17760 Bolt-L
4 1 17794* Bracket - Battery Hold Down
5 6 NB161 Screw - HX Tek 1/4 X 3/4 ZP
6 10 024206 Screw - 12 X 1/2 Hex Self Tap
7 1 N/A Engine (Reference Model Shown)
8 1 17840* Cover - Battery Top
9 1 6000 Guide - Belt
10 1 14869 Guide - Belt; T60
11 2 NB250 Bolt - 1/4-20 X 3/4 GR5
12 2 NB524 Nut - Serr Flange, 1/4-20 Grade 5
13 2 NB515 Bolt - Serr Flange,5/16-18 X1 3/4 Gr5
14 2 NB253 Bolt - Serr Flange, 5/16-18 X1 1/4 Gr5
15 5 NB170 Nut - Serr Flange 5/16-18 Case Hrd
16 4 NB275 Washer - SAE Flat 5/16
17 1 689L Spacer - Long, Engine Pulley, 1.5"
18 1 688 Pulley - Engine, 5.5"
19 1 9031 Key Stock - 1/4 X 1 Undr Size
20 1 689S Spacer - Short, Engine Pulley, .687
21 1 TR150W Washer - .531IDX1 1/2ODX.062(Ht Trt d)
22 2 699 Washer - Belleville 7/16 X 1 1/4
23 1 NB452N Bolt - 7/16-20 X 1 HCF GR5 Nylock
24 1 685SP Switch - Toggle, Single Pole
ITEM # QTY . PART NO. DESCRIPTION
25 1 3623 Switch - Key
26 1 H9C Tether - Safety, Coiled
27 1 17898 Cable - Throttle; T60
28 1 BRS6 Spring
29 1 1002004 Solenoid - 3 Pole
30 2 NB197 Screw - Phillips Truss 8-32 X 1/2
31 2 NB201 Nut - Kep 8-32
32 2 NB180 Nut - Nylock 1/4-20
33 1 NB203 Nut - Kep 1/4-20
34 3 NB181 Nut - Nyloc 5/16-18
35 1 4422 Spring - Idler Tension, Bent Leg
36 1 10636YZ Bolt - Spade, 5/16-18 X12
37 1 NB280 Nut - 2 Way Lock 3/8-16 Wax Gr A
38 1 NB272 Washer - SAE Flat 3/8
39 1 NB107 Bolt - 3/8-16 X 1 1/2 HCC GR5
40 1 NB501 Bolt - 5/16-18 X 1 HCC GR5
41 1 B527 Pulley - Idler, OD-3.25", ID-3/8"
42 1 6009* Idler - Engage Weldment
43 1 17614* Cover - Batt ery Top Front
44 1 17615* Cover - Bat tery Left
45 1 17616* Cover - Bat tery Right
46 1 9087 Nut - Key Switch
47 1 9088 Washer - Lock, Key Switch
48 1 NB210Z Nut - 5/16-18 HNC
49 1 -- See Saftey Switch Detail
50 1 NB182 Nut - Nyloc 3/8-16
51 2 26X263 Screw - Hex .25-20X0.59
Item # 26
Item # 24
MOTOR BASE DETAIL
U1 Battery
(Not Included)
When ordering replacement parts
*USE PAINT CODE: GT=GREY TK=BLACK

Wiring Schematic
Engage Lever Detail Height Adjust Handle Detail Safety Switch & Bracket Detail
Belt Configuration
6055 Idler Detail
ITEM # QTY. PART # DESCRIPTION
1 1 NB155 Bolt - 1/2-13 X 5 HCC GR5 ZP
2 2 NB121 Nut - 2 Way Lock 1/2-13 ZY
3 1 18389* Engage - Weldment
4 1 NB170 Nut - Serr Flng 5/16-18
5 1 NB253 Bolt - Serr Flng,5/16-18 X1 1/4
6 1 NB181 Nut - Nyloc 5/16-18
7 1 4578* Pivot - Engage
8 2 NB555 Washer - 1/2
9 1 11158 Nut - Jam, 2-Wy Lck, 5/16-18
ITEM # QTY. PART # DESCRIPTION
1 1 H7N1TK** Tube - Height Adjust
2 1 ES214** Rod - Crank, For H7N
3 1 H7K** Knob - Height Adjustment
4 2 NB117** Nut - Push, 5/16
5 1 OD41** Decal - Ruler
**Parts Included in Service Part # H7N
Harness Part # 18057
ITEM # QTY. PART # DESCRIPTION
1 1 18390* Mount - Switch Safety
2 1 3695 Switch - Normally Closed
3 2 NB197 Screw - Phillips Truss 8-32 X 1/2
4 2 NB201 Nut - Kep 8-32
ITEM # QTY. PART # DESCRIPTION
1 1 6054* Idler - Bott om
2 1 B527 Pulley - Idler, OD-3.25", ID-3/8"
3 1 NB107 Bolt - 3/8-16 X 1 1/2 GR5
4 2 NB181 Nut - Nyloc 5/16-18
5 1 NB170 Nut - Serr Flange 5/16-18
6 1 NB272 Washer - SAE Flat 3/8
7 1 NB280 Nut - 2 Way Lock 3/8-16 Gr A
8 1 NB501 Bolt - 5/16-18 X 1 GR5
9 1 6037 Bushing - Idler
10 1 NB182 Nut - Nyloc 3/8-16
11 1 6040Z Washer - Idler
12 1 NB618 Bolt - 3/8-16 X 1 1/4 GR5
13 1 TZ2S Spring
14 1 NB315 Eyebolt - 5/16-18 X 3 w/Gap
15 1 NB173 Nut - Jam 5/16-18
17.5 HP Briggs
When ordering replacement parts
*USE PAINT CODE: GT=GREY TK=BLACK
14
5058 Long Belt 6046HP Short Belt

NOTES:
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
15

OWNER’S
MANUAL
MODEL NO.
QBFC14560
QBFC14560-CA
HOW TO ORDER
REPAIR PARTS:
60” FAST FINISH
TRAIL MOWER
Each mower has its own model number. Each engine has its
own model number. The model number for the mower will be
found at the left rear of the unit on the belt cover skirt.
The model number for the engine will be found on the top of
the blower fan housing.
All mower parts listed herein may be ordered directly from
Swisher or your nearest Swisher dealer.
All engine parts may be ordered from the nearest dealer of the
engine supplied with your mower.
Color cannot be guaranteed on service parts.
WHEN ORDERING PARTS, PLEASE HAVE THE
FOLLOWING INFORMATION AVAILABLE:
* PRODUCT – FC60 FAST FINISH TRAIL MOWER
* SERIAL NUMBER - _______________
* MODEL NUMBER - _______________
* ENGINE MODEL NUMBER - _______________
TYPE - _______________
* PART NUMBER
* PART DESCRIPTION
TELEPHONE - 1-800-222-8183
FAX - 1-660-747-8650
SWISHER ACQUISITION INC.
1602 CORPORATE DRIVE
WARRENSBURG, MO 64093
www.swisherinc.com
